Metra Electronics MPS-GEN01 Manuale utente

INSTALLATION INSTRUCTIONS

MPS-GEN01

Attention! Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory radio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

KIT FEATURES

• ISO DDIN radio provision

• Replaces upper pocket

• Textured to match factory ﬁnish

KIT COMPONENTS

• A) Radio housing • B) Radio brackets • C) Phillips screws (12)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 1/8” drill bit

TABLE OF CONTENTS

Dash Disassembly ..................................................2

Kit Preparation .......................................................2

Kit Assembly ..........................................................3

A B C

Polaris General 2016-Up

Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle

speciﬁc applications

MetraOnline.com

DASH DISASSEMBLY KIT PREPARATION

1. Remove the storage pocket from the

upper dashboard. (Figure A)

Continue to Kit Preparation

(Figure A) (Figure A)

1. Enlarge the storage pocket opening to

allow room for the aftermarket radio

and mounting kit. (Figure A)

Continue to Kit Assembly

Remove shaded area

REV. 2/12/2020 INSTMPS-GEN01 3

KIT ASSEMBLY

1. Secure the radio brackets to the radio

housing using (4) Phillips screws

provided. (Figure A)

2. Slide the radio into the radio housing

assembly, then secure using screws

supplied with the radio. (Figure B)

3. Complete all necessary connections to

the radio, then test the radio for proper

operation. Use Metra part number 44-

UA20 (sold separately) for an antenna.

4. Slide the radio assembly into the dash.

Pre-drill (8) pilot holes in the dash

using a 1/8” drill bit. Using a manual

screwdriver, secure the radio assembly

to the dash using (8) Phillips screws

provided. Do not overtighten! (Figure C)

(Figure A)

(Figure C)

(Figure B)

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

INSTALLATION INSTRUCTIONS

MPS-GEN01

If you are having difﬁculties with the installation

of this product, contact our Tech Support line

either by phone at 386-257-1186, or email at

techsupport@metra-autosound.com. Before

doing so, look over the instruction booklet a

second time and ensure that the installation was

performed exactly as the instruction booklet

is stated. Have the vehicle apart and ready to

perform troubleshooting steps before contacting

Metra/Axxess Tech Support.
