MARK I

Maintenance and repair information.

Malfunctions can be cured easily when a proper diagnosis of the fault is made. Usually

only one part (most often a tube) is all that has gone bad, and the Boogie has been

designed and constructed to make any maintenance simple and straight forward.

Following is an outline covering just about any possible problem which might occur with

suggestions on how to proceed in determining what is wrong and curing it.

AMP IS DEAD

Check fuse, A.C. cord and wall socket -Check On-Off switch, power transformer.

TUBES & PILOT LIGHT UP BUT NO SOUND

• Set all front panel controls at 5.

• Make sure speaker is plugged into correct jack.

• Check speaker wire connections.

• Plug external speaker into amplifier.

• Make sure all tubes are in sockets and that none are broken.

• Broken tube will appear white and cloudy inside.

AMP WORKS BUT TONE IS WEAK, MAY HUM OR BLOW FUSES

Set MASTER to 10, Volume 2 to 3-4, plug instrument into #2

• Check 6L6's: Dead tube will only be luke warm, properly running they will be too hot to

handle after a minute. NOTE: only outside (end) 6L6's run when 100/60 switch is in 60

watt position. Shorted 6L6 glows red hot. NOTE: when 100/60 switch is in 100 watt

position (all 4 on) one shorted tube will cause the one next to it to also become red hot:

turn switch to 60 watt position and see if the end tube remains red - if so, it is the bad one.

If both cool down then probably (but not always) the inside 6L6 is at fault. A shorted 6L6

will often correct itself and un-short when momentarily interrupted by the STANDBY

switch or even a pulse from the 100/60 switch, but should be replaced by a reliable tube.

Whenever replacing 6L6 tubes, allow a few minutes of warm-up operation, then with the

power fully on (but not volume controls) tap each tube 5-6 times while watching for

shorting, arcing, or noise. Remember: 10% to 25% or more of all brand new tubes aren't

good enough. Weed out the bad ones before your gig. Recommended MESA 6L6 (STR

427).

• Check the pre-amp tubes. The best way is to replace them one at a time with a tube you

know is good. Tapping on the pre-amp tubes will often reveal the one causing noise or

detiroration of tone.

Almost all are one type: 12AX7. Those numbered 7025 or 6681 are selected but they are

still 12AX7. Recommend MESA 12AX7. 12AT7 is different and is used in the REVERB

Driver circuit. It belongs in the left hand most socket (viewed from rear) in the front row;

that is the one nearest the ON-OFF switch.

A bad pre-amp tube can also be the cause of scratchiness in the amp's volume controls.

• Check Fetron. It is the metal can type tube device located in the right hand most socket -

the one nearest the INPUT jacks. To check, merely replace it with a type 12AX7.

Occasionally a Fetron will deteriorate, drift or break down altogether, overall though, the

Fetron's performance will be hotter (amplify more) than the 12AX7 and much more

dependable, particularly where noise, vibration or microphonics are concerned.

A bad Fetron can be the cause of scratchiness in guitar volume control. Usually you can

only get a replacement Fetron from us. We use a special type and we select and install

load resistors to fine tune each Fetron. If you ever do need a replacement, notify us.

Installing a new Fetron with its particular resistors should take anyone with any soldering

skills only 10 minutes or so and is not difficult.

Use a 12AX7 in place of the Fetron. They are direct replacements for each other and

either device can be plugged into the socket and will work perfectly with the surrounding

circuitry. Tube performance is not substantially altered by the load resistors selected for

the Fetron, but you should select a tube which does not rattle or feed back when an

instrument is plugged into INPUT 1. A rubber band stretched tightly around the tube will

reduce noise. Replace the shield. Always tap on new pre-amp tubes to check for

noise and stability.

If the amp experiences a cutting out when in the heavy distortion, loud driving mode after

a 12AX7 has been substituted for the Fetron, then install a 250 pf 1000v disc capacitor

across the plates of the driver tube (12AX7) next to the 6L6's. The plates are pins

1 and 6. If an oscilloscope is available and the Fetron shows a lopsided wave form or

uneven clipping, it can sometimes be corrected by changing the value of the plate load

resistor. Values should fall in the range of 33K to 100K. Check Channel 2 first with

controls set as follows:

V1:0

V2: adjust for clipping with 1 Khz 1 volt input.

MASTER: 10

TREBLE: 10

OTHER CONTROLS: 0

Then, leaving V2 at clipping, plug signal into INPUT 1. Changing plate resistor value

will shift the operating point of the Fetron.

• Check Filter capacitors. A shorted filter will cause smoke and blow the fuse; an open or

intermittent-open filter cap will cause hum, distortion and weak tone. To test, merely clip-

lead a cap of sufficient voltage across each filter, one at a time. (Filter caps are large

yellow, orange, or blue cylinders mounted on heavy eyeletted power supply board.

Any significant improvement of tone or wave shape or any reduction in hum indicates an

open cap. To replace, merely clip out bad cap - it cannot be unsoldered because its leads

extend underneath the board. Make sure you note the proper polarity and replace with the

+ at the same end as the original, note especially the 2 marked 60 mf 350 volt, since they

face opposite directions. A subharmonic note audible below the note you are playing

(when fairly loud, lower to midrange) indicates an open main input capacitor, either one of

the 60 mf 350 volt or the capacitor connected to the output side of the standby switch

(located next to power transformer in models having the Graphic Equalizer.)

• Check the bias. Should have -52 Volts across 50mf 75 volt bias filter (small white cap on

power supply board). An open cap will cause low bias with lots of hum. The bias voltage

is permanently set when amp is first tested and shouldn't need adjustment; however a

malfunctioning Graphic Equalizer can sometimes cause a change in bias. Problem would

then be a blown transistor on the EQ board. See section on Graphic Equalizer.

• Check diodes. A blown rectifier diode will cause low voltage at the STANDBY switch

(should be 450-465). Test each diode in circuit (power off) with an ohm meter. Resistance

reading in one direction should be much greater than reading with meter leads reversed.

Use heat sinks whenever soldering is done to diodes. You may remove the 3 Phillips

screws holding down power supply board to gain better access.

• Output transformer. If all voltages are correct and good clean drive appears on the 6L6

grids, (pins 5) but not on plates (pins 3) or on plates but not at the speaker output, then the

output transformer is suspect. To verify, use areplacement, available from us.

NOISE PROBLEMS: Buzzing or loud hum with no signal plugged in

• Unplug instrument and see if buzz goes away.

• Try GRND switch, center position is off, left or right switches cap in between chassis

ground and A.C. supply.

• Make sure reverb cables are securely plugged in.

• Make sure tube shields are in place, particularly over the metal Fetron and that its case

is grounded by stretching out the spring inside the shield.

•Check pre-amp tubes, loud hum most often caused by a shorted pre-amp tube.

• Check the 100 ohm 12 watt resistors (2) located on the output circuit board nearly

beneath the speaker jacks. These resistors connect either side of the 6.3 volt A.C. filament

line to ground and can be blown out by a defective 6L6.

• Visually follow the filament string beginning with the twisted green leads at the power

transformer and look for shorts or bridges to any other parts.

• With the MASTER up and its input lead removed from the right end lug, you can quickly

ascertain board where buzz is originating. You have removed the pre-amp signal so if

buzz continues, it's on output board.

SPORADIC CRACKLING OR RUSHING SOUND

This is nearly always a tube noise (often the 12AT7) and will be the worst while warming

up. Less frequently it is a resistor in the pre-amp: the higher the resistance the more likely

it is to be noisy. Check the 100K plate resistors first by simple replacements. If noisy only

when TREBLE is up, replace 250 pf disc cap leading to TREBLE control.

REVERB PROBLEMS (See addendum for modifications in Reverb circuit)

• Make sure springs are unlocked.

• Check tubes and cables. output,

• Tap on the spring unit, hollow echo sound indicates spring output cable and reverb -

return circuitry are functioning.

• Remove spring unit and check for a lead broken off one of the jacks inside.

• A bad reverb driver transformer can be disconnected or replaced by small 4 Ohm output

transformer with single ended primary for temporary service.

• Arcing at the 12AT7 (reverb driver) socket may be remedied by squirting control cleaner

on the socket.

• Excess reverb feedback may be reduced by loosening (or sometimes tightening) the 4

screws which mount the reverb pan to the back panel.

• Certain speakers cause premature feedback by interacting magnetically with the reverb.

• Reduced MASTER setting results in less feedback with more reverb.

OTHER REPAIR TECHNIQUES

The following are valuable aids in troubleshooting and in verifying the stability of the amp

and it’s parts.

• A plug must be inserted into INPUT 1 in order to connect the first stage's output into the

second stage. With nothing plugged into the #1 jack and with VOLUME 1 turned on, the

switch contacts are free to vibrate and may start a resonant feedback at high settings. But

this is no problem because if INPUT I is not being used, its volume control should be

turned off and when a plug is inserted in the jack, all vibrating will stop instantly.

• Look carefully at all the connections around the tube sockets, then look at all the

connections of parts and wires to the boards jacks and controls. Give each one a little pull

test with pliers while the amp is running. Knock the chassis several times with a small

hammer, it should be quiet and stable and able to withstand great amounts of shock and

vibration; it has been built tough and carefully.

• An arced out circuit board can be repaired by scraping away all carbon traces and

replacing any arced high voltage stripes with wires leading directly to the tube socket

pins. Remove all carbon from arced tube socket, or replace socket.

• Sugar residue or beer, etc. on the circuit boards must be removed to allow stable

operation.

• A 10-24 tap can be useful for straightening out damaged threads in the chassis if a

mounting screw gets cross threaded.

• When removing the grille board to get access to the speaker, back the 4 black screws

half-way out and grip them like handles to pull off the grille board.

• If speaker mounting screws won't tighten after several replacements, you can rotate the

speaker slightly to expose fresh board underneath. Don't mount a speaker with the frame

contacting any pre-amp tubes or excess feedback will result and the tubes won't unplug.

• Speaker and reverb cables are long enough to allow chassis to sit on top of cabinet to

make work and testing easy.

• Any problem you or your technician are unable to solve may be referred to

MESA/Boogie for assistance over the telephone.

GRAPHIC EQUALIZER PROBLEMS

•Are rare indeed.

• Check switch-lug action on footswitch jack inside chassis, it should provide a ground

connection to the filter circuit with nothing plugged in.

• Check for 52 volt Bias across 50 mf. cap.

• Check transistors. Q4 is NPN, others are PNP. A blown transistor will upset bias voltage

to 6L6's as the equalizer circuit uses the same supply. Use min. 50V silicon replacements.

Transistor sockets make testing and repair simple.

• A low growling oscillation occurs if Q1 has too high gain, even though another of same

type make work OK.

• In case of real difficulty with the EQ board, contact factory for replacement. The board

can be hard to fix but is easy to replace. You may remove transistors and reset bias by

adding 5K to l0K resistance across bias filter cap. With EQ switch OFF, equalizer circuit is

completely bypassed.

ADDENDUM

A metallic sounding buzz in the tone of amps having Reverb may be traced to a parasitic

oscillation in the Reverb driver stage under certain settings. To cure, perform the following

modifications:

• Install minimum 220K resistance in series with the capacitor (.005) coupling signal to the

12AT7 grid (pin 7, or pins 2 & 7 if amp also has Graphic EQ.) There may be approximately

50 K in series already, but it might not provide enough isolation from the adjacent circuitry.

(If the buzz is greatly reduced but still persists, substitute 470K for 220K above, and

reduce .005 coupling cap to .001.)

• Replace the 470K (yellow-purple-yellow) grid leak resistor (also leading to pin 7 or 2&7)

with 100K.

• The cathode circuit of the 12AT7 (pins 8 or 3&8 if EQ) should have a 470 ohm to ground

with no bypass capacitor.

Altri manuali per Three Channel Dual & Triple Rectifier Solo...

Indice

Altri manuali Mesa/Boogie Amplificatore

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale operativo

Mesa/Boogie

Mesa/Boogie Lonestar Manuale utente

Mesa/Boogie

Mesa/Boogie REVOLVER Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie SINGLE RECTIFIER RECT-O-VERB 50 2 Series Guida rapida

Mesa/Boogie

Mesa/Boogie WalkAbout Manuale utente

Mesa/Boogie

Mesa/Boogie DC5 Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie FLUX-DRIVE Manuale utente

Mesa/Boogie

Mesa/Boogie BASS STRATEGY Eight:88 Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie MARK VII Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie TC50 Manuale utente

Mesa/Boogie

Mesa/Boogie M-PULSE Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale operativo

Mesa/Boogie

Mesa/Boogie Stiletto Manuale utente

Mesa/Boogie

Mesa/Boogie Three Channel Dual & Triple Rectifier Solo... Manuale utente

Mesa/Boogie

Mesa/Boogie California Tweed 6V6 2:TWENTY Manuale utente

Manuali Amplificatore popolari di altre marche

ASTRO

ASTRO HVO V40 P Manuale utente

Marantz

Marantz SUPERSCOPE BLA-545 Istruzioni per il montaggio

NAD

NAD CI980 Manuale utente

Technics

Technics SE-CH770 Manuale utente

Harman Kardon

Harman Kardon HK6300 Manuale utente

NAD

NAD T975 Manuale utente

McIntosh

McIntosh MA6850 Manuale utente

Electro-Harmonix

Electro-Harmonix ENGLISH MUFF’N Manuale utente

Viatron

Viatron Autrix Manuale utente

GME

GME GA9800 Manuale utente

Atlas

Atlas CP700 Manuale utente

Roland

Roland KC-1000 Manuale utente

Pyle

Pyle PFMRA350BW Manuale utente

Advantage

Advantage S-250 Manuale utente

IRT Electronics

IRT Electronics DVA-3007 Manuale utente

Dimavery

Dimavery BA-100 Series Manuale utente

Sony

Sony XM-S400D Manuale utente

Schertler

Schertler ROY X Manuale utente
