MVA660

Power Steering Evac Adapter

Precautions

• Alwaysreadcarefullyandunderstandinstruc-

tionspriortousingthisequipment

• Wearsafetyglassesatalltimes

• Operatevehicleonlyinawellventilatedarea,

andawayfrompotentialsourcesofameor

ignition

• Priortoandduringoperationoftheengine,

makesureallequipmentcomponents,body

parts,andpersonalclothingareclearofrotating

enginecomponents

• Avoidburnsbyremainingcautiousofengine

partsthatmaybecomehotwhentheengineis

running

• Neverleaveavehicleunattendedwhileper-

formingthisprocedure

Procedures

Bleeding Air from the Power Steering System

1. Checkthelevelofpowersteeringuidinthe

reservoir.ItshouldbebetweentheMAXand

MINlevelwhentheuidisatnormalambient

temperature.Adjustthelevelasnecessary.

2. RemovethereservoircapandinsertthePower

SteeringEvacAdapterintotheneckoftheres-

ervoiruntilitissnug.

3. Connectthehandvacuumpumpandreservoir

totheevacadapterasshowningure1.

NOTE: Theuidbottleisrequiredtoprevent

uidfromenteringthepump.

4. Operatethevacuumpumptoapply20-25in-

Hg(68-85kPa)vacuumtothesystem.Main-

tainthevacuumforatleastthreeminutes.

WARNING: Topreventdamagetothepump,

donotruntheenginewhilethesystemisunder

vacuum.

5. Releasethevacuumandremovetheevacplug

fromthereservoir

6. Top-offtheuidlevelasrequired

7. Repeattheprocessuntiltheuidlevelremains

stable

8. Starttheengineandturnthewheellock-to-lock

threetovetimes

WARNING:Donotholdthewheelatthestops.

9. Stoptheengineandcheckthepowersteering

systemforleaks.

10.Checktheuidinthereservoirforbubbles

andcheckthelevel.Ifbubblesarepresentor

theuidlevelislow,repeattheprocedureas

necessary.

Instructions

Figure 1

Evac

Adapter

PowerSteeringReservoir

FluidBottle

HandVacuumPump

Page Number - 2 Form 824864

MVA660

Power Steering Evac Adapter

Americas:

OneLincolnWay

St.Louis,MO63120-1578

USA

Phone+1.314.679.4200

Fax+1.800.424.5359

Europe/Africa/MiddleEast

LincolnGmbH

Heinrich-Hertz-Str.2-8

69190Walldorf-Germany

Phone/Fax+49.6227.33-0/-259

www.lincolnindustrial.de

Asia/Pacic:

51ChangiBusinessPark

Central2

#09-06TheSignature

Singapore486066

Phone+65.6588.0188

Fax+65.6588.3438

©CopyrightLincolnIndustrial

Corporation2010

PrintedinChina

Website:

www.lincolnindustrial.com

Checking for Power Steering Leaks

1. Checkthelevelofpowersteeringuidinthe

reservoir.ItshouldbebetweentheMAXand

MINlevelwhentheuidisatnormalambient

temperature.Adjustthelevelasnecessary.

2. RemovethereservoircapandinsertthePower

SteeringEvacAdapterintotheneckoftheres-

ervoiruntilitissnug.

3. Connectthehandvacuumpumpandreservoir

totheevacadapterasshowningure1.

NOTE:Theuidbottleisrequiredtoprevent

uidfromenteringthepump.

4. Operatethevacuumpumptoapply20-25in-Hg

(68-85kPa)vacuumtothesystem.

WARNING: Topreventdamagetothepump,

donotruntheenginewhilethesystemisunder

vacuum.

5. Watchthegaugeneedle.Adropofmorethan

2or3in-Hgindicatesaleakinthesystem.

Also,airbubblescantypicallybeseeninthe

reservoir.

6. Ifaleakexists,repairandretest.
