JALOUSIE ACTUATOR
JAS-04.16
PASSPORT
МГРЛ-27.12.1931-002.02 ПС
BASIC INFORMATION
The jalousie actuator is designed to control motorized curtains, jalousie, roller shutters and similar devices
powered by AC. Each output has a bistable relay, designed for high inrush currents, and can be controlled
manually.
• 4 independent channels for a maximum capacitive load of 140µF
• Ability to connect outputs to different phases
• Manual control of outputs using front panel buttons
• LED indication of output status
• Extendet logic and scenario functions for each output
• The choice of operation mode curtains / jalousie
• Saving settings during a KNX power failure
• Power supply via KNX bus
• DIN rail 35 mm mounting
page 1
1. Outputs 2. Output status indicator LED 3. Output control button
4. Programming button 5. Programming LED 6. KNX connector
Module Electronic LLC
module-electronic.ru, [email protected]
phone: +7-495-150-27-25
SPECIFICATIONS
Device model
JAS-04.16
Outputs (control channels)
Number of outputs
4
Output type / Disconnection type
Potential-free outputs-bistable relay with tungsten pre-make
contact / Micro-disconnection
Rated current per output
16A/230V AC
Capacitive load
140µF
Maximum switching voltage
400V AC
Maximum load
(resistive / inductive)
4000W / 1500W
Maximum inrush current
165A/20ms
800А/200µs
Maximum relay response time
10ms
Cross-section of the connected wire to the screw
terminals
0,5-4mm²
Mechanical lifetime of the relay (cycles, minimum)
3.000.000
KNX interface
Specification
TP-256
Available application soware
ETS 5
KNX connector
4-wire EIB connector (PUSH WIRE spring clips) for standard
cable TP1 0,8мм Ø
Power supply
via KNX bus
Consumption on the KNX bus (29V DC)
< 5mA
< 150mW
Operation temperature
0°C .. + 45°C
Operation humidity
5 .. 95% (no condensation)
Degree of protection
IP 20, clean environment
Mounting type
DIN rail 35mm
Dimensions
71,3 х 90,5 х 62mm (4TE)
Weight
260g
page 2
PASSPORT
МГРЛ-27.12.1931-002.02 ПС
JAS-04.16
+
-
12345678910
ММММ
L
N
KNX
page 3
INSTALLATION
WIRING DIAGRAMS
KNX bus
Attaching to DIN rail
Removing from DIN rail
Motor 1 Motor 2 Motor 3 Motor 4
SAFETY INSTRUCTIONS
ATTENTION! Installation and connection of the device to the mains must only be carried out by
qualified personnel! There is a risk of electric shock! Be sure to turn off the power before installing or
removing the device! Even when the device is turned off, the output terminals can be live! Do not
connect to the outputs a load that exceeds the recommended values! The design of the device meets
the requirements of electrical safety according to GOST 12.2.007.0-75.
SETTING INSTRUCTIONS
The device is set up in accordance with the instruction manual. (The full manual and application program can be
downloaded at https://module-electronic.ru/documents or by scanning the QR code at the bottom of the
document).
TRANSPORTATION, STORAGE AND DISPOSAL
The conditions for the transportation of devices must comply with conditions 5 of GOST 15150-69.
Storage of devices in packaging at the warehouses of the manufacturer and consumer must comply with storage
conditions 1 in accordance with GOST 15150-69. Aer transportation or storage at low temperatures, it is
necessary to withstand the device at room temperature for at least 2 hours before turning it on. Do not dispose
of the device with household waste.
WARRANTY
Warranty period - 12 months from the date of sale to the consumer. The manufacturer is not liable and does not
indemnify for damage caused by the fault of the consumer in case of non-compliance with the conditions of
transportation, storage, installation and operation, as well as in case of violation of the seal when trying to repair
the device yourself.
All the necessary information on the warranty can be obtained by the consumer by calling Module Electronics or
on the website: www.module-electronic.ru.
Serial number
page 4
Made in Russia
Name, address of the trading organization
Date of sale
Seller Signature
module-electronic.ru
seller's stamp
