DX-NT400E

All the memory you need

for your safety

The DX-NT400E can be easily operated via the wire 

remote control, the on-screen menu and also over the 

network connection. Using the intelligent search func- 

tion you’ll find specific picture sequences in seconds. 

The integrated timer programs recording in intervals 

or on public holidays, so that the DX-NT400E has 

everything under control, even when you’re not there.



•Maintenance free operation

•Full-duplex function for simultaneous recording 

and playback

•Alarm recording through motion detection or 

alarm contact

•Fully automatic daylight saving conversion

•“On-board” network connection

•Net Hunter Lite application software

You know best how much memory you need for your 

long-play recorder. And with the DX-NT400E you 

choose. As an option a removable tray is available, in 

which 2 internal hard drives can be installed. The 

DX-NT400E adapts itself to your needs. You decide 

how much you record or see. Thanks to the integrated 

Multiplexer up to 4 channels can be viewed simul- 

taneously. And you also determine the grade of the 

compression and the sensor adjustment for each 

individual camera: with a maximum of 25 pictures per 

second at a resolution of 720 x 288 pixels. In critical 

situations too, you can rely on the DX-NT400E. Errors 

during recording are automatically recognized and 

indicated on the monitor or over the network. Allowing 

you to react quickly. Even in the case of a power cut, 

the DX-NT400E starts up automatically with all preset 

parameters and resumes recording.

Mitsubishi Electric Europe B. V. • German Office • Electronic Visual Systems • Gothaer Straße 8 • D-40880 Ratingen

Tel.: +49 (0) 21 02/4 86 92 50 • Fax: +49 (0) 21 02/4 86 73 20 • www.mitsubishi-evs.de

Model DX-NT400E (Full-Duplex)

Recording System Digital wavelet, 720 x 288 pixels

Recording Medium Hard drive of customer’s choice

Max. Recording Capacity 2 x HDDs each 250 GB IDE

Recording Type Field/second

Picture Recording 25 frames/second incl. motion detection

Horizontal Resolution s/w (TV-Lines) > 450

Horizontal Resolution Color (TV-Lines) > 450

No. of Video Inputs/Outputs 4/1

No. of Audio Inputs/Outputs 1/1

Audio Recording/Continuous Playback by Run Time Yes

On-Screen: Display, Date/Time/Mode Yes – 4 modes

On-Screen: Display, Alarm Yes

On-Screen: Display, Power Loss Yes

Alarm: Time Lapse/Real Time Yes

Alarm Index Yes

Recording via Alarm Contact Yes

No. of Timer Programs 3

HDD Automatic Overwriting/Endless Recording Yes

HDD Full: Acoustic Signal/Electrical Contact Signal Yes

HDD Full: Transfer to Subsequent Device Yes

Lock Function Yes + password

Error Indication Yes

Continuous Recording after Power Loss Yes

Record – Original Check: Watermark Yes

Operating Hours Counter Yes

Search: Fields Stepping Yes

Search: Speeds Yes

Search: Reverse Playback Yes

Search: for Date/Time Yes

Search: for Alarms Yes/colored search mode display

Automatic Summer/Winter Time Yes

Remote Operation (Cable) Yes

Remote-Control Interface Yes (RS-232)

Operating Voltage (Volt) 100–240 V/AC

Power Consumption (Watt) Approx. 60 W (240 V/AC)

Operating Temperature (min./max. °C) 5–40

Dimensions in mm (W x H x D) 300 x 343 x 88

Weight (kg) 5.8

Certification (VDE/GS/etc.) EN 60850, EN 55022 Class B, EN 55024, EN 50130

Menu Languages GB/D/FR/I/ES/RU

Items Included Wire remote control, software, operation manual, power cable

Special Features Maintenance-free, optional removable tray, “on-board” network connection,

integrated multiplexer (sequential/split function), search and find within

seconds, alarm recording via motion detection and alarm contacts, 5 levels

of selectable image quality (individual for each camera), audio recording

(mic./line), full-duplex, digital zoom, public holiday program

(The right to make technical changes is reserved; no liability is accepted for printing or other errors)
