Metkon FORCIPOL Series Manuale utente

OPERATINGandINSTRUCTIONSMANUAL

FORCIPOL

GRINDING&POLISHINGSYSTEM

EC DECLARATION OF CONFORMITY

Manufacturer : Metkon Instruments Inc.

Address : Demirtas Dumlupinar Organize Sanayi Bolgesi

Ali Osman Sonmez Cd. No:14 Bursa / TURKEY

Herewith declares that;

Metallographic Grinding&Polishing Machine, Model: FORCIPOL

-is in conformity with the provisions of the Machinery Directive (directive 2006/42/EEC), as

amended, and with national implementing legislation;

-is in conformity with the provisions of the Low Voltage Directive (directive 2006/95/EEC), as

amended, and with national implementing legislation;

-is in conformity with the provisions of the EMC Directive (directive 2004/108/EEC), as

amended, and with national implementing legislation;

and furthermore declares that

-the following (parts/clauses of) standards have been applied

EN ISO 12100:2010, TS EN 60204-1, TS EN 61000-6-2, TS EN 61000-6-4

......................................................................................................................................................................

Authorized Person: Ercin Senay

Position: Manager of Research and Development Department

Year: 2014

INDEX

A. DESCRIPTION ................................................................................................................................................ 5

1. DESİGN ............................................................................................................................................................... 5

2. TECHNİCAL DATA .................................................................................................................................................. 6

3. WARRANTY ......................................................................................................................................................... 6

4. SAFETY PRECAUTİONS ............................................................................................................................................ 6

B. INSTALLATION & SET UP ............................................................................................................................... 7

1. UNPACKİNG &CHECKİNG CONTENTS OF PACKAGE ...................................................................................................... 7

2. INSTALLATİON AND SET-UP..................................................................................................................................... 8

2.1 Electrical Installation ............................................................................................................................... 9

2.2 Water & Cable Connections .................................................................................................................. 10

2.3Noise Level............................................................................................................................................. 12

C. CONTROL PANEL ..........................................................................................................................................12

1. CONTROL BUTTON FUNCTİONS.............................................................................................................................. 12

D. OPERATION..................................................................................................................................................12

1. PLATEN INSTALLATİON ......................................................................................................................................... 12

2. OPERATİON ....................................................................................................................................................... 13

3. TİME SETTİNG .................................................................................................................................................... 13

E. SERVICE AND MAINTENANCE.......................................................................................................................13

1. MAINTENANCE............................................................................................................................................... 13

1.1 Daily Maintenance ................................................................................................................................ 13

1.2 Weekly Maintanance ............................................................................................................................ 14

1.3 Yearly Maintanance .............................................................................................................................. 14

2. TROUBLESHOOTİNG............................................................................................................................................. 15

F. ACCESSORIES AND CONSUMABLES ..............................................................................................................15

1. ACCESSORİES...................................................................................................................................................... 15

2. CONSUMABLES................................................................................................................................................... 16

G. TECHNICAL DOCUMENTATION.....................................................................................................................21

1. RECOMMENDED SPARE PART LİST .......................................................................................................................... 21

2. CUSTOMER SERVİCE ............................................................................................................................................ 22

3. ELECTRİCAL WİRİNG DİAGRAMS............................................................................................................................. 23

A. DESCRIPTION

1. Design

FORCIPOL Series of instruments are avaible as Single Disc Units and Double Disc Units. The drive

elements are fixed on heavy duty aluminium alloyed casting. The rotating discs are mounted on ball

bearings which allow the application of high pressures to prepare even large specimens. Ball bearings

used provide quite and vibration free operation.

FORCIPOL uses a powerful high torque motor. The power transmission from the motor to the rotating

disc is made via belt drive. Motor overload protection switch ensures maintenance-free operation.

FORCIPOL grinders and polishers, both single or double disc versions are avaible with constant or

infinitely variable rotating speeds, with digital display. This allows the setting of the optimum speed for

each individual perparation process. The modern state of the art electronics in the form a compact

printed circuit board provides a smooth speed variation.

Water inlet and flexible water outlets with control valves for wet grinding and the facilility for

FORCIMAT attachment are standard features.

Motor on / off and water on / off buttons are mounted on the front panel.

FORCIPOL instruments can be used for grinding, lapping and polishing by quick and simple exchange of

discs which takes only a few seconds. When the number of specimens to be prepared increases,

FORCIPOL instruments can be fitted with FORCIMAT attachment for automation. FORCIMAT provides

high rate of sample preparation and frees the operator from the polishing procedures.

FORCIMAT can accomodate upto six specimens. By using the spacer rings, the diameter of the

specimens can vary from 25 to 40 mm. Also you can attach 3 x 50 sample holder.

Fig. 1 FORCIPOL 1V & FORCIPOL 2V

2. Technical Data

No. Of

Discs

Motor

Discs

Speed

rpm

Discs Size

Dimens.

Weight

kg.

FORCIPOL 1V

Single

0.75HP,220V-

50Hz, 1 ph

50-600

Var.

200, 250

380x690x340

FORCIPOL 300-1V

Single

1,0 HP,220V-

50Hz, 1 ph

50-600

Var.

300

420x730x350

FORCIPOL 2V

Double

0.75HP,220V-

50Hz, 1 ph

50-600

var.

200, 250

700x690x340

3. Warranty

The FORCIPOL is guaranteed against defective material or workmanship for a period of 12 months from

the date of receipt by the customer or latest 18 months after the shipping date. Warranty is not valid if

inspection shows evidence of misuse or unauthorized repair. Warranty covers only replacement of

defective materials. In case this unit must be returned to our factory for warranty service please ask for

prior authorization and include the following details: Serial Number of the unit, Invoice number and

date. Transport costs belong to the customer.

4. Safety Precautions

Read the below instructions carefully before use.

Place the machine on a sturdy and safe table.

The equipment must be installed in compliance with local safety regulations.

Only use approved METKON accessories and consumables to achieve max. safety and

lifetime.

Follow the instructions and safety regulations when lifting and carrying the equipment.

Be sure that the water connections are assembled properly without any water leakage.

Be sure that the water outlet hose is safely assembled to the outlet connection.

Make sure that the grinding and polishing discs are correctly assembled and the pins on the

face plate are engaged with the grinding disc.

While grinding manually be careful not to touch the grinding disc.

Do not try to collect a specimen from the working area while the disc is turning.

Disconnect the electrical connection before servicing the equipment.

Follow the periodically maintenance.

The equipment is designed to be used with METKON accessories and consumables. In

case of misuse of equipment, improper installation, alteration, use of different source

parts, improper repair, METKON will accept NO responsibility for any damages to the

operator or the equipment. Disassembling of any part should always be performed by

a qualified technician.

B. INSTALLATION & SET UP

1. Unpacking & Checking Contents of Package

Carefully unpack and check contents of the package. If any components are missing or damaged,

save the packing list and materials and advise the carrier and Metkon Instruments Ltd. of the

discrepancy.

Carefully unpack and check that the following items have been received:

oPower Cable, 1.8 mt, 1 piece

oDrain Hose, 1.5 mt, 1 piece

oWater Inlet Hose, 1.5 mt, 1 piece

oPneumatic Fitting, 8 mm to ¼”, 1 piece

oBrass adapter, ¼” to ½”, 1 piece

oHose Clamp, Ø22 to Ø36 mm, 1 piece

WARNING! The FORCIPOLs weighs from 29 kgs to 40 kgs. please be sure that there are

enough people (at least 2) to safely lift the unit from the shipping carton. It is recommended

to wear safety shoes during transportation. Follow the steps on 1.1 which the unpacking

procedure is described step by step with photos.

ATTENTION! The FORCIPOLs are bolted to a wood base for protection during shipping. Lift

the unit out of the carton and position it on a table so it overhangs on the edge. Remove the

bolt securing the unit to the wood base.

Carefully remove outer packing material. Refer to the packing documents for a list of items supplied.

2. Installation and Set-Up

CAUTION! Follow approved procedures and take all necessary preventive safety measures

when lifting and installing this equipment. Improper lifting can result equipment damage.

FORCIPOL units are shipped as already assembled.

FORCIPOL is only available as bench top.

FORCIPOL should be placed on a sturdy and safe platform. Please be sure that the platform is

large enough and can stand it’s weight.

In order to work with equipment comfortably, it is recommended to leave at least 30 cm space

from all side of the equipment.

You can see the dimensions and weight of FORCIPOL as below:

Equipment

Dimensions

Weight

Forcipol 1V

380 mm

690 mm

340 mm

30 kgs

Forcipol 300-1V

420 mm

730 mm

350 mm

30 kgs

Forcipol 2V

700 mm

690 mm

340 mm

40 kgs

Place the FORCIPOL on a sturdy table with convenient access to a 1-phase grounded power source,

water supply and water drain. Make the drain connection with the plastic hose and the hose clip

supplied. Connect the nylon tube to the water outlet at the rear of the instruments for water supply.

Place the disc and the splash guard. (Fig. 2)

2.1 Electrical Installation

Before making electrical connections, check that the voltage and frequency stated on the specification

plate correspond to the local voltage and frequency. Check that the values for three-phase voltage, is

compatible with the intended electrical supply before installation.

ATTENTION! Connect the unit to the grounded mains voltage.

WARNING! Electrical Shock Hazard. A qualified electrical technician should perform

optional hard wiring and electrical maintenance.

Disconnect the power supply before making any electrical adjustments.

Make sure that the supply voltage and frequency is correct. Check the values from the back thin

metal plate.

Voltage

Operational Power Range

230 V, 50/60 Hz. 1 ph.

220 - 240 V

115 V, 50/60 Hz. 1 ph.

110 - 120 V

Equipment

Fuse Ratings

230 V

115V

Forcipol 1V

6 A (C Type)

Forcipol 300-1V

10 A (C Type)

Forcipol 2V

6 A (C Type)

Connect the equipment to the grounded mains voltage.Power cord will be supplied with the

equipment.

Lenght of power cable is 1.8 meters.

You can see suitable power sockets as below. If you have not suitable power socket, in this case

you should supply a suitable power cord.

2.2 Water & Cable Connections

The recommended cooling water flow rate is a minimum of 2 liters/min with max water pressure 3 bars.

Water inlet and drain hoses will be sent together with the equipment. (See: Installation Kit)

Please see diameters of hoses as below:

Drain Hose:

Input diameter: 29 mm

Outer diameter: 33 mm

Water Hose:

Input diameter: 5 mm

Outer diameter: 8 mm (5/16”)

Please be sure that there are enough space or holes for hoses at the back side of the equipment.
