Mitsubishi MIRAGE 2014 Guida utente

Owner’s Handbook

www.mitsubishicars.com

2014 MIRAGE

Dieline -DO NOT PRINT!

PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:

1. Pre-Delivery Inspection Form (Customer Copy)

2. Triple Diamond Delivery Checklist (Customer Copy)

3. Salesperson or Key Dealership Contact’s Business Card

Owner’s Handbook

www.mitsubishicars.com

2014 MIRAGE

Dieline -DO NOT PRINT!

Thank you for buying a Mitsubishi Mirage. There’s no doubt you’ve already realized how well

your car drives on the open road. What you may not know is all the great features that help

your car perform the way it does. In the pages ahead we’re going to run through the basics

and prepare you for the road.

We’d also love to hear from you about your overall Mitsubishi experience. If you haven’t

already, please log on to www.MitsubishiSSIsurvey.com and tell us how we did. This will help

us make sure your next visit is that much better.

We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news

and special offers. Here you can also keep track of your car’s warranty and servicing needs,

get Roadside Assistance Information and tap into other owner-centric details. Just log on to

www.Mitsubishicars.com/ownersonly.

Driver’s View ..................... Page 2-3

Controls ............................ Page 4

Own the Road................... Page 5

Technology ...................... Page 6-7

Audio System.................... Page 8

Bluetooth®(if equipped).... Page 9

Navigation System

(if equipped)..................... Page 10-11

FAQ’s................................ Page 12-13

Table of Contents

Driver’s View

1 Ignition Switch (DE Model only) ........... Page 3

2 Side

Mirror Adjustment

......................... Page 4

3 Climate Controls................................... Page 4

4 Headlights ........................................... Page 4

5Windshield Wiper Lever........................ Page 4

6 Cruise Control (if equipped) ................. Page 5

7Multi Information Display (MID)............ Page 5

8 ASC Off Switch..................................... Page 6

9 Start/Stop Engine Switch

(if equipped with F.A.S.T.-key).............. Page 7

10 Audio Remote Control Switches

(if equipped)........................................ Page 8

11 Bluetooth®Controls (if equipped) ......... Page 9

12 Navigation System (if equipped)........... Page 10-11

A- Temperature control switch

B - Air conditioning switch

C - MODE switch

D - Air selection switch

E - Blower speed selection switch

F - Defogger switch

G - AUTO switch

H - Electric rear window defogger switch

I - OFF switch

The outside rearview

mirrors can be adjusted

when the ignition switch

is in the “ON” or “ACC”

position or the operation

mode is put in ON or ACC.

Move the lever (A) to the

same side as the mirror

you wish to adjust.

4CONTROLS

Regular Headlights Windshield Wipers

The wipers will operate once.

OFF

Intermittent (Speed sensitive)

Slow

Fast

Rear Window Wiper and Washer

Adjust switch

Turn the knob Bto operate the rear

window wiper.

The wiper operates continuously

for several seconds then operates

intermittently at intervals of about 8

seconds.

Washer ﬂuid is sprayed, the wiper will

automatically operate 2 or 3 times.

Headlights and other lights on.

Parking, tail, front and rear

sidemarker lights, license plate

and instrument panel lights on.

All lights off

Pull lever toward driver to

activate high beams.

OFF

Automatic Air Conditioning

Side Mirror Adjustment

F G H I

A - CRUISE CONTROL ON/OFF switch

Used to turn on and off the cruise

control.

B - SET - switch

Used to reduce the set speed and

to set the desired speed.

C - RES + switch

Used to increase the set speed and

to return to the original set speed.

D - CANCEL switch

Used to deactivate the set speed

driving.

1.Temperature Indicator Lamp

Illuminated Green

• When the temperature indicator lamp

is illuminated Green this indicates

the engine has not reached normal

operating temperature.

NOTE: This will result in cooler heater

outlet temperatures until engine reaches

normal operating temperatures.

OWN THE ROAD

Cruise Control (if equipped) Temperature Indicator Lamp Operation

Multi Information Display Switch Each time you lightly press the multi-information display switch (A), the display switches in the following order.

1- Odometer

2- Trip odometer A

3- Trip odometer B

4- Instrument panel light dimmer control

5- Driving range display

6- Average fuel consumption display

7- Service reminder (distance)

8- Service reminder (month)

NOTE

• When the ignition switch or the operation mode is in OFF, the driving range display and average fuel

consumption display are not displayed.

• While driving, the service reminder is not displayed even if you operate the multi-information display switch.

NOTE:

When operating the cruise control switches, press the cruise

control switches correctly. The set speed driving may be

deactivated automatically if two or more switches of the cruise

control are pressed at the same time.

2.Temperature Indicator Lamp Off

• When the temperature indicator lamp is Off this indicates the engine is

at normal operating temperature.

3.Temperature Indicator Lamp Illuminated Red

• When the temperature indicator is illuminated Red this indicates the

engine is overheating.

NOTE: If the engine is overheating, ﬁnd a safe place to park the vehicle, then

shut the engine off and call Roadside Assistance as continued driving could

cause the engine to fail.

6TECHNOLOGY

Active Stability Control (ASC) Off Switch

You can deactivate the system

by pressing down the “ASC OFF”

switch for 3 seconds or longer.

When the ASC is deactivated,

the indicator will turn on. To

reactivate the ASC, momentarily

press the “ASC OFF” switch; the

indicator is turned off.

ECO indicator

This indicator will be displayed when fuel

efﬁcient driving is achieved.

Tire Pressure Monitoring System (TPMS)

The Tire Pressure Monitoring System

light illuminates when one or more of

your tires is signiﬁcantly under inﬂated.

Please note that changes in the outside

temperature may decrease tire pressure

causing the TPMS light to turn on. If

the TPMS light remains illuminated,

check your tire pressure.

If the warning light illuminates, take the necessary measures

referring to the owner’s manual.

Setting the Clock with Navigation (if equipped)

You can set various settings related to the clock.

1. Touch the CLOCK key. The Clock screen is displayed.

2. Touch the desired menu item to set.

On-screen Clock key: Sets whether to display the clock on the screen.

Clock Format (24h) key:Sets to ON to change the clock to 24-hour format.

Turn off to change the clock to 12-hour format.

Setting the Clock

1. Press and hold the button and the clock display ﬂashes.

2. Press the or button to adjust the “hours” digit.

If you keep pressing the button, fast-forward begins.

3. When the “hours” digit is adjusted, press the button to ﬂash the

“minutes” digit.

Press the or button to adjust the “minutes” digit.

If you keep pressing the button, fast-forward begins.

4. When the time is set, press the button to stop the clock display

from ﬂashing.

TECHNOLOGY

Keyless Entry System

Start/Stop Engine Switch (if equipped with F.A.S.T.-key)

F.A.S.T.-Key Normal Key

Operation indicator light

LOCK ( ) button

UNLOCK ( ) button

PANIC button

If the F.A.S.T.-key is not operating properly

Remove the key from the F.A.S.T.-key remote and

unlock the door manually. Then, insert the F.A.S.T.-

key into the key slot in the instrument panel. Starting

the engine and changing the operation mode should

be now possible. Remove the F.A.S.T.-key from the

key slot after starting the engine or changing the

operation mode.

While carrying the F.A.S.T.-key, press

the driver’s door lock/unlock switch A .

While carrying the F.A.S.T.-key within the operating range, the Start/Stop button can be used to start the engine.

• Move the selector lever in “P” position and hold the brake pedal down, push the Start/Stop button.

• To stop the engine, stop the vehicle completely and move the selector lever in “P” then press the Start/Stop button.

* If you have to bring the engine to an emergency stop while driving, press and hold the Start/Stop button for 3 seconds or

more, or press it quickly 3 times or more.

• If you press the Start/Stop button without depressing the brake pedal, you can change the operation mode in the

order of OFF, ACC, ON, OFF.

• If the engine cannot be started or the operation mode cannot be changed, check the position of the F.A.S.T.-key or

the battery performance of the F.A.S.T.-key.

To connect a USB memory device

1. Park your vehicle in a safe place and turn

the ignition switch to the “OFF” position

or put the operation mode in OFF.

2. Open the glove compartment and remove

the connector cable A , Bfrom clips C .

3. Connect a commercially available USB

connector cable Dto the USB memory

device E .

4. Connect the commercially available

USB connector cable Dto the vehicle’s

connector cable B. Be sure to hold the

terminal part Aof the connector cable as

shown in the illustration.

5. Fix the connector cable A, Bon the clips.

8AUDIO SYSTEM

NOTE: Please refer to your Owner’s Manual for more detailed

information on how to use your audio system.

USB and iPod Input (if equipped)

Audio Remote

Control Button

(if equipped)

VOLUME

Down

SEEK

Change

station or

track

MODE

Change the

audio source

To enter frequencies into the memory (AM/FM)

1. Press Ato turn on the audio system.

2. Press Bto select the desired band (AM/FM).

3. Press Cto Seek Station

4. Hold down one of the Memory select buttons D(1-6) until it

beeps in order to save that station to memory.

To remove

1. Turn the ignition switch to the “OFF”

position or put the operation mode in OFF.

2. Remove the commercially available USB

connector cable D. Be sure to hold the

terminal part Aof the connector cable as

shown in the illustration.

3. Fix the connector cable on the clips and

close the glove compartment.

Indice

Altri manuali Mitsubishi Automobile

Mitsubishi

Mitsubishi Pick-Up 1987 Manuale utente

Mitsubishi

Mitsubishi 1985 Mirage Manuale di riferimento

Mitsubishi

Mitsubishi Mirage 2017 Manuale utente

Mitsubishi

Mitsubishi EVO VIII 260 Manuale utente

Mitsubishi

Mitsubishi 2015 OUTLANDER Manuale utente

Mitsubishi

Mitsubishi Lancer Evolution IX 2005 Guida rapida

Mitsubishi

Mitsubishi Pajero Manuale di istruzioni

Mitsubishi

Mitsubishi OUTLANDER Manuale utente

Mitsubishi

Mitsubishi 3000gt 1997 Manuale di istruzioni

Mitsubishi

Mitsubishi Montero 1984 Manuale utente

Mitsubishi

Mitsubishi outlander sport Guida utente

Mitsubishi

Mitsubishi 2008 passenger car Manuale utente

Mitsubishi

Mitsubishi LANCER EVOLUTION-VII 2001 Documento tecnico

Mitsubishi

Mitsubishi OUTLANDER Manuale utente

Mitsubishi

Mitsubishi OUTLANDER PHEV 2018 Manuale utente

Mitsubishi

Mitsubishi 3000GT 1991 Manuale utente

Mitsubishi

Mitsubishi ECLIPSE Manuale utente

Mitsubishi

Mitsubishi PAJERO IV Manuale utente

Mitsubishi

Mitsubishi Stealth 1994 Manuale utente

Mitsubishi

Mitsubishi L200 Manuale tecnico

Mitsubishi

Mitsubishi LANCER 2017 Guida utente

Mitsubishi

Mitsubishi ECLIPSE SPYDER 2009 ECLIPSE Manuale utente

Mitsubishi

Mitsubishi 1995 3000GT Spyder Manuale operativo

Mitsubishi

Mitsubishi 2018 ECLIPSE CROSS Guida utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
