Momentum Axel Manuale utente

xel

USER MANUAL

Contents

Introduction 4

LED Indicators 5

What’s Included 6

Wi-Fi Requirements 7

Mobile Device Requirements 7

Download the Momentum App 8

Pairing 9

Pairing additional Momentum Devices 11

Pairing additional non-Momentum Devices 11

Setting up Rules 12

Triggers 12

Adding a New Rule 12

Mobile Alerts 13

Storage Options 14

Momentum Capture Cloud Storage 14

Micro-SD Card Storage 15

Your Dashboard 16

Camera Functions 17

Watching Live Video 17

Taking Photos 18

Recording Videos 18

Audio Functions 19

Viewing Recorded Photos and Videos 20

Saving and Deleting recordings 21

Device Settings 22

Deleting Devices 22

Restoring Forgotten Passwords 23

Resetting the Device 24

Troubleshooting 25

About Momentum 26

Momentum is a registered trademark in the United States. Apple and iPhone

are registered trademarks of Apple Inc. Google, Google Play, and Android are

trademarks of Google LLC. All other brands and product names are or may

be trademarks of their respective owners.

Note: Screen shots and procedures described in this manual are subject to

change without notice. The latest Momentum User Guide is always available

on our website at http://www.momentumcam.com.

Introduction

The Momentum Axel™ is an indoor HD Smart Home

Security Camera with remote monitoring capabilities that

can be accessed from anywhere with an internet

connection. It’s great for indoor surveillance for your

home, office, shop, warehouse, or other locations. All you

need is a:

1. Wireless internet connection, and

2. Mobile device (Android or iOS)

See page #6 for device requirements.

Use your smartphone and/or tablet to use and manage

the camera and app’s functions remotely.

Front Rear

Built

in speaker

Infrared lights

Camera lens

Micro- USB port

for power supply

Reset button

Indicator light

Microphone

LED Indicators

Axel displays an LED indicator light that lets you know

what it is doing.

Solid Red Light: Camera is booting up.

Slow Blinking Red Light: Disconnected from Wi-Fi.

Double Blinking Blue Light: Ready to connect to Wi-Fi.

Blinking Blue Light: Axel is connected to Wi-Fi.

Solid Blue Light: User is currently live streaming.

Micro SD card

slot (128GB max)

What’s Included

Axel Camera

AC Power Adaptor

USB Cable

Double Sided Sticker

Metal Plate

Wall Anchors x 2

Screws x 2

Wi-Fi Requirements

Axel requires a 2.4GHz or 5GHz router (802.11bg/n) for

Wi-Fi connectivity. This is a standard home Wi-Fi router.

You will need your Wi-Fi name and password when

pairing your mobile device and camera.

Note: If you are using a 2.4GHz + 5 GHz dual band

router, create separate SSID names for each band on

your Wi-Fi router settings page. This will make it easier for

you to select the 2.4GHz or 5GHz band for camera setup.

Mobile Device Requirements

The Momentum app requires a smart phone or tablet

device that runs on Android 5.0+ (Lollipop) for Android

devices or iOS 9.0+ for Apple devices.

Download the Momentum App

Download and install the Momentum app on your mobile

device.

Search for Momentum on the Google Play Store for

Android devices, or on the Apple App Store for iOS

devices. You may also scan the QR code below from your

mobile device to route you directly to the app.

Make sure the app logo you download matches the one

shown below.

Create an Account

If you don’t already have a Momentum account, you will

need to create one. To create a new account, follow the

in-app instructions.

Setup

To begin using your Momentum device you will first need

to pair it to your Momentum account and then connect it to

your Wi-Fi network.

Pairing

IMPORTANT: Make sure your mobile device is

connected to the same Wi-Fi network as the one you

will be connecting the camera to. (This is required just

for the pairing process; feel free to disconnect your

mobile device from the Wi-Fi network after pairing is

complete if you wish to do so.)

1) Power on the Axel camera.

Once your Axel has been powered on, it should already

be put into pairing mode. There will also be a sound

played to notify you that it’s ready to connect.

-If it’s not in pairing mode, you will need to hold the

reset button for 10 seconds. You should hear a

sound play that the camera is ready to connect.

2) Open the app and select Axel.

From the Momentum app, select Pair device, then

select Axel.

3) Connect to Axel’s Wi-Fi access point.

When prompted in the app, go to your mobile device’s

Wi-Fi settings. You should see a Wi-Fi network option

for “MOCAM-720-01”. Tap the network to connect, then

return to the Momentum app again.

4) Enter Wi-Fi credentials.

Your Wi-Fi network will automatically be detected. Enter

in the password (if any) for the Wi-Fi network.

5) Name your device.

Select from the provided list of names or create a

custom name for your new camera. Once you’ve

finished naming your device, your setup is complete!
