MegaLite HELIUS L Series Guida
EN
7002017506
W-CM011/01Doc. No. Tracking Code: 1400-2460CM-94-452No. Minutes: 05/09/2015Execution Date:
[email protected]www.megalite.com
Instruction for Installation and Utilization of HELIUS L
1- For proper utilization of this product and safety, it is mandatory to closely
comply with the directions and notes in this instruction and guide.
2- Earth connection as provided is mandatory.
3- Do not directly touch or impact LED module.
4- Do not stare at LED light source.
5-
The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person. Always switch
off the power prior to installa-tion, maintenance or repair activities.
8
Close!
7
Close!
Close!
5 Nm
400 160
760
Ø48/60
M314LU3LED7730-S
M314LU3LED7740-S
M314LU4LED9730-S
M314LU4LED9740-S
M314LU5LED10730-S
M314LU5LED10740-S
10.3
10.3
10.8
10.8
11.3
11.3
W
(kg)
Cat. No.
Mounting Height
Cx. S = 0.074 m2
max: 15 m
Ø48 mm
G314PJ45
Ø48 mm
G314PJ45
3
Open the luminaire door:
1
Open!
2
Open!
B
D
Push!
Pull!
NO
OK
Open!
A
Pull!
Pull!
C/1
Open!
C/2
Close!
10 Nm
4
Horizontal pole mounting:
Close the luminaire door:
1 2
Vertical pole mounting:
4
10 Nm
1 2 4
3
6
31
Pull!
Open!
Electrical connections:
5
L
N
max.150 mm
Ø 8-12 mm
3X1.5 mm
2
3X2.5 mm
2
60245 IEC 57
7 mm
1 2 3
Close!
Bubble level feature to precisely align luminaire with horizontal plane
2
Push!
15 Nm
15 Nm
