Heating Radiator Thermostat
MLR003RiEU61-07-1.1
LoRaWAN CLASS A EU868MHz SF7BW125
User Manual and Device Specification
The Micropelt MLR003R product series has been designed for use with heating radiators and M30x1,5
valve thread. LoRaWAN allows to control heating radiators over long distances, even inside buildings.
Significant cost savings on labor and material cost for wiring, network infrastructure, buildingstructural
changes will reduced the amortization time over conventional systems while installing the system is only
a matter of days.
For inquiries please visit us at: Customer Service Portal
1 Revision History MLR003RiEU61-07-1.1 ................................................................................................... 3
2 Use and Safety MLR003R .......................................................................................................................... 5
3 General Description MLR003R .................................................................................................................. 6
4 Operating Modes MLR003R....................................................................................................................... 8
5 Power Consumption MLR003R............................................................................................................... 10
6 Power management MLR003R ............................................................................................................... 11
6.1 Energy Harvesting................................................................................................................................... 11
6.1.1 Device power management.................................................................................................................... 11
6.1.2 Energy Storage ........................................................................................................................................ 12
7 Forced Heating MLR003R........................................................................................................................ 15
7.1 Slow Harvesting ...................................................................................................................................... 15
8 Communication Profile MLR003RiEU61-07-1.1 ..................................................................................... 16
8.1 FPORT 0x01 UPLINK: MLR003RiEU61-07-1.1 to Controller / Network Server ...................................... 17
8.2 FPORT 0x01 DOWNLINK: Controller / Network Server to MLR003RiEU61-07-1.1 ................................ 20
8.3 FPORT 0x02 REV Number, Hardware and Firmware Version MLR003R................................................ 24
8.4 FPORT 0x03 Motor operating range MLR003R....................................................................................... 25
8.5 FPORT 0x04 LoRa Spread factor MLR003R............................................................................................. 26
8.6 FPORT 0x05 Slow Harvesting SH and Valve Opening Point Detection OPD MLR003R ........................ 27
9 Operating Instructions MLR003R ........................................................................................................... 28
9.1 User Interface functionality.................................................................................................................... 28
9.2 Setting up a Gateway.............................................................................................................................. 28
9.3 Pairing the Device with a Room Controller or Gateway........................................................................ 29
9.4 Mounting Position and OFF .................................................................................................................... 29
9.5 Attaching and Activating a unit .............................................................................................................. 29
9.6 Reset (from Normal Operation only)...................................................................................................... 30
9.7 No Reset from Mounting Position .......................................................................................................... 30
9.8 Removal from the Valve.......................................................................................................................... 30
9.9 Temperature Control Loop..................................................................................................................... 30
9.10 Antifreeze................................................................................................................................................. 30
9.11 Battery Charging Flow Chart .................................................................................................................. 31
10 Performance Data MLR003RiEU61-07-1.1.............................................................................................. 32
11 Mechanical Interface to circulation valve body MLR003R .................................................................... 35
12 CE Conformity MLR003RiEU61-07-1.1.................................................................................................... 36
13 Labeling MLR003R................................................................................................................................... 37
13.1 Product Label .......................................................................................................................................... 37
13.2 NFC Tag Label.......................................................................................................................................... 38
14 Accessories MLR003 ................................................................................................................................ 39
14.1 MLR003-KEY Magnetic switch................................................................................................................. 39
Copyright Micropelt
Revision History MLR003RiEU61-07-1.1 – 3
•
•
•
•
•
•
1 Revision History MLR003RiEU61-07-1.1
Rev.-No. Description of Revision Revised
by
Date
v8e has been derived from the Micropelt technology
platform description v7e.
Changed name to MLR003.
Document describes the first release of MLR003.
Most recent changed against the general-purpose
platform description.
v8e Removed Summer mode
Added 480min RF CI in Payload
Added temperature offset for valve- and ambient-
sensor.
Added harvesting halt during radio communication.
Schmidt/
Volkert
Jan. 21, 2021
v10e Change product name to MLR003
General update on description and user guide
Volkert Jun. 21, 2021
v11e Change downlink payload
Added Label spec.
Couzens
Volkert
Jun. 22, 2021
v12e Change Activating from Mounting Position operating
flow diagram
Changed front page picture of MLR003
Couzens
Volkert
Aug. 04, 2021
Aug. 20, 2021
v13e Full document review
Update cover page, headlines, added sect. 7.2
Couzens
Volkert
Sept. 22, 2021
Sept. 23, 2021
v14e Adjust speaker beeping communication in user
interface
Added SF7BW125 to front page
Removed downlink “reserved” bytes 7 and 8
Added picture of MLR003-KEY
Couzens
Volkert
Sept. 28, 2021
Oct. 11, 2021
Copyright Micropelt
Revision History MLR003RiEU61-07-1.1 – 4
•
•
V15e Added clauses and information required by product
safety, EN60335-1:2012.
Described the position of the labels
Corrected distortion of “CE”-print on product label
Schmidt Nov. 05, 2021
V16e Added certification details
Added contact email
Corrected NFC-Tag label (16.2)
Volkert Nov 19, 2021
v17e Update from Rev1.0 to Rev1.1:
Extend Uplink payload to include User Mod and User
Value
Extend motor Reference Run travel distance
Added declaration of conformity (CE)
Couzens
Volkert
Jan. 24, 2022
Added new section 09.11 Battery Charging Flow Chart Bala Feb 16, 2022
Changed product name and article number to
MLR003RiEU61-07-1.1
Volkert Feb 23, 2022
Copyright Micropelt
Use and Safety MLR003R – 5
•
•
•
•
•
•
•
•
•
•
2 Use and Safety MLR003R
Use and safety instructions:
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or a lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the device by a person responsible for their safety.
This product is not a toy. Children shall be advised to refrain from playing with it.
The metallic part of the unit’s housing serves as a heat sink. Be sure that the air circulation around it is not
obstructed by furniture, curtains, plants, or any other object.
If the device has been stored in a cold environment, make sure that it resumes close to room temperature
before use. This is to prevent damaging due to condensation.
The thermostatic head is designed for indoor use only. Do not allow the thermostatic head to get wet. Its
sensitive electronics can be affected.
The unit is best cleaned with a dry or slightly damp cloth. Do not use aggressive cleaning agents or solvents.
Refrain from exposing the unit to environmental stress such as high mechanical forces (do not step on it),
strong vibrations, direct sunlight or extreme temperatures.
The unit must not be disassembled or modified. There are no user-serviceable parts inside.
Be aware that correct operation can be affected by strong electromagnetic fields. Typical sources of such are
mobile phones, 2-way radios, RC transmitters, microwave ovens, electric motors.
The thermostatic head has been designed and must solely be used for the purpose of controlling a M30 x 1.5
circulation valve. Any other use may pose a hazard to the device itself, to the equipment involved, or to the
health of the user.
When operating the device in a workplace environment, be sure to observe the workplace regulations that
may apply.
Intended use: The self-powered thermostatic head is suitable solely for controlling water-filled heating
radiators. Any other use – including control of floor heating systems – is not permitted and can result in
malfunctions or damage. Do not disassemble or modify any part of the product. It is important to comply
with the safety notice included in these operating instructions.
In case of questions, please contact us:
https://micropelt.atlassian.net/servicedesk/customer/portal/1
Copyright Micropelt
General Description MLR003R – 6
3 General Description MLR003R
This document defines the properties of Micropelt’s maintenance free, intelligent thermostatic head
MLR00RiEU61-07-1.1. This MLR003 is used for control of heating radiators with standard valve connection
M30x1.5 (Section 10).
MLR00RiEU61-07-1.1 is an 868MHz LoRaWAN CLASS-A wireless actuator operating in SF7BW125.
LoRaWAN end-devices of Class A allow for bidirectional communications whereby each end-device’s
uplink transmission is followed by two short downlink receive windows. The transmission slot scheduled
by the end-device is based on its own communication needs with a small variation based on a random
time basis (ALOHA-type of protocol). Class-A operation is the lowest power end-device system for
applications that only require downlink communication from the server shortly after the end-device has
sent an uplink transmission. Downlink communications from the server at any other time will have to
wait until the next scheduled uplink. SF7 is using the shortest time-on-air to maximize the number of end
nodes operating on one gateway.
Each standard production MLR00RiEU61-07-1.1 unit has a unique DEVEUI, APPEUI (JOINEUI) and a
randomly generated APPKEY. Device credentials are secret and will only be submitted with the product
To operate the device, the unit must be paired with a compatible controller or gateway unit supporting
its communication profile (Section 7). The pairing is done as described in Section 8.3. Once mounted and
activated on the valve body using the magnetic key, a calibration cycle starts to automatically adapt
itself to the individual valve. Then it is ready for use. Adapters are available for a majority of non-M30x1.5
valve bodies.
Success of activation or deactivation is signaled by tone signals and LED (Section 8.1).
The product is delivered in mounting position (off) with the valve plunger completely retracted. When
operating, the unit recognizes if it is installed on a valve body by means of internal force and travel
distance measurement. The device has built-in motor error detection "ME". The ME bit signals motor
issues during normal operation.
The actuator operates with a communication profile as further specified in Section 11. The default radio
communication cycle is 10 minutes. Installation, activation and a successful join with the network server
will immediately set the radio communication interval to every 10 seconds for an installation period of 5
minutes to provide rapid feedback. Temperature values are transmitted in both raw and corrected
temperature formats.
The actuator has a built-in, valve-side temperature sensor to determine the flow pipe temperature. A
controllable offset of +5°C has been added to compensate for the temperature drop between the hot
water and the sensor element located in the actuator’s aluminum valve adapter.. The device transmits a
variety of information to the control unit by sending an uplink (Section 7.1). The control unit responds by
sending a downlink (Section 7.2).
The integrated valve side temperature sensor is also used for freeze protection. Freeze protection is
activated at <=6°C.
The ambient sensor is used to measure the room temperature. During heating operation, the ambient
sensor is influenced by self-heating of the metallic device housing. The algorithm used to estimate the
actual ambient temperature is described in Section 12.9.
Copyright Micropelt
General Description MLR003R – 7
Unsuccessful radio communication attempts are reported by status bit RCE. After 6 consecutive
unsuccessful radio communication attempts (acknowledge from the gateway), the actuator
automatically switches to the safety mode and safety values as specified by the user. In this situation, the
radio communication period is increased to once every hour.
The actuator generates the required electrical energy for operation (motor, sensors, and radio
communication) by means of a built-in thermoelectric generator (TEG) and therefore operates
maintenance-free. It harvests energy from the temperature difference between the valve body heat and
ambient temperature (usually room temperature). An additional energy source such as a primary battery
or external power supply is not required. The internal energy storage device is charged upon delivery, so
that sufficient energy is available for installation.
