Midea AC100-18BR Manuale utente

OWNER’S MANUAL

AIR COOLER

AC100-18BR

READ AND SAVE THESE INSTRUCTIONS

Attention: Pictures in the IM are for reference only.

1. If the supply cord is damaged, it must be replaced by manufacturer,its

service agent or a similarly qualified person in order to avoid a

hazard.

This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children shall not play with the

appliance. Cleaning and user maintenance shall not be made by

children without supervision.

Unplug the appliance during filling and cleaning.

Prior to cleaning or other maintenance, the appliance must be

disconnected from the supply mains.

Correct Disposal of this product

This marking indicates that this product should not be disposed with

other household wastes throughout the EU. To prevent possible harm to

the environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was

purchased. They can take this product for environmental safe recycling.

SAFETY INSTRUCTION

Front Foot-wheel

Rear Foot-wheel

Foot-Wheel Installation

INSTALLATION INSTRUCTIONS

Name of components

Honeycomb

Filter

Universal

Wheel

Water tank

Ice Box

Water tank

cover

Control panel

Press a key on the unit to activate a corresponding function.

For instance:

● Press [ ] Key to adjust 3 speeds of air flow.

● Press [ ] Key to switch between Natural and Sleep Functions.

● Press [ ] Key：When the fan is on, press the“PRO./TIMER”

key to time the fan to shut down after 1-7 hours. In stand-by mode, you

can pre-set the fan to start in 1-7 hours.

● When [ ] Key is pressed, the indicator lights up constantly

if the operation is normal; when the indicator flashes, it denotes a water

shortage, please add water immediately.

Considerate Hint:

Push Buttons on the unit may differ based on the actual product model.

Instructions for operation of body

Considerate Hint:

When humidifying, water level in the Water Tank must remain under MAX

indication; replenish water if level gets lower than MIN indication.

Using the Ice Box

Water + Ice

Water Level

Using the Water tank

Warm tips:

1. The positive pole shall be faced upward when installing the battery.

2. The remote controller shall be in 5m in the front of the product, and

normally used in the range of deviation angle for 30 degrees.

Instructions for key of remote controller

INSTRUCTIONS FOR USE

Battery installation

WIND TYPE Key

ON/OFF Key

TIMER Key

SPEED Key

SWING Key HUMIDIFYER/

COLD WIND Key

Locking

latch

Pull Notch

CR2032

Battery, 3v

It uses one button battery of type "CR2032".

The fan requires little maintenance. Do not try to fix it by yourself.

Refer it to qualified service personnel if service is needed.

1. Before cleaning and assembling, fan must be unplugged.

2. To ensure sufficient air supply, the honeycomb filter and dust filter

shall be cleaned regularly.

3. Please wipe the exterior parts with a soft cloth soaking a mild

detergent.

4. Do not use any abrasive detergent or solvents to avoid scratching the

surface.

Do not use any of the following as a cleaner: gasoline, thinner.

5. Do not allow water or any other liquid into the motor housing or

interior parts.

1. Be sure to unplug from the electrical supply source before cleaning.

2. Plastic parts should be cleaned with a soft cloth moisten with mild

soap. Thoroughly remove soap film with dry cloth.

MAINTENANCE INSTRUCTION

CLEANING
