Memorex MPD8600 - Sports CD Player Manuale utente
User’s Guide
Personal FM
Stereo Compact
Disc MP3 Player
MPD8600
Before operating this product,
please read these instructions completely.
SAFETY PRECAUTIONS
1
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the appliance.
DANGER:
This product utilizes a Class 1 laser to read compact discs. This
laser Compact Disc Player is equipped with safety switches to
avoid exposure when the CD door is open and the safety interlocks
are defeated. Invisible and hazardous laser radiation when open
and interlock failed or defeated. Avoid direct exposure to beam.
Please do not attempt to defeat or bypass the safety switches.
SAFETY PRECAUTIONS (CONTINUED)
2
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user
could lose the authority to operate this equipment if an unauthorized
change or modification is made.
INFORMATION:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
SAFETY PRECAUTIONS (CONTINUED)
3
SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection.
Lightning and power surges ARE NOT covered under warranty for
this product.
• Do not open the CD compartment while the CD is rotating.
• Always keep the CD compartment closed when not in use.
• Keep all foreign objects out of the CD compartment.
• Place the unit on a stable surface.
• Avoid installing the unit in locations described below:
• Places exposed to direct sunlight or close to heat-radiating
appliances such as electric heaters.
• On top of other stereo equipment that radiate too much heat.
• Places lacking ventilation or dusty places.
• Places subject to constant vibration.
• Humid or moist places.
Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.
4
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
5
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
LOCATION OF CONTROLS
6
1
2
6
5
4
3
7
14
16
13
15
12
11
8
10
9
1. PROG (Program) Button
2. EQ/NAVI (Navigation) Button
3. Stop (■)/Power Off Button
4. Skip/Search/Tuning Up ( ) Button
5. Play/Pause ( )/Power On Button
6. Skip/Search/Tuning Down ( )
Button
7. MODE/Radio On Button
8. VOLUME/Radio Preset –/+ Buttons
9. Headphones Jack
10. Hold Switch
11. DC 4.5V Jack (Side of Unit)
12. LINE OUT Jack (Side of Unit)
13. CD Compartment
14. CD Door OPEN Switch
15. Display
16. Battery Compartment (Under CD
Compartment Door)
–+
This CD player requires either two (2) “AA” cell standard batteries (not
included) or the AC adapter (not included).
BATTERY INSTALLATION
The low battery indicator ( ) will light in the
display when batteries are low (when using battery
power) and need replacing.
1. Open the battery compartment door under the
CD compartment Door by pushing the latch in
and and then lifting it. To prevent the
possibility of losing the cover, it cannot be
removed.
2. Insert two (2) “AA” cell batteries (not included) according to the polarity
diagram inside the battery compartment. Alkaline batteries are
recommended for the longest playing time.
INSTALLATION
7
–
+
–
+
–
+
–
+
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the batteries as indicated
next to the battery compartment. Reversed batteries may cause damage to the
device.
3. Do not mix different types of batteries together (e.g. Alkaline, Rechargeable and
Carbon-zinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of time, remove the batteries to
prevent damage or injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat
and rupture. (Follow battery manufacturer’s directions.)
AC OPERATION
To operate the unit using AC power, connect an AC adapter (not included) to an AC
outlet having 120V, 60Hz AC only. Plug the small end into the DC 4.5V jack on the
side of the unit and connect the other end into the AC outlet. The batteries are
automatically disconnected when the AC adapter is used.
CAUTION: When not using AC power, disconnect the AC adapter from the wall
outlet by pulling the plug (not the cord). Do not touch the AC adapter with wet hands.
Fully insert the plug without exposing any part of the blade.
DC 4.5V
HOLD SWITCH
Slide the HOLD switch until “HOLD” appears in the display and no buttons can be
pressed. After three seconds, “HOLD” will disappear in the display. If you press any
button, “HOLD” will appear in the display again to indicate the button is disabled.
This is useful when jogging/walking. Slide the HOLD switch to the off position to
cancel the Hold function.
–+
INSTALLATION (CONTINUED)
8
Sound Through a Home Audio System
By using a home audio connection cable (not included), superb sound can be
heard through your home audio system. Before making any connections, turn off
the power to all equipment.
Plug a connection cable (not included) between the LINE OUT jack on the side of
the CD player and the amplifier’s AUX or CD input jack. (Do not connect it to the
amplifier’s PHONO jack.)
NOTE: If the radio interferes with TV reception, move the unit away from the TV
or turn off the power to this unit.
OPERATION
9
Plug the headphones into the Headphones jack.
Press the Play/Pause ( )/Power On button ❶
to turn the unit on. If a CD is in the CD
compartment, press the Stop (■)/Power Off
button ❷once to stop playback, otherwise
continue to step 2.
1
2
1
TO LISTEN TO THE RADIO
Press the MODE/Radio On button to enter
the FM Radio mode. Press the MODE button
repeatedly to select STEREO or MONO. If
FM reception is weak/noisy, select Mono, in
this case the reception will be monaural.
2
Press and release the Skip/Search/Tuning
❶ or ❷ button to tune a station;
“Manual” will appear in the display. For
rapid search tuning, press and hold the
Skip/Search/Tuning ❶ or ❷
button for one second, then release; “Auto
Seek” will appear in the display.
2
1
3
To adjust the volume, press and hold the
VOLUME/Radio Preset –/+ buttons for one
second; “VOLUME” will appear in the display.
Within three seconds, press the VOLUME/Radio
Preset –/+ buttons to adjust the volume. If you do
not press the VOLUME/Preset –/+ for one second
first, “PRESET” will appear in the display. If you
then press the VOLUME/Radio Preset –/+ buttons,
the Memory Preset will increase or decrease, not
the volume.
4
CONTINUED ON THE NEXT PAGE
Altri manuali per MPD8600 - Sports CD Player
1
Indice
Altri manuali Memorex Lettore CD
Memorex
Memorex MD6447 - MD CD Player Manuale utente
Memorex
Memorex DB3042-MERSM Guida per l'amministratore
Memorex
Memorex MP3112 Manuale utente
Memorex
Memorex MP3225 Manuale utente
Memorex
Memorex MP3131 Manuale utente
Memorex
Memorex MPD8860 - CD / MP3 Player Manuale utente
Memorex
Memorex MC2864 Manuale utente
Memorex
Memorex MD6459 Manuale utente
Memorex
Memorex DB3042-MEROM Manuale utente
Memorex
Memorex MPD8807CP Manuale utente
Memorex
Memorex MP8800 Manuale utente
Memorex
Memorex MP 31 30 Manuale utente
Memorex
Memorex MPD8812 - CD / MP3 Player Manuale utente
Memorex
Memorex DCD6006-PIROM Manuale utente
Memorex
Memorex MD6441 Manuale utente
Memorex
Memorex MPD8081 Manuale utente
Memorex
Memorex DCD6011-MEROM Manuale utente
Memorex
Memorex MPT-5450 Manuale del proprietario
Memorex
Memorex MP8805 Manuale utente
Memorex
Memorex MP8700 - Boombox - Radio Manuale utente
