Measurement Computing WLS-IFC Manuale utente

WLS-IFC

USB-to-Wireless Interface

User's Guide

Document Revision 4, March, 2010

HM WLS-IFC.doc

Your new Measurement Computing product comes with a fantastic extra —

Management committed to your satisfaction!

Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now enjoy

the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our mission:

To provide PC-based data acquisition hardware and software that will save time and save money.

Simple installations minimize the time between setting up your system and actually making measurements. We offer quick and

simple access to outstanding live FREE technical support to help integrate MCC products into a DAQ system.

Limited Lifetime Warranty: Most MCC products are covered by a limited lifetime warranty against defects in materials or

workmanship for the life of the product, to the original purchaser, unless otherwise noted. Any products found to be defective in

material or workmanship will be repaired, replaced with same or similar device, or refunded at MCC’s discretion. For specific

information, please refer to the terms and conditions of sale.

Harsh Environment Program: Any Measurement Computing product that is damaged due to misuse, or any reason, may be

eligible for replacement with the same or similar device for 50% of the current list price. I/O boards face some harsh

environments, some harsher than the boards are designed to withstand. Contact MCC to determine your product’s eligibility for

this program.

30 Day Money-Back Guarantee: Any Measurement Computing Corporation product may be returned within 30 days of

purchase for a full refund of the price paid for the product being returned. If you are not satisfied, or chose the wrong product by

mistake, you do not have to keep it.

These warranties are in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or

fitness for a particular application. The remedies provided herein are the buyer’s sole and exclusive remedies. Neither

Measurement Computing Corporation, nor its employees shall be liable for any direct or indirect, special, incidental or

consequential damage arising from the use of its products, even if Measurement Computing Corporation has been notified in

advance of the possibility of such damages.

Trademark and Copyright Information

TracerDAQ, Universal Library, Measurement Computing Corporation, and the Measurement Computing logo are either

trademarks or registered trademarks of Measurement Computing Corporation.

Windows, Microsoft, and Visual Studio are either trademarks or registered trademarks of Microsoft Corporation

LabVIEW is a trademark of National Instruments.

CompactFlash is a registered trademark of SanDisk Corporation.

XBee and XBee-PRO are trademarks of MaxStream, Inc.

All other trademarks are the property of their respective owners.

Information furnished by Measurement Computing Corporation is believed to be accurate and reliable. However, no

responsibility is assumed by Measurement Computing Corporation neither for its use; nor for any infringements of patents or

other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or

copyrights of Measurement Computing Corporation.

means, electronic, mechanical, by photocopying, recording, or otherwise without the prior written permission of Measurement

Computing Corporation.

Notice

Measurement Computing Corporation does not authorize any Measurement Computing Corporation product for use

in life support systems and/or devices without prior written consent from Measurement Computing Corporation.

Life support devices/systems are devices or systems which, a) are intended for surgical implantation into the body,

or b) support or sustain life and whose failure to perform can be reasonably expected to result in injury.

Measurement Computing Corporation products are not designed with the components required, and are not subject

to the testing required to ensure a level of reliability suitable for the treatment and diagnosis of people.

Table of Contents

Preface

About this User’s Guide .......................................................................................................................6

What you will learn from this user’s guide.........................................................................................................6

Conventions in this user’s guide.........................................................................................................................6

Where to find more information.........................................................................................................................6

Chapter 1

Introducing the WLS-IFC......................................................................................................................7

Overview: WLS-IFC features.............................................................................................................................7

WLS-IFC block diagram....................................................................................................................................7

Software features................................................................................................................................................7

Chapter 2

Installing the WLS-IFC..........................................................................................................................8

What comes with your WLS-IFC shipment?......................................................................................................8

Hardware .......................................................................................................................................................................... 8

Additional documentation................................................................................................................................................. 8

Unpacking the WLS-IFC....................................................................................................................................8

Installing the software ........................................................................................................................................9

Installing the WLS-IFC ......................................................................................................................................9

Configuring the network parameters ................................................................................................................10

Restoring factory default settings.....................................................................................................................................11

Chapter 3

Functional Details...............................................................................................................................12

External components ........................................................................................................................................12

Status LEDs.....................................................................................................................................................................12

Power LED ......................................................................................................................................................................12

USB connector.................................................................................................................................................................12

Chapter 4

Specifications......................................................................................................................................13

Wireless communications.................................................................................................................................13

Memory ............................................................................................................................................................13

Microcontroller.................................................................................................................................................13

USB +5V voltage .............................................................................................................................................13

Power................................................................................................................................................................14

USB specifications ...........................................................................................................................................14

Environmental ..................................................................................................................................................14

Mechanical .......................................................................................................................................................14

LED configuration............................................................................................................................................15

Declaration of Conformity..................................................................................................................16

Preface

About this User’s Guide

What you will learn from this user’s guide

This user’s guide explains how to install, configure, and use the WLS-IFC. This user’s guide also refers you to

related documents available on our web site, and to technical support resources.

Conventions in this user’s guide

For more information on …

Text presented in a box signifies additional information and helpful hints related to the subject matter you are

reading.

Caution! Shaded caution statements present information to help you avoid injuring yourself and others,

damaging your hardware, or losing your data.

< : > Angle brackets that enclose numbers separated by a colon signify a range of numbers, such as those assigned

to registers, bit settings, etc.

boldtext Bold text is used for the names of objects on the screen, such as buttons, text boxes, and check boxes. For

example:

1. Insert the disk or CD and click the OK button.

italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or phrase. For

example:

The InstaCal installation procedure is explained in the Quick Start Guide.

Never touch the exposed pins or circuit connections on the board.

Where to find more information

For additional information relevant to the operation of your hardware, refer to the Documents subdirectory

where you installed the MCC DAQ software (C:\Program Files\Measurement Computing\DAQ by default), or

search for your device on our website at www.mccdaq.com.

Chapter 1

Introducing the WLS-IFC

Overview: WLS-IFC features

This user's guide contains all of the information you need to configure the WLS-IFC for wireless operation with

remote WLS-Series devices.

The WLS-IFC is a USB-to-wireless interface module that is supported under popular Microsoft®Windows®

operating systems. The WLS-IFC is fully compatible with both USB 1.1 and USB 2.0 ports.

The WLS-IFC device operates as the interface between a computer and one or more remote WLS-Series

devices. The remote devices can be located up to 150 feet (50 meters) indoors, or up to ½ mile (750 m) outdoors

from the WLS-IFC.

You configure the network parameters required for communication with remote devices. All parameters are

software selectable. Only devices with the same parameter settings can communicate with each other. Once you

configure the WLS-IFC to communicate with remote devices, you can connect it to different computers without

having to configure the network parameters.

The WLS-IFC has LEDs that indicate the status of communication over the wireless link. An LED bar graph

shows the fade margin of signals received by the WLS-IFC.

The WLS-IFC is a standalone plug-and-play device which draws power through the USB cable. No external

power is required. All configurable options are software programmable.

WLS-IFC block diagram

WLS-IFC functions are illustrated in the block diagram shown here. The diagram shows the WLS-IFC

communicating with three remote WLS devices. There is no limit to the number of WLS devices that the WLS-

IFC can communicate with.

Figure 1. WLS-IFC functional block diagram

Software features

For information on the features of InstaCal and the other software included with your WLS-IFC, refer to the

Quick Start Guide that shipped with your device.

Chapter 2

Installing the WLS-IFC

What comes with your WLS-IFC shipment?

The following items are shipped with the WLS-IFC.

Hardware

WLS-IFC

USB cable (2 meter length)

Additional documentation

In addition to this hardware user's guide, you should also receive the Quick Start Guide (available in PDF at

www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf). This booklet supplies a brief description of

the software you received with your WLS-IFC and information regarding installation of that software. Please

read this booklet completely before installing any software or hardware.

Unpacking the WLS-IFC

As with any electronic device, you should take care while handling to avoid damage from static

electricity. Before removing the WLS-IFC from its packaging, ground yourself using a wrist strap or by simply

touching the computer chassis or other grounded object to eliminate any stored static charge.

If your WLS-IFC is damaged, notify Measurement Computing Corporation immediately by phone, fax, or

e-mail. For international customers, contact your local distributor where you purchased the WLS-IFC.

Phone: 508-946-5100 and follow the instructions for reaching Tech Support.

Fax: 508-946-9500 to the attention of Tech Support

Email: techsupport@mccdaq.com

WLS-IFC User's Guide Installing the WLS-IFC

Installing the software

Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing Data

Acquisition Software CD. This booklet is available in PDF at www.mccdaq.com/PDFmanuals/DAQ-Software-

Quick-Start.pdf.

Installing the WLS-IFC

Install the MCC DAQ software before you install the WLS-IFC

The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the

MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on installing

the software.

To connect the WLS-IFC to your system, do the following:

1. Turn your computer on, and connect the USB cable to a USB port on your computer or to an external USB

hub connected to your computer. The USB cable provides power and communication to the WLS-IFC.

Always connect an external hub to its power supply

If you are using a hybrid hub (one that can operate in either self-powered or bus-powered mode), always

connect it to its external power supply.

If you use a hub of this type without connecting to external power, communication errors may occur that could

result in corrupt configuration information on your wireless device. You can restore the factory default

configuration settings with InstaCal.

When you connect the WLS-IFC for the first time, a Found New Hardware popup balloon (Windows XP)

or dialog (Windows 2000) opens as the WLS-IFC is detected.

After your system detects new hardware, the Found New Hardware Wizard opens and prompts you to

respond to the question "Can Windows connect to Windows Update to search for software?"

2. Click on the No, not this time option, and then click on the Next button.

The next dialog prompts you for the location of the software required to run the new hardware.

3. Keep the default selection "Install the software automatically" and then click on the Next button.

The wizard locates and installs the software on your computer for the WLS-IFC. A dialog appears when the

wizard completes the installation.

4. Click on the Finish button to exit the Found New Hardware Wizard.

A balloon or dialog appears when the hardware is installed and ready to use. Both the Power LED and the USB

Activity LED should flash, and then the Power LED should remain lit. This indicates that communication is

established between the WLS-IFC and your computer, and that the device is receiving power.

Figure 2. LED locations

WLS-IFC User's Guide Installing the WLS-IFC

If the Power LED turns off

If the Power LED is lit but then turns off, the computer has lost communication with the WLS-IFC. Disconnect

the USB cable from the computer and then reconnect it. This should restore communication, and the Power

LED should remain on after the device is configured.

Configuring the network parameters

The following network parameter options are programmable with InstaCal.

Identifier: Text that identifies the device (optional).

PAN (hex): The personal area network (PAN) ID assigned to the device.

The PAN value is a number used to identify the remote device with which you want to communicate. The

WLS-IFC can only communicate with a device whose PAN is set to the same value.

Most users do not need to change the default value assigned to the device. However, you may want to

assign a different PAN ID in the following situations:

oYou have multiple WLS Series devices, and do not want to allow communication between all of them.

Set the PAN ID to the same value on each device that you want to communicate.

oIf other WLS Series devices are operating in the vicinity, you can avoid accidental changes to your

device settings by changing the default PAN value.

CH: The radio frequency (RF) channel number assigned to the device.

The channel number is used to transmit and receive data over the wireless link. You may want to change

the channel number in InstaCal when another WLS Series device is already transmitting on that channel, or

when noise is present on the channel.

The table below lists each available channel and its corresponding transmission frequency.

Channel

Transmission

Frequency (GHz)

Channel

Transmission

Frequency (GHz)

2.410

2.440

2.415

2.445

2.420

2.450

2.425

2.455

2.430

2.460

2.435

2.465

AES Key: Value used to encrypt data (optional).

AES encryption is disabled by default. Unless you suspect that there are other users of WLS Series devices

in the area, there should be no need to enable encryption. However, if you suspect that there are other WLS

Series devices in the area, and you need to secure the devices from being accessed by other users, enable

AES encryption.

Enabling encryption does NOT secure the device from access through a local USB connection. A remote

device configured for encryption can be connected locally through the USB port to access other remote

WLS Series devices with the same settings; you may need to physically secure the remote devices to

prevent tampering of the of device's network.

Set the PAN ID, RF channel, and AES key to the same value for each device that you want to

communicate

Only devices with matching parameter settings for PAN, CH, and AES Key (if set) can communicate with each

other.

For information on setting up the network parameters for your WLS-IFC, refer to the "WLS Series" section of

the "Temperature Input Boards" chapter in the Universal Library User's Guide.

You only have to set up the network parameters once. The WLS-IFC retains the parameter settings even if you

connect to a different computer.

Indice

Altri manuali Measurement Computing Apparecchiature di registrazione

Measurement Computing

Measurement Computing USB-SSR08 Manuale utente

Manuali Apparecchiature di registrazione popolari di altre marche

KV2 Audio

KV2 Audio 500 Series Manuale utente

Robotics Technologies

Robotics Technologies microBus-Cam II Manuale utente

Seca

Seca 460 Manuale utente

Cognex

Cognex MVS-8000 Series Manuale utente

Mect

Mect MPNC006 Series Manuale utente

Bad Caf

Bad Caf THE LEASH Manuale utente

Strymon

Strymon NIGHTSKY Manuale utente

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuale utente

Tews Technologies

Tews Technologies TPMC465 Manuale utente

Honeywell

Honeywell Excel 50 Manuale utente

SeaLevel

SeaLevel COMM+8.LPCI Manuale utente

Arturia

Arturia AUDIOFUSE STUDIO Manuale utente

Rukra

Rukra RK-1240 Manuale utente

Samson

Samson SCOM Manuale utente

Dynacord

Dynacord DPS260 Manuale utente

Nice

Nice Core Manuale utente

Pyle Pro

Pyle Pro PSS8 Manuale utente

RF-System

RF-System TinyGate Manuale per l'uso e la cura
