Mitsubishi LANCER 2014 SERIES Guida utente

Owner’s Handbook

(5/13)

www.mitsubishicars.com

2014 LANCER SERIES

Dieline -DO NOT PRINT!

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:

1. Pre-Delivery Inspection Form (Customer Copy)

2. Triple Diamond Delivery Checklist (Customer Copy)

3. Salesperson or Key Dealership Contact’s Business Card

Owner’s Handbook

(5/13)

www.mitsubishicars.com

2014 LANCER SERIES

Dieline -DO NOT PRINT!

Thank you for buying a Mitsubishi Lancer. There’s no doubt you’ve already realized how well

your car drives on the open road. What you may not know is all the great features that help

your car perform the way it does. In the pages ahead we’re going to run through the basics

and prepare you for the road.

We’d also love to hear from you about your overall Mitsubishi experience. If you haven’t

already, please log on to www.MitsubishiSSIsurvey.com and tell us how we did. This will help

us make sure your next visit is that much better.

We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news

and special offers. Here you can also keep track of your car’s warranty and servicing needs,

get Roadside Assistance Information and tap into other owner-centric details. Just log on to

www.Mitsubishicars.com/ownersonly.

Driver’s View ..................... Page 2-3

Controls ............................ Page 4-5

Own the Road................... Page 6

Technology ....................... Page 7

Audio System.................... Page 8

Display Audio System

and Navigation System

(if equipped)..................... Page 9-10

Bluetooth® (if equipped).... Page 11

FAQ’s................................ Page 12-13

Table of Contents

Driver’s View

1Side

Mirror Adjustment

............... Page 2

2Headlights and Fog Lights.......... Page 4

3 Air Conditioning ......................... Page 5

4Windshield Wiper Lever.............. Page 5

5Cruise Control ........................... Page 6

6 Paddle Shifters (if equipped)...... Page 6

7Audio System............................. Page 8

8Audio Remote Control Switch

(if equipped).............................. Page 8

9 USB Port (if equipped)............... Page 8

10 Display Audio System

(if equipped).............................. Page 9

11 Navigation System

(if equipped).............................. Page 10

12 Bluetooth®Controls

(if equipped).............................. Page 11

(Inside glove box)

4CONTROLS

Regular Headlights Automatic Headlights

Headlights and other lights on.

Parking, tail, front and rear sidemarker lights, license plate and

instrument panel lights on.

Headlights and other lights turn on and off automatically in

accordance with outside light level.

All lights off

AUTO

OFF

Fog Lights (if equipped)

High/Low Beam Switch

Fog Lights will illuminate only when headlights are on low beam.

Turning the knob in the direction of the ON position turns on the

fog lights. Turning the knob in the direction of the OFF position

turns off the fog lights. The knob will return to the neutral

position when released.

To change the headlights from high beam to low beam and vice versa, pull

the turn signal lever fully towards you (1). An illuminated blue light in the

instrument cluster indicates when the headlights are on high beam.

• Headlightasher

 Youcanashthehighbeamsbypullingthelevergentlytowardsyou(2).

A- Turn for Temperature control

B- Push to select outside air (Indicator light off) or recirculated air (Indicator light on)

C- Turn to select the blower speed. To the right increases blower speed. To the left decreases

blower speed. Turned all the way to the left turns the blower off.

Note: OFF is located above AUTO.

D- Push for air conditioning ON/OFF (Indicator light on/Indicator light off).

E -Turntoselecttheairowanddirectionmode(AUTOpositionisonlyauto

type air conditioning).

F- Push to defog the rear window (Indicator light on). Rear window

defogger light automatically turns off after 20 minutes.

To defog front windshield

1. Set the Mode Dial Eto defrost position.

2. Set the blower speed Cto the maximum position.

3. Set the temperature Ato highest position.

Turn the knob Bto operate the rear

window wiper.

The wiper operates continuously

for several seconds then operates

intermittently at intervals of about 8

seconds.

Washeruidissprayed,thewiperwill

automatically operate 2 or 3 times.

Rear Window Wiper and Washer (Lancer Sportback only)

Air Conditioning (Automatic shown)

The wipers will operate once.

INT: Intermittent intervals can be

adjusted by turning the knob A

AUTO: The wipers will be operated

automatically by rain sensor

(if equipped).

Slow

Fast

Rain Sensing Wipers (if equipped)

It is possible to adjust the sensitivity of the rain sensor

by turning the AUTO ring C .

+ Higher sensitivity to rain

– Lower sensitivity to rain.

Windshield Wipers

CONTROLS

A - CANCEL: To deactivate the cruise control

B - ACC RES: To increase the set speed or resume

previously set cruise control operation.

C- COAST SET: To set the desired speed and to

reduce the set speed

D- ON/OFF: To turn ON/OFF cruise control

To set a cruising speed

1. Press Dand the CRUISE indicator light in the

meter cluster will be turned on.

2. Accelerate or decelerate to your desired speed

(above 25 mph). Press Cand remove your foot

from the accelerator pedal.

To accelerate or decelerate speed

Press Bto increase set cruising speed.

Press Cto decrease set cruising speed.

To cancel the cruising speed

Press Aor press brake pedal, or press D .

6OWN THE ROAD

– :SHIFT DOWN + :SHIFT UP

Paddle Shifters (if equipped)

Seat Heater Switch

Position - Action

(HI) - For quick heating

(LO) - To keep the seat warm

Drive Mode Selector (if equipped)

The drive mode can be selected by pressing the

switch while the ignition switch is in the ON

position.

2WD: This mode is for economical driving on

normal dry roads and freeways.

4WD AUTO: This mode is for all driving conditions

on various roads.

4WD LOCK: This mode is for driving in slippery

conditions such as on snow-covered roads or sand.

Cruise Control

Simply upshift or downshift

with a tap of your ﬁngers,

without moving your hands

from the steering wheel.

You can return to the automatic

shifting mode by pulling the +

(SHIFT UP) side paddle shifter

towards you and holding for

over 2 seconds.

TECHNOLOGY

Multi-information Meter Switch (INFO Button)

Keyless Entry System

[F.A.S.T.-Key] [Normal Key]

LOCK

Press: Once – Lock all doors

UNLOCK

Press: Once – Unlock driver door

Twice – Unlock all doors

TRUNK (except Sportback)

Press twice to open trunk lid.

PANIC

Press and hold. Press any button to

turn off panic.

To lock or unlock the doors while

carrying the F.A.S.T.-key, press the

driver’s or front passenger’s door

lock/unlock switch A .

Change display

information by pushing

the INFO button:

Warnings, Odometer/

Tripmeter, Service

Reminder, Engine Coolant

Temperature, Average

and Momentary Fuel

Consumption, Driving

Range and Average

Speed, etc.

ECO Driving

When the ECO indicator light

is on, your current driving style

supports good fuel economy.

Multi-information

meter

Tire Pressure Monitoring System (TPMS)

The Tire Pressure Monitoring System light illuminates when one or more

ofyourtiresissignicantlyunderinated.Pleasenotethatchangesinthe

outside temperature may decrease tire pressure causing the TPMS light to

turn on. If the TPMS light remains illuminated, check your tire pressure.

Warning light

illuminates when

tire pressure is

too low.

If warning light

illuminates, contact your

local Mitsubishi dealer.

(May be a TPMS system

issue or malfunction).

8AUDIO SYSTEM

NOTE: Please refer to Comfort Controls in your Owner’s Manual for

more detailed information on how to use your audio system.

Audio Remote

Control Switch

(if equipped)

VOLUME

DOWN

SEEK

Change station

or track

MODE

Change the

audio source

To enter frequencies into the memory (AM/FM/SAT)

1. Press Ato turn on the audio system.

2. Press Bto select the desired band (AM/FM/SAT).

3. Press Cto Seek Station

4. Hold down one of the Memory select buttons D(1-6) until it

beeps in order to save that station to memory. 1. Park your vehicle in a safe place and turn the ignition to the LOCK

position.

2. Connect the cable (cable is not included with the vehicle) to the USB

memory device or the Dock connector to the iPod .

3. Open the glove box and connect the cable to the USB input

terminal .

4. Turn the ignition switch to the “ACC” position. Turn on the audio

system.

5. Press B several times to switch to the USB mode. The input mode

changes as follows:



USB



Bluetooth®(if equipped)

6. Depending on your USB device, it may take longer for playback to start.

7. Once the device is selected, playback starts.

With Display Audio System, follow steps 1 through 4 above

5. Press MENU on the touch screen.

6. Touch USB.

7. Touch <Folder> then select a track and begin playback.

USB and iPod Input (if equipped)














