Maytronics MBC2 Manuale utente

Robot Pool Cleaner MBC2

User Instructions

MBC2

8151254

Robot Pool Cleaner MBC2 | User Instructions 1

Robot Pool Cleaner MBC2

User Instructions

WARNINGS AND CAUTIONS

Warnings

• Use the originally supplied power supply only

• Ensure the electrical outlet is protected by a ground fault interrupter (GFI) or an earth

leakage interrupter (ELI)

• Keep the power supply out of standing water

• Position the power supply at least 3m away from the edge of the pool

• Do not enter the pool while the Pool Cleaner is working

• Unplug the power supply before servicing

Cautions

When not in use store the Pool Cleaner in a shaded area, upside down (not on its brushes).

Use the Pool Cleaner in the following water conditions only:

Chlorine Max 4 ppm

pH 7.0 - 7.8

Temperature 6 – 34°C

NaCl Maximum = 5000 ppm

Speciﬁcations

Motor protection: IP 68

Minimum depth: 0.80m

Maximum depth: 5m

GFI/ELI

40°C Max

Set-up

2Robot Pool Cleaner MBC2 | User Instructions

• If Wonder brush rings are dry,

soak them in water until soft.

• Shake robot from side to side or

turn it upside down to release

trapped air.

• Attach the oating cable to the power

supply by inserting it with the notch

on the connector (1) lined up with the

groove in the socket on the power

supply and turning clockwise (2).

• Turn the power supply ON.

The Pool Cleaner will now

operate until it has reached

the end of the cleaning cycle.

Into the Pool

Operation

Robot Pool Cleaner MBC2 | User Instructions 3

OFF

• The Robot will perform automatic shut-off at the

end of the cleaning cycle.

Out of the Pool

10 cm

Out of the Pool

• Using the oating cable, bring the Pool Cleaner to the pool's edge.

Using the handles remove the Pool Cleaner from the pool.

• Do not pull the Pool Cleaner from the pool using the cable.

4Robot Pool Cleaner MBC2 | User Instructions

Maintenance

• Place the Pool

Cleaner on the

edge of the pool

and let the water

drain out.

Robot Pool Cleaner MBC2 | User Instructions 5

• Clean the lter bag with a hose.

It is recommended to periodically wash the

lter bag in a washing machine. Use gentle

cycle cleaning program.

• Periodically clean the brushes with a hose.

Maintenance

• Ret the lter bag with

the tag on the outside

positioned centrally

along the length side

of the bottom lid.

6Robot Pool Cleaner MBC2 | User Instructions

Maintenance

• Place the impeller cover

at an angle so that the

notch is on the second

ring of the spring.

Press down on the

impeller cover in the

direction of the spring,

pushing it into place.

Replace the screws.

Robot Pool Cleaner MBC2 | User Instructions 7

Off season storage:

If the Pool Cleaner will not be in use for an extended period, perform the following storage steps:

•Make sure that no water is left in the Pool Cleaner.

• Thoroughly clean the lter bag and insert in place.

• Roll up the cable so that it has no kinks.

•Store the Pool Cleaner in a protected area upside down (not on its brushes).

Storage
