IMPORTANT SAFETY INSTRUCTIONS

The use of any electrical appliance requires the following

common sense safety rules. Primarily there is danger of

injury or death and secondly the danger of damage to the

appliance. These are indicated in the text by the following

two conventions:

WARNING: Danger to the person!

IMPORTANT: Damage to the appliance!

In addition we offer the following safety advice.

LOCATION

• Remove all the packaging and retain for future reference.

• Ensure the coffee maker is used on a firm, flat surface.

• Do not use the coffee maker outdoors or in a bathroom.

• Do not place the coffee maker on a highly polished wooden

surface as damage may occur to the surface.

• Do not place the coffee maker on or near hot surfaces such

as a hot plate or radiant rings or near a naked flame.

• WARNING: Do not place the coffee maker onto a metal tray

or metal surface whilst in use.

• Do not lift the coffee maker by gripping the water reservoir.

Hold the body of the coffee maker.

Thank you for choosing this Morphy Richards product and

for placing your trust in our brand. This super-automatic

coffee-maker has a maximum performance pressure pump

(18 Bar) to offer you the best professional espresso coffee in

the comfort of your home. With the touchscreen technology,

you can easily select the espresso you prefer by pressing

directly on the digital screen. This high-tech coffee-maker

displays the selection you have made with the appropriate

graphic on the screen. Its menu is highly intuitive and easy

to use so that you can adapt the machine to your personal

preferences without any great complications.

We recommend you read this instruction book carefully to

discover all the options the Momento has to offer. We hope

you enjoy this coffee maker and the delicious coffee it

makes. Keep this instruction book in a safe place, so that you

can refer to this whenever you need to.

MOMENTO FULL AUTO COFFEE MAKER

MODEL NO. 47815

Please note: cups not included with this product

PERSONAL SAFETY

• Disconnect the coffee maker from the mains supply when

filling, cleaning or not in use.

• If the unit stops producing coffee, unplug and see cleaning

instructions page 8.

• Keep the outside of the coffee maker area clean and dry at all

times.

• Always use the controls, knobs and handles that have been

specifically designed for this purpose.

• Do not touch hot surfaces.

• Do not touch metal parts until the unit has cooled.

• WARNING: Do not immerse the coffee maker itself in water

and always ensure the electrical connections are kept dry.

• Do not operate any appliance with a damaged cord or plug

or after the appliance malfunctions or has been damaged in

any manner. Ring the helpline number for advice on

examination and repair.

• The use of attachments or tools not recommended or sold

by Morphy Richards may cause fire, electric shock or injury.

• Do not use abrasive cleaners on the outside of the coffee

maker, they may scratch the surface. Clean only with a soft

damp cloth.

• Do not use the coffee maker for anything other than its

intended purp ose: mak ing cof fee in a domestic

environment.

• Caution must be used when handling hot water, coffee or

steam.

CHILDREN

• Children do not understand the dangers associated with

operating electrical appliances. Never allow children to use

this appliance.

• Young children should be supervised to ensure they do not

play with the appliance.

PRODUCT SAFETY

• Never use warm or hot water to fill the water reservoir.

• Do not overfill the water reservoir.

• Operate the appliance only with the drip tray in place.

TREATING SCALDS

• Run cold water over the affected area immediately. Do not

stop to remove clothing, get medical help quickly.

CHOICE OF COFFEE

• Choose a finely ground espresso coffee to use with this

machine.

Note: Avoid blends that are very powdery. When the coffee

is too finely ground it may block the filter.

• Or use high quality coffee beans, we recommend medium

roasted for most tastes.

ELECTRICAL REQUIREMENTS

Check that the voltage on the rating plate of your appliance

corresponds with your house electricity supply which must

be A.C. (Alternating current).

If the socket outlets in your home are not suitable for the

plug supplied with this appliance the plug should be

removed and the appropriate one fitted.

WARNING: The plug removed from the mains lead, if

severed, must be destroyed as a plug with a bared flexible

cord is hazardous if engaged into a live socket outlet.

Where used, should the fuse in the 13 amp plug require

changing, a 13 amp BS1362 fuse must be fitted.

WARNING: This appliance must be earthed.

1 IMPORTANT

• Do not leave the cable hanging over the edge of the table

or in contact with hot surfaces.

• When disconnecting the coffee-maker, first switch it off by

pressing the on/off switch (OFF position at the rear) and

then unplug the cable from the mains.

• Take particular care when using steam.

• Use the grinder for grinding coffee only.

• This appliance is not intended for use by young children or

infirm persons unless they have been adequately

supervised by a responsible person to ensure that they can

use the appliance safely.

• Do not leave unattended whilst in use.

2 PRECAUTION

• Remove all the used elements to protect the product

during transport, as well as all material used for promotions,

such as plastic bags, cardboard, stickers, the digital screen

protection, etc. on both the outside and inside of the

coffee-maker. Keep these elements out of the reach of

children.

• If the mains cable is damaged, it must be replaced by the

manufacturer or by an authorised technical service to

prevent any possible danger.

• Do not use warm or hot water to fill the tank under any

circumstances. Use only water at room temperature.

• Never clean the coffee-maker with a scouring pad or a

rough sponge. Use only a soft cloth moistened with water.

• To avoid lime scale deposits in the pipes in your

coffee-maker, we recommend you use purified water or still

mineral water.

3 IMPORTANT

The manufacturer will not accept any liability whatsoever for

damage caused by:

• Inappropriate use of the coffee-maker for any purpose

other than that for which it has been designed.

• Repairs carried out by unauthorised persons.

• Manipulation of the mains cable.

• Manipulation of any part of the coffee-maker.

• Use of spares or accessories that are not supplied by the

manufacturer.

• Removal of lime scale from the coffee-maker using any

method that is not in accordance with the instructions giv-

en in chapter 16. REMOVAL OF LIME SCALE.

In these cases, the warranty will be void.

4 SAFETY STANDARDS

In the event of an emergency

Unplug the coffee-maker immediately.

The coffee-maker must be used only:

• Indoors.

• At a room temperature of between 10°C and 40°C.

• To make coffee, hot water, steam milk or heat liquids

using steam.

• For domestic use.

• By adults who are in full possession of their physical and

mental faculties.

Power cable

Connect the coffee-maker to an appropriate socket; the volt-

age must coincide with that indicated on the specifications

plate.

IMPORTANT! Check that the socket is connected to the

mains.

Installation

• Place the coffee-maker on a completely flat surface.

Do not place it on a hot sur face under any

circumstances.

• Keep it at a distance of 10 cm from walls and heat

sources (gas, oven, etc.).

• Do not keep the coffee-maker at a room temperature of

below 0°C; the coffee-maker may be damaged by the

water inside freezing.

• The mains plug must be accessible at all times.

• The mains plug must not be damaged, hanging or

placed on hard surfaces.

• Do not use the power cable to move the coffee-maker

by pulling on it under any circumstances.

Hazards

• Do not aim the steam jet or hot water directly at anyone,

since there is a risk of burns.

• Do not place any objects inside the coffee-maker under

any circumstances (electrical hazard).

• Do not touch the coffee-maker if your hands are wet. Do

not unplug the coffee-maker by pulling on the power

cable.

Responsibilities.

• Do not use the coffee-maker if it does not work

correctly or if you suspect that it may be faulty, e.g.

after it has accidentally been dropped.

• Have the product repaired at an authorised centre.

• Turn off the coffee-maker before opening the side cover.

Spares

To guarantee your safety and the correct operation of your

coffee-maker, use only spares and accessories that are

authorised by the manufacturer.

5 PARTS

Coffee bean tank cover Grind level adjustment

Coffee bean compartment

Water tank cover

Water tank

Steam regulator

Steam nozzle

Hei gh t-a djust abl e

coffee outlet

Handles

Removable drip tray

Ground coffee tank/

sugar cube compartment

Cup-warmer

Standby switch

Information screen

Touchscreen

Tray water level

indicator

6 ACCESSORIES

For your convenience, all the accessories are in a box with the

instructions handbook:

1. Ground coffee dispensing spoon. Capacity 8 g, approx.

2. Lime scale remover.

3. Cleaning brush.

4. Strip of reagent to check water hardness. Levels 1 to 5.

5. Brewing unit switch.

7 BREWING UNIT, THE HEART OF THE

COFFEE-MAKER

This coffee-maker has a professional

unit manufactured and developed by

the best manufacturer of professional

machines (vending) in Italy. The

brewing unit automatically prepares

an excellent espresso coffee and

deposits the grounds in a

compartment. It has been designed

for professional use and,

consequently, does not require

maintenance work until it has made

6,000 cups.

8 TOUCHSCREEN

Esc

Navigation button

Programme button

Preparation of 1

espresso coffee

Preparation of 2

espresso coffees

Light coffee

LCD display

Outlet

Hot water

Steam

Ground coffee

Preparation of

1 large coffee

Strong

coffee

Preparation of

2 large coffees

9 INSTALLATION

If you find coffee grounds, it is because the coffee-maker has

been tested to make sure it works perfectly.

Before switching on the coffee-maker, make sure you have

removed the protection from the screen.

1. Fill the coffee bean tank with coffee beans (the tank has a

capacity for up to 250 g).

2. Fill the water tank with clean, cool water. You can fill it

directly (a) or under the tap (b)

a) Lift the water b) Remove the tank by

tank cover. the handle.

When placing the tank back in position, make sure it fits into

the flap on the body, so that it is perfectly in place.

3. Connect the power cable.

4. Turn on the on/off switch at the rear of the coffee-maker.

Turn it to the “I” position to switch the coffee-maker on.

5. The standby button will come on (blue).

6. The first time you use the coffee-maker, its internal

circuits need to be filled with water. The steam jet/hot

water regulator icon appears on the LCD screen to

indicate that the circuit needs to be filled.

IMPORTANT! Perform this operation BEFORE any other.

IMPORTANT! The circuit must be filled each time the steam

regulator icon appears on the display. This icon appears each

time the machine is PLUGGED IN.

7. Place a compartment (glass or jug) under the steam

nozzle.

8. To fill the circuits with water, turn the steam regulator

anticlockwise as far as it will go.

9. Wait until water or steam comes out of the steam

nozzle.

10. Close the steam regulator to complete the circuit filling

process.

11. Remove the compartment with the hot water.

12. The coffee-maker will turn off and is ready for use. Press

the standby button.

13. An hourglass will appear on the display to indicate that

the system is heating up.

14. The coffee-maker auto-cleans the pipes to remove

possible remains of coffee or water. During this process,

water comes out of the coffee outlet. This ensures that

you enjoy a coffee made with clean, fresh water.

15. The coffee-maker will indicate when it is

ready with a beep and a hand will be

displayed on the screen.

N.B. You can turn off the beep by proceeding as indicated in

chapter 18 PROGRAMMING YOUR COFFEE-MAKER

(page 18).

10 SUGAR CUBE COMPARTMENT

If you normally use sugar cubes, you

can store them in the coffee-maker.

Lift the sugar cube compartment

cover and place the cubes inside.

This compartment can be removed

for cleaning and to make the filling

process easier.

IMPORTANT! Take care not to place

the sugar cubes in the ground coffee

dispenser by mistake.

11 ADJUSTMENTS

A) By adjusting the grinding level

You can regulate the size of the ground

coffee. This size has a direct effect on the

coffee made by the coffee-maker and it is

advisable to test the grinding level until you

obtain the type of grind you prefer. To adjust the grinding

level, use the regulator inside the coffee bean tank.

* Fine grind: The coffee will brew more slowly since it needs

more time and pressure to obtain the coffee. Turn the

regulator to the left (anticlockwise). The finer the grind, the

creamier the coffee will be.

Important! If you grind the coffee too finely (grinding level

regulator full to the left), the coffee will brew very slowly.

* Coarse grind: The coffee will brew more quickly. Press and

turn the regulator to the right (clockwise).

IMPORTANT!

The adjustment must be made when the grinder is in

operation.

Use coffee bean blends specially prepared for espresso

coffee. If you do not obtain the desired result, try different

blends until you get the one you prefer. Store any coffee not

placed in the tank in a hermetically closed compartment in a

cool place.

IMPORTANT! Do not use high roast coffee; this type of

coffee is roasted with sugar (caramelised) and may

damage the coffee-maker.

B) Adjusting the amount of coffee

Before dispensing the coffee, choose the amount of coffee

you want to make, depending on whether you want a strong

or weak coffee.

If you want a weak coffee, press the button:

If you want a strong coffee, press the selector:

C) Adjusting the coffee outlet

The coffee outlet can be adjusted to different heights

depending on the size of the cups that are being used:

1. To use large cups, slide the coffee outlet up to the top

position.

2. To use espresso cups, slide the coffee outlet down to the

bottom position.

N.B. The coffee outlets can be removed for cleaning.

D) Adjusting the amount of water per cup

To adjust the amount of water per cup, press the following

buttons:

Espresso Large

coffee coffee

1 coffee cup

2 coffee cups

12 OBTAINING THE COFFEE

1. Check that the coffee-maker is ready.

2. Check that you have adjusted the coffee-maker to obtain

the coffee you prefer.

3. Place one or two warmed cups under the coffee outlet.

A) Coffee made from coffee beans

IMPORTANT! The first coffee you get from your

coffee-maker will not be good quality. Throw it away.

This occurs because the first time the grinder is used, it

cannot load the complete amount required by the

brewing unit.

4. Press the button for the type of coffee you wish to obtain.

A frame will appear around the selected button to indicate

your selection.

Espresso Large

coffee coffee

1 coffee cup

2 coffee cups

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Morphy Richards Macchina per il caffè

Morphy Richards

Morphy Richards Accents Espresso Manuale utente

Morphy Richards

Morphy Richards CoffeMaker Manuale utente

Morphy Richards

Morphy Richards 47020 MATTINO ESPRESSO MACHINE Manuale utente

Morphy Richards

Morphy Richards IB47071 Manuale utente

Morphy Richards

Morphy Richards MENO ONE CUP Manuale utente

Morphy Richards

Morphy Richards ELIPTA Manuale utente

Morphy Richards

Morphy Richards 47060 Manuale utente

Morphy Richards

Morphy Richards 162100 Manuale utente

Morphy Richards

Morphy Richards ELIPTA 47155 Manuale utente

Morphy Richards

Morphy Richards IB47390 Manuale utente

Morphy Richards

Morphy Richards 47060 Manuale utente

Morphy Richards

Morphy Richards IB47008 Manuale utente

Morphy Richards

Morphy Richards 10 12 CUP FILTER COFFE MAKER Manuale utente

Morphy Richards

Morphy Richards Accents 162005EE Manuale utente

Morphy Richards

Morphy Richards meno Manuale utente

Morphy Richards

Morphy Richards IB47009 Manuale utente

Morphy Richards

Morphy Richards IB47070 Manuale utente

Morphy Richards

Morphy Richards 47507 Manuale utente

Morphy Richards

Morphy Richards 10 CUP FILTER COFFEE MAKER - REV 2 Manuale utente

Morphy Richards

Morphy Richards MISTER CAPPUCINO EXPRESSO AND FILTER COFFEE... Manuale utente

Morphy Richards

Morphy Richards Cascata Manuale utente

Morphy Richards

Morphy Richards IB47001 Manuale utente

Morphy Richards

Morphy Richards Accents U:Pod Manuale utente

Morphy Richards

Morphy Richards Cafe Rico Espresso coffee maker Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente
