Mircom BPS-1100 Manuale utente

Canada

25 Interchange Way

Vaughan, ON L4K 5W3

Tel: 905-660-4655 Fax: 905-660-4113

 Mircom 2002

Printed in Canada

Subject to change without prior notice

www.mircom.com

BPS-1100

Signal Booster Power Supply

LT-913 Rev. 4

May 2008

Installation and Operation Manual

Advanced Life Safety Solutions Advanced Life Safety Solutions

U.S.A.

60 Industrial Parkway

Cheektowaga, NY 14227

Tel: 1-888-660-4655 Fax: 1-888-660-4113

SIGNAL BOOSTER POWE R SUPPLY

BPS-1100

BPS-1100 Installation and Operation Manual

Table of Contents

1.0 Introduction ........................................................................................................................ 1

1.1 Overall Features: ............................................................................................................ 1

1.2 Controls and Indicators ................................................................................................... 1

2.0 General Notes..................................................................................................................... 2

3.0 System Components ........................................................................................................ 3

3.1 Chassis Type .................................................................................................................. 4

3.2 BPS-1100 Accessories ................................................................................................... 4

4.0 Mechanical Installation and Dimensions ......................................................................... 5

4.1 Main Chassis Installation ................................................................................................ 6

5.0 Modules Mounting Locations ........................................................................................... 7

6.0 Module Settings ................................................................................................................. 9

6.1 Main Chassis Board of the BPS-1100 ............................................................................ 9

6.2 Main Display Module (Part of Main Chassis) .................................................................. 10

6.3 Signal Adder Module (Model SGM-1004A)..................................................................... 11

6.4 Relay Adder Module (Model RM-1008A) ........................................................................ 12

7.0 Field Wiring......................................................................................................................... 13

7.1 Main Board Terminal Connections.................................................................................. 13

7.2 Signal Adder Module (SGM-1004A) Terminal Connections ........................................... 15

7.3 Relay Adder Module (RM-1008A) Terminal Connections............................................... 16

7.4 Power Supply Connections............................................................................................. 17

7.5 Wiring Tables & Information............................................................................................ 18

8.0 System Checkout ............................................................................................................... 19

8.1 Before Turning The Power "ON"..................................................................................... 19

8.2 Power-up Procedure ....................................................................................................... 19

8.3 Troubleshooting .............................................................................................................. 19

9.0 Indicators, Controls, & Operation..................................................................................... 20

9.1 Common Indicators......................................................................................................... 21

9.2 Common Controls ........................................................................................................... 21

9.3 Circuit Status Indicators .................................................................................................. 22

9.4 Circuit (Zone) Disconnect Switches ................................................................................ 22

9.5 Circuit Types ................................................................................................................... 23

10.0 System Configuration...................................................................................................... 24

10.1 Introduction To Configuration........................................................................................ 24

10.2 Entering Configuration Mode ........................................................................................ 25

10.3 Exiting Configuration Mode........................................................................................... 25

10.4 Factory Default Configuration ....................................................................................... 26

10.5 Restore To Default / Resize.......................................................................................... 26

10.6 Resize System (Set Adder Module Number & Type).................................................... 26

10.7 Configuring Features .................................................................................................... 27

10.8 Configuring Indicating Circuits: ..................................................................................... 28

10.9 Configuring Circuit Correlations: ................................................................................... 29

10.10 Display Configuration.................................................................................................. 29

Appendix A - Module Specifications And Features .............................................................. 30

Compliance ........................................................................................................................... 30

Appendix B - Power Supply & Battery Calculations (Selection Guide) .............................. 31

Warranty & Warning Information............................................................................................ 32

Warning Please Read Carefully............................................................................................ 32

Limited Warranty................................................................................................................... 34

Warranty Procedure.............................................................................................................. 34

Disclaimer of Warranties....................................................................................................... 34

Out of Warranty Repairs ....................................................................................................... 35

BPS-1100 Installation and Operation Manual

iii

List of Figures and Headings

Figure 1: BPS-1100 Flush or Surface Enclosure Installation and Dimensions ....................5

Figure 2: Main Chassis Installation ......................................................................................6

Figure 3: Module Mounting Locations ..................................................................................7

Figure 4: Adder Module Mounting Details ............................................................................8

Figure 5: Main Chassis board of the BPS-1100 ...................................................................9

Figure 6: Main Display Module (For Service Personnel) .....................................................10

Figure 7: Signal Adder Module ............................................................................................11

Figure 8: Relay Adder Module .............................................................................................12

Figure 9: Main BPS-1100 Module Terminal Connections ....................................................13

Figure 10: Main BPS-1100 Module Terminal Connections (continued) ...............................14

Figure 11: Signal Module Terminal Connections .................................................................15

Figure 12: Relay Adder Module Terminal Connections .......................................................16

Figure 13: Power Supply Connections .................................................................................17

Figure 14: Indicators and Control Location ..........................................................................20

Figure 15: Evacuation Codes ...............................................................................................23

Figure 16: Configuration Indicators and Controls ................................................................24

Table 1: Wiring Table for Input Circuits ................................................................................18

Table 2: Wiring Table for Indicating Circuits ........................................................................18

Table 3: Configuration Dip Switch Function Table ...............................................................25

Table 4: Feature Configuration Dip Switch Table ................................................................27

BPS-1100 Installation and Operation Manual

1.0 Introduction

Mircom's BPS-1100 Signal Booster Power Supply provides up to 20 fully supervised Class A or B (UL Style Z or Y)

Indicating Circuits. All Indicating Circuits are fully supervised for opens, shorts and grounds. Optional Adder

Modules include additional Indicating Circuits and Relay Circuits. Flush or surface mountable enclosures can be

used for retrofits and on new installations.

1.1 Overall Features:

• 120V/240V AC, 24V DC, 11 Amps Max

• Basic unit has 4 Power Limited Class A/B (Style Z/Y) Indicating Circuits with individual trouble indicators (1.7A

Max per circuit).

• 4 supervised programmable inputs

• Optional 3 Adder Modules for additional Indicating and Relay Circuits. Indicating Circuits expandable by 16

(with 3 SGM-1004As) and Relay Circuits by 16 (with 2 RM-1008As).

• Supports supervised and unsupervised suite isolators

• Regulated Auxiliary Output 24V DC, 1.7A

• Space for 10 to 17 Amp Hour Batteries

• Each Indicator Circuit can be configured as Audible or Visual. Audibles may be steady, Temporal Code,

California Code, or March Time.

• Indicating Circuits may be individually Disconnected by a DIP Switch.

• Two outputs (200 mA each Max., 300 mA total Max.)

• Auxiliary Relay Contacts for Common Ground and Common Trouble.

• Easy Configuration via Pushbuttons and Switches.

• Extensive transient protection

• Surface Mountable Enclosures, Flush Trims Available

1.2 Controls and Indicators

4 Pushbuttons, 7 Common Indicators, provision for up to 4 Inputs and 20 Output Points.

2.0 General Notes

Number Of Adders That May Be Installed

The maximum number of Adder Modules that may be physically installed in a BPS-1100 is 3 Adder Modules, a

combination of the following:

SGM-1004A Signal Adder Module (maximum of 16 Indicating Circuits in a system)

RM-1008A Relay Adder Module (maximum of 16 Relay Circuits in a system)

Circuits And Zones

Circuits refers to an actual electrical interface, Input (Detection), Indicating (Signal), or Relay.

Display Points

On the BPS-1100 an important concept is Display Points. Unlike some products the available LED Displays and

matching Circuit Disconnect Switches are not hard-wired to the Circuit Adder Modules. The Main Chassis provides

a fixed number of Display Points on their attached Display Boards. These are assigned during the Configuration

Adder Module Number and Type operation (see Configuration Section) as required in the cabling order in which

Adder Modules are installed. In any system setup, there must be at least as many Display Points available, as those

required by the Circuits.

Wiring Styles

Input Circuits are configured as Class B (Style B).

Indicating (Output) Circuits may be individually wired as Class A (Style Z) or Class B (Style Y) without affecting the

number of circuits available (see Field Wiring instructions).

BPS-1100 Installation and Operation Manual

3.0 System Components

Model Description

BB-1024 Surface Enclosure

MCC-1100-12 12 A Main Chassis

FA-1024TR Flush Trim Ring (add another suffix R for Red Enclosure)

12 VOLT

Batteries (10

to 17AH)

(2 required for

24 volts)

Use Sota Enertech batteries models: SA12120 (Mircom

#BA-110) and SA-12180 (Mircom #BA-117).

SGM-1004A

RM-1008A

Circuit Adder Modules

SIGNAL BOO STER POWER SUPPL Y

BPS-1100

SELECT

CONFIRM

INPUT4

INPUT3

INPUT2

INPUT1

OUTPUT 1

OUTPUT 2

OUTPUT 3

OUTPUT 4

OUTPUT 5

OUTPUT 6

OUTPUT 1

OUTPUT 7

OUTPUT 8

OUTPUT 9

OUTPUT10

OUTPUT11

OUTPUT12

OUTPUT13

OUTPUT14

OUTPUT15

OUTPUT16

OUTPUT17

OUTPUT18

OUTPUT19

OUTPUT20

CONFIG. O/P ZONE

DISCONNECT

I/P ZONE

DISCONNECT

O/P ZONE

DISCONNECT

O/P ZONE

DISCONNECT

W= 5.94"

H= 3.94"

D= 3.86"

W= 7.13"

H= 6.58"

D= 2.29"

SA12120

10AH

SA12180

17AH

3.0 System Components

3.1 Chassis Type

MCC-1100-12

Main Chassis with 4 Style Y or Z Indicating

Circuits, and a 12 ampere Power Supply. See Module Specifications Appendix A - Module Specifications And

Features on page 30 for more details.

3.2 BPS-1100 Accessories

MP-300 EOL Resistor Plate

MP-300R EOL Resistor Plate, Red

MP-300S EOL Resistor Plate, Stainless steel finish
