Midea MA200W80/G-MV Manuale utente
Read This Manual
Use all instructions and explanations on delete installation
before use. Follow the instructions carefully. Keep the operation
instructions handy for later use. If the product is sold or passed
on then ensure that the new owner always receives this manual.
OWNER’S MANUAL
Fully AUTOMATIC WASHING MACHINE
MODEL:
MA200W80/G-MV
MA200W100D/S-MV
Washing Machine
Fully AUTOMATIC
1
Technical Information .............................................................................................
CONTENTS
SAFETY INSTRUCTIONS
Safety instructions ....................................................................................................
INSTALLATION
Product description ..............................................................................................
Installation area ...........................................................................................................
Unpacking the washing machine .........................................................
Levelling the washing machine .................................................................
Selection of tap ............................................................................................................
Connection of inlet hose , tap and washing machine....
Preparation before washing............................................................................
Washing ...............................................................................................................................
After washing...................................................................................................................
Washing matters needing attention ....................................................
The usage of detergent and washing powder........................
Control pane ....................................................................................................................l
Option......................................................................................................................................
Personalized setting of washing program....................................
Operations of washing process..................................................................
Washing program table .....................................................................................
MAINTENANCE
Cleaning and care ....................................................................................................
Cleaning the cabinet...............................................................................................
Cleaning drain pump filter ...............................................................................
Trouble shooting ......................................................................................................
OPERATIONS
Installation of drain hose ..................................................................................
Instructions for detergents and softeners.......................................
2
8
9
9
10
12
12
13
13
13
14
14
15
16
17
17
19
20
20
20
21
10
11
22
SAFETY INSTRUCTIONS
For your safety, the information in this manual mus t be followed
to minimize the risk of fir e or explosion, electric shock, or t o
prevent property damage, personal injury or los s of life.
SAFETY INSTRUCTIONS
• This appliance is not intended for use by persons(including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge unless they have
been given supervision or ins truction concerning use of
the appliance by a person responsible for their safety.
•
•
•
• The openings must not be obstructed by a carpet.
• This appliance is intended to be used in household and similar
applications such as:
− staff kitchen areas in shops, offic es and other working environments;
− farm houses;
− by clients in hotels, motels and other residential type environments;
− bed and breakfast type environments;
− areas for communal use in blocks of fla ts or in launderettes.
Children should be supervised t o ensure that they do not
play with the applianc e.
The new hose-sets supplied with the applianc e are to be
used and that old hose-sets should not be r eused.
If the supply cord is damaged, it mus t be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
2
SAFETY INSTRUCTIONS
3
Warning!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
death or serious injuries unles s it’s avoided.
Explanation of the s ymbols:
Caution!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries or damage t o property and the
environment.
Note!
This combination of symbol and signal word indicates
a potentially dangerous situation which may result in
slight or minor injuries.
Model Washing Capacity Standard Water Pressure
0.03MPa~0.8MPa
8.0kg
MA200W80/G-MV
MA200W100D/S-MV
10.0kg 0.03MPa~0.8MPa
4
SAFETY INSTRUCTIONS
The electric shock!
Warning!
•
•
• Hands shall not be insert ed into running spin-dry tub .
• If the spin-dry tub does not s top within 15 seconds after
opening the cover , please stop using the machine and
have it repaired.
• Before any maintenance the device, unplug the applianc e
from the mains.
• Always unplug the machine and turn off the w ater supply
after use. The max. inlet w ater pressure, in pascals. T he
min. inlet w ater pressure, in pascals.
• To ensure your safety, power plug must be inserted into
an earthed thr ee-pole socket. Check carefully and make sure
that your socket is properly and reliably earthed.
• Make sure that the water and electrical de vices must be
connected by a qualified technician in accordance with the
manufacturer's instructions and local saf ety regulations.
Do not put washing machine at humid place.
This appliance is for indoor use only.
• EN countries: the applianc e can be used by children aged
from 8 years and above and persons with r educed physical,
sensory or mental capabilities or lack of e xperience and
knowledge if they have been given supervision or
instruction concerning use of the applianc e in a safe way
and understand the hazards involved. Children shall not
play with the applianc e. Cleaning and user maint enance
shall not be made b y children without supervision.
• Animals and childr en may climb into the machine. Check
the machine before every operation.
• Young children should be supervised tha t they do not play
with the applianc e.
• Machine may be very hot during the oper ation. Keep kids
and pets far away from the machine during the oper ation
• Plug must be accessible after installation.
very wet rooms as well as in the rooms with explosive or
caustic gas.
•
• The washing machine with single inlet v alve only can be
connected to the cold water supply. The product
inlet valves should be correctly connected to the hot water
and cold water supply.
with double
Remove all packages before using the appliance. Otherwise,
serious damage ma y result.
Risk of explosion!
•
•
Do not wash or dry articles tha t have been cleaned in, washed
in, soaked in, or dabbed with c ombustible or explosive
substances( such as wax, oil, paint, gasoline , degreasers,
dry-cleaning solvents, kerosene, etc.) This may result in
fire or explosion.
Before hand thoroughly rinse items of washing by hand.
5
SAFETY INSTRUCTIONS
Risk to children!
• This washing machine is for indoor use only.
• It isn't int ended to be built-in using.
• The openings must not be obstructed by a carpet.
• Washing machine shall not be ins talled in bath room or
very wet rooms as well as in the rooms with explosive
or caustic gases.
• Remove all packages and transport bolts before using
the appliance. Otherwise, serious damage ma y result.
• The washing machine with single inlet v alve only can be
connected to the cold water supply. The product with
double inlet v alves should be correctly connected to the
hot water and cold water supply.
• Plug must be accessible after installation.
Risk of damaging appliance!
6
SAFETY INSTRUCTIONS
Caution
Installing the product!
• Your product is only for home use and is only designed
for the textiles suitable f or machine washing.
• Do not climb up and sit on t op cover of the machine.
• Do not lean agains t machine door.
• Cautions during Handling Machine:
1.Transport bolts shall be r einstalled to the machine by
a specializ ed person.
2.The accumulated water shall be drained out of the
machine.
3.Handle the machine car efully. Never hold each protruded
part on the machine while lifting. Machine door can
not be used as the handle during the c onveyance.
4.This appliance is heavy. Transport with car e.
Operating the applianc e!
• Before washing the clothes at first time, the product
shall be operated in one round of the whole pr ocedures
without the clothes inside .
• Flammable and e xplosive or toxic solvents are forbidden.
Gasoline and alcohol etc.Shall not be used as det ergents.
Please only select the det ergents suitable for machine
washing, especially f or drum.
• Make sure that all pockets are emptied. Sharp and rigid
items such as coin, brooch, nail, scr ew or stone etc. may
cause serious damages t o this machine.
• Please check whether the w ater inside the drum has
been drained before opening its door.Please do not open
the door if ther e is any water visible.
• Be careful of burning when the pr oduct drains hot
washing water.
• Never refill the water by hand during washing.
• After the program is completed, Please wait for two
minutes to open the door.
This marking indica tes that this product should not be disposed
with other household w astes throughout the EU.To prevent
possible harm to the environment or human health fr om
uncontrolled waste disposal,recycle it responsibly to promote
the sustainable reuse of material resources.To return your used
device,please use the collection systems or contact the retailer
where the product was purchased. They return and can take this
product for environmental safe recycling.
Packaging/ Old appliance
7
SAFETY INSTRUCTIONS
• Please do not close the door with e xcessive forces.
• It is forbidden to wash carpets.
INSTALLATION
Product description
• The product line chart is for reference only, please refer to real product as
standard.
Note!
8
Accessories
Inlet hose ass manual screw
cabinet baseboard
• Note: if the drain hose is already installed on the machine, then there is no
spring clamper and drain hose in the accessories.
• The accessories with” * “ are only applicable to some models.
Note!
Frame
Top lid
Drain hose
Control panel
Softener, inletDetergent
Cabinet
Adjustable foot knob
Handle
Water inlet valve
Power case and plug
spring clamperdrain loose ass
Installation area
Before installing the machine, the location characterized
follows shall be selected:
1.Rigid, dry, and level surface
2.Avoid direct sunlight
3.Sufficient ventilation
4.Room temperature is above 0 C
5.Keep far away from the heat resources such as coal or gas.
as
•
•
Stability is important to prevent the product from
wandering!
Make sure that the product should not stand on
the power cord.
Warning!
9
INSTALLATION
w
w
W> 20mm
Unpacking the washing machine
1. Remove the cardboard box and styrofoam packing.
2. Lift the washing machine and remove the base packing.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
• dangerous for children.
• well away from children.
Packaging material (e.g. Films, Styrofoam) can be
There is a risk of suffocation ! Keep all packaging
Warning!
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali Midea Rondella
Midea
Midea VCWX6 Manuale utente
Midea
Midea FP-90LST060GMTL-N Manuale utente
Midea
Midea MA200W130 Series Manuale utente
Midea
Midea MWMFL070CDR Manuale utente
Midea
Midea MJ70N68P Manuale utente
Midea
Midea MA500W150 Series Manuale utente
Midea
Midea MAV10-A2804PS/01FM-US Manuale utente
Midea
Midea MFES06W50/W-ES Manuale utente
Midea
Midea MLV47C3AWW Manuale
Midea
Midea MAH180-A2801PS/01FM-US Manuale utente
Midea
Midea MAE50-S1102GPS Manuale utente
Midea
Midea MF10EW70B Manuale utente
Midea
Midea FP-90LTL065GETM-N2 Manuale utente
Midea
Midea MWMTL075ZOF Manuale utente
Midea
Midea MF200W80WB Series Manuale utente
Midea
Midea MFC80-JS1403B/C14E-AU Manuale utente
Midea
Midea MLV41N1AWWC Manuale
Midea
Midea MSW-7118P Manuale utente
Midea
Midea MLV47C4AWW Manuale
Midea
Midea MT725B Manuale utente
