Mitsubishi MOTORS LANCER EVOLUTION Manuale utente

LANCER EVOLUTION

OWNER’S MANUAL

LANCER EVOLUTION - ENGLISH - OCZE14E3

Foreword

E09200104542

Thank you for selecting a LANCER EVOLUTION as your new vehicle.

This owner’s manual will add to your understanding and full enjoyment of

the many fine features of this vehicle.

It contains information prepared to acquaint you with the proper way to oper-

ate and maintain your vehicle for the utmost in driving pleasure.

MITSUBISHI MOTORS Europe B.V. reserves the right to make changes in

design and specifications and/or to make additions to or improvements in

this product without obligation to install them on products previously manu-

factured.

It is an absolute requirement for the driver to strictly observe all laws and

regulations concerning vehicles.

This owner’s manual has been written in compliance with such laws and reg-

ulations, but some of the contents may become contradictory with later

amendment of the laws and regulations.

Please leave this owner’s manual in this vehicle at time of resale. The next

owner will appreciate having access to the information contained in this

owner’s manual.

Repairs to your vehicle:

Vehicles in the warranty period:

All warranty repairs must be carried out by a MITSUBISHI MOTORS Au-

thorized Service Point.

Vehicles outside the warranty period:

Where the vehicle is repaired is at the discretion of the owner.

Throughout this owner’s manual the words WARNING and CAUTION

appear.

These serve as reminders to be especially careful. Failure to follow instruc-

tions could result in personal injury or damage to your vehicle.

WARNING

indicates a strong possibility of severe personal injury or death if in-

structions are not followed.

CAUTION

means hazards or unsafe practices that could cause minor personal in-

jury or damage to your vehicle.

You will see another important symbol:

NOTE: gives helpful information.

*: indicates optional equipment.

It may differ according to the sales classification; refer

to the sales catalogue.

Abbreviations used in this owner’s manual:

LHD: Left-Hand Drive

RHD: Right-Hand Drive

M/T: Manual Transmission

The symbol used on the vehicles:

: See owner’s manual

Information for station service

E09300101630

Fuel

Fuel tank capacity 55 litres

Fuel requirements Unleaded petrol octane number (EN228) 98 RON or higher

Refer to the “General information” section for the fuel selection.

Engine oil Refer to the “Maintenance” section for the selection of engine oil.

Tyre inflation pressure Refer to the “Maintenance” section for the tyre inflation pressure.

OCZE14E3

BLC-14-000800

Table of contents

Overview

General information

Locking and unlocking 1

Seat and seat belts 2

Instruments and controls 3

Starting and driving 4

For pleasant driving 5

For emergencies 6

Vehicle care 7

Maintenance 8

Specifications 9

OCZE14E3

Instruments and Controls (Driver’s area)
E00100107145
LHD
12
3
4
6
5
7
8
9
10
11
12
13
14
15 16
1. Multi-information meter switch p. 3-05
2. Instruments p. 3-02
3. Shift paddles* p. 4-21, 4-22
4. Wiper and washer switch p. 3-44
5. Cruise control switches* p. 4-38
6. Ignition switch p. 1-11, 1-16, 4-09
7. Supplemental restraint system - airbag (for driver’s seat) p. 2-18,
2-22
Horn switch p. 3-48
8. Steering wheel height adjustment lever p. 4-06
9. Supplemental restraint system - driver’s knee airbag p. 2-23
10. Bluetooth® 2.0 interface* p. 5-40
11. Bonnet release lever p. 8-03
12. Fuses p. 8-16
13. ASC OFF switch p. 4-34
14. Combination headlamps and dipper switch p. 3-37
Turn-signal lever p. 3-41
Front fog lamp switch p. 3-43
Rear fog lamp switch p. 3-43
Headlamp washer switch p. 3-47
15. AWC switch* p. 4-29
16. Steering wheel audio remote control switches* p. 5-21
Overview
 OCZE14E3

RHD
1 2
3
4
5
6
7
8
9
10
11
12
13
14
15
1. Shift paddles p. 4-21, 4-22
2. Instruments p. 3-02
3. Multi-information meter switch p. 3-05
4. Wiper and washer switch p. 3-44
5. Cruise control switches p. 4-38
6. ASC OFF switch p. 4-34
7. Trunk lid opener switch p. 1-26
8. Ignition switch p. 1-11, 1-16, 4-09
9. Steering wheel height adjustment lever p. 4-06
10. Bonnet release lever p. 8-03
11. Supplemental restraint system - driver’s knee airbag p. 2-23
12. Bluetooth® 2.0 interface* p. 5-40
13. Steering wheel audio remote control switches p. 5-21
14. Supplemental restraint system - airbag (for driver’s seat) p. 2-18,
2-22
Horn switch p. 3-48
15. Combination headlamps and dipper switch p. 3-37
Turn-signal lever p. 3-41
Front fog lamp switch p. 3-43
Rear fog lamp switch p. 3-43
Headlamp washer switch p. 3-47
Overview

OCZE14E3

Instruments and Controls (Instrument panel)
E00100107158
LHD
1
2
3
4
5
7
6
8
9
10
11
12
13
14
1. Ventilators p. 5-02
2. Gearshift lever p. 4-14, 4-17
3. Supplemental restraint system - airbag (for front passenger’s seat)
p. 2-18, 2-22
4. Front passenger’s airbag ON-OFF switch p. 2-18, 2-21
5. Glove box p. 5-63
USB input terminal* p. 5-56
6. Twin Clutch SST control mode switch* p. 4-20
7. AWC switch* p. 4-29
8. Moveable ashtray* p. 5-59
9. Heated seat switch* p. 2-04
10. Floor console box p. 5-63
11. Cup holder p. 5-64
12. Parking brake lever p. 4-04
13. Fuel tank filler door release lever p. 03
14. Trunk lid release lever p. 1-26
Overview
 OCZE14E3

RHD
123
4
5
6
7
8
9
10
11
12
13
1. Supplemental restraint system - airbag (for front passenger’s seat)
p. 2-18, 2-22
2. Gearshift lever p. 4-14, 4-17
3. Ventilators p. 5-02
4. Fuel tank filler door release lever p. 03
5. AWC switch p. 4-29
6. Cup holder p. 5-64
7. Floor console box p. 5-63
8. Heated seat switch p. 2-04
9. Twin Clutch SST control mode switch p. 4-20
10. Parking brake lever p. 4-04
11. Fuses p. 8-16
12. Glove box p. 5-63
USB input terminal* p. 5-56
13. Front passenger’s airbag ON-OFF switch p. 2-18, 2-21
Overview

OCZE14E3

Centre panel

E00100600590

1. Audio* p. 5-09

DISPLAY AUDIO*

MITSUBISHI Multi-Communication System*

Refer to the separate owner’s manual

2. Hazard warning flasher switch p. 3-43

3. Front passenger seat belt warning lamp p. 2-08

4. Rear window demister switch p. 3-47

5. Air conditioning p. 5-04

6. Cigarette lighter* p. 5-59

Accessory socket* p. 5-60

7. Front console box p. 5-63

8. Front passenger’s airbag OFF indication lamp p. 2-18, 2-21

Overview

OCZE14E3

Interior
E00100205096
LHD
1
23
4
5
6
7
8
9
10
11
12
13
1. Electric window control switches p. 1-34
2. Lock switch p. 1-35
3. Electric remote-controlled outside rear-view mirrors switch
p. 4-07
4. Central door lock switch p. 1-23
5. Front room & map lamp p. 5-60, 8-23, 8-28
6. Microphone (for Bluetooth® 2.0 interface)* p. 5-41
7. Inside rear-view mirror p. 4-06
8. Sun visors p. 5-58
Vanity mirror p. 5-58
Card holder p. 5-58
9. Bottle holder (for front seats) p. 5-65
10. Front seats p. 2-03
11. Supplemental restraint system - side airbag (for front seats)
p. 2-25
12. Head restraints p. 2-05
13. Adjustable seat belt anchor (front seats) p. 2-08
Seat belts p. 2-06
Overview

OCZE14E3

RHD
1
2
3
4
5
6
7
8
9
10
11
12
1. Front room & map lamp p. 5-60, 8-23, 8-28
2. Microphone (for Bluetooth® 2.0 interface)* p. 5-41
3. Lock switch p. 1-35
4. Electric remote-controlled outside rear-view mirrors switch
p. 4-07
5. Electric window control switches p. 1-34
6. Adjustable seat belt anchor (front seats) p. 2-08
Seat belts p. 2-06
7. Head restraints p. 2-05
8. Supplemental restraint system - side airbag (for front seats)
p. 2-25
9. Front seats p. 2-03
10. Bottle holder (for front seats) p. 5-65
11. Sun visors p. 5-58
Vanity mirror p. 5-58
Card holder p. 5-58
12. Inside rear-view mirror p. 4-06
Overview
 OCZE14E3
