MELINERA HG00508A Specifiche tecniche

LED MOSAIC SOLAR LIGHT/LED SOLAR LIGHT

IAN 270820

LED MOSAIC SOLAR LIGHT/

LED SOLAR LIGHT

Assembly, operating and safety instructions

LED-MOSAIK-SOLCELLELAMPE /

LED-SOLCELLELAMPE

Monterings-, betjenings- og sikkerhedshenvisninger

LAMPE SOLAIRE À LED MOSAÏQUE/

LAMPE SOLAIRE À LED

Instructions de montage, d‘utilisation et

consignes de sécurité

LED-MOZAÏEK-SOLARLAMP/

LED-SOLARLAMP

Montage-, bedienings- en veiligheidsinstructies

GB/IE Assembly, operating and safety instructions Page 5

DK Monterings-, betjenings- og sikkerhedshenvisninger Side 22

FR/BE Instructions de montage, d‘utilisation et consignes de sécurité Page 38

NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 56

HG00508A/

HG00508B

HG00508C/

HG00508D

HG00508E

HG00508F

HG00508G

HG00508A/

HG00508B

HG00508C/HG00508D/

HG00508E/ HG00508F/

HG00508G

HG00508A/

HG00508B

HG00508C/ HG00508D/

HG00508E/ HG00508F/

HG00508G

5GB/IE

Introduction

Proper use.................................................................................... Page 6

Description of parts and features ............................................... Page 7

Scope of delivery......................................................................... Page 8

Technical data ............................................................................. Page 8

Safety instructions................................................................ Page 9

Product-specific safety instructions.............................................. Page 10

Safety instructions for rechargeable batteries ........................... Page 11

Functioning................................................................................ Page 12

Preparing for use

Installing the light......................................................................... Page 13

Setting up the light....................................................................... Page 14

Replacing the rechargeable battery........................................... Page 15

Charging the rechargeable battery............................................ Page 17

Maintenance and care....................................................... Page 18

Troubleshooting..................................................................... Page 18

Disposal....................................................................................... Page 19

6 GB/IE

LED Mosaic Solar Light/LED Solar Light

Introduction

We congratulate you on the purchase of your new device. You have

chosen a high quality product. The instructions for use are part of

the product. They contain important information concerning safety,

use and disposal. Before using the product, please familiarise your-

self with all of the safety information and instructions for use. Only

use the unit as described and for the speciﬁed applications. If you

pass the product on to anyone else, please ensure that you also

pass on all the documentation with it.

Proper use

The solar lights are intended for outdoor use. The product is not

intended for commercial use.

7GB/IE

Not suitable for ordinary lighting in household

room illumination (for model A/ B/ G only).

This product is suitable for extreme temperature below -20°C

(for model A/ B/G only).

Description of parts and features

Model A/B:

2Solar Cell housing

3Mosaic Jar

4ON/ OFF switch

5Rechargeable battery

6Battery compartment

Model C/D/E/F/G:

1Decoration attachment (for model E/F only)

4ON/ OFF button

5Rechargeable battery

8 GB/IE

6Battery compartment

7Fastening screws (Ø 2.25 x 8.25mm)

8Battery compartment lid

9Silicone cover

Scope of delivery

1 LED solar lamp and rechargeable battery

1 Decoration attachment (for model E/F only)

1 Assembly instruction

Technical data

Operating voltage: 1.2V

Rechargeable battery: 1 x NiMH rechargeable battery/ AAA/

1.2V / 300mAh

LED: 1 x LED (model A/ B)

2 x LED (model C/ D)

9GB/IE

1 x RGB LED (model E/F)

3 x LED (model G)

Rated power LED: approx. 0.06 W per LED

Protection type: IP44 (splash proof)

Solar cell: approx. 40 x 40 mm (model A/B/G)

approx. 30 x 30 mm (model C/D/E /F)

Lighting time

(with full charge): approx. 8 hours

Safety instructions

PLEASE READ THE INSTRUCTIONS FOR USE PRIOR TO USE!

PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASS-

ING THIS PRODUCT ON TO A THIRD PARTY ALSO INCLUDE

ALL DOCUMENTS.

This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge if they have

10 GB/IE

been given supervision or instruction concerning use of the ap-

pliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

Do not use the article if you detect any kind of damage.

Always switch oﬀ the article, when storing it in dark environ-

ment, in order not to discharge the rechargeable battery.

Product-speciﬁc safety instructions

Make sure that the solar cell is free of dirt and free of snow

and ice in winter. Otherwise the performance of the solar cell

will diminish.

Cold temperatures have a negative inﬂuence on the operating

life of the rechargeable battery. If the solar garden lights are

not going to be used for a long time, e.g. in winter, they should

be taken up, cleaned and stored in a dry, warm room (for model

C/ D/E /F only).
