Mazda MX-5 Miata Guida

SMART START GUIDE

M{zd{ Mx-5 Miata

1667913_15a_Mazda_MX5_SSG_032614.indd 1 3/26/14 10:39 AM

Trunk Request Switch

Door Request Switch

Lock

Unlock

Trunk

Panic Alarm

Advanced Key

Key

ADVANCED KEYLESS ENTRY SYSTEM

• This system allows you to lock/unlock

the doors, open the trunk lid, and even

start the engine without ever taking the

key out.

While Carrying the Advanced Key…

• Unlock the driver’s door by pushing

the driver’s door request switch once.

• Unlock both doors by pushing the

driver’s door request switch twice

OR by pushing the passenger’s door

request switch once.

• Lock both doors by pushing the

driver’s door or passenger door request

switch once.

• Open the trunk by pushing the trunk

request switch once.

• Open the front windows by pushing

the unlock button on the advanced key

and then pushing again and holding;

release to stop.

KEYLESS ENTRY SYSTEM

This system remotely locks and unlocks the doors and the trunk, and opens

the power windows.

Release Button

• Push to extend key.

• Push & hold to retract key.

Unlock

• Push once to unlock

driver’s door.

• Push twice (within three

seconds) to unlock

both doors.

• Push twice and hold to

open front windows.

Lock

• Push once to lock

both doors.

• Push twice (within ve

seconds) for horn sound

verication that both

doors are locked.

Panic Alarm

• Push for one second or

more to activate alarm.

• Push lock, unlock, or

panic alarm to turn

alarm off.

Trunk

• Push and hold to

open trunk. Retractable Key

1667913_15a_Mazda_MX5_SSG_032614.indd 1 3/26/14 10:39 AM

Advanced Key (Rear)

STARTING THE ENGINE

While Carrying the Advanced Key…

• Start the engine by pushing the start knob in and turning it (like a

normal key) while pushing the clutch pedal (manual transmission) or the

brake pedal (automatic transmission).

• Shut the engine OFF by turning the start knob to the ACC position

and then pushing in and turning to the Lock position.

NOTE: The KEY indicator light will illuminate GREEN when the

advanced key is detected. If the KEY indicator light ashes GREEN,

the advanced key transmitter battery power is low.

• If the advanced key cannot be used due to a malfunction or dead

advanced key battery, use the auxiliary key to lock/unlock the doors

and to start the engine.

Key

Release

Auxiliary Key

(for opening the doors and

starting the engine)

NOTE: RED Key Indicator Light may ash if the key is placed in the cup

holder. The key may not be detected in the cup holder.

With the Auxiliary Key…

1To start engine, remove

the start knob cover

by squeezing both

release buttons and

pulling the cover off.

2Push the key release to

remove the auxiliary key.

3Insert the auxiliary key into

the key cylinder and turn

it to start the engine.

Release Buttons

www.MazdaUSA.com

1667913_15a_Mazda_MX5_SSG_032614.indd 2 3/26/14 10:39 AM

Behind Seat Storage (Soft Top Only)

Move seatbacks forward to access the

seat back trim storage boxes.

Seats

Seat Warmers

The driver and passenger seats can be

warmed by rotating the applicable seat

warmer dial while the ignition is ON.

• Seat temperature increases as the

number on the dial increases.

• When the seat warmers are not needed, rotate the dials to 0.

SEAT CONTROLS

Height Adjustment Lever

Raise or lower seat height by repeatedly

pulling up or pushing down on the lever.

Slide Release Lever

Pull lever up to

move seat backward

or forward.

Recline Lever

Pull up to adjust

seatback angle.

NOTE: The seat heaters may not turn on if the seats are warmer than the thermostats

low point (such as if the top is down and the seats are warmed by the sun on a cold

sunny day or the ambient temperature is high).

1667913_15a_Mazda_MX5_SSG_032614.indd 3 3/26/14 10:39 AM

FUEL DOOR RELEASE

The fuel door release is in the seat side box located between the seats.

1Pull handle to open the seat side box.

2To open the fuel door, pull the fuel door release.

FUEL REQUIREMENTS

91-octane fuel is recommended. If 91-octane fuel is not available, fuel as

low as 87-octane can be used temporarily for emergency purposes. Use

of fuel lower than 91-octane can decrease performance, cause knocking/

engine noise, deteriorate shift quality, and possibly increase fuel consumption.

Refueling the vehicle with correct octane fuel a couple of times will restore

vehicle performance and shift quality.

FUEL DOOR

To avoid scratching the

paint during refueling,

secure the fuel ller cap

tether over the hook

as shown.

www.MazdaUSA.com

Fuel

1667913_15a_Mazda_MX5_SSG_032614.indd 4 3/26/14 10:39 AM

LIGHTING/

TURN SIGNALS

(P. 9)

CRUISE

CONTROL

WIPER/

WASHER

(P. 10)

BLUETOOTH®

HANDS-FREE/

AUDIO CONTROL

(P. 25)

TILT STEERING

WHEEL LEVER

Driver’s View

HOOD

RELEASE

DYNAMIC

STABILITY

CONTROL (DSC)

TRUNK

RELEASE

1667913_15a_Mazda_MX5_SSG_032614.indd 5 3/26/14 10:39 AM

WIPER/

WASHER

(P. 10)

HAZARD

WARNING

PASSENGER

AIRBAG OFF

INDICATOR1

AUDIO

( PP. 2 3 - 24 )

ACCESSORY

SOCKET

CLIMATE

CONTROL

(PP. 21-22)

SEAT

WARMERS

(P. 3)

AUX JACK

(P. 12 )

POWER

RETRACTABLE

HARDTOP

(If equipped)

(P. 18 )

Driver’s View

1This indicator light illuminates to remind you that the front passenger’s front/side airbags and seat

belt pretensioner will not deploy during a collision. The reason for this is that the weight in the seat

is less than approximately 66 lb. Always wear your seat belt and if a front facing child seat must be

used, you must deactivate the passenger airbag. See the Owner’s Manual for important information

on this safety feature.

www.MazdaUSA.com

1667913_15a_Mazda_MX5_SSG_032614.indd 6 3/26/14 10:39 AM

Instrument Cluster

TACHOMETER

FUEL GAUGE

DASHBOARD

ILLUMINATION1

ENGINE OIL

PRESSURE GAUGE

Low Fuel Level

OFF Dynamic Stability Control

(DSC)/Traction Control

System (TCS) Off

Indicator Light

DSC OFF switch pushed and

TCS/DSC turned off.

ABS (Antilock Brake

System) Malfunction

Check Engine Light

Charging System Malfunction

Traction Control System

(TCS)/Dynamic Stability

Control (DSC)

On: TCS/DSC malfunction

Flashing: TCS/DSC operating

Malfunction Warning Light

Shift Lever Position Indicator

Automatic Transmission

Malfunction

Turn Signals/Hazard

Warning Indicator Lights

Key Warning RED (p. 2)

Advanced key not detected or

advanced key battery is dead.

Key Detected (engine ready

to start) GREEN (p. 2)

On: Advanced key detected; engine

is ready to start.

Flashing: Advanced key battery is low.

Air Bag/Front Seat Belt

Pretensioner System

Malfunction

Headlight High Beams On (p. 9)

Seat Belt

Unbuckled/Malfunction

Security Indicator Light

GLOSSARY OF WARNING AND INDICATOR LIGHTS

NOTE: See Owner’s Manual for more details and explanations.

1667913_15a_Mazda_MX5_SSG_032614.indd 7 3/26/14 10:39 AM

INFO

BUTTON

ENGINE COOLANT

TEMPERATURE

GAUGE

SPEEDOMETER

ODOMETER/

TRIP METER

1When exterior lights are on, rotate the knob to adjust the brightness of the instrument cluster and other

dashboard illuminations.

AMBIENT

TEMPERATURE

www.MazdaUSA.com

Door Ajar

Brake Warning Light

Parking brake on/low brake

uid/malfunction

Cruise Main Indicator

Light On (AMBER)/

Cruise Set Indicator

Light On (GREEN)

Tire Pressure

Monitoring System

(TPMS) Warning Light*

On/Warning Beep: Low tire

pressure in one or more tires.

FLAT

TIRE

Flat Tire

Flat tire/malfunction

*TPMS NOTE: Low ambient temperature and/or high altitude causes tire pressures to

drop and may turn the TPMS warning light on. If the warning light comes on, check the

tire pressure and ll the tires as soon as possible, preferably before moving the vehicle

and warming up the tires. Tire pressure should be checked when the tires are cold.

INFO

Push INFO button to display the

following below the odometer:

• Trip Meter A

• Trip Meter B

• Average fuel economy

• Ambient Temperature Display

NOTE:

• To clear trip and average fuel

economy, push and hold INFO

button when displayed.

• To change the ambient

temperature display between

°F and °C, push and hold INFO

button when displayed.

1667913_15a_Mazda_MX5_SSG_032614.indd 8 3/26/14 10:39 AM

Lights

LIGHTING CONTROL/TURN SIGNAL LEVER

Pull

to Flash

High Beams

Push for

High Beams

:Turns fog lights on only

when headlights are on.

:Turns tail, parking, dashboard,

and headlights on.

:Turns tail, parking, and

dashboard lights on.

1667913_15a_Mazda_MX5_SSG_032614.indd 9 3/26/14 10:39 AM
