Motorola E365
User Guide
2
Table of Contents
Quick Application & Connectivity Guide ...........................................................................................3
Mobile WAP Configuration ...............................................................................................................4
MMS Configuration ..........................................................................................................................5
Further Information...........................................................................................................................6
3
This document is intended to serve as a user’s guide in setting up the internal features of the Motorola E365 GPRS
and MMS capable mobile. It gives instructions on setting up the phone with a laptop and using the supplied GPRS
wizard. While it does include information on setting up the phone and the relevant operating system, basic knowledge
of the operating system is assumed.
As a valued customer we provide you with this User Guide as a reference when setting up your phone and other
related equipment. You acknowledge that the information contained in this User Guide is provided by Motorola or
other suppliers. Call Australia nor any of its representatives has made nor makes any representation or warranty,
express or implied, as to the accuracy or completeness of the information in this User Guide and Call Australia may
but is under no obligation to notify you if it becomes aware of any inaccuracy, incompleteness or change in the
information contained in this User Guide. For accurate and up-to-date information we recommend you visit the
Motorola website links contained at the end of this document.
Quick Application & Connectivity Guide
The Motorola E365 GPRS supports the following list of connections and internal applications for GPRS.
Feature Supported (Yes/No)
Application related
Internal Wireless Application Protocol (WAP) Browser Yes
Over The Air Configuration (OTAC) of WAP settings No
Accepting calls while in WAP GPRS session Yes
Indication is available when SMS is received while in WAP session Yes
Reading SMS while in WAP GPRS session Yes
Making calls while in WAP GPRS session No
Sending SMS while in WAP GPRS session Yes
WAP inactivity linger timer set in GPRS No
Internal Email Client No
SMS over GPRS Yes
Multimedia Messaging Service (MMS) Yes
Connectivity related
RS232 Cable Interface Yes
Infrared No
Bluetooth No
PPP Authentication
PAP Yes
CHAP Yes
MS-CHAP No
Operating Systems supported
Windows 95 / 98 / 98SE / ME / NT Yes
Windows 2000 / XP Yes
Apple MAC No
4
Mobile WAP Configuration
OTAC Support.
The Motorola E365 does not support OTAC. However, this Motorola uses an Openwave browser. Generally, setting
up an Openwave Browser tends to follow the same procedure.
Set-up of the WAP Configuration Profile.
The following instructions refer to the configuration set-up for WAP over GPRS for the Motorola E365 handset.
1. From the idle screen, press the Menu button.
2. Press the down arrow to highlight the Settings menu and press Select.
3. Scroll down to WAP Profile and press Select.
4. Scroll down to Set Profile and press Select.
5. Highlight the next available profile and press Select.
6. Scroll to Rename and enter GPRS WAP and press OK.
7. Scroll down to Edit and press Select.
8. Scroll to Bearer Type and press Select.
9. Scroll to GPRS and press Select.
10. Leave User Name and Password blank.
11. Scroll to Apn and press Select and enter telstra.wap.mnc001.mcc505.gprs and press OK.
12. Press Back and Back again.
13. Scroll to CSD and press Select.
14. Check that all fields are empty under the CSD menu.
15. Press Back, Back.
16. Scroll to WAP Setting and press Select.
17. Select Primary IP and press Select and enter 10.1.1.150 and press OK.
18. Select Primary Port and press Select and enter 9203 and press OK.
19. Select Timer and press Select and enter 9999 and press OK.
20. Select Homepage and press Select and enter http://wap.mdata.net.au/home and press OK.
21. Press the hang up key to return to the idle screen.
Choosing a Profile.
To select the above defined profile, follow these instructions:
1. From the idle screen press the Menu button.
2. Press the down arrow to highlight the Settings menu and press Select.
3. Scroll down to WAP Profile and press Select.
4. Scroll down to Set Profile and press Select.
5. Scroll down to the GPRS WAP profile and press “Select”.
6. Scroll down to Set default and press Select.
5
7. Press the hang up key to return to the idle screen.
Launching WAP.
There are two ways to launch WAP on the Motorola E365.
> Quick access to WAP
WAP can be accessed by pressing the WAPKEY soft key from the idle screen and selecting the GPRS WAP web
shortcut.
> Accessing WAP via menu
1. From the idle screen press Menu, scroll to Shortcuts and press Select.
2. Scroll down to Browser and press Select.
Multimedia Messaging Service (MMS) Configuration
Using MMS.
MMS requires access to an MMSC and a WAP gateway for notification and access. As such, most handsets
supporting MMS will need both the MMSC address which is a URL and the WAP gateway, which is normally an IP
address to function correctly.
Setting up the Motorola E365 for MMS.
1. From the idle screen, press Menu button.
2. Scroll and highlight the Messages menu item and press Select.
3. Scroll down to Message Settings and press Select.
4. Scroll down to Inbox Setup and press Select.
5. Scroll down to Multimedia Msg Setup and press Change.
6. Scroll down to Service Profile and press Change.
7. Highlight the first profile and press Select.
8. Scroll down to Rename and press Select and enter MMS and press OK.
9. Highlight Edit and press Select.
10. Highlight Bearer Type and press Select.
11. Highlight GPRS and press Select.
12. Leave User Name and Password blank.
13. Scroll to Apn and press Select and enter telstra.mms.mnc001.mcc505.gprs and press OK.
14. Press Back.
15. Scroll to CSD and press Select.
16. Check that all fields are empty under the CSD menu.
17. Press Back and Back again.
18. Scroll to WAP Setting and press Select.
19. Select Primary IP and press Select and enter 10.1.1.155 and press OK.
20. Select Primary Port and press Select and enter 9201 and press OK.
21. Select Timer and press Select, ensure it is blank and press Cancel.
22. Select Homepage and press Select and enter http://mmsc.telstra.com:8002 and press OK.
6
23. Press the hang up key to return to the idle screen.
Checking MMS Options for the Motorola E365.
1. From the idle screen, press the Menu button.
2. Scroll and highlight the Messages menu item and press Select.
3. Scroll down to Message Settings and press Select.
4. Scroll down to Inbox Setup and press Select.
5. Scroll down to Multimedia Msg Setup and press Change.
6. Select Expire after, enter 7and press OK.
7. Ensure Size limit is set to 60K.
8. Select Service Profile and select the newly created MMS profile and press Select.
9. Then highlight Set Default and press Select.
10. Press Back and Back again.
11. Select Auto Download and press Select.
12. Highlight On and press Select.
13. Press the hang up key to return to the idle screen.
GPRS data
In order to set-up the Motorola E365 for GPRS data, follow the steps in the user manual and set-up software provided.
While configuring the application it will prompt user to enter the following APN: mdata.net.au
Further Information
Reference Sites
www.motorola.com
http://www.Motorola.com/Products/MobilePhone/Microsite/E365/main.html
http://www.Motorola.com.au/mobile/
http://www.Motorola.com/Products/MobilePhone/support/Download/software/index.htm
