Operating instructions

for condenser tumble dryer

T 8823 C

To avoid the risk of accidents or

damage to the appliance, it is

essential to read these instructions

before it is installed and used for the

first time. M.-Nr. 07 847 190

en - AU, NZ

Disposal of the packing

material

The transport and protective packing

has been selected from materials which

are environmentally friendly for disposal

and can normally be recycled.

Ensure that any plastic wrappings,

bags, etc. are disposed of safely and

kept out of the reach of babies and

young children. Danger of suffocation.

Rather than just throwing these

materials away, please ensure they are

offered for recycling.

Disposal of your old appliance

or machine

Electrical and electronic appliances /

machines often contain materials

which, if handled or disposed of

incorrectly, could be potentially

hazardous to human health and to the

environment. They are, however,

essential for the correct functioning of

your appliance or machine. Therefore,

please do not dispose of your old

machine or appliance with your

household waste.

Please dispose of it at your local

community waste collection / recycling

centre and ensure that it presents no

danger to children while being stored

for disposal.

It should be unplugged or disconnected

from the mains electricity supply by a

competent person.

The plug must be rendered useless

and the cable cut off directly behind the

appliance or the machine to prevent

misuse.

Energy saving tips

To avoid unnecessarily long drying

times and high consumption of energy:

–Make sure that your laundry is

thoroughly spun before drying.

The higher the spin, the greater the

savings that can be made in energy

and time during drying.

– Load according to the optimum

amount of laundry recommended for

the programme being used (see

Programme chart).

Underloading is uneconomical.

Overloading gives a poorer quality of

drying and may cause unnecessary

creasing.

–Make sure the room in which the

dryer is located is well ventilated.

–Make sure the fluff filters are clean

before using the dryer.

–Check the condenser unit from time

to time and clean it when necessary.

Caring for the environment

Caring for the environment..........................................2

Warning and Safety instructions .....................................6

Operating the tumble dryer.........................................15

Control panel .....................................................15

Notes on laundry care .............................................17

Care symbols.....................................................17

Tips on drying ....................................................17

How to dry correctly ..............................................18

Brief instructions ..................................................18

Extra options/Delay start...........................................21

Extra options .....................................................21

Low temperature................................................21

Buzzer........................................................21

Delay start .......................................................21

Programme chart .................................................22

Changing the programme sequence .................................25

Once a programme has started ......................................25

- changing the programme........................................25

- cancelling the programme and then selecting a different programme .....25

- cancelling the programme and then removing the laundry ..............25

Changing Delay start ...............................................25

Adding or removing laundry after a programme has started ................25

Time remaining ...................................................25

Electronic system lock ............................................26

Contents

Cleaning and care ................................................27

Emptying the condensed water container...............................27

Cleaning the fluff filters .............................................28

Cleaning them whilst dry .........................................28

Cleaning them with water .........................................29

Cleaning the tumble dryer ...........................................29

Cleaning the condenser unit .........................................30

Removing the condenser unit......................................30

Checking the condenser unit ......................................31

Cleaning the condenser unit.......................................31

Replacing the condenser unit......................................32

Problem solving guide ............................................33

Problem solving guide ..............................................33

Check and fault messages in the display ...............................33

An unsatisfactory drying result .......................................36

Other problems ...................................................37

Changing the lamp ................................................39

After Sales service................................................40

Future updates (PC) ...............................................40

Optional accessories ...............................................40

Installation ......................................................41

Front view........................................................41

Rear view ........................................................42

Installation site ....................................................42

Transporting the machine to its installation site ........................42

Building under a continuous worktop / in a kitchen run ..................42

Levelling the machine............................................43

Room ventilation ................................................43

Washer-dryer stack..............................................43

Before moving the tumble dryer again (e.g. when moving houses).........43

External condensed water outlet ......................................44

Arranging the drain hose .........................................44

External drainage via a sink or gully ................................45

Installation conditions requiring a non-return valve .....................45

Electrical connection ...............................................47

Contents

Consumption data ................................................48

Technical data ...................................................49

Programmable functions...........................................50

Extending the range of the drying level for the "Cottons" programme..........50

Extending the drying level for the "Minimum iron" programme ...............51

Anti-crease setting.................................................52

Altering the volume of the buzzer .....................................53

Extending the drying level for the "Automatic plus" programme ..............54

Extending the cooling down time .....................................55

Standby .........................................................56

Memory function ..................................................58

Clean out airways indicator ..........................................59

Keypad tone .....................................................60

Adjusting the dryer's electronics for very soft water .......................61

Extending the drying level range......................................62

Contents

~It is essential to read these instructions.

This tumble dryer conforms to current safety requirements.

Inappropriate use can, however, lead to personal injury and

damage to property.

To avoid the risk of accidents and damage to the tumble dryer,

please read these instructions carefully before using it for the first

time. They contain important information on its safety, installation,

use and maintenance.

Keep these instructions in a safe place and ensure that new users

are familiar with the content. Pass them on to any future owner.

Correct application

~This tumble dryer is designed for domestic use and for use in

similar environments by guests in hotel or motel rooms, bed &

breakfasts and other typical living quarters. This does not include

common/shared facilities or commercial facilities within hotels,

motels or bed & breakfasts.

~This tumble dryer must only be used to dry items which have

been washed in a water solution and which are marked on the

manufacturer's care label as being suitable for tumble drying. "Dry

cleaning kits" for freshening up garments in a tumble dryer are

increasingly available on the market. If using, do so at your own risk,

and follow the instructions provided on the packaging.

Any other usage is not supported by the manufacturer and could be

dangerous. Miele cannot be held liable for damage resulting from

incorrect or improper use or operation of the tumble dryer.

Warning and Safety instructions

~The tumble dryer is not intended for outdoor use.

~This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience or knowledge, unless they are supervised whilst

using it or have been shown how to use it correctly by a person

responsible for their safety.

~This tumble dryer must not be installed and operated in mobile

installations (e.g. on a ship).

Safety with children

~Keep children away from the tumble dryer at all times. It is not a

toy! To avoid the risk of injury do not allow them to play on or near it

or to play with its controls. Supervise children whilst you are using it.

~Older children may only use it if its operation has been clearly

explained to them, and they are able to use it safely, recognising the

dangers of incorrect use.

Warning and Safety instructions

Technical safety

~Before setting up the tumble dryer, check it for any externally

visible damage.

Do not install or use a damaged tumble dryer.

~Before connecting the tumble dryer, ensure that the connection

data on the data plate (voltage and connected load) match the

mains electricity supply. If in any doubt, consult a qualified

electrician.

~The electrical safety of this tumble dryer can only be guaranteed

when continuity is complete between it and an effective earthing

system which complies with current local and national safety

regulations. It is most important that this basic safety requirement is

present and regularly tested, and where there is any doubt, the

household wiring system should be inspected by a qualified

electrician. Miele cannot be held liable for the consequences of an

inadequate earthing system (e.g. electric shock).

~Do not connect the tumble dryer to the mains electricity supply by

an extension lead. Extension leads do not guarantee the required

safety of the tumble dryer (e.g. danger of overheating).

~Unauthorised repairs could result in unforeseen dangers for the

user, for which Miele cannot accept liability. Repairs should only be

undertaken by a Miele approved service technician. Ensure current

is not supplied to the tumble dryer until after maintenance or repair

work has been carried out.

~Faulty components must only be replaced by genuine Miele

original spare parts. Only when these parts are fitted can the safety

standards of the tumble dryer be guaranteed.

Warning and Safety instructions

~If the connection cable is faulty, it must only be replaced by a

Miele approved service technician to protect the user from danger.

~In the event of a fault or for cleaning purposes, the tumble dryer

is only completely isolated from the electricity supply when:

–it is switched off at the wall socket and the plug is withdrawn, or

–it is switched off at the mains, or

–the mains fuse is disconnected, or the screw-out fuse is removed

(in countries where this is applicable).

~In areas which may be subject to infestation by cockroaches or

other vermin, pay particular attention to keeping the tumble dryer

and its surroundings in a clean condition at all times. Any damage

which may be caused by cockroaches or other vermin will not be

covered by the warranty.

~Do not make any alterations to the tumble dryer, unless

authorised to do so by Miele.

Warning and Safety instructions

Correct use

,Caution! Risk of fire.

To avoid the possible danger of fire, please

read these warnings carefully.

,A clogged filter is a fire hazard!

The fluff filter must be cleaned after every programme.

~Remove all objects from pockets such as lighters and matches.

~To prevent the risk of fire, the following textiles must not be dried

in this tumble dryer:

– Items which have not been washed.

– Items, such as workwear, which have not been thoroughly

cleaned and which are still soiled with grease, oil or other

desposits (such as cosmetics, lotions etc).

If items have not been thoroughly cleaned, there is a danger that

these might ignite when heated, even after they have been

removed from the dryer at the end of the programme.

–Items that have been soiled with substances such as cooking oil,

acetone, petrol, kerosene, spot removers, turpentine, waxes, wax

removers and other chemicals (e.g. mops and floor cloths) should

be washed in hot water with extra detergent before being dried in

the tumble dryer.

–Items which have been splashed with hair lacquer, hair spray, nail

polish remover or similar substances.

Warning and Safety instructions

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Miele Asciugatrice

Miele

Miele PT 7186 Vario Manuale utente

Miele

Miele T 4804 C Allerdry Manuale utente

Miele

Miele T 1576 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele 11 588 800 Manuale utente

Miele

Miele TWV 680 WP Manuale utente

Miele

Miele T 7644 C Manuale utente

Miele

Miele T 1526 Manuale utente

Miele

Miele PDR 507 HP Marine Manuale utente

Miele

Miele TWL 780 WP Manuale utente

Miele

Miele PT 8301 SL Manuale utente

Miele

Miele PDR 514 Manuale utente

Miele

Miele T 494 C Manuale utente

Miele

Miele T 7944 C Manuale utente

Miele

Miele T 1036 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele TOUCHTRONIC T 9822 Manuale utente

Miele

Miele PDR 510 EL Manuale utente

Miele

Miele T300 Manuale

Miele

Miele PDR 511 HP Manuale utente

Miele

Miele NOVOTRONIC T 7644 C Manuale utente

Miele

Miele PT 5136 OS Scheda tecnica

Miele

Miele Eco&Steam&9kg TCR 780 WP Manuale utente

Miele

Miele PT 8507 Manuale utente

Miele

Miele Touchtronic T 1403 Manuale utente

Miele

Miele PT 8407 EL Manuale utente

Manuali Asciugatrice popolari di altre marche

Bosch

Bosch WTA79200GB Manuale utente

Amana

Amana W10233410A Manuale utente

Asko

Asko T760 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuale utente

Bosch

Bosch Logixx 10 WTB76556GB Scheda tecnica

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manuale di istruzioni

Electrolux

Electrolux EW2H328R2 Manuale utente

Beko

Beko DS8433RX1M Manuale utente

Dawlance

Dawlance Spinner DS 6000 C Manuale utente

Electrolux

Electrolux TP5080TW Manuale utente

AEG

AEG TR838P4OB Manuale utente

Indesit

Indesit IDV 75 Manuale utente

Infiniton

Infiniton SD-DG85C Manuale utente

BOMANN

BOMANN WT 5019 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuale utente

Asko

Asko T793C Manuale utente

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente

Frigidaire

Frigidaire CAQE7077KW0 Manuale del proprietario
