Miranda Vertigo XG Scheda tecnica

w w w . m i r a n d a . c o m

Installation & Quick Start Guide

M848-2705-480

Advanced HD/SD Graphics Processor

Vertigo XG

Vertigo XG21-e

Advanced HD/SD Graphics Processors

Installation & Quick Start Guide

Vertigo Suite v4.8

Vertigo XG22-e

Third Party Trademarks

All other brand names, product names or trademarks belong to their respective holders.

Usage Agreement

Please read the following terms and conditions carefully. By using the Vertigo XG

Installation & Quick Start Guide, you agree to the following terms and conditions:

Miranda Technologies Inc. hereby grants permission and license to owners of Vertigo XG

and Vertigo Suite to use their product manuals for their own internal business use. Manuals

for Miranda Technologies Inc. products may not be reproduced or transmitted in any form

or by any means, electronic or mechanical, including photocopying and recording, for any

purpose unless specifically authorized in writing by Miranda Technologies Inc.

Miranda Technologies Inc. makes no warranty, either expressed or implied, including but

not limited to any implied warranties of merchantability or fitness for a particular purpose,

regarding these materials and makes such materials available solely on an “As-Is” basis.

In no event shall Miranda Technologies Inc. be liable to anyone for special, collateral,

incidental, or consequential damages in connection with or arising out of purchase or use

of these materials. The sole and exclusive liability to Miranda Technologies Inc., regardless

of the form of action, shall not exceed the purchase price of the materials described herein.

Miranda Technologies Inc. reserves the right to revise and improve its products at any time

and without notice. This publication describes the state of this product at the time of its

publication, and may not reflect the product at all times in the future. Thus, different versions

of a manual may exist for any given product. Care should be taken to ensure that one

obtains the proper manual version for a specific product serial number.

Information in this document is subject to change without notice and does not represent a

commitment on the part of Miranda Technologies Inc.

Government Use

The Software {and Documentation} is provided with RESTRICTED RIGHTS. Use,

duplication or disclosure by the United States Government or any agency, department or

instrumentality thereof is subject to the restrictions set forth in the Commercial Computer

Software -- Restricted Rights clause at FAR 52.227-19 or the Commercial Computer

Software -- Licensing clause at NASA FAR Supplement 1852.227-86.

Printed in Canada

Document Identification

•Title: Vertigo XG - Installation & Quick Start Guide

•Part number: M848-2705-480

•Software version: Vertigo Suite v.4.8

•Last revised: June 26, 2012

Safety Compliance

Electromagnetic Compatibility

This equipment complies with the requirements of the following standards for

Safety of Information Technology Equipment:

• CSA C22.2 no. 60950-1-07 (2nd Edition)

• UL 60950-1 (2nd Edition)

• IEC/EN 60950-1 (2nd Edition)

Warning: An appropriately listed/certified main supply power cord must be used for the

connection of the equipment to the main voltage at either 120V~or 240V~

CAUTION: These servicing instructions are for use by qualified service personnel only.

To reduce the risk of electric shock, do not perform any servicing than that

contained in the operating instructions unless you are qualified to do so. Refer all

servicing to qualified service personnel. Servicing should be done in a static-free

environment.

This equipment has been tested for verification of compliance with FCC Part 15,

Subpart B requirements for Class A digital devices.

NOTE

This equipment has been tested and found to comply with the limits for a Class

A digital device, pursuant to Part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment

generates, uses and radiates radio frequency energy, and, if not installed and

used in accordance with the instruction manual, may cause harmful

interference in which case the user will be required to correct the interference

at his own expense.

This equipment has been tested and complies with the requirements of the

directive 2004/108/CE :

• EN 55022 Class A Radiated emissions

• EN 55022 Class A Conducted emissions

• EN 61000 -3-2 Harmonic current emission limits

• EN 61000 -3-3 Volatge fluctation and flicker limitations

• EN 61000 -4-2 Electrostatic discharge immunity

• EN 61000 -4-3 Radiated EMF immunity-RF

• EN 61000 -4-4 Electrical fast transient immunity

• EN 61000 -4-5 Surge immunity

• EN 61000 -4-8 Power frequency magnetic field

• EN 61000 -4-11 Voltage dips, short interruption and voltage variation immunity

WARNING

Vertigo XG devices contain Class 1 lasers, which are deemed safe under normal

operating conditions.

Standalone Equipment - Laser source(s) employed:

CLASS 1 LASER PRODUCT

APPAREIL A LASER DE CLASSE 1

Vertigo XG Installation & Quick Start Guide TOC-1

TABLE OF CONTENTS

Introduction .......................................................................................................................... 1-1

Vertigo XG product description.......................................................................................................... 1-2

Overview of the Vertigo XG chassis .................................................................................................. 1-4

Front panel components ............................................................................................................... 1-5

Rear panel components................................................................................................................ 1-6

Installation and quick start instructions ............................................................................ 2-1

Unpacking and verifying the Vertigo XG shipped items..................................................................... 2-3

Mounting the Vertigo XG chassis in a rack........................................................................................ 2-7

Cabling the Vertigo XG unit ............................................................................................................. 2-11

Starting the Vertigo XG.................................................................................................................... 2-14

Assigning a new IP address to the Vertigo XG device .................................................................... 2-16

Verifying the installation and setup by previewing the playout ........................................................ 2-17

Completing the quick start procedure.............................................................................................. 2-20

Need further assistance? .................................................................................................... 3-1

TOC-2 Vertigo XG Installation & Quick Start Guide

Table of Contents

Vertigo XG Installation & Quick Start Guide 1-1

1 INTRODUCTION

This guide provides basic Vertigo XG product information, as well as an orientation of its

hardware components. This guides also provides instructions for performing a first-time

installation of the Vertigo XG device, as well as initial setup tasks to get the device up and

running.

New Vertigo XG devices are factory configured for standard rendering and playout

workflows. Configuring the Vertigo XG settings for advanced workflows is normally

performed by qualified network administrators or Miranda’s Integration Specialists using the

Vertigo XG Portal and Dashboard software interfaces. Information and instructions for

implementing advanced configurations is beyond the scope of this document, but are

covered in the “Vertigo XG Configuration Guide”.

1-2 Vertigo XG Installation & Quick Start Guide

Introduction

Vertigo XG product description

The Vertigo XG is Miranda’s full-featured HD/SD graphics processor providing high

performance single or dual channel graphics rendering and video playback performance.

The Vertigo XG is ideal for a wide range of advanced real-time broadcast applications, like

HD/SD dual-casting with independent graphics for HD and SD, and single channel

applications demanding sophisticated, multi-channel branding and promotional graphics.

The Vertigo XG is available in two (2) standard models:

Both models of the Vertigo XG have the following features and capabilities:

• 3 RU rack mount chassis

• 2 video input channels

• 1 video output channel (XG21-e) or 2 video output channels (XG22-e)

• SD and HD video support

• 1 TB of video and audio storage, which is expandable to 2 TB

• 16 embedded audio channels per SDI stream

• Discrete AES audio channels - up to 8 in and 16 out (XG21-e) or 2 x 16 out (XG22-e)

• Independent DVEs on each video input

• Tri-mode hardware Video bypasses

• VAnc + VBI extraction processing and insertion or VAnc/VBI pass through

• Unlimited virtual layers that can be controlled independently

• Real-time control of live data sources with automatic on-air updates

• True Type/Unicode character support

• One seat of Xplay is included with each channel of the Vertigo XG purchased which

integrates the following features and functionality:

• Automation interface via RS-232, RS-422 (option) and TCP/IP

• Xplay’s graphical interface used for manual control of playlists

• “As run” logging

VX-Vertigo-XG21-e Vertigo XG single channel graphics engine (2 inputs, 1 output)

used for downstream branding.

VX-Vertigo-XG22-e Vertigo XG dual channel graphics engine (2 inputs, 2 outputs)

used for downstream simulcast branding.
