1

1234567890123456789012345678901212345678901234567890123

Elevation Mobile Stand

Assembly Instructions

2

ALocking Caster 4 EA

BAllen Recess Screw 6 EA

CWasher 6 EA

D

EAllen Wrench 1 EA

F Wood Screw 4 EA

G Caster Wrench 1 EA

H Back Panel Screw 6 EA

I Electrical Strip Screws 2 EA

Part Drawing Description Qty Part Drawing Description Qty

Elevation Mobile Stand

P-1 Base Chart

P-2 Left Upright Chart

P-3 Right Upright Chart

P-4 Back Shelf Chart

P-5 Back Panel 1 EA

Hardware List

Panel Clip 2 EA

(Optional)

MODEL LOAD RATING BASE LEFT UPRIGHT RIGHT UPRIGHT BACK SHELF

P-1 P-2 P-3 P-4

75 LBS

250LBS

350LBS

27624 27625 27626-P2 27626-P3 27624-P4

27738 27740-P2 27740-P3

27740-P2 27740-P3

27739

27747

27748

27747-P4

3

27624

AssemblyDiagram

IdentifyandSeparateallthePartsandHardware.

Illustration # 1

R

EAD

T

HROUGH

I

NSTRUCTIONS

FROM

BEGINNING

TO

END

BEFORE

STARTING

TO

ASSEMBLE

UNIT

.

1.)

2.)

4.) AttachShelf(P-4)tothe one inch support barsonthe Uprightsusing one Panel Clip (D) andtwo

Wood Screws (F) on each bar. Position the Shelf (P-4) on the support bars and line up the predrilled

holesinthe Shelf and thepunchedholes in each PanelClip(D) then attach withWoodScrews (F).

Screwinfour Casters (A) into thebottomof the

Base(P-1)asshowninIllustration#1. Tighten

withCasterWrench(G).

3.) InserttheLeftSupport(P-2)andtheRight Support (P-3) into

the cut outs in the top of the Base (P-1). Use a Washer (C) and

andanAllenRecess Bolt (B)in each ofthe six holes under the

Base(P-1) to secure the Uprightsasshown in Illustration #2.

TightenAllenRecess Bolts(B)usingAllenWrench(E).

P-1 A

Illustration # 3

Illustration # 2

P-3

P-2

BCP-1

F

D

P-4

4

5.) Position and slide the Back Panel (P-5) down into

the three brackets on the Uprights (P-2 and P-3).

Make sure the Back Panel’s (P-5) slots are

oriented as shown in Illustration #4. Lock Back

Panel (P-5) in place using six Back Panel

Screws (H).

Illustration # 4

P-3

P-2 P-5

H

ElevationCart_06-24-15

5

EL-1 7 Outlet Electrical 1 EA

EL-2 Metal Bracket w/Cord Winder 1 EA

EL-3 Phillips Head Screw 2 EA

EL-4 Hex Nut 2 EA

#66572

7OutletElectrical

AssemblyDiagram

Parts/Hardware List

Slide Metal Bracket over the

Electrical Outlet (EL-1) as shown.

(note that Metal Stop is at the end

with the electrical Plug-in.)

Attach Metal Bracket (EL-2) to the

RightLeg Assembly

(P-3) using 2 Socket

Head Screws (I) as shown in

Optional Electrical illustration.

This 7 Outlet electrical is Part # 66572

andmust be purchasedseparately.

Please contact our

Customer Service Department

Monday - Friday

8 a.m. - 5 p.m.

CentralStandardTime

1-800-749-2258

IdentifyandSeparatealltheParts

andHardware.

1.)

2.)

3.)

Optional Electrical

Illustration

(NotUsed)

EL-1

EL-2

P-3

Usetwo

Screws(I)from

27624

1

1234567890123456789012345678901212345678901234567890123

27675

iTeach Flat Panel Cart

Assembly Instructions

2

Part Drawing Description Qty Part Drawing Description Qty

iTeach Flat Panel Cart

P-1 # 27624 1 EA

P-2 # 27678 1 EA

3

1.) Loosen the six Back Panel Screws (H) from Step #5

of the Elevation Mobile Stand (P1) assembly

instructions. See Illustration # 1. Youmaywantto

remove the Back Panel to make wiring

easier or leave it in place for

wire security.

2.) Take the the ElectricTV Wall Mount(P2)andhookthe six mount tabsthatare on the back frame

into the six brackets on the Cart (P1). See Illustration # 2. .

Illustration # 1

27675_05-07-14

# 27624

Assembly

H

Illustration # 2

Illustration # 3

Back Panel

Optional

H

3.)RetightenthesixBack Panel Screws (H)

to secure the two assemblies together.

P2

P1
