Mazda 2009 CX-7 Guida

2009 m{ZD{ CX-7

SMART START GUIDE

Optional equipment shown.

164817_09a_Mazda CX-7_SSG_080808.indd 1 8/8/08 2:22:15 PM

Key

While carrying the Advanced Key you can...

 • Lockthevehiclebysimplypressingthe

driver’sdoorrequestswitchonce.

 • Closethewindowsandmoonroofby

pressingandholdingthedriver’sdoor

requestswitch;releasetostop.

 • Unlockthevehiclebypressingthe

driver’sdoorrequestswitch.

 • Unlockallthedoorsbypressingthe

driver’sdoorrequestswitchtwice

ORbypressingtheunlockbutton

ontheadvancedkey/keylessentry

transmittertwice.

 • Unlocktheliftgatebypressingthe

liftgaterequestswitch.

ADVANCED KEYLESS

ENTRY SYSTEM

• AdvancedKeylessEntryallowsyouto

 lock/unlockthedoorsandliftgateof

 thevehicle,andevenstarttheengine

 withoutevertakingthekeyoutof

 yourpocket.

Auxiliary Key

Advanced Key

Door Request Switch

Liftgate Request Switch

Lock Panic

Alarm

Unlock

164817_09a_Mazda CX-7_SSG_080808.indd 2 8/8/08 2:22:40 PM

STARTING THE ENGINE WITH THE ADVANCED KEY

While carrying the Advanced Key you can...

 • StarttheenginebypushingtheStartknoballthewayin.Whenthe

KEYindicatorlightilluminatesgreen,turntheStartknobfrom

theACCpositiontotheSTARTpositionandholduntiltheenginestarts.

 • ShuttheengineOFFbyturningtheStartknobtotheACCpositionand

thenpressinginandturningtotheLockposition.

 • TheKEYindicatorlightwillshowgreenwhentheadvancedkeyis

detected.IftheKEY indicatorlightashesgreen,theadvancedkey

transmitterbatterypowerislow.

Note:EmergencyVehicle

Entry/EngineStart

Iftheadvancedkeycannotbe

usedduetoamalfunctionor

deadtransmitterbattery,usethe

auxiliarykeytolock/unlockthe

doorsandtostarttheengine.

Tostart,removetheStartknob

coverbypressingbothside

releasebuttonsandpullingthe

coveroff.Inserttheauxiliarykey

intothekeycylinderandturnitto

starttheengine.

Thissystemremotelylocksandunlocksthe

doorsandtheliftgate,andopensthepower

windowsandmoonroof.

 • Toextendthekey,pressthereleasebutton.

 • Toretractthekey,pressthereleasebutton

andfoldthekeybackintotheholder.

KEYLESS ENTRY SYSTEM

Release

Button

Lock

Unlock

Panic

Alarm

164817_09a_Mazda CX-7_SSG_080808.indd 3 8/8/08 2:22:53 PM

Seats

ELECTRONICALLY OPERATED DRIVER SEAT

Recline Switch

Pushforwardor

backwardtoadjust

seatbackangle.

REAR CENTER POSITION SEAT BELT

•Toconnecttheseatbelt,pulltheseatbeltfromtheceilingrecessand

connecttongueAtobuckleB.

•Toweartheseatbelt,slowlypulloutthelap/shoulderbeltandinsert

tongueCintothebuckleDuntilaclickisheard.

•Tounfastentheseatbelt,depressthebucklebuttontorelease.

Note: Leavetherearcenterlapportionofseatbeltfastenedatalltimesexceptwhen

foldingtherearseat.

1Tostowtheseatbelt,insertakeyorothersmallobjectintotheanchor

buckleslottoreleaseentirebelt.

2Letitfullyretract.

3Then,puttonguesAandCtogetherandinsertsecurelyintoroofrecess.

(A)

(B)

(C)

(D)

Slide/Tilt Switch

Pushforwardorbackwardto

slidetheseatbottom.Theseat

canalsoberaised,loweredor

tiltedwiththiscontrol.

Roof Recess

Anchor Buckle Slot

164817_09a_Mazda CX-7_SSG_080808.indd 4 8/8/08 2:23:25 PM

FOLDING SECOND-ROW SEATS

Folding second-row seats

1 Unfastenthelapportionoftherearcenterseatbelt.

2 Supporttheseatbackwithyourhand.

3 Pushtherearseatbackknobdown.

4 Bringtheseatbackforward.

Returning second-row seats to upright position

1 Raiseseatbacksuntiltheylockintoposition.

2 Pullonthetopoftheseatbacksfrominsidethevehicle

tomakesuretheyarelocked.

3 Checkthatallseatbeltsareroutedproperlyforpassengeruse.

LIFTGATE

 • Toopen,pulluponthehandleandraisetheliftgate.

 • Toclose,pushtheliftgatedownwithbothhandsuntilitsecurelylocks,

butdonotslam.

Seatback Knob

Liftgate Handle

164817_09a_Mazda CX-7_SSG_080808.indd 5 8/8/08 2:23:41 PM

Driver’s View (shown with optional

LIGHTING/

TURN SIGNAL

HEADLIGHT

LEVELING

TRACTION

CONTROL

SYSTEM

(TSC)

HOOD

RELEASE

TILT STEERING

WHEEL LEVER

(behind steering wheel)

BLUETOOTH

& AUDIO

164817_09a_Mazda CX-7_SSG_080808.indd 6 8/8/08 2:23:53 PM

Driver’s View (shown with optional

Navigation System)

WIPER/

WASHER

CRUISE

CONTROL/

BLUETOOTH

HAZARD

WARNING

INFORMATION

DISPL AY

NAVIGATION/AUDIO

DISPL AY

CLIMATE

CONTROL

AUDIO SYSTEM

WITHOUT NAVIGATION

AUXILIARY

POWER POINT

164817_09a_Mazda CX-7_SSG_080808.indd 7 8/8/08 2:24:11 PM

Instrument Cluster

Engine Oil Pressure

Tire Pressure Monitoring

System (TPMS)

Check Engine

4WD

Dealer inspection is required

if this light is ﬂashing,

indicating high temperature

differential oil, or if the light

stays illuminated, indicating an

abnormality with the system.

Brake System

ABS

(Antilock Brake System)

TCS OFF

(Traction Control System)

TCS/DSC

(Traction Control System/

Dynamic Stability Control)

Security Indicator

Headlight High Beam

Automatic Transmission

TACHOMETER

GLOSSARY OF WARNING AND INDICATOR LIGHTS

Please see Owner’s Manual for more details and explanations

SPEEDOMETER

TCS

OFF

4WD

INSTRUMENT CLUSTER DIMMER

164817_09a_Mazda CX-7_SSG_080808_IC.indd 1 8/8/08 2:45:38 PM

FUEL GAUGE

Shift Position

Air Bag/Front Seat Belt

Pretensioner System

Charging System

Seat Belt

Turn Signal/

Hazard Warning

Door Ajar

Lights On (Exterior Lights)

KEY Warning Light

(RED)Advanced key not

detected or transmitter

battery is dead.

KEY Indicator Light

(GREEN)Advanced key

detected; engine is ready

to start.

Cruise Main Indicator

Light (AMBER)/Cruise Set

Indicator Light (GREEN)

Low Fuel

ENGINE COOLANT

TEMPERATURE GAUGE

GEAR INDICATOR ODOMETER/

TRIP METER

ODOMETER/TRIP

METER SELECTOR

KEY

164817_09a_Mazda CX-7_SSG_080808_IC.indd 2 8/8/08 2:45:45 PM

Feature Highlights

WINDSHIELD WIPER/WASHER

 • MIST-Pushtheleverupforasingleswipetoclearmist.

 • INT-Pushdowntorstposition,rotatetheinnerringforspeedcontrol.

 • LO-Pushdowntosecondposition.

 • HI-Pushdowntothirdposition.

 • Pulllevertowardyoutodispensewasheruid;thewiperswillmake

severalpassesacrossthewindshield.

Rear Window Wiper/Washer

 • Rotatetherearwindowwiper/washeroutercontrolknobtothe

  desiredspeed.

O F F = OFF

INT =Intermittent

ON =Normalspeed

=Rearwash/wipercycle,holdasdesired

More sensitive

Less sensitive
