Tool-Free TransferBench is made of
ABS Plastic, Aluminum, EPDM, and
Stainless.
WARNING
TO PREVENT SERIOUS OR FATAL INJURY:
Insure product isassembled, adjustedand used
properly. FORUSE ONLY BY PERSONS
WEIGHING LESS THAN250 POUNDS. Failure
to follow correct assembly and/or adjustment
procedurescan make the seat unstable. ALL
FOUR LEGS MUST BE LOCKEDINPLACE AT
THE SAME HEIGHT. DO NOT jump on, stand on
or tilt. Contact CSI immediatelyat 1-800-882-
0116 if any componentsare missing ordamaged.
Do not modify orsubstitute any components.
FOR QUESTIONS ORASSISTANCE WITH
ASSEMBLY CONTACTCSI AT 1-800-882-0116.
Consult healthcare professionalforadviceand
instructions specific to user’s needs before use.
DN7065 –Tool-Free Transfer
Bench
White
1. Determine orientation of chair relative to watersupply in order fortransfer bench to
be positioned outside of bathtub.
2. Locate the twounder seat support beams: Hold the pieces by the straight end with
the curved end away fromyou.
3. Locate the flat, indented area of each beam: Place the twoflat areas together, so
they are touching, and the twobeams forman "X" shape.
4. Locate the leg unit withtop posts that point inward: Align the posts withthe straight
ends of the crossedsupport beams on the small end of the "X".
5. Slide the top posts of the leg unit over the ends of the crossedsupport beams.
6. Take the remaining leg unit, withthe top posts that point straight out, and align it
withthe curved end of the support beams, at the large side of the "X".
7. Slide the top posts of the leg unit over the ends of the crossedsupport beams.
8. Locate the transfer bench. Place it seat side down.
9. Place the curved ends of the crossedsupport beams into the grooves on the
underside of the transferbench, aligning the holes in the support beams withthe
holes inside the grooves.
10. Use the assembly knobs to attach the transferbench to the support beams.
Thread the washers onto the bolt, small lock w asherfirst,followedby the cup
washer.
11. Locate the large seat bottom. Place it under the support beams so that the center
12. of the "X" slides into the center of the "X" shaped grooves on the large seat
bottom.
13. Use the assembly knobs to attach the large seat bottom to the support beams.
Stock Number:_________________ TF Transfer Bench
By Creative Specialties
Installation Instructions:
Home Care Technical Specification
