moda Nexus Manuale utente
Nexus
WiFi Oil-filled Portable Heater
PLEASE READ AND SAVE THESE INSTRUCTIONS
Moda_Nexus_V1-02_21082023 2
Contents
1. Symbols.............................................................................................................. 3
2. Warnings & Precautions........................................................................ 3
3. Technical Information............................................................................. 7
4. Installation ...................................................................................................... 7
5. Control Panel................................................................................................. 10
6. Using the Remote Control.................................................................... 12
7. Connecting to WiFi .................................................................................... 14
8. Using the App ............................................................................................... 18
9. Cleaning........................................................................................................... 20
10. Warranty......................................................................................................... 21
11. Disposal ............................................................................................................ 22
12. Manufacturer Information.................................................................. 22
Moda_Nexus_V1-02_21082023 3
1. Symbols
2. Warnings & Precautions
Read this manual carefully before using or installing the heater.
Always store the manual in the immediate vicinity of the heater
or its site of use.
Read all safety warnings and all instructions.
The heater should only be installed and used according to the
instructions in this manual. Failure to follow the warnings and
instructions may result in electric shock, fire, serious injury, or all
of the above.
This symbol indicates a hazard with an average risk level
which, if not avoided, could result in serious injury or death.
This symbol indicates danger to the life and health of persons
due to electrical voltage.
This symbol located on the device indicates that it is
prohibited to place objects (such as towels, clothes etc.)
above or directly in front of the device. To avoid overheating
and fire hazards, the device must not be covered.
This symbol located on the device indicates that its surfaces
are hot during and immediately after operation. Hot surfaces
should not be touched: danger of burns.
This symbol located on the device indicates that it is
prohibited to spray the device.
This symbol located on the device indicates that instructions in
the operating manual must be observed when installing and
using the device.
Moda_Nexus_V1-02_21082023 4
Save all warnings and instructions for future reference.
Keep the power cable away from all hot parts of the appliance.
Do not use the heater with the power cable wound up. This can cause
a dangerous build up of heat. Do not wind the cable around the
appliance as this may cause weakening and splitting of the
insulation. The power cable should be fully unwound and removed
from any storage areas before use.
Prior to each use of the device, check that the cable, mains plug,
casing and element are intact and in good condition. The heating
element may be damaged if the heater is dropped or hit. Do not use
if you detect damage to any component.
Some parts of this product can become very hot
and cause burns. Do not touch the surface when in
operation. Do not install close to curtains or other
combustible materials. Particular attention should
be given where children and vulnerable adults are
present.
Never cover the heater. Covering the heater risks
overheat and fire.
Children of less than 3 years should be kept away unless
continuously supervised. Children aged from 3 years and less
than 8 years shall only switch on/off the appliance provided
that it has been placed or installed in its intended normal
operating position and they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children aged from 3 years and less than 8 years shall not
plug in, regulate, or clean the appliance, or perform
maintenance.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision.
Moda_Nexus_V1-02_21082023 5
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons to avoid
a hazard.
Make sure that the voltage indicated on the rating plate for this
appliance corresponds to your power outlet: AC 220-240V, 50/60Hz.
Check for transportation damage and make sure all parts are
complete after the appliance is unpacked. Do not use if any parts are
missing or damaged.
Do not leave the heater unattended during use.
Do not use the appliance with an external controller. The heater must
not be set to switch on when it is unattended.
It is recommended to plug the device directly into a wall socket. Use
of extension leads is not recommended because many models do
not support high-powered appliances. Make sure any extension lead
used can safely support the power requirements of the product.
Do not share the heater's socket with other appliances: risk of fire due
to excessive load.
The power cable should not be positioned under the carpet or items
of furniture. Do not run the cable where it will be a trip hazard.
The device must not be located immediately below an electrical
socket outlet.
Do not use this device in the immediate surroundings of a
bath, shower, swimming pool or any other water container.
Risk of electric shock. This product is not suitable for
bathroom use.
The device must be placed where the switches and controllers
cannot be touched by a person in a bathtub or shower. Never place
the device where it may fall into a bathtub or other water receptacle.
Do not use the device with wet or damp hands.
No part of the appliance should be submersed in any type of liquid.
Cleaning should be carried out using a damp cloth only. No abrasive
chemicals or materials should be used.
Moda_Nexus_V1-02_21082023 6
Never insert fingers or other objects or body parts into the heater's
protective grill: risk of electric shock or injury.
The device must only be installed in an upright position on a smooth,
stable, heat-resistant surface.
The device is for indoor use only. Do not use outdoors.
Make sure the minimum safety distances from walls and
objects stated in the installation instructions are observed
at all times. This is very important to prevent damage to
walls, furniture and soft furnishings and to prevent the
product overheating.
Do not use the device in rooms where contact with flammable or
potentially explosive materials like dust, gas or vapour cannot be
avoided. Risk of fire.
Do not operate the device when wet. If the device gets wet during
cleaning, allow it to dry out before using.
Do not expose the device to water jets.
Do not transport the device during operation.
Do not sit on the device.
Before carrying out maintenance, care or repair work on the device,
ensure the device is unplugged. Do not use the cable to tug the plug
from the socket. Switch off the socket, hold the plug, and pull.
Switch the device off and disconnect the power cable from the mains
socket when the device is not in use.
Allow the device to cool down before touching or transporting the
device, or attempting maintenance work.
Moda_Nexus_V1-02_21082023 7
3. Technical Information
4. Installation
4.1. Fixings
Before beginning installation, check that all fixings are supplied. The heater
should only be mounted with the manufacturer’s fixings.
4.2. Attaching the castor wheels
Warning – Installation requires turning the heater upside down. Ensure the
surface is stable and free of sharp objects which may scratch or damage
the finish of the heater.
1. Unpack the Castor Wheels and Arc-shaped Brackets from the heater
packaging.
Table 1: Technical Specifications
Voltage 220-240V AC / 50-60Hz
Wattage 2000W, 2500W
Temperature Range 5–40 °C
Temperature Resolution 1 °C
IP Rating IP00
Appliance Class Class I
Power cable length 1.5m
Component Castor wheels Wing nuts
Quantity 2 2
Component Arc-shaped
Bracket Handle
Quantity 2 1
Moda_Nexus_V1-02_21082023 8
2. Turn the radiator upside-down on a stable and clean surface.
3. Fit the two sets of castor wheels between the outermost fins.
4. Insert the hooked end of the Arc Bracket into the castor wheel, ensuring
the curved section sits over the lower bar of the heater.
5. Insert the straight end of the Arc Bracket into the castor wheel.
6. Secure in place using a wing nut. The wing nuts can be tightened by
hand.
7. Repeat for the second set of castor wheels.
8. Turn the device upright so that it is resting on the castor wheels. The
power cable should be at the bottom of the heater.
9. Attach the handle by clicking it into place on the end panel.
10. The device is now ready to use. Note - When using the heater for the first
time, it may emit a slight odour. This is normal and will soon subside.
Ensure the heater is used in a well-ventilated room.
Figure 1: Attaching castors to heater body
Figure 2: Attaching handle
Moda_Nexus_V1-02_21082023 9
4.3. Using your Moda Nexus
Do NOT!
DO NOT use in a bathroom or in the immediate surroundings
of a swimming pool or other water container. Risk of electric
shock, injury or death.
DO NOT use in rooms where potentially flammable or
explosive materials are present.
DO NOT use in rooms where the device will be left unattended.
DO NOT use outdoors.
DO NOT use the device without properly installing the castor
wheel bases.
DO NOT use if the device is damaged.
DO NOT cover.
DO NOT touch the metal fins during or soon after heating.
Do!
Use for ad-hoc heating in hard-to-heat spaces.
Ensure the device is unplugged before attempting
transportation or maintenance.
Use the handle for moving the device instead of pulling on the
power cord.
Inspect the heater regularly for damage and cease use if any
damage is detected.
Keep the device away from curtains or other flammable
materials.
Allow the device to cool completely before moving or storing
it.
Unplug and place device in its original packaging if it is not
going to be used for a long period of time.
Moda_Nexus_V1-02_21082023 10
5. Control Panel
5.1. Display
The heater features a dimmable touchscreen LED display.
5.2. Standby mode
The heater first starts in standby mode, where the display shows only the
standby and WiFi symbols. On this mode the heater will not heat. You
can use the standby key to switch between standby and the heating
modes.
5.3. Heating modes
Tap the standby key to switch the heater on. Tap the mode key to
switch between modes. The displayed icon will change accordingly,
browsing through: Comfort , Eco and Anti-Frost .
5.3.1. Comfort
When the display is showing the comfort icon, the heater is in comfort
mode. In this mode, the heater heats on full power to a constant set
temperature. The thermostat measures the room temperature and
Comfort
(full power)
Eco
(half power) Anti-Frost
Connected to
WiFi
Device is
heating Keypad locked
Timer in
progress
Keypad
locked
Increase
button
Standby/On
button
Set temp
display
Heating icon
Decrease
button
Brightness
button
Timer set
button
Figure 3: Control Screen Layout and symbols
Change mode
button
Indice
Manuali Stufa popolari di altre marche
Empire Heating Systems
Empire Heating Systems WCC65 Manuale utente
Wetekom
Wetekom 92 86 43 Manuale utente
Desa
Desa SPC170-F Manuale utente
Watlow
Watlow Watrod Electric Tubular Heaters Manuale utente
Haverland
Haverland ECO-DRY GPS Series Manuale elenco delle parti
Stelpro
Stelpro ASILVC2060 Series Manuale utente
