Mitsubishi MELSEC-QnA Series Manuale utente

MELSECNET/10

Network Module

User's Manual

(Hardware)

A1SJ72QLP25, A1SJ72QLR25

A1SJ72QBR15

Thank you for buying the Mitsubishi general-purpose programmable

logic controller MELSEC-QnA Series

Prior to use, please read both this manual and detailed manual

thoroughly and familiarize yourself with the product.

MODEL A1SQ-NET10-R-U-JE

MODEL

CODE 13JQ94

IB(NA)-0800111-B(0605)MEE

2000 MITSUBISHI ELECTRIC CORPORATION

-1

zSAFETY PRECAUTIONS z

(Always read before starting use.)

Before using this product, please read this manual and the relevant manuals

introduced in this manual carefully and pay full attention to safety to handle the

product correctly.

The instructions given in this manual are concerned with this product. For the

safety instructions of the programmable controller system, please read the CPU

module user's manual.

In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".

Indicates that incorrect handling may cause hazardous

conditions, resulting in death or severe injury.

Indicates that incorrect handling may cause hazardous

conditions, resulting in medium or slight personal injury or

physical damage.

Note that the CAUTION level may lead to a serious consequence according to

the circumstances.

Always follow the instructions of both levels because they are important to

personal safety.

Please store this manual in a safe place and make it accessible when required.

Always forward it to the end user.

[INSTALLATION PRECAUTIONS]

CAUTION

zUse the PLC in an environment that meets the general specificaitons

contained in CPU module user’s manual. Using this PLC in an environment

outside the range of the general specifications could result in electric shock,

fire, erroneous operation, and damage to or deterioration of the product.

zFully insert the projection on the bottom of the module into the hole in the

base unit, press the module into position, and tighten the module fixing

screws.

Not installing the module correctly or not fixing it with the screws could result

in malfunction, damage, or drop of some pieces of the product.

Always tighten the module fixing screws within the specified torque range.

Loose tightening could result in drop of some pieces of the product,

short-circuit, and malfunction.

Tightening the screws too much could result in drop of some pieces of the

product, short-circuit, or malfunction due to the breakage of a screw or the

module.

zCompletely turn off the externally supplied power used in the system before

mounting or removing the module.

Not doing so could result in damage to the product.

DANGER

CAUTION

-2

[INSTALLATION PRECAUTIONS]

CAUTION

zDo not directly touch the printed circuit board, the conducting parts and

electronic parts of the module. It may cause damage or erroneous operation.

zBefore handling the module, touch a grounded metal object to discharge the

static electricity from the human body. Failure to do so may cause

malfunction or failure of the module.

[WIRING PRECAUTIONS]

DANGER

zBefore installation or wiring, be sure to shut off all phases of the external

power supply used by the system.

Failure to do so may cause electric shocks or damage the product.

CAUTION

zSolder the coaxial cable connector properly. Incomplete soldering may

cause a malfunction.

zBe sure there are no foreign substances such as sawdust or wiring debris

inside the module. Such debris could cause fires, damage, or erroneous

operation.

zMake sure to place the communication and power cables into a duct or

fasten them using a clamp.

Cables not placed in the duct or not clamped may hang or shift, allowing

them to be accidentally pulled, which may cause a module malfunction and

cable damage.

zWhen removing the communication cable or power cables from the module,

do not pull the cable. When removing the cable with a connector, hold the

connector on the side that is connected to the module. When removing the

cable connected to the terminal block, first loosen the screws on the terminal

block. Pulling the cable that is still connected to the module may cause

malfunction or damage to the module or cable.

-3

Revisions

* The manual number is noted at the lower right of the top cover.

Print Date *Manual Number Revision

Jan.,2000 IB(NA)-0800111-A First printing

May,2006 IB(NA)-0800111-B

Correction

SAFETY PRECAUTIONS, Compliance

with the EMC Directive and the Low

Voltage Directive, Chapter 1, 2, 3, 4, 5, 6

This manual confers no industrial property rights or any rights of any other kind, nor does

it confer any patent licenses. Mitsubishi electric Corporation cannot be held responsible

for any problems involving industrial property rights which may occur as a result of using

the contents noted in this manual.

2000 MITSUBISHI ELECTRIC CORPORATION

-4

CONTENTS

1. Overview ...................................................................................................... 1

2. Performance Specifications.......................................................................... 2

3. Handling....................................................................................................... 4

3.1 Cable length restrictions between stations .............................................. 4

4. The Name and Setting of Each Part............................................................. 5

5. Wiring........................................................................................................... 9

6. External Dimensions .................................................................................. 10

6.1 A1SJ72QLP25....................................................................................... 10

6.2 A1SJ72QLR25 ...................................................................................... 10

6.3 A1SJ72QBR15...................................................................................... 11

-5

About the Manuals

The following product manuals are available. Please use this table as a

reference to request the appropriate manual as necessary.

Detailed Manual

Manual name Manual No.

(Model code)

For QnA/Q4AR MELSECNET/10 Network System

Reference Manual

IB-66690

(13JF78)

Before use of this module, be sure to read the For QnA/Q4AR

MELSECNET/10 Network System Reference Manual

Compliance with the EMC Directive and the Low Voltage Directive

When incorporating the Mitsubishi PLC into other industrial machinery or

equipment and keeping compliance with the EMC and low voltage directives,

refer to Chapter 3 "EMC Directive and Low Voltage Instruction" of the User’s

Manual (Hardware) for the CPU module used or the PLC CPU supplied with the

base unit.

The CE logo is printed on the rating plate of the PLC, indicating compliance with

the EMC and low voltage directives.

For making this product compliant with the EMC and low voltage directives,

please refer to Section 3.1.3 "Cable" in Chapter 3 of the above-mentioned

user’s manual.

1. Overview

This manual explains the specifications and part names of the A1SJ72QLP25,

A1SJ72QLR25 and A1SJ72QBR15 model MELSECNET/10 network modules

(abbreviated as Network Modules) which are used to construct remote I/O

systems on MELSEC-QnA series MELSECNET/10 network systems.

(1) The use, cable used and installation position of the Network Modules are

indicated on the following chart.

Cable used

Application Optical

fiber cable

Coaxial

cable

Position

A1SJ72QLP25 -

A1SJ72QLR25

A1SJ72QBR15

For remote I/O station

of MELSECNET/10 -

Main base CPU

slot

(2) After unpacking the Network Modules, confirm that any of the following

products is enclosed.

Model Description Quantity

A1SJ72QLP25 Model A1SJ72QLP25 MELSECNET/10 network module

(optical loop type) 1

A1SJ72QLR25 Model A1SJ72QLR25 MELSECNET/10 network module

(coaxial loop type) 1

Model A1SJ72QBR15 MELSECNET/10 network module

(coaxial bus type) 1

A1SJ72QBR15

F-type connector (A6RCON-F) 1

(3) The coaxial bus-type network system requires terminal resistors

(A6RCON-R75: 75 ) at both terminal stations of the network. The user

should arrange for terminal resistors, since the A1SJ72QBR15 does not

come with terminal resistors.

2. Performance Specifications

The performance specifications for Network Modules are indicated as follows.

(1) A1SJ72QLP25

Specifications

Item A1SJ72QLP25

X/Y 8192 points

B 8192 points

Maximum link

points per

network W 8192 points

Maximum link points per

station

yRemote master station remote I/O station

Y+B

8+ (2 W) <1600 bytes

yRemote I/O station remote master station

X+B

8+ (2 W) <1600 bytes

yRemote master station remote sub-master station

Remote sub-master station remote master station

Y+B

8+ (2 W) <2000 bytes

Maximum number of I/O

points per remote I/O station

X+Y<1024 (main base unit + 1 extension base units)

When X and Y overlap, either of them becomes effective.

Communication speed 10Mbps (equivalent to 20Mbps for multiple transmission)

Communication method Token ring

Synchronization method Frame synchronization

Encoding method NRZI encoding (Non Return to Zero Inverted)

Transmission route format Duplex optical loop

Transmission format Conform to HDLC (frame format)

Maximum number of networks 239

Number of stations for

connection per network

65 stations (Remote master station: 1 Remote I/O stations: 64)

Overall distance 30km

Station-to-station distance *1 SI optical cable : 500m

H-PCF optical cable : 1km

Broad-band H-PCF optical cable : 1km

QSI optical cable : 1km

Error control method Retry by CRC (X16+X12+X5+1) and overtime

RAS function yLoop back function due to abnormality detection and cable

disconnection

yDiagnostic function for local link circuit check

yAbnormality detection by link special relay, resistor

yNetwork monitor, each type of diagnostic function

Transient transmission Monitoring with peripheral device, program up/download

Connection cable Optical fiber cable (Arranged by user *2)

Applicable connector 2-core optical connector plug (Arranged by user *2)

5VDC current consumption 0.52A

Weight 0.41kg

*1: The distance between stations is restricted in accordance with the type of cable and number

of stations. Refer to Reference Manual of master module in use for details.

*2: Specialised training and specific tools are required to connect the connector to the

optical-fiber cable; the connector itself is a custom product. Please contact your nearest

Mitsubishi Electric System Service Corporation when purchasing these items.

For general specifications of the network module, refer to the user's manual for the PLC CPU

that is to be used.

(2) A1SJ72QLR25, A1SJ72QBR15

Specifications

Item A1SJ72QLR25 A1SJ72QBR15

X/Y 8192 points

B 8192 points

Maximum link

points per

network W 8192 points

Maximum link points per

station

yRemote master station remote I/O station

Y+B

8+ (2 W) <1600 bytes

yRemote I/O station remote master station

X+B

8+ (2 W) <1600 bytes

yRemote master station remote sub-master station

Remote sub-master station remote master station

Y+B

8+ (2 W) <2000 bytes

Maximum number of I/O

points per remote I/O station

X+Y<1024 (main base unit + 1 extension base units)

When X and Y overlap, either of them becomes effective.

Communication speed 10Mbps (equivalent to 20Mbps

for multiple transmission)

10Mbps

Communication method Token ring Token bus

Synchronization method Frame synchronization

Encoding method Manchester encoding

Transmission route format Duplex coaxial loop Single coaxial bus

Transmission format Conform to HDLC (frame format)

Maximum number of networks 239

65 stations 33 stationsNumber of stations for

connection per network Remote master station: 1

Remote I/O stations: 64

Remote master station: 1

Remote I/O stations: 32

3C-2V 19.2km(300m) 3C-2V 300m(300m)

5C-2V 30km(500m) 5C-2V 500m(500m)

Overall distance

(Station-to-station distance)

Can be extended to 2.5km when

used with a repeater module

(A6BR10, A6BR10-DC)

Error control method Retry by CRC (X16+X12+X5+1) and overtime

RAS function yLoop back function due to abnormality detection and cable

disconnection (A1SJ72QLR25)

yDiagnostic function for local link circuit check

yAbnormality detection by link special relay, resistor

yNetwork monitor, each type of diagnostic function

Transient transmission Monitoring with peripheral device, program up/download

Connection cable Equivalent to 3C-2V, 5C-2V cables (Arranged by user)

Applicable connector Equivalent BNC-P-3-NiCAu (For 3C-2V),

BNC-P-5-NiCAu (For 5C-2V) (DDK) (Arranged by user)

5VDC current consumption 1.24A 0.70A

Weight 0.42kg 0.43kg

*1: The distance between stations is restricted in accordance with the type of cable and number

of stations. Refer to Reference Manual of master module in use for details.

For general specifications of the network module, refer to the user's manual for the PLC CPU

that is to be used.

3. Handling

[INSTALLATION PRECAUTIONS]

CAUTION

zUse the PLC in an environment that meets the general specificaitons

contained in CPU module user’s manual. Using this PLC in an environment

outside the range of the general specifications could result in electric shock,

fire, erroneous operation, and damage to or deterioration of the product.

zFully insert the projection on the bottom of the module into the hole in the

base unit, press the module into position, and tighten the module fixing

screws.

Not installing the module correctly or not fixing it with the screws could result

in malfunction, damage, or drop of some pieces of the product.

Always tighten the module fixing screws within the specified torque range.

Loose tightening could result in drop of some pieces of the product,

short-circuit, and malfunction.

Tightening the screws too much could result in drop of some pieces of the

product, short-circuit, or malfunction due to the breakage of a screw or the

module.

zCompletely turn off the externally supplied power used in the system before

mounting or removing the module.

Not doing so could result in damage to the product.

zDo not directly touch the printed circuit board, the conducting parts and

electronic parts of the module. It may cause damage or erroneous operation.

zBefore handling the module, touch a grounded metal object to discharge the

static electricity from the human body. Failure to do so may cause

malfunction or failure of the module.

3.1 Cable length restrictions between stations

(1) The main modules case is made of plastic, so do not drop it or subject it to

strong impacts.

(2) Do not dismount the printed wiring board from the case. It may damage the

module.

(3) When wiring, be careful never to let foreign matter from the above module

such as wiring scraps get inside the module. If something goes in, get rid of

it.

(4) The module installation screw should be kept within the following range.

Screw Locations Tightening Torque Range

Module installation screws (M4 screws) 78 to 118Nycm

Altri manuali per MELSEC-QnA Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Mitsubishi Controllori

Mitsubishi

Mitsubishi FX1N-422-BD Manuale utente

Mitsubishi

Mitsubishi MELSEC-F Guida all'installazione

Mitsubishi

Mitsubishi a2 Series Manuale del proprietario

Mitsubishi

Mitsubishi MELSEC F FX-40DU-E Istruzioni per il montaggio

Mitsubishi

Mitsubishi MELSEC-F FX3U-4AD-TC-ADP Manuale utente

Mitsubishi

Mitsubishi AG-150A Manuale utente

Mitsubishi

Mitsubishi QD60P8-G Manuale utente

Mitsubishi

Mitsubishi MELSEC-F FX1N-40MT-001 Manuale utente

Mitsubishi

Mitsubishi MELSEC-A series Manuale utente

Mitsubishi

Mitsubishi AJ65BT-R2N-U-HW Manuale utente

Mitsubishi

Mitsubishi MELSEC QS Series Manuale del proprietario

Mitsubishi

Mitsubishi FX3U-4LC Manuale utente

Mitsubishi

Mitsubishi MELSEC-A series Manuale utente

Mitsubishi

Mitsubishi FX3G-4EX-BD Manuale utente

Mitsubishi

Mitsubishi A-Melsec A1FXCPU Manuale utente

Mitsubishi

Mitsubishi FBC15N Manuale utente

Mitsubishi

Mitsubishi FX3UC Series Manuale utente

Mitsubishi

Mitsubishi A Istruzioni per il montaggio

Mitsubishi

Mitsubishi alpha 2 Manuale utente

Mitsubishi

Mitsubishi PAC-YG60MCA Manuale di servizio

Mitsubishi

Mitsubishi FX3U Series Manuale utente

Mitsubishi

Mitsubishi MELSEC-F FX3U-4AD-ADP Manuale utente

Mitsubishi

Mitsubishi MELFA CR1D Manuale utente

Mitsubishi

Mitsubishi AL-232CAB Manuale utente

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
