Alarm Controller

User Instructions

Thank you for choosing to purchase this micron security alarm controller. Micron product is manufactured to

exacting quality standards. We understand the importance of designing products that are reliable and easy to

use. You can rest secure knowing we have thought of everything to ensure your complete peace of mind.

The Keypad......................................................................................................................................................................3

The ‘Status’ (S1) Lamp................................................................................................................................................3

The ‘Mains’ Lamp .......................................................................................................................................................3

The ‘Armed’ Lamp ......................................................................................................................................................3

Two Key Panic.............................................................................................................................................................4

User Codes.......................................................................................................................................................................4

Adding, Changing or Deleting a user Code .................................................................................................................4

Arming the System ......................................................................................................................................................5

To Arm the System and Exclude a Zone(s) .................................................................................................................5

Disarming the System..................................................................................................................................................6

Night Arming Options .....................................................................................................................................................6

Remote Arming................................................................................................................................................................7

Arming.........................................................................................................................................................................7

Answer Phone Defeat ..................................................................................................................................................8

Nitewatch (if connected)..................................................................................................................................................8

Hold Down Commands....................................................................................................................................................9

Follow Me Mode..........................................................................................................................................................9

Chime Mode ..................................................................................................................................................................10

24 Hour Zones ...............................................................................................................................................................10

Icon LCD Keypad (if supplied) .....................................................................................................................................10

Using the Scorpion Z4110C Alarm Controller

The Keypad

The Scorpion Z4110C communicates system status through the keypad beeper. During an arming cycle the

beeper will sound for the entire exit time. This is a ‘leave now’ warning. Scorpion will arm at the end of this

period. On entry, the beeper sounds for the programmed entry period. If a valid user code is entered to

disarm the system, the beeper emits two short tones. An incorrect entry is signalled by one long tone.

The ‘Status’ (S1) Lamp

The yellow status lamp is used to indicate several conditions.

Yellow lamp on: the system is armed or arming

Yellow lamp off: the system is disarmed

Yellow lamp flashing: an alarm has occurred, a system fault exists or

the panic function has been activated

The ‘Mains’ Lamp

The ‘Mains’ lamp is on when mains power is applied. In the event of a mains failure the ‘Mains’ light flashes

until mains power is restored and an arm/disarm cycle is completed. The ‘Mains’ lamp also flashes to indicate

a low battery condition. When the battery is restored to full charge and an arm/disarm cycle is completed, the

‘Mains’ lamp stops flashing.

The ‘Armed’ Lamp

The ‘Armed’ lamp illuminates when the system is armed. The ‘Armed’ lamp also flashes to indicate when an

alarm condition has occurred.

12 3 4then 1 3

+then 1912then

Two Key Panic

If this function has been programmed in the Scorpion Z4110C by your installer it may be activated by pressing

the keypad *and # keys simultaneously. All internal and external alarms will activate. A panic activation may

be cancelled by entering any valid user code then #.

In panic situations press

User Codes

Scorpion Z4110C is capable of storing up to twelve user codes. Each user code may be two to four digits in

length and each may be used to arm and disarm the system.

User code 11 is factory set as user code 1234 and should be changed to your own selection. User codes 11 and

12 are assigned as master user codes. These user codes can be used to program the other ten user codes.

Master and non-master user codes operate in exactly the same manner and can arm, disarm and exclude zones.

Adding, Changing or Deleting a user Code

Enter a valid master user code, press keys 1+3 together then enter a new user code then enter # then the user

identifier (1 to 12). Repeat the procedure for adding other new user codes. To delete user codes, follow the

same procedure, but omit the ‘new user code’ step. Finish by entering a #.

Example. To change user code one to 1912 where 1234 is a master user code, press the following sequence:

1 #

2 3 4

1 #

then

2 3 4

1then then 45then #

Arming the System

Using Quickarm

If your installer has programmed the quickarm option you can arm the system by entering 1then #.

Quick arming Scorpion

Using a User Code

Enter a valid two, three or four digit user code then #.

If all zones are clear, the keypad sounds a repeating sequence of three short beeps for the duration of the exit

delay and the yellow status lamp and red armed lamp turn on. The zone lamps for all zones that are arming are

also turned on. At the end of the exit delay the zone lamps extinguish and the system is now armed.

If a zone fault or potential alarm condition exists and the user attempts to arm the system, the lamp(s) for those

zone(s) flash and are accompanied by a repeating sequence of long beeps. This indicates that one or more of

the zones are faulty or not secured. The panel should be disarmed, the problem located (possible open door or

window) and the system re-armed.

To Arm the System and Exclude a Zone(s)

Enter a valid user code then *(all zone LED’s light) followed by the zone number(s) to be excluded (those

zone LED’s turn off), then press #.

Example: To arm the system with zones 4 and 5 excluded press:

2 3 4

1 #

then

Disarming the System

Follow the same sequence as for arming, enter a valid two, three or four digit user code then #.

The keypad will beep twice and the yellow status light will turn off. A flashing yellow status lamp indicates

that one or more zones have been alarmed. The zone lamps for any zones that have alarmed will flash until the

next arming cycle. Note the zone number(s) and notify your installer, or security monitoring company.

If the yellow status lamp is flashing and no zone lamps are flashing the condition may have been caused by a

system fault, press 8 9 then #on your keypad. The following table indicates the type of alarm condition that

has occurred:

Zone 1 lamp flashes Alarm caused by a nitewatch panic

Zone 2 lamp flashes Alarm caused by a keypad panic

Zone 3 lamp flashes The battery has discharged or is faulty

Zone 4 lamp flashes Mains power to the alarm has failed

Zone 5 lamp flashes Phone line is faulty or is disconnected

Night Arming Options

You will need to discuss with your installer the configuration of your system’s night arming zones, as this is an

installer selectable option. It is important that your installer completely familiarises you with how Scorpion

arms and alarms in the two ‘Night Arming’ modes.

Scorpion Z4110C has two night arming options. Night arming offers the user perimeter protection with the

freedom to move freely within the areas that would normally be protected by the alarm control. The Z4110C

can be night armed with either instant zones, that is zones that arm instantly and alarm instantly, or with

delayed zones, zones that arm with a delay or alarm with a delay on entry.

18 #

9 1 #

The method of night arming with Delay is used where the system is to be armed at night with the occupants at

home, but a member of the family is yet to arrive home and must be able to enter and disarm the alarm system

before re-arming in Instant mode.

To night arm your system with instant arming and alarming enter 8 1 #.

To night arm your system with delayed arming and alarming enter 9 1 #.

To ‘instant’ night arm press for ‘delayed’ arming press

If night arming with delayed arming and alarming (9 1 #) is selected, the alarm control allows an exit period

before arming, however the keypad beeper exit alert is NOT sounded, except where a zone is not secure

(possible door/ window open or sensor activated). At the end of the exit period the keypad beeps three times.

Violating a night arm zone starts the entry pre-alert keypad beeper before sounding an alarm. To deactivate the

system during the pre-alert, enter a valid user code then #.

Remote Arming

Scorpion may be armed by any touch tone phone. This feature must be pre-enabled by the installer.

Arming

From a touch tone phone call the alarm phone number. The installer will have programmed the alarm to answer

after 2 to 15 rings. When the alarm answers the incoming call there is a short delay while Scorpion listens for a

remote computer modem. When you hear 2 short beeps, hold the STAR [*] key down for four seconds. If the

access has been successful the user hears the ‘leave now’ warning beeper indicating that the system is arming.

Hang up the phone.

ARM

EMERGENCY

NITEWATCH

UNSAFE ARMED

Answer Phone Defeat

If the alarm system phone line is shared with an answer phone or fax and it is proposed to use the ‘Remote’

arming feature, it will be necessary to advise your installer so that Scorpion may be programmed for answer

phone defeat.

To defeat the answer phone, call the alarm system phone number. When the answer phone or fax answers the

call, hang up and call again within 60 seconds. Scorpion will answer the call on the first ring thus defeating

other devices. Wait for the 2 beep acknowledge and arm the system as detailed above.

Nitewatch (if connected)

To night arm the system, simply press the ‘ARM’ key on the Nitewatch station.

To disarm the system, press the ‘ARM’ key again. Note: If an activation

occurs and the sirens are activated, the system can NOT be disarmed from the

Nitewatch station. Once activated and alarmed the system can only be

disarmed by entering a valid user code then #at the keypad.

If the ‘UNSAFE’ lamp is illuminated, this indicates an unsecured zone. This

should be secured before arming the system safely in Night mode. The

‘ARMED’ lamp illuminates when the system is armed.

Night arming from Nitewatch may be either delayed perimeter arming with pre-

alerts or instant perimeter arming with instant alarms. To arm the system in

‘delayed’ mode, press the ARM button momentarily. Nitewatch beeps once

and the ARMED led starts flashing. At the end of the programmed exit delay, Nitewatch beeps three times and

the ARMED led locks on. The control is now armed and all night arming zones will sound a pre-alert for the

programmed entry delay before activation.

To arm the system in ‘instant’ mode, press the ARM key for 2 seconds. Nitewatch beeps and the ARMED led

lights. The control is now armed and will activate instantly if any night arming zone is violated.

HOLD

DOW N 8

BEEP BEEP

2 3 4

1 # 8 1 9 7 6 5 4#

then 8 2 5 6 6 3 1 # then 5 2 9 2 0 48

If onlyonenumber is called, terminatehere withthe 'STAR' key

then then

The Nitewatch emergency panic key may be activated at any time by using two fingers to press both ends of

the EMERGENCY key simultaneously. The back light intensity of these keys may be adjusted up and down

by pressing the right side of the emergency key to increase the brightness and the left side to decrease

brightness. The Nitewatch ‘Auto Dim’ feature will automatically dim the ‘UNSAFE’ and ‘ARMED’

lamps 60 seconds after the ARM key is pressed.

Hold Down Commands

To use a ‘hold down’ command the function key (keypad digit) must be pressed and held down until a second

key-beep is heard. Note that hold down commands will only function when the alarm control is fully

disarmed. The following hold down command is available:

Follow Me Mode

The installer must enable this feature during installation. Scorpion Z4110C may be programmed by the end

user to call one or more phone numbers to report alarms. The called number(s) may be changed at will by

entering the following sequence at the keypad:

Press and hold down key 8 until a second key-beep is heard then enter a master user code then # then the

follow me telephone number(s) then * (star). Use the #key between numbers if more than one number is to

be called. Note: the ‘star’ key ends this sequence.

Example: Programming the alarm system to call 8197654 then 8256631 then 5292048

Selecting this option forces all dialler transmissions to be signalled in the ‘home warble’ format. The alarm

will call each number in turn and transmit a siren warble sound followed by a sequence of beeps and a short

pause, after which the entire sequence is repeated. The number of beeps sent correspond to the zone number

that has been activated. If the called party presses the * (Star) key for 4 seconds on the telephone keypad

during the pause, the call is terminated and no further calls are made. If the ‘Star’ key is not heard by the

dialler within 60 seconds, the call is terminated and Scorpion dials the next programmed number.

Chime Mode

Your installer must program the zones that will be active in chime mode. If this feature is programmed, each

time a chime mode sensor is activated while the system is disarmed and chime mode is turned on, the keypad

beeps for 5 seconds. This is followed by a 30 second silence period before chime mode can be repeated. In

this mode Scorpion can act as a door or area minder when the alarm system is disarmed. Chime mode is

temporarily disabled each time the alarm system is armed. To turn Chime mode on and off press 7 1 then #.

24 Hour Zones

If your installer has fitted a smoke detector(s) to your system, it will be connected to a 24 hour zone, thus

ensuring that this device is always active. In the event of an activation or detector malfunction your alarm

system will activate. Enter a valid user code at the keypad and all sirens will be silenced. If the activation or

malfunction is repeated Scorpion will count the number of activations until the ‘shutdown’ count of 4

activations has been reached and then shut down the zone, thus preventing further activations. You should

immediately contact your alarm service or installation company and report the fault. The system should NOT

be armed as this will re-set the ‘shutdown’ counter and allow further activations.

Icon LCD Keypad (if supplied)

The LCD keypad gives full visual indication of the status of your alarm. The keypad has five graphic symbols,

an area identifier and 5 zone indicators.

Indice

Altri manuali Micron Router di rete

Micron

Micron Scorpion Z4120C Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
