62541, 62543

Essential Mobile Whiteboard

Assembly Instructions

P1 PanelAssembly 1 EA

P2 Foot 2 EA

Part Drawing Description Qty Part Drawing Description Qty

Essential Mobile Whiteboard

Hardware List

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

A Locking Caster 2 EA

B Caster 2 EA

C Chart Hook 2 EA

D Allen Wrench 1 EA

E Marker Cup 1 EA

Assembly Diagram

Illustration # 2

3.)

2.)

Illustration # 1

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

Identifyand Separateall theParts andHardware.

Onthe PanelAssembly (P1),remove theeight Screwsfrom thebottomtubesofthe vertical

postsas shownin illustration#1.

1.)

Long

Screws

Short

Screws

Long

Screws

Inserta Foot(P2)on thebottom ofeach

verticaltube onthe PanelAssembly(P1).

Replacethe Screwsexactly asthey were

removedin Step2. UseAllenWrench (D)

totighten Screws.

Short

Screws

Long

Screws

Long

Screws

Illustration # 4

Illustration # 3

4.)

5.)

Pushtwo Locking Casters(A) into thebottom ofthefront legsas

shownin illustration#3. Pushin twoCasters (B)into therearlegs.

Attachthetwo ChartHooks(C)overthe topextrusion ofthe PanelAssembly(P1). Attachyour

MarkerCup (E) tothe side ofthe PanelAssembly.

Essential Mobile Whiteboard

62541, 62543_11-07-16

71 3/4”

42”

21”

38 1/2”

Clear

38 1/2” W X 54” T

WritingSurface

AdjustableChart Hooks

2 1/4” to 37 1/2” W

15”
