280w Pointe BEAM –SPOT
moving head light
User Manual
This manual contains important information.
Please read before operating fixture.
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light
1
2 TECHNOLOGY REFERENCE
Electrical:
Power supply:electronic auto-ranging
Input voltage range:supply 100-240V, 50/60Hz
Live Fuse: T 5 A/250V,
Neutral Fuse: T 5 A/250V
Max. power consumption: 470 W at 230V (I=2,05A,power factor 0.96)
Typical power consumption: 390W at 230V (I=1.8A, power factor 0.95)
*Allow for a deviation of +/-10%
Lamp:
Approved model: YODN HRI 280W RO
Base FaP2.5
Lamp life: 2000 hrs (Standard mode)
3000 hrs (Eco mode)
Ballast:Electronic
Optical System:
High luminous-efficiency glass reflector
Beam range: 5°-20°(spot application)
2.5°-10°(beam application)
Colour wheel:13 dichroic filters + white
Static gobo wheel:10 metal gobos & 4 beam reducers
Rotating gobo wheel:
9 glass gobos can be indexed and rotated in both directions at different
speeds
2
Gobo wheel continuous rotation
Glass gobos: outside diameter=15.9 mm, image diameter=12.5 mm,
thickness=1.1 mm,
high temperature borofloat or better glass
"Slot&lock" system for easy replacement of gobos
Prisms:
Rotating 6-facet linear prism with continuous rotation in both directions
Rotating 8-facet circular prism with continuous rotation in both
directions
Frost filter:Separate,variable frost filter
Zoom:Linear motorized zoom
Strobe:Strobe effect with variable speed (max.15 flashes/sec.)
Dimmer:Smooth dimmer from 0 - 100 %
Control:
Graphic touch screen for fixture setting and addressing
Gravitation sensor for auto screen positioning
Battery backup of the touch screen
Readout fixture and lamp usage, receiving DMX values, temperatures,
etc
Built-in analyzer for easy fault finding, error messages
Remotely switching on/off the lamp
Built-in demo sequences
Black-out while head moving, colour or gobo changing
Self-resetable thermo-fuse
Stand-alone operation
3 user editable programs, each up to 100 steps
Supported protocols: USITT DMX 512, RDM, ArtNet, MANet, MANet2,
3
sACN
Support of RDM (Remote Device Management)
3 DMX modes (24,16, 30 control channels)
Wireless DMX/RDM module (only for wireless DMX version):
Compliance with USITT DMX-512 (1986 & 1990) and 512-A
Full DMX fidelity and frame integrity
Auto sensing of DMX frame rate and frame size
<5ms DMX latency
Operational frequency range of 2402-2480 MHz
Producer: LumenRadio
Pan/Tilt:
Pan movement range 540°
Tilt movement range 270°
1 6 bit movement resolution
Automatic Pan/Tilt position correction
Remotely controllable speed of pan/tilt movement for easy programming
Movement control: tracking and vector
Pan/tilt-lock mechanism
Connection:
DMX in/Out: 3-pin and 5-pin XLR
Ethernet: RJ 45
Power In: Chassis connector Neutrik PowerCon, A-type, NAC3MPA
Rigging:
Mounting points: 2 pairs of 1/4-turn locks
Mounting horizontally or vertically via 2 Omega brackets
Temperatures:
Maximum ambient temperature : 45°C
Maximum housing temperature : 90°C
4
Minimum distances:
Min. distance from flammable surfaces: 1 m
Min. distance to lit objects (Standard mode-280W): 10 m
Min. distance to lit objects (Eco mode-230W): 7.5 m
Total heat dissipation:
1 600 BTU/h (calculated)
469 Wh (calculated)
Weight (net):
15 kg
3 Board Instruction
Control menu:
Control menu map:
ESCAPE
NEXT
PREV
ENTER
DISPLAY ON
5
FEATURES SETTING
Run Mode WIRE/AUTO/DMX
ChanMode SMAL/STANDEFE
X Reverse
ON/OFF
Y Reverse ON/OFF
XYspeed NORM/FAST/SLOW
X angle 360/540/630
XY Fback ON/OFF
SignalClear ON/OFF
Full Color ON/OFF
Shortcut ON/OFF
ADVANCEO FUNCTION:
Zero. Set Plane(0-255)
Tilt(0-255)
FixeGobo(0-255)
RotGobos(0-255)
Color(0-255)
Focus(0-255)
Zoom(0-255)
Shutter(0-255)
Prism(0-255)
Prism2(0-255)
GobosRot(0-255)
ADV.
RST.
SAVE
ESC
6
Frost(0-255)
gobosRowRot(0-255)
Frost2(0-255)
Chan. Def. Color
Shutter
Dimmer
Gobo1
prismInt
PrismRot
Gobo2
Frost
Focus
Plane
PlaneFine
Tilt
TiltFine
Reset
XY speed
Fact. Set (0-255)X Master
(0-255)X Slave
(0-255)Y Master
(0-255)Y Slave
Lamp GND/5V
(0-255)YAngle
Logo Neutral/Custom
7
KEY 4KEY/SHUTTLE
(0-255)UsePassWord1
(0-255)UsePassWord2
FactPassWord1
(0-255)FactPassWord2
Use. Mang. Limit
Defaults
MANUAL
LAMP REST ALL MOTER
PART MOTER
XY MOTER
TEST RUN AUTO
SOUND
SMULATE DMX CH1-CH32(0-255)
SYSTEM INFO
DMX VALUE
CH1-CH32(0-255)
OTHER INFO (0-9999)Run Time
(0-9999)Run Count
(0-9999)Residue T
(0-9999)Residue C
8
(0-9999)Fan 1
(0-9999)Fan 2
(0-100)Temp 1
(0-100)Temp 2
PCB1 Ver
PCB2 Ver
PCB3 Ver
ERROR INFO Color
RotGobos
FixeGobos
Plane
Tilt
RotGobs1
Prism
Effect
Prism.R
Effect.R
Zoom
focus
DISPLAY SETTING
Brightness 1-7 Level
LightDelay Sec/On
Menuback Sec/Off
9
