Morphy Richards IB48730 Manuale utente

SC48730M UK Rev 1 07/03

The After Sales Division,

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK 0870 060 2612

Republic of Ireland 1800 409119

Morphy Richards products are intended

for household use only

Morphy Richards has a policy of

continuous improvement in product

quality and design. The Company,

therefore, reserves the right to change

the specification of its models at any

time.

Your two year guarantee

It is important to retain the retailers receipt

as proof of purchase. Staple your receipt to

this back cover for future reference.

Please quote the following information if

the product develops a fault. These numbers

can be found on the base of the product.

Model no. Serial no.

All Morphy Richards products are

individually tested before leaving the factory.

In the unlikely event of any appliance proving

to be faulty within 28 days of purchase it

should be returned to the place of purchase

for it to be replaced.

If the fault develops after 28 days and

within 24 months of original purchase, you

should contact the Helpline number quoting

Model number and Serial number on the

product, or write to Morphy Richards at the

address shown.

You will be asked to return the product (in

secure, adequate packaging) to the address

below along with a copy of proof of

purchase.

Subject to the exclusions set out below

(see Exclusions) the faulty appliance will then

be repaired or replaced and dispatched

usually within 7 working days of receipt.

If for any reason this item is replaced

during the 2 year guarantee period, the

guarantee on the new item will be calculated

from original purchase date. Therefore it is

vital to retain your original till receipt or

invoice to indicate the date of initial

purchase.

To qualify for the 2 year guarantee the

appliance must have been used according to

the manufacturers instructions. For example

kettles should have been regularly descaled.

EXCLUSIONS

Morphy Richards shall not be liable to

replace or repair the goods under the terms

of the guarantee where:

1The fault has been caused or is

attributable to accidental use, misuse,

negligent use or used contrary to the

manufacturers recommendations or where

the fault has been caused by power

surges or damage caused in transit.

2The appliance has been used on a voltage

supply other than that stamped on the

products.

3Repairs have been attempted by persons

other than our service staff (or authorised

dealer).

4Where the appliance has been used for

hire purposes or non domestic use.

5Morphy Richards are not liable to carry

out any type of servicing work, under the

guarantee.

6Plastic filters for all Morphy Richards

kettles and coffee makers are not covered

by the guarantee.

This guarantee does not confer any rights

other than those expressly set out above and

does not cover any claims for consequential

loss or damage. This guarantee is offered as

an additional benefit and does not affect your

statutory rights as a consumer.

• This guarantee is valid in the UK and

Ireland only.

digital slow cooker rev 1 20/8/03 3:57 pm Page 1

Digital slow cooker

Please read and keep these instructions

getting the best from your

new digital slow cooker...

• Safety first

Do not immerse the electrical base in water or in any other

liquid.

•Do not touch hot surfaces. Use oven gloves or a cloth when

removing lid or handling hot containers. Use handles or

knobs.

www.morphyrichards.co.uk

digital slow cooker rev 1 20/8/03 3:57 pm Page 2

Important safety

instructions

The use of any electrical appliance

requires the following of basic common

sense safety rules.

Primarily there is danger of injury or

death and secondly the danger of damage

to the appliance. These are indicated in the

text by the following two conventions:

WARNING: Danger to the person!

IMPORTANT: Damage to the appliance!

In addition we offer the following essential

safety advice.

Your safety

• Never touch the outer enclosure of the

slow cooker during its operation or before

it cools. Do not touch hot surfaces. Use

oven gloves or a cloth when removing

the lid or handling hot containers as hot

steam will escape.

• To protect against fire, electric shock and

personal injury do not immerse cord,

plugs, or appliance in water or other

liquid.

• Unplug from the socket when not in use,

before putting on or taking off

attachments, and before cleaning.

• Do not operate any appliance with a

damaged lead or plug, or after an

appliance has malfunctioned, or has

been dropped or damaged in any way.

Contact Morphy Richards for advice on

examination, repair or electrical or

mechanical adjustment.

• Do not switch on the cooker if the

ceramic pot is empty.

• Never cook directly in the base unit. Use

the ceramic pot.

Location

• Do not use outdoors.

• Ensure that this appliance is situated out

of reach of children.

• Do not place directly under kitchen wall

cupboards when in use as it produces

large amounts of steam. Avoid reaching

over the slow cooker when in use.

Mains lead

• The mains lead should reach from the

socket to the base unit without straining

the connections.

• Do not let the cord hang over the edge of

the table or counter and keep it away

from any hot surfaces, including the slow

cooker itself.

• Do not let the lead run across an open

space e.g. between a low socket and

table.

Children

• Never allow a child to operate this

appliance. Teach children to be aware of

dangers in the kitchen, warn them of the

dangers of reaching up to areas where

they cannot see properly or should not

be reaching.

Other safety

considerations

• Do not use attachments or tools not

recommended by Morphy Richards as

this may cause fire, electric shock or

injury.

• Extreme caution must be used when

moving the cooker when containing hot

food, water, or other hot liquids.

• To open, lift the lid off towards yourself

but tilted away from you.

• Do not use any slow cooker parts in a

microwave or on any cooking/heated

surfaces.

• Do not place on or near a hot gas or

electric burner, or in a heated oven.

• Do not use the appliance for other than

intended use.

• Never leave the appliance connected to

the socket outlet when not in use.

• Do not switch on the appliance when it is

upside down or laid on its side.

• The glass lid and ceramic pot are fragile.

Handle them with care.

• Allow the lid and the crock pot to cool

before immersing in water.

• Do not use crock pot or glass lid if

cracked or chipped.

digital slow cooker rev 1 20/8/03 3:57 pm Page 3

Electrical

requirements

Check that the voltage on the rating plate

of your appliance corresponds with your

house electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and

the appropriate one fitted.

WARNING: The plug removed from the

mains lead, if severed, must be destroyed

as a plug with bared flexible cord is

hazardous if engaged into a live socket

outlet.

Should the fuse in the 13 amp plug

require changing, a 3 amp BS1362 fuse

must be fitted.

WARNING: This appliance must be

earthed.

⁄

‹

›

ﬁ

ﬂ

Features

⁄Glass lid

¤Ceramic crock pot

‹Base

›Control panel

ﬁPower indicator

ﬂPower on/off button

‡Timer set button

·LCD display

‚Increase cooking time button

„Decrease cooking time button

‰Handles

‡

‚

„

‰

Cooking capacity

The 6.5 litre digital slow cooker has a

maximum working capacity of 4.5 litres.

Before using the

digital slow cooker

for the first time

1Remove all labels and tags from the

product.

2Wash the crock pot and glass lid in hot

soapy water, with a sponge or a dish

cloth, rinse thoroughly and dry.

Warning : Do not immerse the slow

cooker base in water.

Please note

During initial use you may notice a slight

odour due to the burning off of

manufacturing residues. This is completely

normal and will disappear after a few uses.

Instructions for use

1Place the base ‹on a dry, level, heat

resistant surface, away from the edge of

the work surface. Do not use on the floor.

2Place the ingredients into the ceramic

crock pot ¤, and place the pot into the

base. Cover with the glass lid. If you need

to pre-cook or brown foods prior to slow

cooking, this must be done in a pan. Do

not try to brown or pre-cook food in a

slow cooker.

3Plug the slow cooker into the mains

socket.

Quick start

•When plugged in, the red LED will glow

and the unit will display '' 06:00 '' as the

default cooking time.

• If the recipe calls for 6 hours cooking

time, simply press O/I and cooking will

begin. The green LED will glow to show

that cooking has begun.

• During the cooking process, the display

will count down minute by minute to the

keep warm time when your meal is ready

to eat. ''WARM'' will then be displayed, to

indicate that the cooking process has

stopped and the unit is on keep warm.

• Please follow the timings in the recipes

provided for recommended cooking

durations.

Adjusting the cooking time

• If the recipe calls for an alternative

cooking time, follow this procedure to

adjust the cooking time.

Please note:

Cooking time can be adjusted to between

4 and 12 hours.

4Press the SET button, (numbers will

flash).

5Press +to increase the cooking time in

hours or -to decrease cooking time until

the desired cooking time is shown.

6Press the SET button again to adjust the

cooking time by minutes in the same way

as above, (time advances in 10 minute

increments).

7Press the SET button again, (numbers

stop flashing) and press O/I when you are

ready for cooking to begin. The LED will

glow green to indicate that cooking has

begun.

Unit is plugged in and the

default cooking time is

showing.

Unit is cooking and there is 2

hours and 30 minutes left to

cook.

The unit has finished cooking

and is on keep warm. The

meal is ready.

digital slow cooker rev 1 20/8/03 3:57 pm Page 5

Keep warm

• At the end of the cooking time the unit will

go onto the keep warm function.

•“WARM” will then be displayed on the

digital display showing that the cooking

process has stopped and the unit is on

keep warm.

8Switch off and unplug the slow cooker

after cooking and remove the crock pot

using oven gloves.

Warning: Be careful not to touch the

base unit after cooking as it remains hot.

About slow cooking

• Slow cooking has always been the best

way to prepare nutritious hot meal with

minimum preparation and maximum free

time away from the kitchen. Morphy

Richards has brought this style of cooking

right up to date with this modern, cooking

system.

• Traditionally slow cooking has centred on

soups and casseroles but with this oval

ceramic cook pot you can also produce

most modern family meals and dinner

party dishes. This pot is convenient as

well as looking good enough to take

straight to the table for serving. (Always

place crock pot on a heat proof mat or

surface).

• This method of cooking is ideal for

preparing tougher cuts of meat, giving

them the long, gentle simmering that

ensures that they become tender and full

of flavour.

IMPORTANT

The slow cooker works by building up

heat and maintaining an even temperature.

To get the best cooking results, do not

remove the lid during cooking, since this will

lose heat and therefore slow down the

cooking time. The glass lid allows you to

monitor the cooking progress without

interrupting the cooking time. Each time you

remove the lid allow 10 minutes extra

cooking time.

Suitable foods

• Most foods are suited to slow cooking

methods, however there are a few

guidelines that need to be followed.

• Make sure all frozen ingredients are well

thawed out.

• Cut root vegetables into small, even

pieces, as they take longer to cook than

meat. They should be gently sauted 2-3

minutes before slow cooking. Ensure that

root vegetables are always placed at the

bottom of the pot and all ingredients are

immersed in the cooking liquid.

• Trim all excess fat from meat before

cooking, since the slow cooking method

does not allow fat to evaporate.

• If adapting an existing recipe from

conventional cooking, you may need to

cut down on the amount of liquid used.

Liquid will not evaporate from the slow

cooker to the same extent as with

conventional cooking.

• Never leave uncooked food at room

temperature in the slow cooker.

• Do not use the slow cooker to reheat

food.

• Uncooked red beans must be soaked and

boiled for at least 10 minutes to remove

toxins before use in a slow cooker.

• Insert a meat thermometer into joints of

roasts, hams, or whole chickens to ensure

they are cooked to the desired

temperature.

digital slow cooker rev 1 20/8/03 3:57 pm Page 6

Do's and Don'ts for

crock pot

• Authentic stoneware is fired at high

temperatures therefore the crock pot may

have minor surface blemishes, the glass

lid may rock slightly due to these

imperfections. Low heat cooking does not

produce steam so there will be little heat

loss. Due to normal wear and tear

through the products life, the outer

surface may start appearing 'crazed'.

• Do not put the crock pot or glass lid in an

oven, freezer, microwave or on a

gas/electrical hob.

• Do not pre-heat before adding

ingredients.

• Do not subject the crock pot to sudden

changes in temperature. Adding cold

water to a very hot pot could cause it to

crack.

• Do not allow the pot to stand in water for

a long time (You can leave water in the

pot to soak).

There is an area on the base of the crock

pot that has to remain unglazed for

manufacturing purposes. This unglazed

area is porous, therefore will soak up

water, this should be avoided.

• Do not switch the cooker on when the

crock pot is empty or out of the base.

Tips for slow

cooking

• The slow cooker must be at least half full

for best results.

• The lid is not a sealed fit. Don’t remove

unnecessarily as the built up heat will

escape. Each time you remove the lid

allow 10 minutes extra cooking time.

• If cooking soups, leave 5cm space

between the top of the cook pot and the

food surface to allow simmering.

• Many recipes require all day cooking, if

you do not have time to prepare food that

morning prepare it the night before and

store the food in a covered container in

the fridge. Transfer the food to the crock

pot and add boiling liquid / gravy.

• Most meat and vegetable recipes require

4-6 hours.

• Do not use frozen meat or poultry unless

it is thoroughly thawed out first.

• Some ingredients are not suitable for slow

cooking. Pasta, seafood, milk and cream

should be added towards the end of the

cooking time. Many things can affect how

quickly a recipe will cook, water and fat

content, initial temperature of the food

and the size of the food.

• Pieces of food cut into small pieces will

cook quicker, a degree of 'trial and error'

will be required to fully optimize the

potential of your slow cooker.

• Vegetables usually take longer to cook

than meat, so try and arrange vegetables

in the lower half of the pot.

• All food should be covered with a liquid,

gravy or sauce. In a separate pan or jug

prepare your liquid, gravy or sauce and

completely cover the food in the crock

pot.

• Pre-brown meat and onions in a pan to

seal the juices. This also reduces the fat

content if separated before adding to the

crock pot. This is not necessary if the time

is limited, but improves the flavour.

• When cooking joints of meat, ham,

poultry etc the size and shape of the joint

is important. Try to keep the joint in the

lower 2/3of the pot and fully cover with

water. If necessary cut in two pieces. Joint

weight should be kept within the

maximum limit.

1.5 kg Large sized slow cooker

digital slow cooker rev 1 20/8/03 3:57 pm Page 7

Cooking guide

• The recipes are based on MAXIMUM

WORKING VOLUMES which are:

6.5 Litres

Working capacity 41/2litres / 8 pts

This allows a 3cm space between the top of

the cook pot and the food.

Recipes

Soups

Minestrone Soup

55g butter

100g streaky bacon chopped

2 onions, finely chopped

2 cloves garlic, crushed

4 ticks celery, chopped

500g potatoes, peeled and cubed

2 large carrots, peeled and diced

4 cabbage leaves, shredded

4 large tomatoes, skinned and roughly

chopped

2.25 litres chicken stock

3 tbsp tomato puree

3 tsp worcestershire sauce

Salt and freshly ground blackpepper

2 tbsp parsley, finely chopped

150g pasta shells

3 tbsp parmesan cheese, grated

Melt the butter in a pan and fry bacon and

vegetables until soft. Make up stock and add

stock, bacon and vegetables to the crockpot.

Add remaining ingredients except the

parsley, pasta shells and parmesan cheese.

Place the crockpot in the base unit, cover

with the lid and cook for approx 4-6 hours.

45 minutes before serving add the pasta

shells and parsley. Adjust the seasoning if

neccessary and sprinkle with parmesan

cheese. Serve with crusty french bread.

Lentil soup

200g smoked bacon, chopped

2 large onions, finely chopped

4 carrots finely diced

4 sticks of celery, finely sliced

400g orange lentils

2x400g cans of chopped tomatoes

2 litres chicken stock

4 tsp worcestershire sauce

pinch nutmeg

1 bayleaf

2 tsp basil

salt and freshly ground black pepper

2 tbsp parsley, finely chopped

In a pan gently fry the bacon until the fat

begins to run. Add all the remaining

ingredients except the parsley and bring to

the boil. Simmer for 2 minutes. Transfer to

the crock pot. Place the crock pot into the

slow cooker base, cover with the lid. Cook

for approx 4-8 hours. If a smoother

consistency is required liquidise the soup

after cooling and then reheat the soup in a

pan. Sprinkle with parsley and serve with

crusty french bread.

Vegetable Soup

60g butter

2.2kg mixed vegetables, e.g potatoes,

onion, carrot, parsnips, celery,

leek, tomato

60g flour

Salt and freshly ground black pepper

2 tsp mixed herbs

Peel, wash and cube or slice the

vegetables. Melt butter in a pan and gently

fry the vegetables for 2-3 minutes. Add the

hot stock. Stir well and bring to the boil.

Season to taste and add mixed herbs.

Transfer all ingredients to the crock pot and

place pot in the slow cooker base. Cover

with lid and cook for approx 6-8 hours. Cool

and liquidise the soup and then reheat in a

pan on the hob. Thicken it with flour.

digital slow cooker rev 1 20/8/03 3:57 pm Page 8

Poultry

Chicken Paprika

8 chicken portions

60g butter

60g seasoned flour

4 large onions, chopped

6 carrots peeled and sliced

2 green pepper, de-seeded and

chopped

3 tsp paprika

3 tsp tomato puree

1 litre chicken stock

Salt and freshly ground black pepper

Clean, wipe and dry chicken, coat in

seasoned flour. Using a pan, fry the chicken

in the butter until brown all over. Add onions

and carrots and fry until soft. Add pepper,

paprika, tomato puree, and the remaining

flour, stir well. Gradually mix in chicken

stock. Bring to the boil and season. Transfer

all the ingredients to the crock pot and place

in the base unit. Cover with the lid and cook

for approx. 4-7 hours.

Caribbean chicken

3 tbsp vegetable oil

2 large onions, chopped

4 sticks celery, chopped

3 carrots, sliced

500g mushrooms, sliced

2 red peppers, de-seeded and

sliced

8 chicken joints, skinned

400g can sliced peaches

400g can pineapple chunks

10 tbsp cornflour

3 tsp paprika

3 tsp soy sauce

3 tbsp worcestershire sauce

8 tbsp malt/wine vinegar

1 litre boiling water

Salt and freshly ground black pepper.

Fry onions, celery, carrot, mushrooms,

and pepper in a pan. Add chicken joints and

fry until brown all over. Drain peaches, and

pineapple, reserving juice, and add them to

the pan. To make the sauce, blend cornflour

and paprika with soy sauce, worcestershire

sauce, vinegar and reserved juice, add

seasoning, boiling water and pour into pan.

Bring the sauce to the boil, stirring

continuously. Transfer all ingredients to the

slow crock pot and place pot into the base

unit. Cover with the lid and cook for approx.

5-7 hours.

Chicken in white wine sauce

8 chicken joints, skinned

75g butter

2 large onions, finely chopped

250g mushrooms, sliced

3 tbsp cornflour

1 litre dry white wine

3 tsp mixed herbs

Salt and freshly ground black pepper

2 egg yolks

9 tbsp double cream

Place the chicken joints and butter in a

pan and gently fry until all the juices are

sealed in. Add the onion and fry until

softened but not browned. Add the

mushrooms and cook for a minute on low

heat. Blend the cornflour with a little of the

wine. Pour the remaining wine into the pot

with the blended cornflour, mixed herbs and

seasoning. Bring to the boil, stirring

continuously until thickened. Transfer all

ingredients to the crock pot, place in the

base of the slow cooker and place the lid on.

Cook for approx. 5-8 hours. Just before

serving beat together the egg yolk and

cream. Beat in a few tablespoons of hot

sauce, mix well together. Pour this mixture

into the slow crock pot and stir until the

sauce thickens.

digital slow cooker rev 1 20/8/03 3:57 pm Page 9

Chicken and mushroom casserole

8 chicken quarters

75g butter

3 tbsp flour

2 large onions, finely chopped

3 sticks celery, thinly sliced

500g mushrooms, thinly sliced

2 cloves garlic, crushed

1 litre chicken stock

Salt and freshly ground black pepper

7 tbsp cream (optional)

Toss the chicken in the flour, place in a

pan and fry in the butter until golden brown

on all sides. Add the onion and celery and

gently fry until softened but not browned.

Add the mushroom and garlic and stir in the

stock. Bring to the boil and season. Transfer

all the ingredients into the slow crock pot

and place the pot in the base unit. Place lid

on the slow cooker. Ensure that the chicken

and vegetables are immersed. Cook for

Approx. 5-7 hours. Before serving, stir in the

cream.

Fricasse of Turkey

8 turkey portions

2 large onions, finely chopped

75g butter

225g mushrooms, sliced

Bouquet garni

Sliver of zest of lemon

Salt and freshly ground black pepper

1 litre stock

5 tbsp cornflour

9 tbsp milk

In a pan gently fry the onions in the butter

until softened but not browned. Cube the

turkey meat and add to the pan. Add the

remaining ingredients, except the milk and

cornflour, and bring to the boil.

Transfer all ingredients to the crock pot.

Place the crock pot in the slow cooker base

unit. Place the lid over the slow cooker. Cook

for approx. 4-6 hours. Remove the bouquet

garni and lemon, half an hour before serving.

Pour the liquid into a pan. Blend the

cornflour with the milk and pour into the pan,

stir well and leave to thicken.

Meat

New England beef

1.5kg piece of topside

1 bouquet garni

1 1/2tsp thyme

1 1/2tsp black peppercorns

8 shallots

400g carrots, sliced

200g swede, diced

Put the beef into a pan and cover with

cold water. Add all the remaining ingredients,

cover and bring to a simmer. Season well

and transfer all the ingredients to the slow

crock pot. Place the crock pot into the slow

cooker base. Place the lid on to the slow

cooker. Cook for approx. 5-7 hours. Take the

beef out of the slow cooker with a slotted

spoon and allow to cool for 10 minutes. The

cooking liquid can be used as a base to

make gravy. Cut the beef into slices and

spoon a little of the cooking liquid over.

Serve with vegetables and garnish with fresh

parsley.

IMPORTANT

When buying a joint of meat, make sure

that it will fit into the crock pot so that when it

is covered with liquid it will still be 2.5cm

below the rim of the pot. The joint must not

stick out above the rim and there should be

enough room to cover the meat with water.

The shape of the meat is just as important as

the weight.

digital slow cooker rev 1 20/8/03 3:58 pm Page 10

Indice

Altri manuali Morphy Richards pentola a cottura lenta

Morphy Richards

Morphy Richards 48705 Manuale utente

Morphy Richards

Morphy Richards Digital Slow Cooker Manuale utente

Morphy Richards

Morphy Richards 460018 Manuale utente

Morphy Richards

Morphy Richards 48784 Guida rapida

Morphy Richards

Morphy Richards Ecolectric 48790 Manuale utente

Morphy Richards

Morphy Richards 461010 Manuale utente

Morphy Richards

Morphy Richards 48720 Manuale utente

Morphy Richards

Morphy Richards 460751 Manuale utente

Morphy Richards

Morphy Richards IB48710 Manuale utente

Morphy Richards

Morphy Richards Sear and Stew MRRSC65CR Manuale utente

Morphy Richards

Morphy Richards 48762 Manuale utente

Morphy Richards

Morphy Richards Round slow cooker Manuale utente

Morphy Richards

Morphy Richards DIGITAL 5 LITRE SLOW COOKER Manuale utente

Morphy Richards

Morphy Richards 460004 Manuale utente

Morphy Richards

Morphy Richards Digital Slow Cooker Manuale utente

Morphy Richards

Morphy Richards SC460751 Manuale utente

Morphy Richards

Morphy Richards SUPREME PRECISION Manuale utente

Morphy Richards

Morphy Richards 460016 Manuale utente

Morphy Richards

Morphy Richards IB461016 Manuale utente

Morphy Richards

Morphy Richards 461002 Manuale utente

Morphy Richards

Morphy Richards Digital Slow Cooker Manuale utente

Morphy Richards

Morphy Richards 48795 Manuale utente

Morphy Richards

Morphy Richards SC48701 Manuale utente

Morphy Richards

Morphy Richards 460251 Manuale utente

Manuali pentola a cottura lenta popolari di altre marche

Bravetti

Bravetti KC241B Manuale utente

Cookworks

Cookworks SC-35-0001 Manuale

Hamilton Beach

Hamilton Beach 33740W Istruzioni operative

Realtree

Realtree Weston 03-2100-RT Manuale utente

GE 168945 Manuale utente

Hamilton Beach

Hamilton Beach Stay or Go Manuale utente

Russell Hobbs

Russell Hobbs RHSC4A Manuale di istruzioni per l'installazione

Rival

Rival Portable Slow Cooker Manuale utente

Hamilton Beach

Hamilton Beach 33195 Manuale utente

Hamilton Beach

Hamilton Beach 33957 Manuale del proprietario

Lakeland

Lakeland 17168 Manuale utente

Rosemary Conley

Rosemary Conley enerGi CT-HC3 Manuale utente

Breville

Breville Banquet BSC400 Manuale utente

Centurion

Centurion SCR220 Manuale utente

Sencor

Sencor SPR 5500SS Manuale utente

GE 106828 Manuale utente

Tesco

Tesco SCSS12 Manuale utente

Electrolux

Electrolux ESC7400 Manuale utente
