INSTALLATION INSTRUCTIONS FOR PART 95-7861

95-7861

KIT FEATURES

•Double DIN Radio Provision

•Stacked ISO Mount Units Provision

A) “LX” Double DIN Trim Plate B) “EX” Double DIN Trim Plate C) Double DIN Brackets

KIT COMPONENTS

Small Flat Blade Screwdriver/ • Panel Removal Tool

•Phillips Screwdriver • Socket Set

1-800-221-0932

www.metraonline.com

TOOLS REQUIRED:

APPLICATIONS

Honda Pilot

•2003-2005

•2006-2008

(Without Factory Navigation)

Dash Disassembly

-HondaPilot2003-2005 .......................................... 1

-Honda Pilot 2006-2008

(Without Factory Navigation) . .

............2

Kit Assembly

-DINRadioProvision .............................................3

-ISORadioProvision .............................................4

Final Assembly ..........................................5

TABLE OF CONTENTS

95-7861

*Note:

Refer also to the instructions included with the aftermarket radio.

95-7861 DASH DISASSEMBLY

HONDA PILOT 2003-2005

Disconnect the negative battery-

terminal to prevent an accidental

short circuit.

Using a small flat blade screw-

driver remove the blank plate

from upper right side of radio

trim panel.

(Figure A)

Unsnap radio trim panel. Unplug

switches and remove panel.

(Figure B)

Remove (4) 10mm bolts securing

radio, unplug and remove radio.

(Figure C)

Continue to kit assembly.

95-7861 DASH DISASSEMBLY

HONDA PILOT 2006-2008

(Without Factory Navigation)

Disconnect the negative battery-

terminal to prevent an accidental

short circuit.

Remove (2) screws from the top

of the instrument panel trim.

Unclip and remove the instrument

panel trim.

(Figure A)

Unclip and remove the left center trim

panel.

(Figure B)

Unclip the radio trim panel.

Unplug and remove the panel.

(Figure C)

Remove the (4) screws securing

the radio. Unplug and remove the

radio.

(Figure D)

Continue to kit assembly.

95-7861 KIT ASSEMBLY

DOUBLE DIN RADIO PROVISION

Slide the Double DIN radio into the

bracket/trim plate assembly and

secure the radio to the assembly using

the screws supplied with the radio.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

Snap the Double DIN brackets to the

inside edge of the Double DIN trim

plate. (

Figure A)

NOTE: Select the proper radio housing for your vehicle. EX models use the (EX)

Double DIN Trim Plate and LX models use the (LX) Double DIN Trim Plate.

95-7861 KIT ASSEMBLY

STACKED ISO UNITS PROVISION

Slide the stacked ISO units into

the bracket/trim plate assembly

and secure the units to the

assembly using the screws sup-

plied with the units.

(Figure B)

Continue to final assembly.

*Note: Refer also to the instructions included with the aftermarket radio.

Snap the Double DIN brackets to

the inside edge of the Double DIN

trim plate.

(

Figure A)

NOTE: Select the proper radio housing for your vehicle. EX models use the (EX)

Double DIN Trim Plate and LX models use the (LX) Double DIN Trim Plate.

95-7861 FINAL ASSEMBLY

FINAL ASSEMBLY

(A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Locate the factory wiring harness in the dash. Metra recommends using the

proper mating adapter and making connections as shown. (Isolate and individ-

ually tape off the ends of any unused wires to prevent electrical short circuit.)

Re-connect the negative batteryterminal and test the unit for proper operation.

Reassemble radio and dash assemblies in reverse order of disassembly.

FINAL WIRING CONNECTIONS

Make wiring connections using the EIA color code chart shown belowand the instructions included with the

head unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and

individually tape off ends of anyunused wires to prevent electrical short circuit.

METRA / EIA WIRING CODE

12V Ignition / Acc. . . . . . . . . . Red

12V Batt / Memory. . . . . . . . . Yellow

Ground. . . . . . . . . . . . . . . . . . Black*

Power Antenna. . . . . . . . . . . . Blue

Amp Turn-On . . . . . . . . . . . . . Blue / White

Amp Ground. . . . . . . . . . . . . . Black / White

Illumination . . . . . . . . . . . . . . Orange

Dimmer.................Orange / White

Right Front (+) . . . . . . . . . . . . Gray

Right Front (-). . . . . . . . . . . . . Gray/ Black

Left Front (+) . . . . . . . . . . . . . White

Left Front (-). . . . . . . . . . . . . . White / Black

Right Rear (+) . . . . . . . . . . . . Violet

Right Rear (-) . . . . . . . . . . . . . Violet / Black

Left Rear (+) . . . . . . . . . . . . . Green

Left Rear (-) ..............Green / Black

*NOTE: When a Black wire is not present, ground radio to vehicle chassis.

All colors may not be present on all leads due to manufacturer’s specifications.

95-7861 INSTRUCTIONS

1-800-221-0932

www.metraonline.com
