Modulex MMT-101/TLF/01 Manuale utente

Weight0.34kg

Theﬁxtureisforindooruseonlyingeneralconditions.

Cannotbeusedfollowingconditions(Causesoffalling,electrocutionandﬁre)

●Ambienttemperatureunder0℃andover35℃

●Highhumidity

●Outside

●Ontheﬂoor

●Insulatedinsideofceiling

20cm〜

10cm〜

●Vibratedorshockedareas

●Areasgetdirectsunlight

●Inclined,unevensurface

●

Ceilingwhichcanʼtholdtheﬁxtureweight

●Onthewall

●

Placesaﬀectedbywindorair-conditionermachine

●Nearﬁre

●

Dustyareas,corrosivegasoutbreaksareas

Before

installation

Warning

Caution

Pleasecontactifyouarenotabletojudgewhetherinstallation

environmentissuitabletotheplacesornot.

Insulator

InsulatorInsulator

Toinstalltheﬁxturesafely《Readcarefullyandfollowallthe instructionsintheguide》

Warning: Failuretoinstalltheﬁxtureproperlycouldresultinpersonalinjury.

Failuretoinstalltheﬁxtureproperlycouldresultinpropertydamage.

:Prohibited

:Strictobservance

Caution:

Warning

Pleasefollowtheﬁxturesʼindicationorspeciﬁcationforthedistanceofirradiatedarea.

(Causesofchangeinshape,changeincolorofirradiatedobjects)

Atlighting

ﬁxture

installation

Caution

Makesuretheconstructionwillnotaﬀectanyﬁrepreventionsystemssuchassprinklerbyheatfromtheﬁxture.

(Causesforimproperoperation)

Pleasefollowtheﬁxturesʼinstructionorthisguidetoinstalltheﬁxtureandlamp.(Causesoffalling・electriﬁcation・ﬁre)

Makesuretoinstallallthepartsofﬁxturesbesidesinstallationandmountingpartswillnottouchwithany

objectsbothinsideandoutsideofceilingsuchaslightingtrack,etc.(Causesoffalling・electriﬁcation・ﬁre)

Donotdismountorremodelﬁxtures.(Causeofelectriﬁcation・ﬁre・falling・brokenﬁxtures)

holedimension

formounting

162×162

Conformityceilingthickness 12.5～25mm

TRIMLESSFRAME

InstallationGuideMounting

InstallationGuide Mounting

MMT-101/TLF/01

Frame

Installthemounting

12.5mm

screw

Punchingmetal

9.5mm +12.5mm

12.512.512.512.5 9.59.59.5

9.5mm +9.5mm

12.5mm +12.5mm

１

２

３

４

Decoratetheceilingtoﬁnish.4

ｂ

ｂ-1

ｂ-2

ｂ-3

ｂ-1

ｂ-2

ｂ-3

TRIMLESSFRAME

intheopeningoftheceiling

Openthemountinghole

andinserttheframe.

Afteradjustingthethickness

oftheboard,securethe

punchingmetaltotheboxwith

screwsecurely.

Securethepunchingmetal

totheimplantboxwithscrew.

Finishthesurfaceoftheceiling

boardandtheboxwith

cheeseclothundercoatand

putty.

Forceilingconstruction,itbecomes

contractor'swork,butbecareful

onthecautionsoftheconstruction.

Whenconstructing,makesure

theputtyissecurelyﬁnished

andtherewillbenocrack.

Makesuretherewillbenoceiling

paintontheopeningofthebox.

Makesuretohavetheceiling

surfaceandtheopeningto

becomeﬂush.

Buttermuslin

Paint

Putty

Ceilingboard

Surfaceﬁnish

Recommendedhole

dimensionformounting

162×162

ToinstallModuleXsafety

InstallationDetails InstallationDiagram Caution Caution

InstallationDiagram

InstallationDetails

Ceilingcutout

screw

Ceilingboard

Mounting

InstallationGuide

MMT-101/TLF/01

5/F,LongbowHouse,14-20ChiswellStreet,London,EC1Y4TW,UK

Tel:+44-01273-616649

ConcordLighting

（Contact）（Manufacturer）

ModuleXInc.

#21AraiBldg,1-20-6Ebisu-MinamiShibuya-ku,Tokyo

Tel:+81-3-5768-3131
