Midea JHDWSD7SS Manuale utente
Model : JHDWSD7SS
Please read this manual carefully
before using your dishwasher,
and keep it for future reference.
4
QUICK USER GUIDE
1Discard scraps
Scrape large food particles off and
remove any foreign objects.
2Load dishes carefully
For better washing result, place the
dishes properly avoiding any contact
or overlapping between them.
3Check spray arm
Ensure there are no items blocking
the spray arm from rotating.
Add detergent and check rinse aid
If the “ ” indicator is lit, or the
rinse aid is below the minimum
capacity line, please refill.
65 Set up the dishwasher function
Power the dishwasher on, then select
wash program and function.
Start wash or set Delay start
Close the drawer and press “ ”.
Starting A Wash
1
2
NOTE:
Reviewing the section on TROUBLESHOOTING TIPS will help you solve some
common problems by yourself.
If you cannot solve the problems by yourself, please ask for help from a
professional technician.
The manufacturer, following a policy of constant development and updating of
the product, may make modifications without giving prior notice.
If lost or out-of-date, you can receive a new user manual from the manufacturer
or responsible vendor.
After The Wash
The drying fan may continue to run for a set time after that the washing cycle is over
or until the drawer is open.
For best drying result, we recommend to unloading the dishes when they have
cooled down.
SAFETY INFORMATION
5
CONTENTS
INSTALLATION INSTRUCTION
28
28
29
30
33
Product Dimensions
Before Installation
Installing Your Dishwasher
Electrical Requirements
PRODUCT DESCRIPTION
9
Product Overview
Control Panel
9
USING YOUR DISHWASHER
Basket Use Tips
Preparing And Loading Dishes
Adding Detergent
Adding Rinse Aid
19
19
16
OPERATING THE APPLIANCE
Wash Cycle Table
Starting A Cycle Wash
Changing The Program Once Started
Adding Items While A Wash Is In Progress
21
21
22
23
MAINTENANCE AND CLEANING
External Care
Internal Care
Caring For The Dishwasher
24
24
24
27
TROUBLESHOOTING TIPS
34
Error Codes
Product Specification
10
13
13
36
37
22
SAFETY INSTRUCTIONS
WARNING
READ ALL INSTRUCTIONS BEFORE USE
This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- farm houses;
5
It is your responsibility to use caution when installing
maintaining, and operating your dishwasher.
We will not be liable for any damage resulting from
improper use.
This is the safety alert symbol. This symbol alerts you to
potential hazards that can result in property damage or
serious bodily harm, even death.
The safety alert symbol will be followed by either the
word “WARNING” or “CAUTION” then an important
safety message. These words mean:
,
Indicates the possibility of serious
bodily harm or death.
Indicates the possibility of injury or
damage to property.
WARNING
CAUTION
Basic Safety Precautions
6
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge providing they have been given supervision
or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children should not play with the appliance. Cleaning
and user maintenance should not be done by children
without supervision.(For EN60335-1)
This appliance is not intended for use by persons
(including children ) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction regarding the use of the appliance by a
person responsible for their safety. (For IEC60335-1 )
Packaging material could be dangerous for children!
This appliance is for indoor household use only.
To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
Unplug before cleaning and performing maintenance
on the appliance.
Do not put downward force on either opened drawer
prior to the dishwasher being fully installed. It will be
unstable and may tip forward.
7
Do not use the dishwasher before it is fully installed
as per the Installation Instructions. It will be
unstable and be likely to tip forward.
Do not operate the dishwasher without all the
enclosures fixed in place.
The sharp edges of knives and utensils with sharp
points should not face upwards.
Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep
children away from the dishwasher when the door
is open.
Check that the detergent receptacle is empty after
completion of the wash cycle.
The door should not be left open position since this
could present a tripping hazard.
When emptying the dishwasher, check that all the
detergent has been dissolved.
The inlet water hose supplied must be used. Do not
reuse a used or old hose.
The power cable must be safely routed. If it is ever
damaged, it must be replaced with a similar item by
a registered electrician.
An earthed 3 pin socket must be used. Consult a
registered electrician if there is doubt regarding the
earth connection.
8
Product Disposal
The packaging can be recycled.
If the product is to be disposed of, do this
responsibly at your local Council Waste
Depot.
DISPOSAL: Do not dispose this product
as unsorted municipal waste. Collection of such
waste separately for special treatment is
necessary.
PRODUCT DESCRIPTION
To get the best performance from your dishwasher, read all operating instructions
before using it for the first time.
IMPORTANT:
Product Overview
Cutlery basket Detergent chute
Spray armDrying fan
DispenserFilter assembly
Tub
Cup rack
Basket
Adjustable racks
Handle Control panel
9
Control Panel
Operation (Button)
Power1
2
Program
selector
3
Press this button to turn on your dishwasher, the screen will
light up.
Press this button to select the appropriate washing program, the
selected program indicator will light up.
Press the button to select a option, corresponding indicator ( )
will be lit.
4Option
selector
Press the button to increase the delay start time. Delay a cycle
for up to 24 hours in one-hour increments. After setting the
delay time, press the Start/Pause button to start.
5Delay start
Dry&Fresh
10
For removing bad odor and moisture even when dishes are left
longer time in the baskets.
A) when selected this option will start to run at the end of the
washing cycle, its indicator will blink.
B) Press and hold the Option button for 3s, when dishwasher is
on, for let the option run immediately.
1 2 3 4 6 5 7
8 9 1110
