QUICK SET UP GUIDE

BASIC CONNECTIONS

MENUS

Coaxial Cable (Not Included)

From

RF Out

RF IN

Coaxial Cable (Not Included)

To RF IN

From Source (i.e. cable, etc.)

LOCATION OF CONTROLS

For more complex connections, such as Component jacks and home theater connections, see pages 13 and

14 of the owner’s manual. To connected an external unit to the IN or DV IN jacks, see pages 15 and 16.

TV SETUP PAGE:

When the recorder is turned on for the first time, there will be several wizard pages displayed one by

one which will allow you to set the basic options as follows:

1. At the first screen, press the ENTER button to advance to the next screen.

2. The TV Type selection will appear. Select the desired TV Type (NTSC or PAL M) using the

Navigation (π,†)buttons, then press the ENTER button.

To go back to the previous page, select BACK using the Navigation (π,†)buttons, then press the

ENTER button. Select NTSC for USA markets.

3.The Clock Setting selection will appear. Select the desired year using the Navigation (π,†)

buttons or using the Number buttons, then press the Navigation (®)button. Repeat to set the

month, day, hour, minute and AM/PM. Then, press the ENTER button.

4. The Tuner Mode selection will appear. Select the desired Tuner Mode (Antenna or CATV) using the

Navigation (π,†) buttons, then press the ENTER button.

5.The unit will then automatically cycle through all the channels and store active channels into

memory.To cancel the scanning, select Cancel using the Navigation (√,®)buttons, then press the

ENTER button.

6. The Complete screen will appear. Select FINISH using the Navigation (√,®)buttons, then press

the ENTER button.

INITIAL SETUP MENU:

The Setup menu lets you customize the DVD recorder by allowing you to select various preferences.

1. Without a disc inside the disc tray, press the SETUP button to enter the Setup menu.

2. Select one of the Initial Setup pages at the left of the screen (see the following pages for

descriptions) using the Navigation (π,†)buttons, then press the Navigation (®)button to select

it.

3. Use the Navigation (π,†)buttons to select one of the setup options, then press the Navigation

(®)button to select it.

4. Use the Navigation (π,†)buttons to select the desired setting, then press the ENTER button to

make the change. Press the Navigation (√) button

repeatedly to back out of the menus or press the SETUP

button to exit setup.

RECORDING SETUP PAGE: Enter the Setup menu, then

select the RECORDING Setup page using the Navigation

(π,†)buttons followed by the Navigation (®) button, then

select/change the setup option.

RECORDING QUALITY: Select the desired recording mode

using the Navigation (π,†)buttons, then press the ENTER

button.

CHAPTER MARKERS: Select CHAPTER MARKER, then select the desired time interval to record

before entering a Chapter Marker. Select OFF if you do not want Chapter Markers recorded.

TIMER RECORDING: For detailed instructions on how to navigate the Timer Recording setup page,

please see page 60 of the manual.

OVERWRITE: If using a Rewriteable disc, you can choose to overwrite existing recordings by

selecting OVERWRITE. Then select ON to enable overwriting or OFF to disable overwriting. When

you select ON for the overwrite function, then if you insert a recorded DVD+/-RW into this unit and

start recording, while recording, the existing titles/programs on the disc will be overwritten by the

new titles/programs.

AUDIO/VIDEO SETUP PAGE:

Enter the Setup menu as described previously, then select

the AUDIO/VIDEO Setup page using the Navigation (π,†)

buttons followed by the Navigation (®)button, then

select/change the setup option.

DOWNMIX: Select the desired setting (see below).

LT/RT: The source will be downmixed into two channels with

encoded Dolby Prologic surround information.

STEREO: Only the original front stereo channels will be

output. Surround information will be lost.

SPDIF OUTPUT: Select the desired setting:

SPDIF Off: Digital audio output is off.

SPDIF/RAW: Dolby Digital signals are going out unchanged to the digital output. MPEG-2 multi-

channel signals are converted to PCM (Pulse Code Modulation).

SPDIF/PCM: Dolby Digital and MPEG-2 multi-channel signals are converted to PCM (Pulse Code

Modulation).

DRC: Select ON to turn the DRC (Dynamic Range Compression) on, OFF to turn DRC off or Auto

to have the DRC automatically set for you. Dynamic Range Compression will compress the

dynamic range of the DVD’s audio track.

HDCD: Off: disable the Filter. 1X: set to normal sampling. 2X: set to double sampling.

QUALITY: Select QUALITY, then select the desired option to adjust. At the next screen, adjust the

selected setting using the Navigation (√,®)buttons, then press the ENTER button.

TV DISPLAY: Select TV DISPLAY and select the desired setting:

Normal/PS: use when you connect a normal TV to the recorder. Displays a wide picture on the

whole TV screen with a portion (right and left sides of the picture) automatically cut off.

Normal/LB: use when you connect a normal TV to the recorder. Displays a wide picture with bands

displayed on the upper and lower portions of the screen.

Wide: use when you connect a wide screen TV to the system.

SCAN MODE: Select SCAN MODE and select the desired setting:

INTERLACE: Select Interlace when connecting via other methods.

P-SCAN: Select P-SCAN (Progressive-Scan) when connected to the Component jacks for a more

stable, flicker free picture.

DISC SETUP PAGE:

Enter the Setup menu as described previously, then select the

DISC Setup.

ANGLE MARK: Select ON to turn the anglemarks on and

OFF to turn them off.

LAST MEMORY: Turn Last Memory ON or OFF. When ON,

during playback of a DVD or VCD, if you change the unit to

another source or stop playback, when you playback the disc again, it will resume to the last

segment before changed/stopped. However, if the disc is changed, there will be no Last Memory

function and it will just playback the disc from the beginning. When this option is OFF, the segment

will not be saved.

CLOSED CAPTIONS: Turn Captions ON or OFF. When this option is set to ON, closed captions will

appear on the screen for the hearing impaired (if originally recorded on the DVD). When this option

is OFF, the closed captions will not appear..

GENERAL SETUP PAGE:

Enter the Setup menu as described previously, then select the

GENERAL Setup.

OSD LANGUAGE: Select the desired language for the On-

Screen Display to display text.

DISC MENU LANGUAGE: Select the language the DISC

MENU will be in.

CONNECTING THE DVD TO A TV AND

CATV USING THE RF INPUT/OUTPUT

JACKS

CONNECTING THE DVD TOATV

USING THE AUDIO/VIDEO OUTPUT

JACKS

1 32 4 5 76 98 12

1. ON/STANDBY Button

2. DV IN Jack, S-Video IN

Jack and A/V IN Jacks

(under door)

3. CHANNEL Up/Down

Buttons

4. SOURCE Button

5. RECORD Button

6. Disc Tray

7. Display

8. Remote Sensor

9. OPEN/CLOSE Button

10. SKIP o/nButtons

11. STOP (X) Button

12. PLAY/PAUSE (®p)

Button

1. RF IN Jack

2. Rear Video IN

3.Right Audio IN (Rear

Video/S-Video)

4. Component Y Output

5.Component Cb/Pb

Output

6. Video OUT

7. Right Audio OUT

8. AC Power Cord

9. Optical Digital Audio

Output

10. Coaxial Digital Audio

OUT

11. Left Audio OUT

12. S-Video OUT

13. Component Cr/Pr

Output

14. Left Audio IN (Rear

Video & S-Video)

15. S-Video IN

16. RF OUT Jack

COMMON QUESTIONS

How do I stop the picture from rolling/flickering:

This could be caused by the accidental pressing of the I/P (Interlace/ Progressive) button. If using a TV

that is not compatible with progressive scan, press this button to select Interlace. If using a compatible

TV, select Progressive and connect this unit using the Component jacks on the rear of this unit.

How do I select a different channel?

For ANTENNA, enter a two digit channel number; i.e., enter "02" for Channel 2, enter "69" for Channel 69.

For CATV, enter a three digit channel number; i.e., enter "002" for Channel 2, enter "125" for Channel 125.

OPERATION OPERATION

TUNER OPERATION:

1. Press the STANDBY ON/OFF button to turn on the unit.

2. Press the SOURCE button to select TV, “Input Tuner” and a channel number will appear on the TV.

3. Set channels into memory as described previously. Press and release the CHANNEL Up or Down

button. The TV automatically stops at the next channel set into memory.

4. Direct Program Selection buttons (0- 9). Use these buttons to select a channel. For ANTENNA, enter

atwo digit channel number; i.e., enter "02" for Channel 2, enter "69" for Channel 69, etc. For CATV,

enter a three digit channel number; i.e., enter "002" for Channel 2, enter "125" for Channel 125, etc.

BASIC DVD OPERATION:

DISPLAY BUTTON (DVD MODE) - See page 35 for more details:

While playing a DVD, press the DISPLAY button. Press the Navigation (√,®)buttons to select the

desired icon, then press the ENTER button to select it. Once selected, press the Navigation (π,†)

buttons or the Number buttons to change the option, then the ENTER button, if required, to confirm the

change. You can select and change the following modes:

Title: Select a title to start playing.

Chapter: Select a chapter to start playing.

Elapsed Time: The Title's elapsed time will appear. Press the Navigation (†)button repeatedly to cycle

through Title's remaining time, Chapter's elapsed time and Chapter's remaining time. For the Title's

elapsed time and the Chapter's elapsed time, you can press the ENTER button to select. Enter the

desired Title's or Chapter's time to playback using the Number buttons.

Audio Setting: Select a desired audio setting.

Subtitle: Select the desired Subtitle language.

Repeat: Select desired Repeat setting (Off, CH-Chapter, TT-Title or All).

A-B Repeat: Select this option and press the Navigation (†)button when the desired starting segment

is playing to set point A. Press the Navigation (†)button again when the desired ending segment is

playing to set point B; the unit will then automatically start playing this segment repeatedly. To cancel,

press the Navigation (†) button again.

Random: Select to turn the Random feature On or Off.

Language: Select the desired Language (English or Spanish) the menus will be in.

OSD (On-Screen Display) Language: Select this option and select the desired Language (English or

Spanish) the menus will be in using the Navigation (π,†)buttons followed by pressing the ENTER

button.

AUDIO MODE: For DVD,Press the MTS AUDIO button

repeatedly to cycle through the audio languages available on

the playing DVD.

MUTE: Press the Mute button to turn off the sound. The

sound can be turned back on by pressing this button again.

SKIP Button: Press to skip ahead or skip backward through

the tracks/chapters.

SEARCH: Repeatedly press to search forward or backwards

through the disc at high speeds.

PAUSE: Press once to pause the DVD/CD.For DVD and

VCD playback, repeatedly press to advance the picture one

frame.

RECORDING:

INSERTING A BLANK DVD-R, DVD-RW, DVD+R, DVD+RW:

After inserting a blank recordable DVD disc, after loading, "Init Disc" (Initialize Disc) or "Erase" (Format

Disc) menu will appear on the screen. Using the Navigation (√,®)button to select OK and press the

ENTER button to format or initialize the disc. Then the disc will be ready to be recorded by this

recorder.

NOTE: If the blank DVD-R, DVD-RW, DVD+R or DVD+RW disc was already formatted or initialized by

this recorder, after loading the disc, you can record onto the disc as described below.

MANUALLY RECORDING:

After the DVD is inserted (see above), manually record a program as follows:

1. With the unit on and a recordable DVD inserted, press the SOURCE button repeatedly to select the

desired recording source.

2. Tostart recording, press the RECORD button once. If desired, repeatedly press the RECORD button

to activate One Touch Recording, which will allow you to increase the recording time in intervals of

30 minutes.

3. Press the DISPLAY button to show the recording message box. To pause recording, press the

PAUSE/STEP button once. To resume recording, press the RECORD button.

4. To stop recording, press the STOP (X) button.

FOR MORE RECORDING OPERATIONS,such as Timer Recording and Auto restore, see pages 60

and 65..

OPERATION

DVD TITLE MENU:

When a prerecorded DVD+RW or DVD+R disc which was previously recorded by this model of recorder

unit is inserted, a special DVD Title menu will be displayed.

1. Functional Block–see below for how to navigate the Title operations within this block.

2. Recorded Titles–shows recorded titles available for play/edit.

3. Title Page Number–shows DVDRW Title Page Number.

4. Disc Remains information–shows Disc Remains information.

DISC OPERATION MENU:

While playing a recordable disc or while in the Stop mode, press the DISC OPER(ATION) button. The

list of functions that can be performed from the Disc

Operation menu are shown below:

Disc Info: Choose the Disc Info icon using the

Navigation (π,†)buttons; the Disc Info menu will

appear (as shown left) showing information regarding

the disc.

Format: Choose the Format icon using the Navigation

(π,†)buttons. Select OK (to format the disc) or

CANCEL using the Navigation (√,®)buttons then

press the ENTER button. If you select OK, after

several seconds, the disc will be formatted.

Finalize (For DVD+/-R and DVD-RW discs only) or Unfinalize (For DVD-RW discs only): For the

DVD+/-Rs, they must be FINALIZED before being used in a standard DVD player. Unlike DVD+/-RWs,

DVD+/-Rs cannot be moved back and forth between the recorder and standard DVD players. You must

finish all recordings on the disc and finalize the disc before it will be usable on any other player.

However, for DVD-RWs, you also need to finalize the disc before it will be usable on any other player;

but, you can unfinalize the disc and edit/record/erase the disc again. To unfinalize a disc, please see

below.

To Finalize the Discs: Choose the Finalize icon using the Navigation (π,†)buttons. Select OK (to

finalize the disc) or CANCEL (to NOT finalize the disc) using the Navigation (√,®)buttons then press

the ENTER button. If you select OK, then the unit will finalize the disc (this will take several seconds).

NOTE: For DVD+/-Rs, once the disc is finalized, no further recordings/edits can be made on the disc.

For DVD-RWs, if the disc is finalized and you need to record/edit the disc, follow the Unfinalize

procedure described below:

Unfinalize (For DVD-RWs only): With a finalized DVD-RW disc inserted, press the Disc Oper(ation)

button, the Unfinalize option will be available instead of the option "Finalize". Choose the Unfinalize icon

using the Navigation (π,†)buttons. Select OK (to unfinalize the disc) or CANCEL (to cancel

unfinalizing the disc) using the Navigation (√,®)buttons then press the ENTER button. If you select

OK, then the unit will unfinalize the disc (this will take several seconds). After you unfinalize the DVD-

RW, then the disc will be editable/recordable again.

Protect/Unprotect Disc: Choose the Protect Disc icon using the Navigation (π,†)buttons. Select OK

(to confirm) or Cancel using the Navigation (√,®)button then press the ENTER button. The unit will

automatically protect the disc. Once the disc is protected, you cannot edit the disc or record on the disc.

For DVD+/-RW discs, you cannot erase the disc as well. If you want to edit, erase or record the disc again,

then you need to Unprotect the disc. With a protected disc loaded, enter the DVD Operation menu, choose

the Unprotect Disc icon using the Navigation (π,†)buttons. Select OK (to confirm) or Cancel using the

Navigation (√,®)button then press the ENTER button. The unit will automatically unprotect the disc.

Once the disc is unprotected, you can edit, record or erase the disc again.

Make Comp(atible) (for DVD+/-RW discs only): This function makes your edits–such as hidden

chapters–compatible with standard DVD players. Use this option before distributing any recordings that

you have edited to clients or friends. Before a RW disc is made compatible, all edits will only be visible

when the disc is used in this unit. You can use this option multiple times, moving a RW disc back and

forth between the DVD Recorder and a standard DVD player. Each time a disc is edited, it must be

made compatible again. Choose the Make Compatible icon using the Navigation (√,®,π,†) buttons.

Select OK (to confirm) or Cancel using the Navigation (√,®)button then press the ENTER button.

Adapt: For a DVD-RW or DVD+RW disc, where the disc is recorded with some program by another

brand DVD recorder, if the disc isn't made compatible or finalized, then you can use the ADAPT function

to adapt the disc so the disc can continuously record programs with this unit. Also, you can edit the title

and edit the disc. Further, this function will change the DVD+/-RW disc/titles menu format to the format

that this unit uses, so, you can edit the disc or continue to record scenes/titles on the disc.

NOTES:

•If the DVD+/-RW disc has already been finalized or made compatible on the previous DVD recorder,

then, you cannot ADAPT the disc anymore and you won't be able to select this function inside the

DISC OPERATION menu.

•For this unit, the video recording format is DVD+VR. If the DVD+/-RWs that are recorded by another

DVD recorder which is using a non-DVD+VR video format, such as DVD-Video, DVD-VR, then the

discs will not be able to be adapted.

ToAdapt the DVD+/-RW, choose the ADAPT icon using the Navigation (π,†)buttons. Select OK (to

adapt the disc) or CANCEL using the Navigation (√,®)buttons then press the ENTER button. If you

select OK, then the unit will adapt the disc (this will take several seconds).

AUDIO: Select the language the DVD will be played back in.

SUBTITLE: Select the language the subtitles will be in.

TV TYPE: Select the desired setting to match your TV set (NTSC or PAL M).

CLOCK SETTING: Set the year using the Number buttons or the Navigation (π,†)buttons, then

press the Navigation (®)button; the Month field will be highlighted. Set the month, day, hour, minute

and AM/PM (if using 12 Hour Time System) fields following this same procedure, and then press the

ENTER button; the date and time will be set.

TIME SYSTEM: Select 12 HOUR (USA Standard) or 24 HOUR.

SCREEN SAVER: When this option is set to ON, the screen saver will come on when a disc is

paused for approx. 5 minutes. When this option is OFF, the screen saver will not come on.

AUTO GO TO (For DV Input): When this option is set to ON, the unit will automatically switch to

the DV input when a DV plug is inserted (with the power on) into the front DV jack. When this option

is OFF, the feature is not activated.

USER DEFAULT: Performing this step will reset the unit’s options (time, preferences, etc.) to their

factory settings. Once you have selected OK to reset the unit, all the Timer Recording programs will

be erased. Also, you will have to set the Initial Setup again.

TV SETUP PAGE:

While in the TV Tuner mode, enter the Setup menu, then select

the TV Setup page using the Navigation (π,†)buttons followed

by the Navigation (®)button, then select/change the setup

option.

TV SIGNAL: Select CATV if using cable television or ANTENNA

if using an outdoor antenna.

AUTO CHANNEL SCAN: Select CATV or ANTENNA as shown

above. Follow the steps in the TV SIGNAL section (above), then select AUTOMATIC SEARCH.

Select OK using the Navigation (√,®) buttons followed by the ENTER button ; the unit will then

automatically cycle through all the channels and store active channels into memory. During

AUTOMATIC SEARCH, press the ENTER button to cancel searching.

EDITING TV CHANNELS

1. While in the TV Tuner mode, enter the TV Setup page as described previously, then select CH

Edit

2. To Skip the currently viewed channel select SKIP using the Navigation (π,†)buttons, then press

the Navigation (®)button to select ON to skip the channel when using the Channel Up or Down

buttons.

To Add the currently viewed channel select SKIP and select OFF to not skip the channel when

using the Channel Up or Down buttons.

3. Follow Step 1. To Fine Tune the currently viewed channel select Ch Fine Tune using the

Navigation (π,†)buttons, then press the Navigation (√,®)buttons repeatedly to fine tune the

selected station as desired.

4. Follow Step 1. To Copy the currently viewed channel into another channel number, select COPY

TO using the Navigation (π,†)buttons then select the desired channel number using the

Navigation (√,®) buttons. When done, press the ENTER button to make the change.

ToExchange the currently viewed channel with another channel number, select EXCHANGE

FROM using the Navigation (π,†)buttons then select the desired channel number using the

Navigation (√,®) buttons. When done, press the ENTER button to make the change.

MTS SETTING:Enter the TV Setup page as described on the previous page. Then, select MTS

SETTING. Select the desired setting:

Stereo:record TV program in stereo.

SAP (Secondary Audio Program): record TV program in SAP.

Dual:record TV program in Dual.

MTS SETTING:Enter the TV Setup page as described on the previous page. Then, select MTS

SETTING. Select the desired setting:

Stereo:record TV program in stereo.

SAP (Secondary Audio Program): record TV program in SAP.

Dual: record TV program in Dual.

Before operating this product,

please read these instructions completely.

User’s Guide

DVD VIDEO RECORDER

MMVVDDRR22110022SSuuffffiixxAA

Contents ..........................................................................1

Important Safety Instructions........................................2

Precautions .....................................................................5

Power Source..................................................................5

Location of Controls ......................................................6

• Front ...........................................................................6

•Rear............................................................................6

• Remote .......................................................................7

• Display........................................................................8

Remote Control...............................................................9

• Battery Installation ......................................................9

• Effective Distance of the Remote

Control Transmitter .....................................................9

Connection....................................................................10

• Connecting the DVD to a TV and CATV

Using the RF Input/Output Jacks .............................10

Connection-OUT ...........................................................11

• Connecting the DVD to a TV Using the

Audio/Video Output Jacks.........................................11

• Connecting the DVD to a TV Using the

S-Video Output Jack.................................................12

• Connecting the DVD to a TV Using the

Component Jacks.....................................................13

• Progressive (YUV) VIDEO OUT...............................13

• 525 Line Digital Progressive-scan Component

Video Output.............................................................13

• Connecting the DVD to a Home

Theatre System ........................................................14

Connection-IN ...............................................................15

•Connecting an External Unit Using

the Audio/Video In Jacks ..........................................15

•Connecting an External Unit Using

the S-Video In Jack ..................................................15

• Connecting an External Unit Using

the DV IN Jack..........................................................16

•Connecting an External Unit Using

the Front S-Video or A/V In Jacks ............................16

About Discs...................................................................17

Initial Setup Wizard ......................................................19

Initial Setup Menu.........................................................20

•Recording Setup.......................................................21

• Audio/Video Setup....................................................23

• Disc Setup ................................................................26

•General Setup...........................................................27

•TV Setup...................................................................30

Tuner Operation............................................................33

DVD Basic Operation ...................................................34

•Audio Mode...............................................................34

• Mute..........................................................................34

• Display Button (DVD Mode) .....................................35

•Playback of a DVD ...................................................36

• Playback of a Prerecorded and Finalized

DVD+/-RW or DVD+/-R............................................37

•Skip...........................................................................38

• Search ......................................................................38

• Pause/Step ...............................................................38

• Slow/F.......................................................................38

• Repeat ......................................................................39

• Repeat A-B ...............................................................39

•Random ....................................................................39

• Angle.........................................................................39

•Audio.........................................................................40

• Zoom.........................................................................40

• DVD Menu ................................................................40

• Title Menu .................................................................40

•Subtitle Menu............................................................40

• Programmed Playback .............................................41

• Bookmark..................................................................42

• Digest........................................................................42

MP3 Basic Operation....................................................44

• Playback of a MP3....................................................44

• Playback Mode .........................................................45

• Repeat A-B ...............................................................45

• Selecting Folders/Tracks ..........................................45

• Search ......................................................................45

• MP3 FAQs ................................................................45

CD/VCD Basic Operation .............................................46

• Display Button (CD/VCD Mode) ...............................46

• Playback of a CD/VCD .............................................47

• Turning PBC (PlayBack Control) ON or OFF...........47

• Forward/Reverse Search..........................................48

• Repeat Play ..............................................................48

• Repeat A-B Play .......................................................48

• Selecting Tracks .......................................................48

• Audio.........................................................................48

• Intro...........................................................................48

• Bookmark (VCD Only) ..............................................49

• Digest (VCD Only) ....................................................49

• Pause/Step (VCD Only)............................................51

•Slow/F (VCD Only) ...................................................51

•Zoom (VCD Only) .....................................................51

• Programmed Playback .............................................52

MPEG 4 Basic Operation .............................................53

•Display Button (MPEG 4 Mode) ...............................53

• Playback of a MPEG 4 .............................................54

• Playback Mode .........................................................55

• Repeat A-B ...............................................................55

• Selecting Folders/Files .............................................55

•Search ......................................................................55

•Pause/Step ...............................................................56

• Slow/F.......................................................................56

• Zoom.........................................................................56

Picture CD Basic Operation.........................................57

•Playback of a Picture CD .........................................57

• Playback Mode .........................................................57

Recording......................................................................58

•Inserting a Blank DVD-R / -RW / +R / +RW.............58

• Manually Recording..................................................58

• One-Touch Recording...............................................59

•Timer Recording .......................................................60

• DVD Title Menu ........................................................61

• Title Operations ........................................................62

•Disc Operation Menu................................................64

• Automatic Restore Technology System....................65

Troubleshooting Guide ................................................66

Care and Maintenance .................................................68

Specifications ...............................................................69

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This Caution Marking is located at the bottom enclosure of the unit.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

The lightning ﬂash with arrowhead symbol

within an equilateral triangle is intended to alert

the user to the presence of uninsulated

dangerous voltage within the product’s

enclosure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The symbol for class II

(Double Insulation)

CAUTION:

THIS DIGITAL VIDEO DISC PLAYER EMPLOYS A

LASER SYSTEM.

TO ENSURE PROPER USE OF THIS PRODUCT,

PLEASE READ THIS OWNER’S MANUAL CAREFULLY

AND RETAIN FOR FUTURE REFERENCE. SHOULD

THE UNIT REQUIRE MAINTENANCE, CONTACT AN

AUTHORIZED SERVICE LOCATION-SEE SERVICE

PROCEDURE.

USE OF CONTROLS, ADJUSTMENTS OR THE

PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN MAY RESULT IN

HAZARDOUS RADIATION EXPOSURE.

TO PREVENT DIRECT EXPOSURE TO LASER BEAM,

DO NOT TRY TO OPEN THE ENCLOSURE. VISIBLE

LASER RADIATION MAY BE PRESENT WHEN THE

ENCLOSURE IS OPENED. DO NOT STARE INTO BEAM.

FCC NOTICE:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does

cause harmful interference to radio or television

reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and

receiver.

• Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV

technician for help.

FCC CAUTION:

To assure continued compliance, follow the attached

installation instructions and use only shielded cables

when connecting to other devices. Also, any changes or

modifications not expressly approved by the party

responsible for compliance could void the user’s authority

to operate the equipment.

This Class B digital apparatus complies with

Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à

la norme NMB-003 du Canada.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN

OR MOISTURE.

WARNING:

TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, AND ANNOYING INTERFERENCE, USE THE

RECOMMENDED ACCESSORIES ONLY.

SURGE PROTECTORS:

It is recommended to use a surge protector for AC

connection. Lightning and power surges ARE NOT

covered under warranty for this product.

Manufactured under license from Dolby Laboratories.

"Dolby" and the double-D symbol are trademarks of Dolby

Laboratories.

ATTENTION:

POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE

CORRESPONDANTE DE LA PRISES ET POUSSER JUSQU’AU FOND.

Before using the unit, be sure to read all operating instructions carefully. Please note that these are general

precautions and may not pertain to your unit. For example, this unit may not have the capability to be connected to

an outdoor antenna.

1. READ INSTRUCTIONS

All the safety and operating instructions should be read before the product is operated.

2. RETAIN INSTRUCTIONS

The safety and operating instructions should be retained for future reference.

3. HEED WARNINGS

All warnings on the product and in the operating instructions should be adhered to.

4. FOLLOW INSTRUCTIONS

All operating and use instructions should be followed.

5. CLEANING

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a dry cloth

for cleaning.

6. ATTACHMENTS

Do not use attachments not recommended by the product's manufacturer as they may cause hazards.

7. WATER AND MOISTURE

Do not use this product near water–for example: near a bathtub, washbowl, kitchen sink or laundry tub;

in a wet basement; or near a swimming pool.

8. ACCESSORIES

Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing

serious injury and serious damage to the product. Use only with a cart, stand, tripod, bracket or table

recommended by the manufacturer or sold with the product. Any mounting of the product should follow the

manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

8A. An appliance and cart combination should be moved with care. Quick stops, excessive force and

uneven surfaces may cause the appliance and cart combination to overturn.

9. VENTILATION

Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable operation of

the product and to protect it from overheating. These openings must not be blocked or covered. The openings should

never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should never be

placed near or over a radiator or heat source. This product should not be placed in a built-in installation such as a

bookcase or rack unless proper ventilation is provided or the manufacturer's instructions have been adhered to.

10. POWER SOURCES

This product should be operated only from the type of power source indicated on the marking label. If you are not sure of

the type of power supply to your home, consult your appliance dealer or local power company. For products intended to

operate from battery power, or other sources, refer to the operating instructions.

11. GROUNDING OR POLARIZATION

This product is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).

This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into

the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet.

Do not defeat the safety purpose of the polarized plug.

12. POWER-CORD PROTECTION

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or

against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from

the appliance.

13. LIGHTNING

To protect your product from a lightning storm, or when it is left unattended and unused for long periods of time, unplug it

from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning

and power-line surges.

14. POWER LINES

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power

circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care

should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

IMPORTANT SAFETY INSTRUCTIONS (CONTINUED)

IMPORTANT:

PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS

PRODUCT TO YOUR PLACE OF PURCHASE OR TO MEMOREX.

15. OVERLOADING

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

16. OBJECT AND LIQUID ENTRY

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short out

parts that could result in fire or electric shock. Never spill or spray any type of liquid on the product.

17. OUTDOOR ANTENNA GROUNDING

If an outside antenna is connected to the product, be sure the antenna system is grounded so as to provide some

protection against voltage surges and built-up static charges. Section 810 of the National Electric Code, ANSI/NFPA 70,

provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire

to an antenna discharge product, size of grounding conductors, location of antenna discharge product, connection to

grounding electrodes and requirements for grounding electrodes.

18. SERVICING

Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified service personnel.

19. REPLACEMENT PARTS

When replacement parts are required, be sure the service technician uses replacement parts specified by the

manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions may result in fire,

electric shock or other hazards.

20. SAFETY CHECK

Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine

that the product is in proper operating condition.

21. WALL OR CEILING MOUNTING

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

22. DAMAGE REQUIRING SERVICE

Unplug the product from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered

by the operating instructions, as an adjustment of other controls may result in damage and will often require extensive

work by a qualified technician to restore the product to its normal operation.

e. If the product has been dropped or the cabinet has been damaged.

f. When the product exhibits a distinct change in performance–this indicates a need for service.

23. HEAT

The product should be situated away from heat sources such as radiators, heat registers, stoves or other products

(including amplifiers) that produce heat.

24. NOTE TO CATV SYSTEM INSTALLER

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding

system of the building, as close to the point of cable entry as practical.

IMPORTANT SAFETY INSTRUCTIONS (CONTINUED)

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

PRECAUTIONS

POWER SOURCE

Insert the AC plug (with the 2 blades) into a conveniently located AC outlet having 120V,

60Hz.

NOTE: The AC plug supplied with the unit is polarized to help minimize the possibility of

electric shock. If the AC plug does not ﬁt into a nonpolarized AC outlet, do not ﬁle or cut

the wide blade. It is the user’s responsibility to have an electrician replace the obsolete

outlet.

AC Plug

AC Outlet

NOTES ON HANDLING:

• When shipping the DVD recorder, always use the

original shipping carton and packing materials. For

maximum protection, repack the unit as it was

originally packed at the factory.

• Do not use volatile liquids, such as insect spray, near

the DVD recorder. Do not leave rubber or plastic

products in contact with the DVD recorder for a long

time. They will leave marks on the finish.

• The top and rear panels of the DVD recorder may

become warm after a long period of use. This is

normal and not a malfunction.

• When the DVD recorder is not in use, be sure to

remove the disc and turn off the power.

• If you do not use the DVD recorder for a long period,

the unit may not function properly in the future. Turn

on and use the DVD recorder occasionally.

NOTES ON LOCATING THE DVD RECORDER:

•When you place this DVD recorder near a TV,radio or

VCR, the playback picture may become poor and the

sound may be distorted. In this case, move the DVD

recorder away from the TV, radio or VCR.

NOTES ON CLEANING:

Use a soft, dry cloth for cleaning.

• For stubborn dirt, soak the cloth in a weak detergent

solution, wring well and wipe. Use a dry cloth to wipe

it dry. Do not use any type of solvent, such as thinner

and benzene, as they may damage the surface of the

DVD recorder.

• If you use a chemical-saturated cloth to clean the unit,

follow that product’s instructions.

Warning: Cleaning and adjustment of lenses and/or

other components of playback mechanism should be

performed by a qualified service technician.

NOTES ON MOISTURE CONDENSATION:

Moisture condensation damages the DVD recorder.

Please read the following carefully.

•Moisture condensation occurs, for example, when you

pour a cold drink into a glass on a warm day. Drops of

water form on the outside of the glass. In the same

way, moisture may condense on the optical pick-up

lens inside this unit, one of the most crucial internal

parts of the DVD recorder.

Moisture condensation occurs during the following

cases:

• When you bring the DVD recorder directly from a cold

place to a warm place.

• When you use the DVD recorder in a room where you

just turned on the heater, or a place where the cold

wind from the air conditioner directly hits the unit.

• In summer, when you use the DVD recorder in a hot

and humid place just after you moved the unit from an

air conditioned room.

• When you use the DVD recorder in a humid place.

Do not use the DVD recorder when moisture

condensation may occur.

• If you use the DVD recorder in such a situation, it may

damage discs and internal parts. Remove the disc,

connect the power cord of the DVD recorder to the

wall outlet, turn on the DVD recorder and leave it

“ON” for two or three hours. After two or three hours,

the DVD recorder will have warmed up and

evaporated any moisture. Keep the DVD recorder

connected to the wall outlet and moisture

condensation will seldom occur.

TO OBTAIN A CLEAR PICTURE:

The DVD recorder is a high technology, precision device.

If the optical pick-up lens and disc drive parts are dirty or

worn down, the picture quality becomes poor. To obtain a

clear picture, we recommend regular inspection and

maintenance (cleaning or parts replacement) every 1,000

hours of use depending on the operating environment.

For details, contact your nearest dealer.

1 32 4 5 76 98 121110

LOCATION OF CONTROLS

1. ON/STANDBY Button

2. DV IN Jack, S-Video IN Jack and A/V IN

Jacks (under door)

3. CHANNEL Up/Down Buttons

4. SOURCE Button

5. RECORD Button

6. Disc Tray

7. Display

8. Remote Sensor

9. OPEN/CLOSE Button

10. SKIP o/nButtons

11. STOP (X) Button

12. PLAY/PAUSE (®p) Button

FRONT

1. RF IN Jack

2. Rear Video IN

3. Right Audio IN (Rear Video/S-Video)

4. Component Y Output

5. Component Cb/Pb Output

6. Video OUT

7. Right Audio OUT

8. AC Power Cord

9. Optical Digital Audio Output

10. Coaxial Digital Audio OUT

11. Left Audio OUT

12. S-Video OUT

13. Component Cr/Pr Output

14. Left Audio IN (Rear Video & S-Video)

15. S-Video IN

16. RF OUT Jack

REAR

LOCATION OF CONTROLS (CONTINUED)

1. I/P (Interlace/Progressive) Button

2. SOURCE Button

3. HQ/SEP (Recording Quality) Button

4. TIMER PROGRAM Button

5. FWD ®

®®

®Button

6. REV √

√√

√Button

7. PLAY (®

®) Button

8. PAUSE/STEP Button

9. DISPLAY Button

10. Navigation (π) Button

11. ENTER Button

12. Navigation (√) Button

13. Navigation (†) Button

14. SETUP Button

15. PBC/TITLE Button

16. DVD MENU Button

17. ZOOM Button

18. PROGRAM Button

19. BOOKMARK Button

20. MUTE Button

21. Number (0–9) Buttons

22. OPEN/CLOSE Button

23. STANDBY ON/OFF Button

24. RECORD Button

25. TIMER Button

26. SKIP (o) Button

27. SKIP (n) Button

28. STOP (X

X) Button

29. SEARCH Button

30. Navigation (®) Button

31. DISC OPERATION Button

32. SUBTITLE Button

33. MTS AUDIO Button

34. DIGEST Button

35. CHANNEL Up Button

36. ANGLE Button

37. CHANNEL Down Button

38. Repeat A-B Button

39. REPEAT/PLAY MODE Button

REMOTE

REMOTE PART NO. HS-T466MB-GY-320*

REMOTE BATTERY

COVER PART NO. 111-03530-0784*

AV CABLES PART NO. 043-26102-533*

*Consumer Replaceable Part

(See page 67 to order.)

Altri manuali per MVDR2102

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Memorex Registratore digitale

Memorex

Memorex DVR H264 Manuale utente

Manuali Registratore digitale popolari di altre marche

FLIR

FLIR M3100E Series Manuale utente

VTRACKPRO

VTRACKPRO FPRO300 Manuale utente

Swann

Swann NVR-7085 models Manuale utente

XtendLan

XtendLan DVR-1670C Manuale utente

urmet domus

urmet domus 1093/004AHD Manuale utente

Holux

Holux M1 Manuale utente

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Manuale utente

Whistler

Whistler D16VRS Manuale utente

Defender Security

Defender Security 82-20235 Manuale utente

MISUMI

MISUMI MP-WF100M Manuale utente

Speco

Speco D8HU Manuale utente

UST

UST DDR-E04AA Istruzioni per l’uso

Consolidated

Consolidated Digital Video Recorder Manuale utente

Mace

Mace DVR0404RW Guida rapida

RCA

RCA RTD315W Manuale utente

FSM

FSM Colibri Grande PRO Manuale utente

Hauppauge

Hauppauge HD PVR 2 Manuale utente

Identivision

Identivision ICR-PH161i PIONEER Manuale utente
