Assembly and instruction manual

Series:

Invisible &

Glass panel

heater

Please read the instructions carefully before use.

Take good care of this manual for later use.

Scandinavian

home comfort

Mill is a Norwegian brand that develops heating and indoor

air quality products tailored for your modern home. Inspired

by Scandinavian nature, our products are designed to sustain

the toughest of climates to ensure safe, efﬁcient and com-

fortable temperatures, as well as good air quality.

Mill products are praised for their minimalistic and elegant

features as they blend in naturally with any modern interior.

Our advanced and user-friendly technology will support a

relaxing and healthy home space with reliable temperatures

and air quality. Mill’s vision is to develop products that create

an enjoyable and harmonic household atmosphere, enhan-

cing both comfort and style; the ultimate Scandinavian home

comfort.

We hope you enjoy your Mill product.

fb.com/millnorway

@millnorway

millnorway.com

Content

24

Important safety information

Speciﬁcations

Before ﬁrst use

First use

Minimum distances

Description of heater

Assembly

Temperature calibration

Resetting the heater

Memory function

“Open window” function

Instructions electronic thermostat

Power indicator for electronic thermostat

Set desired temperature for electronic thermostat

Instructions day/night thermostat

Power indicator day/night thermostat

Set desired temperature for day/night thermostat

Day- and nighttime setback

How to activate daytime setback

How to activate nighttime setback

Change setback temperature — daytime

Change setback temperature — nighttime

Change number of hours — daytime

Change number of hours — nighttime

Cancel (skip) setback period

Delete setback program

Maintenance

Warranty

Waste disposal

Please read the instructions carefully before use.

Take good care of this manual for later use.

STORE THIS INSTRUCTION MANUAL

FOR FUTURE USE!

NEVER TOUCH YOUR HEATER OR ITS

CASING WITH WET HANDS!

IN ORDER TO AVOID OVERHEATING,

DO NOT COVER THE HEATER.

2millnorway.com

Important safety information

You must obey common safety guidelines when using

electrical products, especially in the presence of chil-

dren.

WARNING! To avoid electric shock or damage due

to the heat, always make sure the plug is pulled out

before the heater is moved or cleaned.

READ THE INSTRUCTIONS CAREFULLY

• The product is intended for home use only.

• Make sure the heater is connected to the house’s regular

mains as indicated on the heater.

• New heaters will produce a speciﬁc odor when used the

ﬁrst time. This will stop after a short time and is completely

harmless.

• Check for any pieces of packing foam or cardboard that

may have fallen into the heating elements of the heater.

These pieces must be removed to avoid unpleasant odors.

• Prevent the heater from overheating -do not cover.

• Always turn off the heater and unplug it when not used for a

long period of time.

• Pay special attention if the heater is used in rooms where

children, the handicapped or elderly reside.

• The heater should not be set up directly beneath an electri-

cal socket outlet.

• The cord must not be laid under any kind of carpet. Make

sure the cord is laid in such a way that nobody can trip on it.

• The heater must not be used if either the cord or plug

is damaged. The heater must not be used if it has been

dropped on the ﬂoor is damaged in any other way causing

it to malfunction.

• The cord must be repaired by the manufacturer or by an ex-

pert if it has been damaged, to avoid dangerous situations.

• Avoid using extension cords, which may overheat and

could possibly start a ﬁre.

• Never cover the air vents on the heater. Avoid potential ﬁre

hazards by making sure the air intakes are not blocked or

covered. The heater should be used in rooms with normal

ﬂat ﬂoors.

• The heater should not be installed in close proximity to

ﬂammable materials of any kind because there can always

be a risk of ﬁre. The heater must never be used in rooms

where gasoline, paint or other ﬂammable liquids are stored,

such as in a garage.

• Never touch an electric heater with wet hands. The heater

should be installed so a person showering or taking a bath

cannot come into direct contact with it.

• Some parts of this product can become very hot and cause

burns. Particular attention has to be given where children

and vulnerable people are present.

• The heater must be switched off, the plug removed and the

heater must cool down before it is moved.

• Avoid overloading the mains (the circuit) where the heater

is connected. The heater may overload the electrical circuit

if other electrical devices are plugged into the same socket

outlet.

• Do not use this heater in small rooms when they are occu-

pied by persons not capable to leaving the room on their

own, unless constant supervision is provided.

4millnorway.com

• The product cannot be used by children under 8 years of

age and persons with reduced physical or mental abilities

or lack of experience and knowledge unless they have

been given supervision or instruction in the safe use of the

product and understand the hazards involved.

• Children should not play with the product. Cleaning and

maintenance should not be done by unsupervised children.

• Children under the age of 3 should be kept away from the

product, unless they are under constant supervision.

• Children aged 3 to 8 years are only permitted to turn the

product ON/OFF, assuming the heater is mounted accord-

ing to the assembly instructions and the children have

received instruction or supervision in the safe use of the

product and understand the hazards involved.

• Do not use this heater in the immediate surroundings of a

bath, a shower or a swimming pool.

WARNING! The heater must not be used if the glass panels

are damaged (this applies to the products with model names

starting with MB).

Speciﬁcations

Model Thermostat Color Height Width Amperage Power (W) IP rating

IB250 Electronic White 30.0 cm 35.0 cm 220240V~, 5060Hz 250 IPx4

IB600DN Day/Night White 40.0 cm 65.0 cm 220240V~, 5060Hz 600 IPx4

IB900DN Day/Night White 40.0 cm 85.0 cm 220240V~, 5060Hz 900 IPx4

IB1200DN Day/Night White 40.0 cm 105.0 cm 220240V~, 5060Hz 1200 IPx4

IB800L DN Day/Night White 25.0 cm 105.0 cm 220240V~, 5060Hz 800 IPx4

IB1000L DN Day/Night White 25.0 cm 121.5 cm 220240V~, 5060Hz 1000 IPx4

MB250 Electronic White 30.0 cm 36.5 cm 220240V~, 5060Hz 250 IPx4

MB600DN Day/Night White 40.0 cm 66.5 cm 220240V~, 5060Hz 600 IPx4

MB900DN Day/Night White 40.0 cm 86.5 cm 220240V~, 5060Hz 900 IPx4

MB1200DN Day/Night White 40.0 cm 106.5 cm 220240V~, 5060Hz 1200 IPx4

MB800L DN Day/Night White 25.0 cm 106.5 cm 220240V~, 5060Hz 800 IPx4

MB1000L DN Den /noc White 25.0 cm 123.0 cm 220240V~, 5060Hz 1000 IPx4

The heater is approved for use in bathrooms zone 2 {IPX4 approved)

Before ﬁrst use

After unpacking the heater, check to make sure the product was not damaged during

transport. Contact the retailer or importer if you discover any visible damages to the

product.

Keep the outer packaging to transport the heater in the future. If you want to dispose the

packaging, make sure it is done properly. Keep plastic bags away from children.

First use

After turning on the heater for the ﬁrst time or after an extende the heater can produce a

burnt odor for a short time. This is normal. Please read all the instructions carefully before

use. Save the instruction manual for future use.

It is also normal for the heater to make “sounds” when it warms up or cools down.

Minimum distances

100 mm

50 mm50 mm

100 mm

100 mm in front

of heater

Description of heater

See ﬁgure 1 on separate illustration sheet

MILL INVISIBLE

1. On/Off

2. Wall bracket

3. Temperature sensor

4. Heat emission

5. Thermostat

6. Steel front

MILL GLASS

1. On/Off

2. Wall bracket

3. Temperature sensor

4. Heat emission

5. Thermostat

6. Glass front

6millnorway.com

Assembly

See ﬁgure 2 on separate illustration sheet

A. Drill holes in the wall for holes 1 & 2. Then drill holes in the wall for the topmost holes

(holes 3 & 4 by using 6).

B. Insert the wall plugs into the drilled holes and attach the bracket with 4 screws.

C. Place the heater on the lower lugs on the bracket, then hang the heater on the

upper lugs (lift the heater slightly to align the heater with for the upper lugs). Screw in

the locking screws on the top of the bracket (clockwise).

ATTENTION! HORIZONTAL PLACEMENT ONLY

Temperature calibration

See ﬁgure 3 on separate illustration sheet

It may occur deviation between the temperature registered by the heater and the actual

temperature in the room. This can be caused by several reasons, however, the most com-

mon is that the heater is placed in a fair distance from where you usually reside. When you

set the temperature to for example 22 degrees, it is only natural that you expect the same

temperature where your sofa is placed for instance. However, the temperature sensor is

placed on the product itself, and therefore a deviation in temperature may occur. To adjust

this, all Mill heaters are equipped with a calibration function, which enables you to adjust

the temperature registered by the heater. N.B! The room must have achieved a stable

temperature before any calibration.

Press ○2 times and use + or - to set the actual temperature observed in the room. Con-

ﬁrm with○or wait 15 seconds for automatic conﬁrmation.

Resetting the heater

See ﬁgure 4 on separate illustration sheet

Turn off the heater‘s main switch. Press and hold (9 while you turn on the heater‘s main

switch.

Memory function

The heater remembers all the temperature settings and will automatically return to the

desired temperature after a power cut. Your day- and nighttime setbacks will however be

deleted after a power cut, and you will need to register the programs again.

“Open window” function

The heater has an “open window” function that is activated instantly when it registers a

sudden drop in temperature with more than 2 degrees Celsius in 2 minutes. The heater will

automatically stop heating and FO will be visible in the display of the heater.

The heater will automatically start heating again after 10 minutes (the display switch from

FO to desired room temperature).

Instructions electronic thermostat

Please see table on page 4 for which models that have electronic thermostats

Control panel

See ﬁgure 5 on separate illustration sheet

1. Display (shows the desired room temperature by default)

2. Power indicator - shows whether the heater is using power or not

3. Control button ( +) (increase temperature)

4. Control button (-) (reduce temperature)

5. Function button

ATTENTION! After a power cut the thermostat will return to the last registered

temperature

WARNING! BEFORE THE HEATER IS TURNED ON, IT MUST BE ATTACHED TO A WALL.

IF THE HEATER IS NOT INSTALLED CORRECTLY OR IS INSTALLED ASKEW, THIS MAY

CAUSE THE HEATER TO MALFUNCTION OR IN THE WORST CASE, BE DAMAGED.

If the temperature sensor is not functioning properly, you will see this symbol on the

display. Please contact the dealer or importer.

Power indicator for electronic thermostat

See ﬁgure 6 on separate illustration sheet

When the panel heater is using power (i.e. when it is heating), the power indicator is lit ϟ

Set desired temperature for electronic thermostat

See ﬁgure 7 on separate illustration sheet

Press the arrow buttons to set the desired temperature.

Instructions day/night thermostat

Please see table on page 4 for which models that have day- and night thermostats.

TIP! The thermostat can be used as a regular electronic thermostat (i.e. the heater will

maintain a constant temperature 24 hours a day). Please see the section instructions elec-

tronic thermostat for further information.

8millnorway.com

Control panel

See ﬁgure 8 on separate illustration sheet

1. Display (shows the desired room temperature by default)

2. Control light — night function

3. Control light — day function

4. Power indicator — Shows whether the heater is using power or not

5. Control button ( +) (Increase temperature)

6. Control button (-) (Reduce temperature)

7. Night function

8. Day function

9. Function button

ATTENTION! After a power cut the thermostat will return to the last registered tempera-

ture.

WARNING! BEFORE THE HEATER IS TURNED ON, IT MUST BE ATTACHED TO A WALL.

IF THE HEATER IS NOT INSTALLED CORRECTLY OR IS INSTALLED ASKEW, THIS MAY

CAUSE THE HEATER TO MALFUNCTION OR IN THE WORST CASE, BE DAMAGED.

If the temperature sensor is not functioning properly, you will see this symbol on the

display. Please contact the dealer or importer.

Power indicator for day/night thermostat

See ﬁgure 9 on separate illustration sheet

When the panel heater is using power (i.e. when it is heating), the power indicator is lit ϟ

Set desired temperature for day/night thermostat

See ﬁgure 7 on separate illustration sheet

Press the arrow buttons to set the desired temperature.

Day- and nighttime setback

When programming the heater for either day- or nighttime setback, the setback period will

be active from the time you register the program. Which means; if you want to start your

daytime setback at 7.30 am, you need to register the program at 7.30 am.

You only need to program the heater 1 time for daytime setback and 1 time for nighttime

setback. If you have programmed the heater, the setback programs will be active on all 7

days (or 7 nights).

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali MILL Stufa

Manuali Stufa popolari di altre marche

oventrop

oventrop Regucor Series Manuale utente

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuale utente

ELMEKO

ELMEKO ML 150 Manuale utente

BN Thermic

BN Thermic 830T Manuale utente

KING

KING K Series Guida

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guida rapida

Well Straler

Well Straler RC-16B Manuale utente

EUROM

EUROM 333299 Manuale utente

Heylo

Heylo K 170 Manuale utente

Eterna

Eterna TR70W Manuale utente

Clarke

Clarke GRH15 Manuale di istruzioni

IRSAP

IRSAP The Radiator Company Ovali Manuale utente

Empire Heating Systems

Empire Heating Systems WCC65 Manuale utente

Wetekom

Wetekom 92 86 43 Manuale utente

Desa

Desa SPC170-F Manuale utente

Watlow

Watlow Watrod Electric Tubular Heaters Manuale utente

Haverland

Haverland ECO-DRY GPS Series Manuale elenco delle parti

Stelpro

Stelpro ASILVC2060 Series Manuale utente
