Assembly and instruction manual

Series:

Invisible & Glass

WiFi panel heater

Please read the instructions carefully before use.

Take good care of this manual for later use.

Scandinavian home comfort

Mill is a Norwegian brand that develops heating and indoor

air quality products tailored for your modern home. Inspired

by Scandinavian nature, our products are designed to sustain

the toughest of climates to ensure safe, efﬁcient and com-

fortable temperatures, as well as good air quality.

Mill products are praised for their minimalistic and elegant

features as they blend in naturally with any modern interior.

Our advanced and user-friendly technology will support a

relaxing and healthy home space with reliable temperatures

and air quality. Mill’s vision is to develop products that create

an enjoyable and harmonic household atmosphere, enhanc-

ing both comfort and style; the ultimate Scandinavian home

comfort.

We hope you enjoy your Mill product.

ErP energy efﬁciency data

Our products strictly comply with ErP relevant regulation and

directive.

You can ﬁnd energy efﬁciency data for each model on the

ﬁnal pages of this booklet.

fb.com/millnorway

@millnorway

millnorway.com

Content

23

56

67

89

1011

Important safety information

Speciﬁcations

Before ﬁrst use

First use

Minimum distances

Description of heater

Assembly

Power indicator

Temperature calibration

Resetting the heater

Memory function

“Open Window” function

Instructions

Usage without WiFi connection

Child lock

Commercial lock

Usage with WiFi connection

Color codes (WiFi control light)

Activating WiFi

Delete WiFi settings

Maintenance

Warranty

Waste disposal

STORE THIS INSTRUCTION MAN-

UAL FOR FUTURE USE!

NEVER TOUCH YOUR HEATER OR

ITS CASING WITH WET HANDS!

IN ORDER TO AVOID OVERHEATING,

DO NOT COVER THE HEATER

2millnorway.com

Important safety information

You must obey common safety guidelines when using

electrical products, especially in the presence of children.

WARNING! To avoid electric shock or damage due

to the heat, always make sure the plug is pulled out

before the heater is moved or cleaned.

READ THE INSTRUCTIONS CAREFULLY

• The product is intended for home use only.

• Make sure the heater is connected to the house’s regular

mains as indicated on the heater.

• New heaters will produce a speciﬁc odor when used the ﬁrst time.

This will stop after a short time and is completely harmless.

• Check for any pieces of packing foam or cardboard that may

have fallen into the heating elements of the heater. These piec-

es must be removed to avoid unpleasant odors.

• Prevent the heater from overheating - do not cover.

• Always turn off the heater and unplug it when not used for a

long period of time.

• Pay special attention if the heater is used in rooms where chil-

dren, the handicapped or elderly reside.

• The heater should not be set up directly beneath an electrical

socket outlet.

• The cord must not be laid under any kind of carpet. Make sure

the cord is laid in such a way that nobody can trip on it.

• The heater must not be used if either the cord or plug is dam-

aged. The heater must not be used if it has been dropped on

the ﬂoor is damaged in any other way causing it to malfunction.

• The cord must be repaired by the manufacturer or by an expert

if it has been damaged, to avoid dangerous situations.

• Avoid using extension cords, which may overheat and could

possibly start a ﬁre.

• Never cover the air vents on the heater. Avoid potential ﬁre

hazards by making sure the air intakes are not blocked or

covered. The heater should be used in rooms with normal ﬂat

ﬂoors.

• The heater should not be installed in close proximity to ﬂammable

materials of any kind because there can always be a risk of ﬁre.

• The heater must never be used in rooms where gasoline, paint

or other ﬂammable liquids are stored, such as in a garage.

• Never touch an electric heater with wet hands. The heater

should be installed so a person showering or taking a bath can-

not come into direct contact with it.

• Some parts of this product can become very hot and cause

burns. Particular attention has to be given where children and

vulnerable people are present.

• The heater must be switched off, the plug removed and the

heater must cool down before it is moved.

• Avoid overloading the mains (the circuit) where the heater

is connected. The heater may overload the electrical circuit

if other electrical devices are plugged into the same socket

outlet.

• Do not use this heater in small rooms when they are occupied

by persons not capable to leaving the room on their own, un-

less constant supervision is provided.

• The product cannot be used by children under 8 years of age

and persons with reduced physical or mental abilities or lack

of experience and knowledge unless they have been given

supervision or instruction in the safe use of the product and

understand the hazards involved.

• Children should not play with the product. Cleaning an mainte-

nance should not be done by unsupervised children.

• Children under the age of 3 should be kept away from the

product, unless they are under constant supervision.

• Children aged 3 to 8 years are only permitted to turn the prod-

uct ON/OFF, assuming the heater is mounted according to the

assembly instructions and the children have received instruc-

tion or supervision in the safe use of the product and under-

stand the hazards involved.

• Do not use this heater in the immediate surroundings of a bath,

a shower or a swimming pool.

• Do not use if there are visible signs of damage to the heater.

• WARNING: To reduce the risk of ﬁre, keep textiles, curtains, or

any other ﬂammable material a minimum distance of 1 m from

the air outlet.

WARNING! The heater must not be used if the glass panels

are damaged (this applies to the products with model names

starting with GL).

4millnorway.com

Speciﬁcation

Model Thermostat Color Height Width Amperage Power

(W) IP WiFi

PA400WIFI3 WiFi White 38,4 cm 49,2 cm 220240V~, 5060Hz 400 IPx4 802.11b/g/n

GL500LWIFI3M WiFi White 25,0 cm 80,0 cm 220240V~, 5060Hz 500 IPx4 802.11b/g/n

PA500LWIFI3M WiFi White 25,0 cm 78,0 cm 220240V~, 5060Hz 500 IPx4 802.11b/g/n

GL400WIFI3 WiFi White 38,4 cm 50,7 cm 220240V~, 5060Hz 400 IPx4 802.11b/g/n

PA600WIFI3 WiFi White 40,0 cm 65,0 cm 220240V~, 5060Hz 600 IPx4 802.11b/g/n

PA600WIFI3B WiFi Black 40,0 cm 65,0 cm 220240V~, 5060Hz 600 IPx4 802.11b/g/n

GL600WIFI3 WiFi White 40,0 cm 66,5 cm 220240V~, 5060Hz 600 IPx4 802.11b/g/n

GL600WIFI3B WiFi Black 40,0 cm 66,5 cm 220240V~, 5060Hz 600 IPx4 802.11b/g/n

PA800LWIFI3 WiFi White 25,0 cm 105,0 cm 220240V~, 5060Hz 800 IPx4 802.11b/g/n

GL800LWIFI3 WiFi White 25,0 cm 106,5 cm 220240V~, 5060Hz 800 IPx4 802.11b/g/n

PA900WIFI3MP WiFi White 40,0 cm 85,0 cm 220240V~, 5060Hz 900 IPx4 802.11b/g/n

GL900WIFI3MP WiFi White 40,0 cm 86,5 cm 220240V~, 5060Hz 900 IPx4 802.11b/g/n

PA1000LWIFI3 WiFi White 25,0 cm 121,5 cm 220240V~, 5060Hz 1000 IPx4 802.11b/g/n

PA1000LWIFI3B WiFi Black 25,0 cm 121,5 cm 220240V~, 5060Hz 1000 IPx4 802.11b/g/n

GL1000LWIFI3 WiFi White 25,0 cm 123,0 cm 220240V~, 5060Hz 1000 IPx4 802.11b/g/n

GL1000LWIFI3B WiFi Black 25,0 cm 123,0 cm 220240V~, 5060Hz 1000 IPx4 802.11b/g/n

PA1200WIFI3 WiFi White 40,0 cm 105,0 cm 220240V~, 5060Hz 1200 IPx4 802.11b/g/n

PA1200WIFI3B WiFi Black 40,0 cm 105,0 cm 220240V~, 5060Hz 1200 IPx4 802.11b/g/n

GL1200WIFI3 WiFi White 40,0 cm 106,5 cm 220240V~, 5060Hz 1200 IPx4 802.11b/g/n

GL1200WIFI3B WiFi Black 40,0 cm 106,5 cm 220240V~, 5060Hz 1200 IPx4 802.11b/g/n

PA1500WIFI3 WiFi White 40,0 cm 85,0 cm 220240V~, 5060Hz 1500 IPx4 802.11b/g/n

PA2000WIFI3 WiFi White 40,0 cm 105,0 cm 220240V~, 5060Hz 2000 IPx4 802.11b/g/n

Maximum transmitting power: ≤20dBm

Frequency range: 24002483.5MHz

The heaters are approved for use in zone 2 in wet rooms (IPx4 approved)

ATTENTION! The heaters will be connected directly to your WiFi router and it is

therefore important to make sure the router has sufﬁcient capacity for the number

of active devices connected at the same time.

Before ﬁrst use

After unpacking the heater, check to make sure the product was not damaged during trans-

port. Contact the retailer or importer if you discover any visible damages to the product.

Keep the outer packaging to transport the heater in the future. If you want to dispose the

packaging, make sure it is done properly. Keep plastic bags away from children.

First use

After turning on the heater for the ﬁrst time or after an extended period without use, the heater

can produce a burnt odor for a short time. This is normal.

Please read all the instructions carefully before use. Save the instruction manual for future use.

It is also normal for the heater to make “sounds” when it warms up or cools down.

Minimum Distances

Description of heater

See ﬁgure 1 on separate illustration sheet

MILL INVISIBLE

1. On/Off

2. Wall bracket

3. Temperature sensor

4. Heat emission

5. Thermostat

6. Steel front

MILL GLASS

1. On/Off

2. Wall bracket

3. Temperature sensor

4. Heat emission

5. Thermostat

6. Glass front

Assembly

See ﬁgure 2 on separate illustration sheet

A. Drill holes in the wall for holes 1 & 2. Then drill holes in the wall for the topmost holes

(holes 3 & 4 by using 6)

B. Insert the wall plugs into the drilled holes and attach the bracket with 4 screws

C. Place the heater on the lower lugs on the bracket, then hang the heater on the upper

lugs (lift the heater slightly to align the heater with for the upper lugs). Screw in the

locking screws on the top of the bracket (clockwise)

Attention! Horizontal placement only

Power indicator

See ﬁgure 3 on separate illustration sheet

If the heater uses power (for example, when it heats up), the power indicator is on

Temperature calibration

See ﬁgure 4 on separate illustration sheet

It may occur deviation between the temperature registered by the heater and the

actual temperature in the room. This can be caused by several reasons, however, the most

common is that the heater is placed in a fair distance from where you usually reside. When

you set the temperature to for example 22 degrees, it is only natural that you expect the

same temperature where your sofa is placed for instance. However,

the temperature sensor is placed on the product itself, and therefore a deviation in tem-

perature may occur. To adjust this, all Mill heaters are equipped with a calibration function,

which enables you to adjust the temperature registered by the heater. N.B! The room must

have achieved a stable temperature before any calibration.

6millnorway.com

Press and hold ○for 5 seconds and use + or – to set the actual temperature ob-

served in the room. Conﬁrm with ○ or wait 5 seconds for automatic conﬁrmation.

For models PA500LWIFI3M, GL500LWIFI3M, PA900WIFI3MP, GL900WIFI3MP

please follow the steps below to activate temperature calibration:

Press ○to enter menu and use + and - button to navigate the menu until you see “CAL” in

the display. Press ○to enter calibration mode. The registered room temperature will blink

on the display. Use + or - button to set the actual temperature observed in the room. Con-

ﬁrm with ○or wait 10 seconds for automatic conﬁrmation.

Resetting the heater

See ﬁgure 5 on separate illustration sheet

Turn off the heater s main switch. Turn the heater back on, within 5 seconds press and

hold ○. After 20 seconds the display will show “Fr”, once you see “Fr” release ○and the

heater will reset to factory settings.

For models PA500LWIFI3M, GL500LWIFI3M, PA900WIFI3MP, GL900WIFI3MP

please follow the steps below to reset the heater:

Press ○to enter menu. Use + and - button to navigate the menu until you see “Hr” in the display.

Press ○to enter reset mode. Press + or - button to choose between “YES” or “NO”. Select

option by pressing ○. After selecting “YES”, the “YES” label blinks twice and heater restarts. For

a few seconds, the whole display is off, before the heater starts normal operation.

Memory function

The heater remembers all the temperature settings and will automatically return to the de-

sired temperature after a power failure. If your heater is connected to WiFi it will automati-

cally reconnect with WiFi (where all temperatures are saved) after a power cut.

“Open Window“ function

The heater has an “open window” function that is activated instantly when it registers a

sudden drop in temperature with more than 5 degrees Celsius in 15 minutes. The heater

will automatically stop heating and FO will be visible in the display of the heater.

While in open window mode, it will maintain 5°C (to avoid frost damage).

The heater will automatically start heating again if temperature increase by at least 3

degrees within 15 minutes.

You can switch the heater back to normal mode by pressing the settings button 1 time.

Open window function can be disabled/enabled by pressing and holding the settings

button for 3 seconds. You can also disable/enable open windows function from the app if

conﬁgured to WiFi.

The heater will stay in open window mode for maximum 1 hour, it then will go back to

normal heating mode.

For models PA500LWIFI3M, GL500LWIFI3M, PA900WIFI3MP, GL900WIFI3MP

please follow the steps below to enable/disable open window function:

Press ○to enter menu. Use + and - button to navigate the menu until you see “Fo” in

the display. Press ○to enter open window function mode. Press + or - button to choose

between “On” or “Off”. Select option by pressing ○. This will enable or disable the open

window function. You can also disable/enable open window function from the app if con-

nected to WiFi.

Instructions

TIPS! The thermostat can be used as a regular electronic thermostat (i.e. the heater will

maintain a constant temperature 24 hours a day). Please see the section explaining usage

without WiFi connection for further information

Control Panel

See ﬁgure 6 on separate illustration sheet

1. Display (shows the desired room temperature by default)

2. WiFi indicator

3. Power indicator — Shows whether the heater is using power or not 4. Control button (+)

(increase temperature)

5. Control button (–) (reduce temperature)

6. WiFi button

7. Settings button

8. LED lights indicating how much power the heater is using

9. ON/OFF indicator

ATTENTION! In the event of a power cut, the thermostat will reconnect with WiFi where all

the temperatures are saved.

WARNING! BEFORE THE HEATER IS TURNED ON, IT MUST BE ATTACHED TO A WALL.

IF THE HEATER IS NOT INSTALLED CORRECTLY OR IS INSTALLED ASKEW, THIS MAY

CAUSE THE HEATER TO MALFUNCTION OR IN THE WORST CASE, BE DAMAGED.

Usage without WiFi connection

Set desired temperature without WiFi connection

See ﬁgure 7 on separate illustration sheet

Press the arrow buttons to set the desired temperature. The heater keeps an even temper-

ature the whole day and night.

8millnorway.com

Child lock

You can enable/disable child lock from the app. But in addition, you can also enable/disa-

ble child lock from the heater itself. Turn off the heater using the main power switch. Turn

the heater back on, within 5 seconds press the and hold ○. After 3 seconds the display

will show “CHL”, once you see “CHL” release ○and the heater enables/disables child

lock.

For models PA500LWIFI3M, GL500LWIFI3M, PA900WIFI3MP, GL900WIFI3MP

please follow the steps below to activate child lock:

Press ○to enter menu. Use + and - button to navigate the menu until you see “ChL” in

the display. Press ○to enable “Child Lock”. “ChL” will blink on the display twice and “Child

Lock” is activated. To unlock, quickly press ○5 times. “NoL” will appear on the display

and “Child Lock” will be disabled.

Commercial Lock

You can enable and disable commercial lock from inside the app. But in addition, you can

enable/disable commercial lock from the heater itself. Turn off the heater using the main

power switch. Turn the heater back on, within 5 seconds press the and hold ○. After

10 seconds the display will show “COL”, once you see “COL” release ○and the heater

enables/disables commercial lock.

For models PA500LWIFI3M, GL500LWIFI3M, PA900WIFI3MP, GL900WIFI3MP you

can only enable “Commercial Lock” from inside the app once the device is connect-

ed. Please follow in-app instructions to enable/disable “Commercial Lock”.

Usage with WiFi connection

A free app is available for downloading for iOS and Android.

By connecting your heaters with the iOS/Android device you can do the following:

• Control all your heaters situated in multiple locations. Everything is controlled with the

Mill-app (with same user)

• Set up weekly programs (or use the standard program already available in the app) by

using the 4 modes: Comfort, Sleep, Away and OFF

• Set individual temperature for different modes in each room

• Override the set programs for the whole house, a speciﬁc room or a speciﬁc heater.

There is no need to edit your program if you get home earlier than normal one day

Enable vacation mode for saving energy while you are away. The app will automatical-

ly increase the temperature in your house before you get back home

• Share your house with other family members, making control easy

• If internet is down the heater will follow its weekly program which is stored on the

heater. One can easily turn off the WiFi on the heaters and control them manually, so

that the heaters keep an even temperature throughout the whole day and night.

• + many other things

Altri manuali per PA400WIFI3

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali MILL Riscaldatore elettrico

MILL

MILL Steel & Glass WiFi Series Guida utente

MILL

MILL PA400WIFI3 Guida utente

MILL

MILL Steel & Glass WiFi Series Manuale utente

MILL

MILL Gentle Air Series Guida utente

Manuali Riscaldatore elettrico popolari di altre marche

Heatscope

Heatscope PURE Guida rapida

Sunbeam

Sunbeam Calentador SFH457A Manuale utente

Dura Heat

Dura Heat DH2000C Manuale utente

Harvia

Harvia K10.5GS Manuale utente

Harvia

Harvia GL70 Manuale utente

Heylo

Heylo DE 2 XL Manuale utente

Heylo

Heylo DE 20 SH Manuale utente

Harvia

Harvia PP70SP Manuale utente

Tylo

Tylo SENSE SPORT Manuale utente

Dirna

Dirna ecodirna SUN Manuale di istruzioni

Creda

Creda Heating Solution Manuale utente

THERMEx

THERMEx Frame E Wi-Fi Series Manuale utente

SHUFT

SHUFT UniMAX-R 1400VE EC Manuale utente

HUUM

HUUM CLIFF Series Manuale utente

Harvia

Harvia HL70S Manuale utente

Dimplex

Dimplex DHEBHT Manuale utente

Radialight

Radialight SIRIO Manuale utente

Polaris

Polaris PRE E 0715 H Manuale utente
