Mini Gadgets BB2K Manuale utente
1Version 1.0
BB2K DVR Hidden Camera
Manual
2Version 1.0
THANK YOU FOR PURCHASING THE BB2K DVR
HIDDEN CAMERA
Please read this manual before operating the
camera and keep it handy.
Your purchase should include:
●1 x BB2K DVR Camera
●1 x AC Wall Charger
●1 x Manual
●1 x 8-Pin MiniUSB Cable
●1 x Remote
●1 x 128GB MicroSD Card
●1 x MicroSD Card Reader
3Version 1.0
GET FAMILIAR WITH YOUR BB2K DVR HIDDEN
CAMERA
4Version 1.0
IMPORTANT WARRANTY INFORMATION: If the
warranty sticker on your device has been
removed or tampered with, your lifetime
warranty will be voided. You may be charged
fees or denied a return should this happen.
HOW TO CHARGE THE CAMERA
Note: If you are not located in the US, or if you
intend to use this product anywhere other than
the US, you will need to purchase a converter in
order to use the AC wall plug in and avoid
damaging the product. Because different
countries use different voltages in their
electrical wiring, you will need a converter that
adapts to the current in your particular country.
1. Connect the 8-Pin Mini USB cable to the
device.
5Version 1.0
2. Connect the other end of the cable to
the included AC wall charger, then plug
the charger into a functional electrical
outlet.
3. Allow the device to charge 6-8 hours.
The LED will be a solid red light once
fully charged.
OPERATING THE CAMERA
HOW TO TURN ON THE CAMERA
1. Once the device is finished charging,
unplug it from the charging adapter.
2. Hold the Power Button (A) on the for 3s
and let go. The LED will turn Red/Blue
for a second, then Blue for a second,
and then blink 4 times and go out. The
6Version 1.0
device is now in 3K Continuous
Recording mode.
3. To return to standby mode and choose
a different recording option, press the
3K Continuous Recording button (B) on
the remote. The red LED will flash to
indicate the device is saving the current
recording and then the blue LED will
turn on solid for Standby mode.
NOTE: If the light does not turn on, make sure
you are holding and releasing the power
button for 3 seconds.
HOW TO RECORD 3K CONTINUOUS VIDEO
1. When the camera is in Standby Mode,
press the “3K Continuous Recording
Button.” (B) The Indicator LED will
7Version 1.0
quickly flash blue 4 times and then go
out.
2. Once the Indicator LED turns off, the
camera is now recording 3K resolution
video continuously.
HOW TO STOP RECORDING VIDEO
1. While the camera is recording video,
press the “3K Continuous Recording
Button” once more. (The Indicator LED
will turn back on and be solid blue.)
2. The camera has now stopped recording
and is now in Standby Mode.
HOW TO TAKE PICTURES
1. When the camera is in Standby Mode,
press and hold the “Photo Button” (C)
for 3 seconds and let go once the LED
8Version 1.0
turns red. The LED will remain red while
the photo is being taken.
2. Once the photo is taken, the light will
turn back to a solid blue and the device
will return to standby mode.
HOW TO RECORD MOTION DETECTION
1. When the camera is in Standby Mode,
quickly press the “Motion Detection
Button” once (D).
a. Do NOT hold or the device will
format the microSD card.
2. The red/blue LED will stay on until the
device detects motion.
3. Once the device detects motion, the
red/blue LED will flash 4 times and then
go out. The device is now recording
video.
9Version 1.0
4. If there is no motion after 1 minute, the
device will return to detection standby
mode until motion is detected again.
While waiting, the red/blue LED light
will be on. .
HOW TO STOP RECORDING MOTION
DETECTION
1. While the camera is recording motion
detection, press the “Motion Detection
Button” (D) quickly once more. (The red
LED will flash to indicate the unit is
saving the current recording, and then
the blue Indicator LED will turn back
on.)
10Version 1.0
2. The camera has stopped recording
motion detection and is now in Standby
Mode.
CHANGING YOUR DATE/TIME STAMP
Your BB2K DVR Camera can have the date/time
stamp set by visiting
http://mgidownloads.com/Date_Time_Set/.
1. Choose ‘BB2K DVR’ from the Device SKU
drop down.
2. Choose your time zone.
3. Press ‘Download’.
4. Plug in the microSD card from your device
into your computer using the included microSD
card reader.
5. Copy the downloaded text file to the
microSD card of the unit.
