Motorola ATRIX Manuale utente

MOTOROLA ATRIX

1Welcome

Welcome

MOTOROLA ATRIX™

It’s not part computer, it’s leave-your-computer-behind.

• A computer that doubles as a phone: Built with

PC-like dual-core technology, the MOTOROLA

ATRIX also comes packing 1GB of RAM. You’ll see

everything in crisp, rich 24-bit color with the world’s

first qHD smartphone display. With the support of

up to 48GB memory, you’ll be able to store

thousands of songs, photos, and files.

• A phone that acts like a computer: With the

revolutionary webtop, you now have the freedom to

access and manage your files, photos, emails and

web on a larger screen virtually anywhere you go.

Just connect your MOTOROLA ATRIX using the

optional Lapdock™ or HD Multimedia Dock (page

33).

This product meets the applicable limit for

exposure to radio waves (known as SAR) of

1.6 W/kg (FCC). The limits and guidelines

include a substantial safety margin designed to assure

Caution: Before assembling, charging, or using your

phone for the first time, please read the important

safety, regulatory and legal information in this guide.

the safety of all persons, regardless of age and health.

The highest SAR values measured for this device are

listed in the legal and safety information packaged with

your product.

Note: When using the product while worn on your

body, either use an approved accessory such as a

holster, or maintain a distance of 2.5 cm (1 inch) from

the body to ensure compliance with SAR

requirements. Note that the product may be

transmitting even if you are not making a phone call.

•Answers:Touch > Help Center.

You can also flick your home screen left or right to

show the Getting Started and Tips & Tricks widgets.

•Updates:Get phone updates, PC software, online

help and more at www.motorola.com/myatrix.

•MOTOBLUR:After you create a MOTOBLUR

account, open it at

www.motorola.com/mymotoblur.

• Accessories: Find accessories for your phone at

www.motorola.com

2Your phone

Your phone

the important keys & connectors

TV & Radio

Messaging

Market

Browser

H+ 11:35

http://www.

TV & R

adi

& R

adi

Messaging

Messag

ing

Mar

ket

Mar

ket

Bro

wser

Browser

Mar

ket

H+

htt

://www

Microphone

Micro USB

Volume

3.5mm

OMTP

Headset

WebcamMessage

Light

Back

Power /

Sleep

Hold=power

Press=sleep

HDMI

Home

For keyboard details, see “Text entry” on page 23.

Note: Your phone may look a little different.

ZXCVBNM

ASDFGH JKL

QW E R T Y U I O P

Done

Enter message here

?123

11:19

Delete

ReturnSymbols

Press=symbols

Hold=settings

Shift Voice

3Let’s go

Contents

Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Touchscreen & keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Photos & videos. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Webtop application & Entertainment Center . . . . . . . . . 33

Bluetooth™ & Wi-Fi connections. . . . . . . . . . . . . . . . . . . . . . . 35

File transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Let’s go

let’s get you up and running

Assemble & charge

Caution: Please read “Battery Use & Safety”

on page 49.

To save battery life, see “Battery tips” on page 44.

1Cover off 2SIM in

3Battery in 4Cover on

5Charge up 6Power up, log in

4Let’s go

Set up & go

When you first turn on your phone, you

need to create or log into your

MOTOBLUR account. MOTOBLUR syncs

your contacts, email, messages, and

status information, for all your accounts, all in one

place. Registration is secure and should only take a

few minutes.

Note: This phone supports apps and services that use

a lot of data, so make sure your data plan meets your

needs. For details, contact your service provider.

1To turn on your phone, press and

hold the Power Key on top of your

phone.

2Select a language.

3Register or log in.

To create a MOTOBLUR account, enter your name,

your current email address (where MOTOBLUR can

send account information), and a new MOTOBLUR

password.

You can touch Menu to skip setup, then touch

> Accounts to add accounts later.

4Add your accounts to MOTOBLUR.

To add an account, touch it. Then, enter the user

name or email and password that you set up on that

account.

Tip: For more, or to add accounts anytime, go

to “Add accounts” on page 20.

5When your phone shows your home screen, import

your SIM contacts: Touch Dialer > Contacts,

then touch Menu > Import/Export > Import

contacts from: SIM card. Touch OK to confirm.

Your MOTOBLUR account

Only MOTOBLUR syncs contacts, posts, feeds,

messages, emails, photos, and much more—from

sources like Facebook®, Twitter, MySpace, your work

email, Picasa™, and Photobucket®—and serves them

up just the way you want them.

To add or edit the email, social networking, and other

accounts in your MOTOBLUR, touch > Accounts.

To set up email accounts, see “Set up messaging”

on page 22.

You can log into MOTOBLUR from a computer to

upload contacts, reset your password, get help, or

even locate your phone:

www.motorola.com/mymotoblur

5Touchscreen & keys

Wi-Fi connect

If you want to use a Wi-Fi network for even faster

Internet access, touch Menu > Settings >

Wireless & networks > Wi-Fi settings. Touch Wi-Fi to

search for and connect to wireless networks. There’s

more in “Wi-Fi networks” on page 37.

Security

Your contacts are backed-up on MOTOBLUR, so don’t

worry. Even if you lose your phone, MOTOBLUR can

help you find it or wipe it. And when you get your next

MOTOBLUR product, your stored info makes it a snap

to set up with just your username and password.

Of course, it doesn't stop there. There are plenty of

ways to protect your phone and your information,

in “Security” on page 42.

Touchscreen & keys

a few essentials

Quick start: Touchscreen

• Touch items to select them. Try it: In the home

screen, touch Dialer > Contacts.

• Touch & hold items to open options. Try it: In the

home screen, touch Dialer > Contacts, then

touch and hold a contact to open options.

TV & Radio

Messaging

Market

Browser

H+ 11:35

http://www.

Touch to open. Touch & hold

to move or delete.

Drag or flick to scroll panels

(or long lists).

Touch & hold an empty spot

to add a shortcut or widget.

6Touchscreen & keys

•Draga list, or the home screen, to see more. Try it:

In the home screen, touch Dialer > Contacts

then drag your list up or down.

When you drag or flick a list, a scroll button appears

on the right. Drag the scroll button to move faster.

•Flick(drag quickly and release) a list to move quickly.

When you flick a long list, touch the screen to stop it

from scrolling.

•To make the screen sleep or wake up, press the

Power Key.

Note: Your touchscreen

might stay dark if the sensor

just above it is covered.

Don't use covers or screen protectors (even clear

ones) that cover this sensor.

Tips & tricks: Touchscreen & keys

•To show options for list items (like Contacts), touch

and hold them. To show options for your current

display, touch Menu .

•To set a security lock that you need to enter

whenever you wake up your phone, touch Menu >

Settings > Location & security > Set up screen lock.

•In many apps, the touchscreen switches from

portrait to landscape when you rotate your phone.

To turn this on or off, touch Menu > Settings >

Display > Auto-rotate screen.

Power & sleep key

Press and hold the Power Key to open

a menu where you can turn off sound

(Silent mode), network and wireless

connections (Airplane mode), or the

phone (Power off).

To save your battery, prevent accidental touches, or

when you want to wipe smudges off your

touchscreen, put the touchscreen to sleep by

pressing the Power Key. To wake up the touchscreen,

just press the Power Key again.

To change how long your phone waits before the

screen goes to sleep automatically, touch Menu >

Settings > Display > Screen timeout.

Tip: To make the screen lock when it goes to sleep,

use “Security” on page 42.

Volume keys

Press the volume keys on the side of

the phone to change the ring volume (in

the home screen), or the earpiece

volume (during a call).

7Home screen

Menu, home, search, & back keys

Touch Menu to open menu options in your home

screen, lists, and other places.

Touch Home to close any menu or app and return

to the home screen. Touch and hold Home to

show the last few apps you used, then touch an app to

open it. In the home screen, touch Home to open

or close the app menu.

Touch Search to open “Search” on page 8.

Touch Back to go to the previous screen.

Home screen

quick access to the things you need most

Quick start: Home screen

You’ll see the home screen when you turn on the

phone or touch Home from a menu:

TV & Radio

Messaging

Market

Browser

H+

11:35

http://www.

Notifications

Flick down for details.

Status Indicators

Shortcuts

Open the app menu.

Widgets

Touch to open. Touch & hold to

add, move, or delete.

Drag or flick to scroll panels.

8Home screen

On your home screen, shortcuts are icons that open

your favorite apps, web bookmarks, contacts, mail

labels, or music playlists. Widgets show you news,

weather, messages, and other updates.

•To show other panels of shortcuts and widgets,

flick the home screen left or right.

•To open shortcuts or widgets, touch them.

Touch Home to return to the home screen.

Tip: When you open a widget, touch Menu to

show any options or settings (you can choose

accounts for Messages, Social Networking, or

Calendar widgets).

There’s more about social networking widgets in

“Quick start: Social networking” on page 19 and

“Update your status” on page 20.

•To resize Motorola

widgets, touch and hold

one until you feel a

vibration, then release.

Drag a corner to resize.

•To add something or

change your wallpaper,

touch and hold an empty spot until you open the

Add to Home screen menu.

You can add a folder to organize your shortcuts.

THURSDAY

JULY

1:30 pm to 2:30 pm

Lunch with Ray Smith

3:00 pm to 4:00 pm

Team Meeting: Design Review

+2 more

1:30 pm to 2:30 pm

Lunch with Ray Smith

5th and Broadway

2:00 pm to 3:00 pm

Business Plan discussion with team

3:00 pm to 4:00 pm

Team Meeting: Design Review

1:30

pm to

2:30

nch

with

Ray

Smith

3:0

m to 4:00

eam

Meetin

: Desi

n Review

+2 m

1:3

m to 2:30

unch

with Ra

Smit

5th

th a

nd Broadwa

2:0

pm to

3:00

usin

ess Plan discussion with team

3:0

pm to 4:

eam

Meeti

ng: D

esign

Review

team

1:3

•To move or delete something, touch and hold it

until you feel a vibration, then drag it to another

spot, another panel, or the trash at the bottom of

the screen.

Tips & tricks: Home screen

•To return to the home screen, touch Home .

•To add an app shortcut to the home screen, you

can open the app menu, then touch and hold an

icon.

Phone status & notifications

At the top of the screen, icons on the left notify you

about new messages or events (flick the bar down for

details). Icons on the right tell you about phone status:

Bluetooth™ Wi-Fi

GPS active airplane mode

silent ring vibrate ring

mic mute speakerphone

Text Search

Type, then touch

Voice Search

Touch, then speak.

Choose what you search.

Altri manuali per ATRIX

Indice

Altri manuali Motorola Telefono cellulare

Motorola

Motorola DEBUT i856 Manuale utente

Motorola

Motorola V60p Manuale utente

Motorola

Motorola Moto G5 Foglio di istruzioni

Motorola

Motorola i205 - Cell Phone - iDEN Manuale utente

Motorola

Motorola TELUS H83XAH6RR4AN Manuale utente

Motorola

Motorola MOTOKRZR K1m Manuale utente

Motorola

Motorola Hint QA30 Manuale elenco delle parti

Motorola

Motorola MOTORAZR² V9 - MOTORAZR2 V9 Manuale utente

Motorola

Motorola MOTORAZR VE20 Manuale utente

Motorola

Motorola V557 Manuale utente

Motorola

Motorola MOTO W408g Manuale utente

Motorola

Motorola C257 Manuale utente

Motorola

Motorola V3 Manuale utente

Motorola

Motorola V975 Manuale utente

Motorola

Motorola 8200 Manuale utente

Motorola

Motorola Moto G Manuale utente

Motorola

Motorola Motorokr U9 Manuale utente

Motorola

Motorola Motokey Social Manuale utente

Motorola

Motorola HELLOMOTO SLVR L7 Istruzioni operative

Motorola

Motorola MOTO 68014173001 Manuale utente

Motorola

Motorola A780 Manuale utente

Motorola

Motorola XPRT Guida

Motorola

Motorola DROID RAZR Manuale utente

Motorola

Motorola BACKFLIP 68000202422-A Manuale utente

Manuali Telefono cellulare popolari di altre marche

Zte

Zte BLADE A520 Manuale utente

Nokia

Nokia Lumia 620 Manuale utente

Blackbe;rry

Blackbe;rry KEYone Manuale utente

Bea-fon

Bea-fon X5 Premium Manuale utente

Blackbe;rry

Blackbe;rry 8707 Series Manuale utente

Blackbe;rry

Blackbe;rry Storm Istruzioni operative

LG LM-X420QN Manuale utente

LifeWatch

LifeWatch V Manuale utente

Bea-fon

Bea-fon SILVER LINE SL860 Manuale utente

IKI Mobile

IKI Mobile KF4.5i Manuale utente

Hitech

Hitech HT-850 Manuale utente

Yezz

Yezz Fashion F10 Manuale utente

Point Mobile

Point Mobile PM60 Manuale utente

Blackbe;rry

Blackbe;rry Q10 Manuale utente

Blackbe;rry

Blackbe;rry Bold 9900 Manuale utente

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuale utente

LG LM-K420EMW Manuale utente

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuale utente
