Mitsubishi Electric MDT521S Manuale utente

MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

Leading the evoLution of

HIGH-DEFINITION

digital signage

Slim eye-catching bezel design•

Advanced high-definition digital signage display•

Full 1920 x 1080 native resolution•

Built-in CAT5 transmitter and receiver•

Front and rear ambient light sensors•

www.mitsubishi-presentations.com

888.307.0349

MDT521S

52” LCD Monitor

CLASS 52” (Diagonal) LCD Monitor

VIEWABLE IMAGE SIZE 45.4” x 25.5”

ORIENTATION Landscape / Portrait / Face Up

BRIGHTNESS/LUMENS 700 cd/m2

PIXEL PITCH 0.600 mm

CONTRAST RATIO 2000:1

DIMENSIONS

(W x H x D in.)

47.3 x 27.5 x 4.8

WEIGHT

(WITHOUT STAND

AND SPEAKERS)

88 lbs. (Net)

BEZEL WIDTH 0.77”

RESPONSE TIME 8 ms (gray to gray)

VIEWING ANGLE Horizontal and vertical: 178O

VIDEO/AUDIO

INPUTS AND OUTPUTS

mini D-Sub 15 pin In/Out, HDMI, DVI-D,

CAT5 In/Out, BNC (R,G,B,H,V) In/out,

S-Video, Composite (BNC, RCA), Audio

LR (RCA), Audio Stereo mini jack

SPEAKER OUTPUT External speaker jack

CONTROL INPUT/OUTPUT RS232C (mini D-Sub 9 In/Out)

POWER CONSUMPTION

(WITHOUT SPEAKERS)

360 W

ESTIMATED BACKLIGHT LIFE Up to 50,000 hours*

AUDIO SPEAKER Optional: SP-521S

TABLE STAND Optional: ST-521S

WALL MOUNT

COMPATABILITY

Optional: CTM-MS2

WARRANTY 3-years parts and labor, Express

Replacement Assistance, toll-free 24x7

technical support

*Results may vary depending on usage and operating environment

MITSUBISHI

ELECTRIC

PRESENTATION PRODUCTS

MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.

Presentation Products Division

Toll Free:

Email: [email protected]

www.mitsubishi-presentations.com

Canada

Mitsubishi Electric Sales Canada Inc.

Information Technologies Group

Phone: 905.475.7728

www.mitsubishielectric.ca

LITMDT521S

Optional Stand:

ST-521S

MDT521S

52” LCD Monitor

Slot for optional CAT5

input/output connectors

(modular connector 8pin)

EXTERNAL CONTROL

(mini D-Sub 9 pin)

VIDEO IN/OUT

VIDEO IN CONNECTOR (BNC and RCA)

VIDEO OUT CONNECTOR (BNC)

S-VIDEO IN CONNECTOR (Mini DIN 4 pin)

RGB 4 IN/ DVD/HD IN (BNC)

AC IN connector

EXTERNAL SPEAKER TERMINAL

AUDIO OUT

AUDIO IN 1,2,3

RGB 1 IN (HDMI)

RGB 2 in (DVI-D)

RGB 3 IN (mini D-Sub 15 pin)

RGB out (mini D-Sub 15 pin)

multiple standard input and output connectors

Out OutIn In In In

Side Connector

Panel

Rear Connector

Panel

1 3
