Mitsubishi Electric PAR-30MAA Manuale utente

UserGuide

Controls

PAR-30MAA

BackUpandRotate

PAR-30MAA Back Up and Rotate

Select the Main enu by pressing

In the main menu screen move the

cursor using F1/F2 to Service

option and press

Move the cursor next to the Check

option and press

Then select Request code

and press

In the Request code screen enter

the outdoor unit address and the

appropriate rotation setting -

see list on reverse.

Outdoor unit address is the same

as the refrigerant address.

Enter aintenance password

(default is 9999)

Repeat step 5 for the slave unit as

both ref addresses (both outdoor

units) need a code request in order

for back up and rotate to operate.

UNITEDKINGDOMMitsubishiElectricEurope Living Environmental Systems Division

Travellers Lane, Hatfield, Hertfordshire, AL10 8XB, England General Enquiries Telephone: 01707 282880 Fax: 01707 278881

IRELANDMitsubishiElectricEurope Westgate Business Park, Ballymount, Dublin 24, Ireland

Telephone: Dublin (01) 419 8800 Fax: Dublin (01) 419 8890 International code: (003531)

Telephone: 01707282880

email: airconditioning@ euk. ee.co web: www.airconditioning. itsubishielectric.co.uk

Country of origin: United Kingdom – Japan – Thailand – Malaysia. ©Mitsubishi Electric Europe 2011. Mitsubishi and Mitsubishi Electric are trademarks of Mitsubishi Electric Europe B.V. The company reserves the right to make any variation in technical specification to the equipment described, or

to withdraw or replace products without prior notification or public announcement. Mitsubishi Electric is constantly developing and improving its products. All descriptions, illustrations, drawings and specifications in this publication present only general particulars and shall not form part of any

contract. All goods are supplied subject to the Company’s General Conditions of Sale, a copy of which is available on request. Third-party product and brand names may be trademarks or registered trademarks of their respective owners.

UserGuide

Controls

PAR-30MAA

BackUpandRotate

Request Code List

Rotation Setting

Setting No.

(Request Code)

Initial

Setting

Setting Contents

o.1 (310)

o.2 (311)

o.3 (312)

o.4 (313)

o.5 (314)

o.6 (315)

o.7 (316)

o.8 (317)

o.9 (318)

Monitoring the request code of current setting

Rotation and Back-up off ( ormal group control operation)

Back-up function only

Rotation O (Alternating interval = 1 day) and back up function

Rotation O (Alternating interval = 3 day) and back up function

Rotation O (Alternating interval = 5 day) and back up function

Rotation O (Alternating interval = 7 day) and back up function

Rotation O (Alternating interval = 14 day) and back up function

Rotation O (Alternating interval = 28 day) and back up function

2nd Stage Cut-in Setting

Setting No.

(Request Code)

Initial

Setting

Setting Contents

o.1 (320)

o.2 (321)

o.3 (322)

o.4 (323)

o.5 (324)

Monitoring the request code of current setting

Cut-in Function OFF

Cut-in Function O (Set point = Set temp. +4ºC(7.2ºF)

Cut-in Function O (Set point = Set temp. +6ºC(10.8ºF)

Cut-in Function O (Set point = Set temp. +8ºC(14.4ºF)

Related Links Model Number: PAR-30MAA

Controls Brochure

M Series and Mr Slim Optional Parts

PAR-30MAA Simple Instruction Book WT05949X01

PAR-30MAA Installation Manual WT05950X01

PAR-30MAA Declaration of Conformity

PAR-30MAA_Rotation_Guide

PAR-30MAA_User_Guide
