Moticon SCIENCE
Effective August 1, 2019
PRELIMINARY
Instruction Manual
SCIENCE

Content
Warning Symbols and Labeling
02
03
Overview04
Intended Use05
Operation Modes06
Connectivity08
Software Setup09
Safety Instructions10
Sensor Insole Setup12
Handling Instructions15
Environment17
Reprocessing16
Product Compliance18
System Functions07
Data Acquisition Procedure13
Imprint19
Moticon SCIENCE Instruction Manual 03.00.00

The following signs and symbols are used in this instruction manual, the SCIENCE Sensor Insole
labeling, and the packaging labeling:
Warning Symbols & Labeling
Safety critical warning
Safety critical warning, prohibited action
Safety critical warning, mandatory action
Indicates that the insctructions for use must be consulted
Keep away from children
Do not dispose of in your household waste (EU WEEE Directive 2012/19/EU)
Device serial number
Temperature range for operation / storage
Humidity range for operation / storage
Handle package with care
On the sensor insoles, the labeling is located in the mid area of the lower surface. On the packaging,
handling instructions are given on the outer surface of the packaging.
03
Moticon SCIENCE Instruction Manual 03.00.00

The Moticon SCIENCE Sensor Insole is a versatile tool for sensing human foot dynamics.
The sensor insole is fully integrated and highly flexible. It incoporates all technological components to
execute standalone measurements. No external devices are required for data acquisition.
The following table depicts the basic specifications. For more information, refer to the detailed
product specifications on www.moticon.de/support.
Sensors
Power Supply
Wireless
16 pressure 3 acceleration 3 angular rate per side
Bluetooth Low Energy
PD2032 coin cell battery, rechargeable
Sizes 9 double sizes EU 32/33 - 48/49 US 1/2 - 12½/13½
Data Storage On-board memory & live transmission to smartphone
Model
Insole3
Overview
04
Moticon SCIENCE Instruction Manual 03.00.00

In the following, the terms "sensor insole" and "product" refers to an individual left / right
Moticon SCIENCE Sensor Insole, as well as to a pair of sensor insoles.
Intended Use
Intended Use
Measurements may be incorrect when the product is used outside of the defined
intended use.
Professional use only.
Always keep the product and the coin cell batteries away from children to prevent
swallowing.
The sensor insole is inteded to be used inside a shoe for measuring the plantar pressure
distribution at the sole of foot, and the acceleration in three aces and rotation of the foot
in three axes.
This product is not a medical product. It is the responsibility of the user to interpret the
measurement data obtained from the product, and no diagnosis or treatment decision may
be carried out soley on the basis of the data obtained from the sensor insole.
Contraindications
The following conditions are absolute contraindiciations for using the product:
- open wounds of the foot, irritated or otherwise unhealthy foot skin
- orthopedic or other reasons depending on the health status of the wearer, which do not
allow for waring the sensor insole
- severe gait impairments where the sensor insole might increase the risk of fall
- inability of the wearer to wear closed shoes for wearing the sensor insoles
When applying the sensor insole to a wearer for more than one day , the user applying the
product to the wearer must ensure that the wearer will not encounter negative orthopedic
long-term effects from wearing the product, and must instruct the wearer to report discomfort
and pain due to wearing the device, and to stop wearing the sensor insole in such case.
05
Moticon SCIENCE Instruction Manual 03.00.00

Operation Modes
Standard Modes Description
Live Transmits sensor data wirelessly to endpoint
(cloud/desktop computer)
Record On-board sensor data recording
Use Case
Direct data transmission for storage on endpoint
Standalone data acquisition without smartphone
Transmits fixed basic sensor data wirelessly
Notes
The operation modes can be selected in the Moticon SCIENCE Mobile App.
Smart Recording is an activity triggered recording mode where internal firmware algorithms control the intermediate pausing
and resuming in action. The mobile device (phone/tablet) is only required for starting and stopping, not for the recording itself.
For further details on the operation modes refer to the applications note on www.moticon.de/support.
Preview
1
1
2
Transmit Wireless sensor data transmission from
on-board memory to endpoint (cloud/PC)
Transmitting previously recorded sensor data
to endpoint for storage on endpoint
Live showcasing and activity checks in the
Moticon SCIENCE Mobile App
Intelligence Modes Description
Smart Sleep Automatic shut down into power safe mode
when sensor insole is not in use.
No hardware switches are used.
Use Case
No user interaction for turning on/offrequired
Activity triggered recording mode. Recording
is only on when users are active.
Internal firmware controls start/stop of
recording automatically. No phone is required.
Smart Recording 2For longterm gait monitoring
1
06
Moticon SCIENCE Instruction Manual 03.00.00

System Functions
Function Description
Firmware Update Firmware of the sensor insoles can be updated wirelessly using the Moticon SCIENCE Mobile App
File Management
System Status
The firmware runs a file management system on the on-board memory of the sensor insoles.
Measurements can be selected, deleted and transmitted individually using the
Moticon SCIENCE Mobile App
The firmware checks the system status and transmits status information.
Status information includes:
1. Restarts
2. Active time
3. Miscelaneous: firmware version, serial number, size, side
Battery Status The firmware detecs the battery charge status of the inserted coin cell batteries.
The charge status is transmitted to the Moticon SCIENCE Mobile App.
07
Moticon SCIENCE Instruction Manual 03.00.00

Connectivity
Notes
For instructions of use refer to the tutorials on www.moticon.de/support.
Legend
Wireless data transmission.
Cable bound data transmission.
Sensor Data / Status
Moticon SCIENCE
Sensor Insoles
Moticon SCIENCE
Mobile App
Moticon SCIENCE
Desktop Software
Settings / Control Sensor Data Sensor Data
WiFi Access Point
Moticon SCIENCE
Cloud
Measurements
WiFi or LAN
connection
Sensor Data
08
Moticon SCIENCE Instruction Manual 03.00.00

Software Setup
09
Moticon SCIENCE Mobile App
The Moticon SCIENCE Mobile App is available for Android only! For more information, refer
to the system requirements on www.moticon.de/support#faq.
this email address for the closed Moticon SCIENCE user group.
2. In Google Play Store, search for "Moticon SCIENCE" and install the mobile app on your phone or tablet.
3. When you launch the mobile app, grant the following permissions:
Bluetooth service
Location service
You need an active email address linked to a Google account to activate the mobile app.
Moticon SCIENCE Desktop Software
The Moticon SCIENCE Desktop Software is available for Windows 10 (or higher) only! Refer to
the system requirements for more information on www.moticon.de/support#faq.
4. Download and install the desktop software on your computer using the access/license credentials
indicated on the software deployment document attached to your product shipment.
Network Setup
You need to connect both your phone/tablet and your computer to the same local network.
For troubleshooting, go to www.moticon.de/support#sw-setup.
5. Connect your phone/tablet and your computer to the same local network (options: local WiFi, wireless
access point, hotspot initiated by computer).
6. Find the IP (IPv4) address of your computer (e.g. '192.168.?.???') in the system network/internet settings.
7. In the Moticon SCIENCE Mobile App, go to the 'Settings' section, enter the IP address of your computer.
8. Press the confirm button and check that the notification indicates a successful network connection.
Moticon SCIENCE Insole Instruction Manual 03.00.00

Safety warnings for sensor insole application
Safety Instructions
The sensor insole is not an orthotic. In case an orthotic is used by the wearer, the attentding
doctor must be consulted about wether it can be replaced by the sensor insole.
The sensor insoles must be worn only pairwise (both left and right) on order to avoid
asymmetric gait.
Only sensor insoles with appropriate size may be worn. Incorrect sizes (too small, too big, or
improper fit) are potentially dangerous, may be damaged during walking, and cause erroneous
measurement values. Check the proper fit of the sensor insole after insertion into the shoe.
The sensor insole may only be worn in closed footwear.
Immediately stop wearing sensor insoles in case of pain or skin irritation.
The weight of the wearer wearing the sensor insole may not exceed 120 kg.
Remove the coin cell battery from both insoles after finishing a measurement, or when the
coin cell battery is not used for some time. Store the sensor insole only without coin cell battery.
In case of an internal fault, surface temperature of 41 °C to 43 °C may occur, consituting a
possible temperature hazard.
The sensor insole may not be worn with open wounds or ulcers.
The sensor insole must be worn with socks in order to avoid direct skin contact.
See the detailed product information on www.moticon.de/insole3-specs and tutorial videos
about correct sensor insole handling on www.moticon.de/support
The battery compartment must face down towards the floor when insertig the sensor insole
into a shoe.
10
