Metra Electronics 70-6514 Manuale utente

CHRYSLER, DODGE

AMPLIFIER BYPASS HARNESS

1-800-221-0932 www.axxessinterface.com

70-6514

INSTALLATION INSTRUCTIONS

1-800-221-0932 www.axxessinterface.com

70-6514 70-6514

APPLICATIONS:

REV. 08/22/11 INST70-6514

Chrysler

300 2005-2007

Aspen 2007

Dodge

Charger 2005-2007

Dakota 2005-2007

Durango 2004-2007

Magnum 2005-2007

Ram 2006-2009

Amplifier locations and wiring

Caravan 2005-2007 Behind Right rear speaker

Wire Colors for Bypass Harness:

Brown/White Not Used

Blue Dark/Pink Not Used

Yellow/Blue Left Front Tweeter (+)

Yellow/Black Left Front Tweeter (-)

Yellow/Red Right Front Tweeter (+)

Yellow/Orange Right Front Tweeter (-)

Green/White Left Rear Tweeter (+)

White/Red Left Rear Tweeter (-)

Brown/Yellow Right Rear Tweeter (+)

Brown/Blue Right Rear Tweeter (-)

The rest of the speaker wires are standard Metra/AEI color

code that can be found on the back of this package.

NOTE

The factory amplifier has the crossover built in. When

bypassing the factory

amplifier be sure to use crossovers to protect the factory

speakers.

This harness is designed to be

used with all vehicles listed above

that are equipped with the

amplified Infinity sound system.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certified technicians

70-6514 70-651470-6514

Amplifier locations and wiring

300 2005-2007* To the left of the Steering column

Charger 2005-2007* To the left of the Steering column

Commander 2006-2007 Left Rear quarter

Grand Cherokee 2005-2007 Left Rear quarter

Magnum 2005-2007* To the left of the Steering column

Ram 2006-2009* Behind glove box

Wire Colors for Bypass Harness:

Brown/White**** Center Speaker (+)

Blue Dark/Pink**** Center Speaker (-)

Yellow/Blue Left Front Tweeter (+)

Yellow/Black Left Front Tweeter (-)

Yellow/Red Right Front Tweeter (+)

Yellow/Orange Right Front Tweeter (-)

Green/White Subwoofer (+)

White/Red Subwoofer (-)

Brown/Yellow Not Used

Brown/Blue Not Used

The rest of the speaker wires are standard Metra/AEI color

code that can be found on the back of this package.

NOTE

The factory amplifier has the crossover built in. When

bypassing the factory amplifier be sure to use crossovers to

protect the factory speakers.

* DOES NOT RETAIN FACTORY SUBWOOFER IN CHRYSLER

300, DODGE CHARGER, RAM SRT AND 2006 &2007 MAGNUM

**** NOT USED IN DODGE DURANGO, MAGNUM AND JEEP

GRAND CHEROKEE

Amplifier locations and wiring

Aspen 2007 Passenger Kick panel

Durango 2004-2007 Passenger Kick panel

Wire Colors for Bypass Harness:

Brown/White Not Used

Blue Dark/Pink Not Used

Yellow/Blue Left Front Tweeter (+)

Yellow/Black Left Front Tweeter (-)

Yellow/Red Right Front Tweeter (+)

Yellow/Orange Right Front Tweeter (-)

Green/White Subwoofer 1 (+)

White/Red Subwoofer 1 (-)

Brown/Yellow Subwoofer 2 (+)

Brown/Blue Subwoofer 2 (-)

The rest of the speaker wires are standard Metra/AEI color

code that can be found on the back of this package.

NOTE

The factory amplifier has the crossover built in. When

bypassing the factory amplifier be sure to use crossovers to

protect the factory speakers.

Amplifier locations and wiring

Dakota 2005-2007*** Right front kick panel

Wire Colors for Bypass Harness:

Brown/White Not Used

Blue Dark/Pink Not Used

Yellow/Blue** Subwoofer 1 (+)

Yellow/Black** Subwoofer 1 (-)

Yellow/Red** Subwoofer 2 (+)

Yellow/Orange** Subwoofer 2 (-)

Green/White Left Front Tweeter (+)

White/Red Left Front Tweeter (-)

Brown/Yellow Right Front Tweeter (+)

Brown/Blue Right Front Tweeter (-)

The rest of the speaker wires are standard Metra/AEI color

code that can be found on the back of this package.

NOTE

The factory amplifier has the crossover built in. When bypass-

ing the factory

amplifier be sure to use crossovers to protect the factory

speakers.

** NOT USED IN 2005 DAKOTA

*** TO RATAIN FACTORY SUBWOOFER IN DODGE DAKOTA CLUB

CAB HOOK UP AMPLIFIER TURN ON WIRE ON THE RADIO

POWER HARNESS
