QUICK START GUIDE

BRAVO TOUCH K

1Download the quick start guide in another language ............................... 2

1.1 Bravo Touch K Quick start guide EN ______________________________ 2

1.2 Bravo Touch K Schnellstartanleitung DE ___________________________ 2

1.3 Bravo Touch K Guide de démarrage rapide FR______________________ 2

1.4 Bravo Touch K Snelstartgids NL _________________________________ 2

2Download the full manual ......................................................................... 2

3Safety instructions and general warnings................................................. 3

3.1 General warnings _____________________________________________ 3

3.2 Safety warnings ______________________________________________ 3

3.3 Wiring precautions ____________________________________________ 4

3.4 Disposal ____________________________________________________ 4

4Operating the display ................................................................................ 5

5User menu functions.................................................................................. 6

6Installer menu functions ........................................................................... 6

7Alarm overview.......................................................................................... 7

8Front board overview ................................................................................ 7

9Bottom board overview ............................................................................. 8

9.1 Detail A: jumper settings _______________________________________ 9

9.2 Detail B: connections __________________________________________ 9

10 Technical specifications........................................................................... 10

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 2 | 12

1Download the quick start guide in another language

The Bravo Touch K Quick start guide is available in various languages. Download the version you need via

the QR-code. You can also find more information via www.microfan.com.

1.1 Bravo Touch K

Quick start guide EN

1.2 Bravo Touch K

Schnellstartanleitung DE

1.3 Bravo Touch K

Guide de démarrage rapide FR

1.4 Bravo Touch K

Snelstartgids NL

2Download the full manual

Scan the QR-code below to download the latest full manual of the BRAVO TOUCH. This manual contains all

necessary information to install and use the BRAVO TOUCH SL, 06, 10 and K. You can also find more

information via www.microfan.com.

Remark: The full manual is currently only available in English.

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 3 | 12

3Safety instructions and general warnings

Carefully read, understand, and follow all the warnings and instructions provided by Microfan B.V. to safely

use our products. These warnings and instructions are found on the equipment, in manuals, in brochures, on

our website, or by contacting us. The selection and application of Microfan B.V. products remain the

responsibility of the equipment installer or end user. Microfan B.V. accepts no responsibility for the way its

products are incorporated. All Microfan B.V. products must be supplied to the end user with appropriate

warnings and instructions as to safe use and operation. Microfan B.V. assumes no liability for any personal

injury, property damage, losses, or claims arising from misapplication of its products.

3.1 General warnings

󱛻󱛼󱛽WARNING

•Read and understand all the warnings and instructions provided by Microfan B.V. before

installing, operating, or servicing any of our products.

•All work must only be performed by qualified personnel.

•The product must only be set up, used, or stored in places that are not accessible to

children.

•Handle the product with care; impacts, shock or fall even from low heights will damage it.

•Do not expose the product to direct sun irradiation, strong heat or cold.

•After installation, always check all settings to ensure they work correctly.

•Do not use running water to clean your computer. The computer is splash proof, not

waterproof!

•It is of the utmost importance that the installation is equipped with a solid alarm system

that is tested for correct operation at least once a day.

3.2 Safety warnings

󱛻󱛼󱛽WARNING

•Do not wear any metal or conductive materials, such as jewelry (necklaces, bracelets,

rings, etc.) during installation or service on electrical parts or components.

•Always shut off the power before opening the housing.

•Never remove components or wires from electronic boards when the unit is switched on.

•Do not use an improper voltage source.

•Make sure all terminal screws are tightened correctly.

•Always make use of the supplied cable glands when installing cables to the controller.

•After installation, unused cable glands must be sealed to prevent water, dust, and other

substances from entering the controller.

•If you have a reason to believe that the device can no longer be operated safely,

disconnect it immediately and make sure it is not operated unintentionally.

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 4 | 12

3.3 Wiring precautions

󱛻󱛼󱛽WARNING

•For all weak current connections, always use shielded cable.

•For all high voltage power connections, always use shielded cable.

•For communication connections, always use twisted pair shielded cable.

•Do not connect the shielding of weak current connections to the ground block (PE).

•Do not connect the shielding of communication connections to the ground block (PE).

•The maximum communication connection length must not exceed 1200 meters.

•Separate high voltage power connections from weak current connections and/ or

communication connections to avoid voltage distortion.

•If inductive loads are connected to the equipment, Microfan B.V. advises to suppress

these loads by installing an RC filter (100ohm + 100nF) parallel on them.

3.4 Disposal

Electronic devices are recyclable and should not be disposed of in household waste. Dispose of

the product according to the applicable statutory provisions at the end of its service life.

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 5 | 12

4Operating the display

Select

On the right side of the screen you

can swipe up and down through all

menu icons. The currently set values

are visible here. Press on the icon or

the currently set value to enter a new

value.

Adjust

If you select a menu icon, an

orange adjustment bar becomes

visible. Press “+”to increase a

setting and “-” to decrease.

Save

Once a desired value has been

entered, press “OK”to save.

To cancel an adjustment, press

anywhere on the left half of the

screen. The settings bar closes and

the value resets to its previous

setting.

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 6 | 12

5User menu functions

6Installer menu functions

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 7 | 12

7Alarm overview

8Front board overview

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 8 | 12

9Bottom board overview

See section 9.1 for detail A.

See section 9.2 for detail B.

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 9 | 12

9.1 Detail A: jumper settings

9.2 Detail B: connections

Q u i c k _ s t a r t _ 2 0 2 0 0 5 1 5 _ B R A V O _ T O U C H _ K _ E N _ V 1 . 0 2 . 0 2 . d o c x P a g e 10 | 12

10 Technical specifications

General

Dimensions (external)

Housing

Connections

Environmental temperature

: 204x229x116mm (depth x width x height)

: Plastic IP54

: Via terminal strip

: 0 –45˚C no direct sunlight or radiation from heat source

Power supply

Power supply voltage

Mains frequency

Power consumption

Fuse:

: 110 –240Vac

: 50/60Hz

: Max. 20 Watt

: F5A

Power supply 12/24Vdc

24Vdc output

12Vdc output

: Max. 0.8A

: Max. 250mA

Analog inputs

Analog input 1

Analog input 2

Analog input 3

Temperature inputs measuring range

: Room temperature sensor (type: PT3000 / ARGOS-TV)

0-10V / 10K input impedance (1mA)

: Outside temp. sensor, additional heating control temp. sensor

0-10V / 10K input impedance (1mA)

or motor control feedback

: Selected sensor as additional control (pressure / RH / CO2 /

NH3) 0-10V / 10K input impedance (1mA)

: -70.0˚C to 130.0˚C

Digital inputs

Digital input 1

Digital input 2

: RPM feedback

NPN-sensor / max. 250Hz; Unloaded voltage max. 24Vdc

: External alarm (NC)

NPN-sensor / max. 250Hz; Unloaded voltage 24Vdc

Analog outputs

Analog output 1

Analog output 2

FAN output

: Damper control output

0-10V minimum impedance 1K2 (max. 8 mA)

: Follow-up control or pressure control output

0-10V minimum impedance 1K2 (max. 8 mA)

: N.A.

Digital outputs

Relay 1

Relay 2

Alarm relay

: Heating control relay

max. 24Vac/dc 2Amp. potential free

: External alarm output (NC), cooling control relay

or motor control direction relay.

max. 24Vac/dc 2Amp. potential free

: Max. 24Vac/dc 2Amp. potential free
