VGAExtender

UserGuide

VGAEXTENDER

1.WhatistheVGAExtender?

TheVGA ExtenderfromMinicomextendsvideo (VGA)signalsup to 110m/360ft

(dependingon resolution).

2.Features

·Supportsdistancesupto 110m/360ft

·SupportsCAT5/5e/6/7 FTP/UTPcable

·Supportresolution up to1080p /1920 x 1080 @60Hz(dependingon cable

length)

·Plug-and-playinstallation – no extraprotocolsneeded

·Cascadable -add VDS Line Splitterstoincreasethe numberofReceivers

·3 yearwarranty

3.SystemComponents

·VDSTransmitter

·VDS DualScreen (Receiver)

·OptionalCAT5VDS Line Splitter

4.Connecting theVGAExtendersystem

Thefigure belowillustratesthe VGA Extendersystemoverview. Connectthe

Receiverto 1 or2 screens,up to 110m/360ft awayfromthe Transmitter(depending

on resolution).

Computer

Transmitter

CAT5cable

Upto 110m/360ft

VDS Dual

Screen

2screens

eyb

use1

Vid

Par

Figure1The VGAExtendersystem overview

Thefigure belowillustrates theVGA Extender systemwith aconnected

LineSplitter addingup to 14 more screens to thesystem. (With cascading

you can haveamaximumof64 screens).

USER GUIDE

Computer

Transmitter

Upto 110m/ 360ft

Keybd

Mouse100T

Video

SerialA

Parallel

SerialB

LineSplitter

VDSDual

Screen

VDSDual

Screen

5.Pre-installation guidelines

·Switch offthe computer

·Placecablesawayfromfluorescentlights, air conditioners,and machines

thatare likelyto generateelectricalnoise

6.Connecting theTransmitter

ConnecttheTransmitterasillustrated in Figure 2.

Keybd

Mouse 100T

VideoSerial A

Parallel

Serial B

Transmitter

ToUSB Port

ToVideo

port

ToVDSDualScreen

/Line Splitter

Figure2Transmitterconnections

Note! Although werecommend connectingtheTransmitter to aswitchedoff

computer,you canconnectit to aswitched on computer.

To do so, you mustconnectit in thefollowingorder:

1. USBconnector.

2. Video connector.

VGAEXTENDER

7.Connecting theReceiver

Connectthe VDS DualScreen Receiverasillustrated below.

Systemcableto

Transmitter/ Line

Splitter

monitors

VDS Dual Screen

Figure3VDS Dual Screen connections

8.Connecting theCAT5/6/7cable

ACAT5/6/7 cable connectsto the RJ45portsofthe Transmitterand theVDS Dual

Screen.

9.Powersupply

Connectthe supplied 5VDCPoweradapterto the Receiver.The Transmitter

receivesitspowerfromthe connectedcomputeroroptionalexternalpowersupply.

10.Connecting theLineSplitter

Connectup to 64 screensby addingup to 2 levelsofCAT5Video DisplayLine

Splitters tothe VGA Extendersystem. Figure 4 illustratesthe portsofthe Line

Splitterand Figure 5 illustartesthe detailed connectionsofthe systemsincluding

the Transmitter, the Recievers and a Line Splitter. Forthe Line Splitterconnectthe

supplied 12VDC Poweradapter.

Figure4Line Splitter

SYSTEMIN

12VDC

SYSTEMOUT

Systemcables

Power

connector

CAT5cablefromTransmitteror

previous Line Splitter

USER GUIDE

www.minicom.com

SYSTEM IN

12VDC

SYSTEMOUT

CAT5cables to

Receivers orLine

Splitter

Line

Splitter

Transmitter

Computer

CAT5 cables to

Receiversor

Line Splitter

To USBPort

ToVideoport

VDS Dual

Screen

Keybd

Mouse 100T

VideoSerial A

Parallel

Serial B

To wallsocket

To wall socket

Figure5Detailedconnections

11.LEDindicators

Both theTransmitterand Receiverhave 2 LEDsabove the RJ45 port.

Thegreen LEDindicatespowerison. The flashingyellowLEDindicatesthe

systemisconnected.

12.Switching on

Before switchingon the computerconnectthe Transmitter.When fullyconnected,

the VGA Extendersystemisreadyto transmit video signals.

13.Pictureadjuster

To geta clearprojected image, use a screwdrivertoturn the pictureadjusteron the

VDS DualScreen Receiverunit. Note:Tosee a difference you have toturn the

pictureadjusterseveraltimes.

VGAEXTENDER

14.Technical specifications

System

System cable CAT5/6/7cable 2x4x24 AWGSolid Wire

Maximum

distance 110m/360ft

Screen

resolution Upto1920X1080 @ 60Hz(depending on cable length)

Warranty 3years

Operating temp. 0ºC to40ºC/32ºFto104ºF

Storage temp. -40°C to70°C/-40ºFto158ºF

Humidity 80% non condensingrelativehumidity

Transmitter Receiver

Cables &

Connectors

VGA –HDD15M

System–RJ45

2xVGA –HDD15F

System–RJ45

Powersupply Fromconnected computer External switchingpower

adapter 5V DC 110/240

Dimensions 89 x46 x25.3mm / 3.5x1.8x0.9”

Shipping weight 552g/1.21lb
