Mokacam Alpha S Manuale utente
ACTION CAMERA USER MANUAL
Alpha S
Share with #mokacam on
TABLE OF CONTENTS
ADD On LCD
Backup Battery
Bluetooth Remote
Connecting to the APP
Offloading Your Content
Waterproof Case
Charging the Battery
1/4“ Adapter Mount
5.
6.
7.
8.
9.
10.
11.
11.
12.
12.
12.
13.
14.
14.
14.
15.
17.
18.
19.
Take a Photo
Photo Burst
Long Exposure
Photo Settings
Record Video
Slow Motion Video
Quick Capture
Video Settings
Time Lapse
Other Functions
Other Settings
2
3
My Mokacam
1. Power/Shutter Button [ ]
2. WiFi Status Light
3. WiFi/Mode Button [ ]
4. Reset Button
5. microSD Card Slot
6. micro USB Port
7. Magnet
8. Battery Contacts
9. Micro HDMI Port
10. USB-C Port
(for LCD connecting only)
11. Microphone
12. Photo Mode Light
13. Video Mode Light
113
12
6
7
8
211
3
4
5
10
9
4
My Mokacam
1. USB-C Port
2. LCD Connector
3. LCD
4. Shutter Wheel
5. Shutter Button [ ]
6. Micro USB Port for LCD Charging
7. OK Button [ ]
8. Menu Button [ ]
1
2
3
7
6
4
5
8
OK
M
5
Add-on LCD
Caution
• Remove the side cap from the camera.
• Insert the USB-C port from the LCD Screen into the USB-C port of the camera, make sure to fully insert the connection.
• Press and hold the “OK” button for 2-3 seconds to rotate the display 180° as needed.
The USB-C Port under this side cap is for LCD screen connection ONLY.
Do NOT insert any USB-C cable, otherwise the camera may be damaged.
6
Backup Battery
Take out the backup-battery from the box, face the connector to the back of the camera, the magnetic force will
help you to put them together.
7
Connecting the Remote
Filming with Remote and Switch Mode
Bluetooth Remote
Pair the camera and remote when you use the remote for the first time. Turn on the switch of remote，click the M
button and enter the setting menu, then enter “Bluetooth Pair” in the menu，the camera will search and pair the
remote automatically. The LCD will show “Bluetooth Pairing”. The remote will be connected automatically next time
after the pairing.
(The light will flash red when the Remote is turned on or the Pairing succeed. If the Remote is
disconnected, the light will also flash red for once when you click the button. When the Remote
is connected, the light will flash blue on all the operation.)
Press and hold the Shutter Button to switch the mode
Photo/Video：Under photo mode, click once to take a photo. Under video mode,
click the remote to start video film, click again to stop filming.
Shutter Button
Power
8
Connecting the APP
Search and download the “MokacamAlpha”mobile application for your respective platform (Apple AppStore,
Google Play Store), you can also download the APP from www.mokacam.com website link.
• Power the camera on
• Press and hold the WiFi / Setting Button for 2-3 seconds to turn on WiFi, you can also turn on WiFi through the
settings menu of the camera. "WiFi ON" will display on the LCD screen.
• Turn on the WiFi function on your mobile device and connect to Mokacam’s WiFi hotspot ''Alpha******''and input
the password "1234567890". Open the "MokacamAlpha" mobile application on your device.
iOS / Android
AEE Mokacam
9
Connect the camera to your Windows PC using a Micro USB cable, your computer will
automatically detect the camera named “Mokacam”. Follow the onscreen instructions to access
the camera contents.
Connect the camera to your MacOS PC using a Micro USB cable, your computer will automatically
detect the camera and create a folder titled “Mokacam”onto your desktop. Open the folder with
your Finder to access the camera contents.
Offloading the Contents
Windows
Mac OS
10
Waterproof Case
Open and insert the camera into the waterproof case according to the instructions below.
Caution
The waterproof case’s element resistance might decrease as a result of normal wear and tear. Please check the
waterproof case for cracks and damaged seals before use. We recommend to test it with paper first before using for
water activities, if any liquid leaks please contact customer service. Liquid damage to the camera and its electronic
accessories are not covered under the manufacturer’s warranty. Do not turn on or charge the camera if it becomes wet.
