Can set wake-up time 4 times each day, would wake-up
automatically in
the setting time and after sent the Data then go
into sleepingmode
Sent the data at one fixed time and sent the location data in the
setting
time
Can set a time point and one day or several days in one week to
sent the
data and then go into sleepingmode
LBS tracking+ GPS
tracking
When GPS cannot get the signal ,the LBS tracking would start
working automatically
Can set IP and port ,APN, Equipment number, correcttime, alarm
mode ,timer mode, week mode
Can set IP and port, APN, Equipment number, alarm mode R,
timermode. W, week mode
Return back to referencesetting
Use the mobile edit (C: TIME) send to the terminal equipment,
afterthe
terminal get the message and would apply time correct
to platform automatically.
When the equipment detected the light turn to bright, the
equipment will send an alarm message to the platform.
Then device will refuse to connect to the fake-LBS locate when
detected
Data send explanation
1.
After battery finish installation. GPS Mode start searching the signal, Within 4 minutes, the GPS
module will be turned off immediately and start dialing. GPS mode will go into sleeping mode after 8s once
sending the last data. If GPS mode has not been positioned, it will start dialing after 4 minutes.
2.
For RTC awaken or Sensor awaken, GPS mode will wait for location no more than 150
seconds,
otherwise it will start to send data by dialing immediately, if GPS mode can’t locate within
150s. Time
modewhich is set 7 to 30 minutes will quick located within 90s.
3.
Time mode which is set 7 to 30 minutes will go into sleeping mode within 3 minutes. The
device
won’t go into sleeping mode if it is set for 1~6 minutes. Other modes need 6 minutes
for going into
sleeping mode.
