OWNER’S MANUAL

Washing Machine

Read This Manual

Use all instructions and explanations of

the installation before use. Follow the

instructions carefully. Keep the operation

instructions handy for later use. If the

application is sold or passed on then ensure

that the new owner always receives those

operation instructions.

DMWM80

CONTENTS

SAFETY INSTRUCTIONS

Safety Instructions ....................................................

INSTALLATION

Product Description ..................................................

Installation area ......................................................

Unpacking the washing machine ...............................

Installation of drain hose ..........................................

Levelling the washing machine ...................................

Selection of Tap .........................................................

OPERATIONS

Preparation Before Washing.......................................

Washing ....................................................................

After Washing............................................................

Washing matters needing attention ...........................

The usage of detergent and Washing powder...............

Control Pane .............................................................

Option......................................................................

personalized setting of washing program....................

operations of washing process....................................

Washing Programmes Table ........................................

Energy efficiency test program....................................

Maintenances

Cleaning And Care .....................................................

Cleaning the inlet filter...............................................

Cleaning drain pump filter .........................................

Trouble Shooting.......................................................

Technical Information ................................................

SAFETY INSTRUCTIONS

！Warning!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

death or serious injuries unless it’s avoided.

For your safety, the information in this manual must be followed

to minimize the risk of fire or explosion, electric shock, or to

prevent property damage, personal injury or loss of life.

Explanation of the symbols:

Caution!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries or damage to property and the

environment.

Note!

This combination of symbol and signal word indicates

a potentially dangerous situation which may result in

slight or minor injuries.

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

• If the supply cord is damaged, it must be replaced by the

•

The openings must not be obstructed by a carpet.

Do not put washing machine at humid place.

This appliance is for indoor use only.

The electric shock!

Warning!

！

SAFETY INSTRUCTIONS

• Hands shall not be inserted into running spin-dry tub .

• If the spin-dry tub does not stop within 15 seconds after

opening the cover , please stop using the machine and

have it repaired.

• The new hose-sets supplied with the appliance are to be

used and that old hose-sets should not be reused.

• Before any maintenance the device, unplug the appliance

from the mains.

• Always unplug the machine and turn off the water supply

after use. The max. inlet water pressure, in pascals. The

min. inlet water pressure, in pascals.

• To ensure your safety, power plug must be inserted into

an earthed three-pole socket. Check carefully and make sure

that your socket is properly and reliably earthed.

• Make sure that the water and electrical devices must be

connected by a qualified technician in accordance with the

manufacturer's instructions and local safety regulations.

Risk to children!

from 8 years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

IEC countries: This appliance is not intended for use by

persons(including children) with reduced

•

physical,

sensory or mental capabilities or lack of experience and

knowledge unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

EN countries: the appliance can be used by children aged

SAFETY INSTRUCTIONS

• Children should be supervised to ensure that they do not

play with appliance.

• Animals and children may climb into the machine. Check

the machine before every operation.

• Young children should be supervised that they do not play

with the appliance.

• Machine may be very hot during the operation. Keep kids

and pets far away from the machine during the operation

with double

to the hot water

• Plug must be accessible after installation.

very wet rooms as well as in the rooms with explosive or

caustic gas.

•

• The washing machine with single inlet valve only can

connected to the cold water supply. The product

inlet valves should be correctly connected

and cold water supply.

Remove all packages before using the appliance. Otherwise,

serious damage may result.

Risk of explosion!

•

Do not wash or dry articles that have been cleaned in, washed

in, soaked in, or dabbed with combustible or explosive

substances( such as wax, oil, paint, gasoline, degreasers,

dry-cleaning solvents, kerosene, etc.) This may result in

fire or explosion.

Before hand thoroughly rinse items of washing by hand.

Caution

• This washing machine is for indoor use only.

Installing the product!

SAFETY INSTRUCTIONS

• It isn't intended to be built-in using.

• The openings must not be obstructed by a carpet.

• Washing machine shall not be installed in bath room or

very wet rooms as well as in the rooms with explosive

or caustic gases.

• Remove all packages and transport bolts before using

the appliance. Otherwise, serious damage may result.

• The washing machine with single inlet valve only can be

connected to the cold water supply. The product with

double inlet valves should be correctly connected to the

hot water and cold water supply.

• Plug must be accessible after installation.

Risk of damaging appliance!

• Your product is only for home use and is only designed

for the textiles suitable for machine washing.

• Do not climb up and sit on top cover of the machine.

• Do not lean against machine door.

• Cautions during Handling Machine:

1.Transport bolts shall be reinstalled to the machine by

a specialized person.

2.The accumulated water shall be drained out of the

machine.

3.Handle the machine carefully. Never hold each protruded

part on the machine while lifting. Machine door can

not be used as the handle during the conveyance.

4.This appliance is heavy. Transport with care.

• Please do not close the door with excessive forces.

• It is forbidden to wash carpets.

SAFETY INSTRUCTIONS

Operating the appliance!

• Before washing the clothes at first time, the product

shall be operated in one round of the whole procedures

without the clothes inside.

• Flammable and explosive or toxic solvents are forbidden.

Gasoline and alcohol etc.Shall not be used as detergents.

Please only select the detergents suitable for machine

washing, especially for drum.

• Make sure that all pockets are emptied. Sharp and rigid

items such as coin, brooch, nail, screw or stone etc. may

cause serious damages to this machine.

• Please check whether the water inside the drum has

been drained before opening its door.Please do not open

the door if there is any water visible.

• Be careful of burning when the product drains hot

washing water.

• Never refill the water by hand during washing.

• After the program is completed, Please wait for two

minutes to open the door.

This marking indicates that this product should not be disposed

with other household wastes throughout the EU.To prevent

possible harm to the environment or human health from

uncontrolled waste disposal,recycle it responsibly to promote

the sustainable reuse of material resources.To return your used

device,please use the collection systems or contact the retailer

where the product was purchased. They return and can take this

product for environmental safe recycling.

Packaging/Old appliance

SAFETY INSTRUCTIONS

INSTALLATION

Product Description

• The product line chart is for reference only, please refer to real product as

standard.

Note!

Frame

Top lid

Drain hose

Handle

Power case and plug

Control panel

Cabinet

Adjustable foot knob

Water inlet valve

Accessories

spring clamper drain loose ass Inlet hose ass manual screw

cabinet baseboard

• Note: if the drain hose is already installed on the machine, then there is no

spring clamper and drain hose in the accessories.

Note!

Installation area

Before installing the machine, the location characterized

follows shall be selected:

1.Rigid, dry, and level surface

2.Avoid direct sunlight

3.Sufficient ventilation

4.Room temperature is above 0 C

5.Keep far away from the heat resources such as coal or gas.

Unpacking the washing machine

1. Remove the cardboard box and styrofoam packing.

2. Lift the washing machine and remove the base packing.

3. Remove the tape securing the power supply cord and

drain hose.

4. Remove the inlet hose from the drum.

•

Stability is important to prevent the product from

wandering!

Make sure that the product should not stand on

the power cord.

Warning!

！

•

Packaging material (e.g. Films, Styrofoam) can be

dangerous for children.

There is a risk of suffocation ! Keep all packaging

well away from children.

Warning!

！

Installation of drain hose

1.Completely sleeve the drain hose over the sewer.

2.Fix and tighten it with a hoop.( As shown in the figure )

• Note: The drain hose of the machine with upper drain system has already been

assembled before leaving the factory. This picture is suitable for lower drain system.

Note!

INSTALLATION

W> 20mm

There are two ways to place the end of drain hose:

•

• Position drain hose properly ,otherwise damage might result of water leakage.

Do not kink or protract the drain hose.

• If drain hose is too long, do not force it into washing machine as it will cause

abnormal noises.

Trough

Hose

Retainer

Bind

Min.86cm

Max.100cm

Warning!

！Warning!

！

water trough

Under3m

Under 15cm

Min.86cm

100cm

Max.

1.For lower drain system

2.For upper drain system

1.Check if the legs are closely attached

the cabinet. If not, please turn them to

their original positions tighten the nuts.

2.Check alignment of the product with a

spirit level and if required, correct.

3.Loosen the lock nut and turn the feet

until it closely contacts with

the floor.

4.After being locked properly, press four

corners again to make sure that they has

been adjusted properly.

• The lock nuts on all four feet must be screwed tightly against the housing.

Levelling the washing machine

Warning!

！

Lock nut foot

Raise Lower

lockloosen

right

wrong

INSTALLATION

Indice

Altri manuali Midea Rondella

Midea

Midea 360111 Manuale utente

Midea

Midea MWMFL070CDR Manuale utente

Midea

Midea MF100W75 Manuale utente

Midea

Midea G06 Manuale utente

Midea

Midea MA200W80/G-MV Manuale utente

Midea

Midea MWMTL075ZOF Manuale utente

Midea

Midea FP-90LTT060GMTM-B Manuale utente

Midea

Midea MFES06W50/W-ES Manuale utente

Midea

Midea X8 Manuale utente

Midea

Midea KL15TTGIW Manuale utente

Midea

Midea 360215 Manuale utente

Midea

Midea MF200W100WB Series Manuale utente

Midea

Midea MF200W70B/E Manuale utente

Midea

Midea MFC80-JS1403B/C14E-AU Manuale utente

Midea

Midea MA100W70/G-MV Manuale utente

Midea

Midea MFWS512 Manuale utente

Midea

Midea MAV10-A2804PS/01FM-US Manuale utente

Midea

Midea MF700S Manuale utente

Midea

Midea MWD-40P Manuale utente

Midea

Midea MFW-850M2 Manuale utente

Midea

Midea MA500W210 Series Manuale utente

Midea

Midea MF20EW70WB Manuale utente

Midea

Midea MF200W90WB Series Manuale utente

Midea

Midea FP-90LST060GMTL-N Manuale utente

Manuali Rondella popolari di altre marche

Tricity Bendix

Tricity Bendix AW 1000 W Guida del prodotto

Panasonic

Panasonic NA-F60L5WRB Manuale utente

GE WSLP1500 Manuale

Electrolux

Electrolux EWF1284EDW Manuale utente

Bosch

Bosch WAN2829BSN Manuale utente

LG TV2516DV3B Manuale utente

LG TH2517DSAV Manuale utente

VESTEL

VESTEL CMH-XL 7510 TE Manuale utente

AEG

AEG 74335 Manuale operativo

Johnson

Johnson JWF721A Manuale utente

Beko

Beko WTE7604XLW0 Manuale utente

Danby

Danby DTT100A1WDB Istruzioni per il montaggio

Amica

Amica WA 14 Ex Manuale utente

Daewoo

Daewoo DWD-F1222 Manuale utente

Bosch

Bosch WAS28461AU Manuale utente

Miele

Miele PW 6080 Vario Manuale utente

Finlux

Finlux FLX108CF220 Manuale utente

Whirlpool

Whirlpool 3LBR5132AN0 Manuale utente
